1. General description
The LPC5411x are ARM Cortex-M4 based microcontrollers for embedded applications.
These devices include an ARM Cortex-M0+ coprocessor, up to 192 KB of on-chip SRAM,
up to 256 KB on-chip flash, full-speed USB device interface with Crystal-less operation, a
DMIC subsystem with PDM microphone interface and I2S, five general-purpose timers,
one SCTimer/PWM, one RTC/alarm timer, one 24-bit Multi-Rate Timer (MRT), a
Windowed Watchdog Timer (WWDT), eight flexible serial communication peripherals
(each of which can be a USART, SPI, or I2C interface), and one 12-bit 5.0 Msamples/sec
ADC, and a temperature sensor.
The ARM Cortex-M4 is a 32-bit core that offers system enhancements such as low power
consumption, enhanced debug features, and a high level of support block integration. The
ARM Cortex-M4 CPU incorporates a 3-stage pipeline, uses a Harvard architecture with
separate local instruction and data buses as well as a third bus for peripherals, and
includes an internal prefetch unit that supports speculative branching. The ARM
Cortex-M4 supports single-cycle digital signal processing and SIMD instructions. A
hardware floating-point unit is integrated in the core.
The ARM Cortex-M0+ coprocessor is an energy-efficient and easy-to-use 32-bit core
which is code and tool-compatible with the Cortex-M4 core. The Cortex-M0+ coprocessor
offers up to 100 MHz performance with a simple instruction set and reduced code size.
2. Features and benefits
Dual processor cores: ARM Cortex-M4 and ARM Cortex-M0+. Both cores operate up
to a maximum frequency of 100 MHz.
ARM Cortex-M4 core (version r0p1):
ARM Cortex-M4 processor, running at a frequency of up to 100 MHz.
Floating Point Unit (FPU) and Memory Protection Unit (MPU).
ARM Cortex-M4 built-in Nested Vectored Interrupt Controller (NVIC).
Non-maskable Interrupt (NMI) input with a selection of sources.
Serial Wire Debug (SWD) with six instruction breakpoints, two literal comparators,
and four watch points. Includes Serial Wire Output for enhanced debug
capabilities.
System tick timer.
LPC5411x
32-bit ARM Cortex-M4/M0+ MCU; 192 KB SRAM; 256 KB flash,
Crystal-less USB operation, DMIC subsystem, Flexcomm
Interface, 32-bit counter/ timers, SCTimer/PWM, 12-bit 5.0
Msamples/sec ADC, Temperature sensor
Rev. 2.1 — 9 May 2018 Product data sheet

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 2 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
ARM Cortex-M0+ core
ARM Cortex-M0+ processor, running at a frequency of up to 100 MHz (uses the
same clock as Cortex-M4) with a single-cycle multiplier and a fast single-cycle I/O
port.
ARM Cortex-M0+ built-in Nested Vectored Interrupt Controller (NVIC).
Non-maskable Interrupt (NMI) input with a selection of sources.
Serial Wire Debug with four breakpoints and two watch points.
System tick timer.
On-chip memory:
Up to 256 KB on-chip flash program memory with flash accelerator and 256 byte
page erase and write.
Up to 192 KB total SRAM consisting of 160 KB contiguous main SRAM and an
additional 32 KB SRAM on the I&D buses.
ROM API support:
Flash In-Application Programming (IAP) and In-System Programming (ISP).
ROM-based USB drivers (HID, CDC, MSC, and DFU). Flash updates via USB is
supported.
Supports booting from valid user code in flash, USART, SPI, and I2C.
Legacy, Single, and Dual image boot.
Serial interfaces:
Flexcomm Interface contains eight serial peripherals. Each can be selected by
software to be a USART, SPI, or I2C interface. Two Flexcomm Interfaces also
include an I2S interface. Each Flexcomm Interface includes a FIFO that supports
USART, SPI, and I2S if supported by that Flexcomm Interface. A variety of clocking
options are available to each Flexcomm Interface and include a shared fractional
baud-rate generator.
I2C-bus interfaces support Fast-mode and Fast-mode Plus with data rates of up to
1Mbit/s and with multiple address recognition and monitor mode. Two sets of true
I2C pads also support high speed mode (3.4 Mbit/s) as a slave.
USB 2.0 full-speed device controller with on-chip PHY and dedicated DMA
controller supporting crystal-less operation in device mode using software library.
See Technical note TN00031 for more details.
Digital peripherals:
DMA controller with 20 channels and 20 programmable triggers, able to access all
memories and DMA-capable peripherals.
Up to 48 General-Purpose Input/Output (GPIO) pins. Most GPIOs have
configurable pull-up/pull-down resistors, programmable open-drain mode, and
input inverter.
GPIO registers are located on the AHB for fast access.
Up to eight GPIOs can be selected as pin interrupts (PINT), triggered by rising,
falling or both input edges.
Two GPIO grouped interrupts (GINT) enable an interrupt based on a logical
(AND/OR) combination of input states.
CRC engine.

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 3 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
Analog peripherals:
12-bit ADC with 12 input channels and with multiple internal and external trigger
inputs and sample rates of up to 5.0 MSamples/sec. The ADC supports two
independent conversion sequences.
Integrated temperature sensor connected to the ADC.
DMIC subsystem including a dual-channel PDM microphone interface, flexible
decimators, 16 entry FIFOs, optional DC locking, hardware voice activity detection,
and the option to stream the processed output data to I2S.
Timers:
Five 32-bit standard general purpose timers/counters, four of which support up to
four capture inputs and four compare outputs, PWM mode, and external count
input. Specific timer events can be selected to generate DMA requests. The fifth
timer does not have external pin connections and may be used for internal timing
operations.
One SCTimer/PWM with eight input and eight output functions (including capture
and match). Inputs and outputs can be routed to or from external pins and internally
to or from selected peripherals. Internally, the SCTimer/PWM supports ten
captures/matches, ten events, and ten states.
32-bit Real-time clock (RTC) with 1 s resolution running in the always-on power
domain. A timer in the RTC can be used for wake-up from all low power modes
including deep power-down, with 1 ms resolution.
Multiple-channel multi-rate 24-bit timer (MRT) for repetitive interrupt generation at
up to four programmable, fixed rates.
Windowed Watchdog Timer (WWDT).
Clock generation:
12 MHz internal Free Running Oscillator (FRO). This oscillator provides a
selectable 48 MHz or 96 MHz output, and a 12 MHz output (divided down from the
selected higher frequency) that can be used as a system clock. The FRO is
trimmed to 1 % accuracy over the entire voltage and temperature range.
External clock input for clock frequencies of up to 25 MHz.
Watchdog oscillator (WDTOSC) with a frequency range of 6 kHz to 1.5 MHz.
32.768 kHz low-power RTC oscillator.
System PLL allows CPU operation up to the maximum CPU rate without the need
for a high-frequency external clock. May be run from the internal FRO 12 MHz
output, the external clock input CLKIN, or the RTC oscillator.
Clock output function with divider.
Frequency measurement unit for measuring the frequency of any on-chip or
off-chip clock signal.
Power control:
Programmable PMU (Power Management Unit) to minimize power consumption
and to match requirements at different performance levels.
Reduced power modes: sleep, deep-sleep, and deep power-down.
Wake-up from deep-sleep modes due to activity on the USART, SPI, and I2C
peripherals when operating as slaves.

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 4 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
The Micro-Tick Timer running from the watchdog oscillator can be used to wake-up
the device from any reduced power modes.
Power-On Reset (POR).
Brown-Out Detect (BOD) with separate thresholds for interrupt and forced reset.
Single power supply 1.62 V to 3.6 V.
JTAG boundary scan supported.
128 bit unique device serial number for identification.
Operating temperature range 40 °C to +105 °C.
Available as WLCSP49 and LQFP64 packages.

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 5 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
3. Ordering information
3.1 Ordering options
4. Marking
Table 1. Ordering information
Type number Package
Name Description Version
LPC54113J256UK49 WLCSP49 wafer level chip-size package; 49 (7 x 7) bumps; 3.436 x 3.436 x 0.525 mm -
LPC54114J256UK49 WLCSP49 wafer level chip-size package; 49 (7 x 7) bumps; 3.436 x 3.436 x 0.525 mm -
LPC54113J128BD64 LQFP64 plastic low profile quad flat package; 64 leads; body 10 10 1.4 mm SOT314-2
LPC54113J256BD64 LQFP64 plastic low profile quad flat package; 64 leads; body 10 10 1.4 mm SOT314-2
LPC54114J256BD64 LQFP64 plastic low profile quad flat package; 64 leads; body 10 10 1.4 mm SOT314-2
Table 2. Ordering options
Type number Flash
in KB SRAM in KB Cortex-M4 with FPU Cortex-M0+ USB FS GPIO
SRAMX SRAM0 SRAM1 SRAM2 Total
LPC54113J256UK49 256 32 64 64 32 192 1 0 1 37
LPC54114J256UK49 256 32 64 64 32 192 1 1 1 37
LPC54113J128BD64 128 32 64 - - 96 1 0 1 48
LPC54113J256BD64 256 32 64 64 32 192 1 0 1 48
LPC54114J256BD64 256 32 64 64 32 192 1 1 1 48
Fig 1. LQFP64 package marking Fig 2. WLCSP49 package marking
1
n
Terminal 1 index area
aaa-011231
aaa-015675
Terminal 1
index area

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 6 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
The LPC5411x LQFP64 package has the following top-side marking:
•First line: LPC5411xJyyy
–x: 4 = dual core (M4, M0+)
–x: 3 = single core (M4)
–yyy: flash size
•Second line: BD64
•Third line: xxxxxxxxxxxx
•Fourth line: xxxyywwx[R]x
–yyww: Date code with yy = year and ww = week.
–xR = Boot code version and device revision.
The LPC5411x WLCSP49 package has the following top-side marking:
•First line: LPC5411x
–x: 4 = dual core (M4, M0+)
–x: 3 = single core (M4)
•Second line: JxxxUK49
–xxx: flash size
•Third line: xxxxxxxx
•Fourth line: xxxyyww
–yyww: Date code with yy = year and ww = week.
•Fifth line: xxxxx
•Sixth line: NXP x[R]x
–xR = Boot code version and device revision.
Table 3. Device revision table
Revision description
‘0A’ Initial device revision with boot code version 18.0.

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 7 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
5. Block diagram
Each Flexcomm Interface includes USART, SPI, and I2C functions. Flexcomm Interfaces 6 and 7 each also provide an I2S
function. Grey-shaded blocks indicate peripherals that provide DMA requests or are otherwise able to trigger DMA transfers
Fig 3. LPC5411x Block diagram
aaa-022099
USB FS
DEVICE
CONTROLLER
ARM
CORTEX M0+
FLASH
ACCELERATOR
FLASH
256 KB
ARM
CORTEX M4
FPU MPU
DEBUG INTERFACE
2× 32-BIT TIMER (TIMER 3, 4)
2× 32-BIT TIMER (TIMER 0, 1)
GPIO PIN INTERRUPTS
MULTILAYER AHB MATRIX
I/O CONFIGURATION
GPIO GROUP INTERRUPTS 0 AND 1
PERIPHERAL INPUT MUXES
MULTI-RATE TIMER
FREQUENCY MEASUREMENT UNIT
PMU REGISTERS
32-BIT TIMER (TIMER 2)
FLASH REGISTERS
FLEXCOMM Interfaces
5 THROUGH 7(1)
DMIC SUBSYSTEM REGISTERS
ADC: 5 Ms/s, 12 BIT, 12 ch.
TEMPERATURE SENSOR
GPIO
SCTIMER/PWM
FRACTIONAL RATE GENERATOR
SYSTEM FUNCTIONS: CLOCKING,
RESET, POWER, FLASH, ETC.
Serial Wire
Debug USB bus
JTAG
boundary scan CLKIN CLKOUT RESET
I-code
D-code
System
SYSTEM
DMA
CONTROLLER
CLOCK GENERATION,
POWER CONTROL,
AND OTHER
SYSTEM FUNCTIONS
POWER-ON-RESET
BROWNOUT DETECT
INTERNAL OSCILLATOR
SYSTEM PLL
BOOT AND DRIVER
ROM 32 KB
SRAMX
32 KB
SRAM0
64 KB
MAILBOX DMA
REGISTERS
USB
REGISTERS
ASYNC APB
BRIDGE
APB
BRIDGE 0
REAL TIME
CLOCK,
ALARM AND
WAKEUP
32.768 kHz
OSCILLATOR
WATCHDOG
OSCILLATOR
WINDOWED
WATCHDOG
MICRO TICK
TIMER
APB
BRIDGE 1
CRC
ENGINE
SRAM1
64 KB
SRAM2
32 KB
FLEXCOMM Interfaces
0 THROUGH 4(1)

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 8 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
6. Pinning information
6.1 Pinning
Fig 4. WLCSP49 Pin configuration
ball A1 (pin #1)
index area
A
B
C
D
E
F
G
7654321
aaa-015470

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 9 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
Fig 5. LQFP64 Pin configuration
LPC5411x
49PIO0_14 32 PIO0_1
50PIO0_15 31 PIO0_0
51PIO1_12 30 PIO1_10
52SWCLK/ PIO0_16 29 PIO1_9
53SWDIO/ PIO0_17 28 PIO1_8
54PIO1_13 27 PIO1_7
55VSS 26 PIO1_6
56VDD 25 VSS
57PIO1_14 24 VDD
58PIO0_18 23 VDDA
59PIO0_19 22 VREFP
60PIO0_20 21 VREFN
61PIO0_21 20 VSSA
62PIO1_15 19 PIO1_5
63PIO0_22 18 PIO1_4
64RESET 17 PIO1_3
1PIO0_23 48 PIO0_13 2PIO0_24 47 PIO0_12 3PIO0_25 46 PIO0_11 4PIO0_26 45 PIO0_10 5USB_DP 44 PIO0_9 6USB_DM 43 PIO0_8 7PIO1_16 42 PIO1_11 8VDD 41 PIO0_7 9VSS 40 PIO0_6
10PIO1_17 39 PIO0_5
11PIO0_29 38 PIO0_4
12PIO0_30 37 PIO0_3 13PIO0_31 36 PIO0_2 14PIO1_0 35 RTCXOUT 15PIO1_1 34 VDD 16PIO1_2 33 RTCXIN
aaa-019386

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 10 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
6.2 Pin description
On the LPC5411x, digital pins are grouped into two ports. Each digital pin may support up
to four different digital functions and one analog function, including General Purpose I/O
(GPIO).
Table 4. Pin description
Symbol
49-pin 64-pin Reset state [1] Type
Description
PIO0_0 A6 31 [2] PU I/O PIO0_0 — General-purpose digital input/output pin.
Remark: In ISP mode, this pin is set to the Flexcomm Interface 0 USART RXD
function.
I/O FC0_RXD_SDA_MOSI — Flexcomm Interface 0: USART RXD, I2C SDA, SPI
MOSI.
I/O FC3_CTS_SDA_SSEL0 — Flexcomm Interface 3: USART CTS, I2C SDA, SPI
SSEL0.
ICTimer0_CAP0 — 32-bit CTimer0 capture input 0.
R — Reserved.
OSCT0_OUT3 — SCT0 output 3. PWM output 3.
PIO0_1 B6 32 [2] PU I/O PIO0_1 — General-purpose digital input/output pin.
Remark: In ISP mode, this pin is set to the Flexcomm Interface 0 USART TXD
function.
I/O FC0_TXD_SCL_MISO — Flexcomm Interface 0: USART TXD, I2C SCL, SPI MISO.
I/O FC3_RTS_SCL_SSEL1 — Flexcomm Interface 3: USART RTS, I2C SCL, SPI
SSEL1.
ICTimer0_CAP1 — 32-bit CTimer0 capture input 1.
R — Reserved.
OSCT0_OUT1 — SCT0 output 1. PWM output 1.
PIO0_2 - 36 [2] PU I/O PIO0_2 — General-purpose digital input/output pin.
I/O FC0_CTS_SDA_SSEL0 — Flexcomm Interface 0: USART CTS, I2C SDA, SPI
SSEL0.
I/O FC3_SSEL3 — Flexcomm Interface 3: SPI SSEL3.
ICTimer2_CAP1 — 32-bit CTimer2 capture input 1.
PIO0_3 - 37 [2] PU I/O PIO0_3 — General-purpose digital input/output pin.
I/O FC0_RTS_SCL_SSEL1 — Flexcomm Interface 0: USART RTS, I2C SCL, SPI
SSEL1.
I/O FC2_SSEL2 — Flexcomm Interface 2: SPI SSEL2.
OCTimer1_MAT3 — 32-bit CTimer1 match output 3.
PIO0_4 C7 38 [2] PU I/O PIO0_4 — General-purpose digital input/output pin.
Remark: The state of this pin at Reset in conjunction with PIO0_31 and PIO1_6 will
determine the boot source for the part or if ISP handler is invoked. See the Boot
Process chapter in UM10914 for more details.
I/O FC0_SCK — Flexcomm Interface 0: USART or SPI clock.
I/O FC3_SSEL2 — Flexcomm Interface 3: SPI SSEL2.
ICTimer0_CAP2 — 32-bit CTimer0 capture input 2.

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 11 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO0_5 C6 39 [2] PU I/O PIO0_5 — General-purpose digital input/output pin.
I/O FC6_RXD_SDA_MOSI_DATA — Flexcomm Interface 6: USART RXD, I2C SDA,
SPI MOSI, I2S data.
OSCT0_OUT6 — SCT0 output 6. PWM output 6.
OCTimer0_MAT0 — 32-bit CTimer0 match output 0.
PIO0_6 D7 40 [2] PU I/O PIO0_6 — General-purpose digital input/output pin.
I/O FC6_TXD_SCL_MISO_WS — Flexcomm Interface 6: USART TXD, I2C SCL, SPI
MISO, I2S WS.
R — Reserved.
OCTimer0_MAT1 — 32-bit CTimer0 match output 1.
R — Reserved.
IUTICK_CAP0 — Micro-tick timer capture input 0.
PIO0_7 D6 41 [2] PU I/O PIO0_7 — General-purpose digital input/output pin.
I/O FC6_SCK — Flexcomm Interface 6: USART, SPI, or I2S clock.
OSCT0_OUT0 — SCT0 output 0. PWM output 0.
OCTimer0_MAT2 — 32-bit CTimer0 match output 2.
R — Reserved.
ICTimer0_CAP2 — 32-bit CTimer0 capture input 2.
PIO0_8 D5 43 [2] PU I/O PIO0_8 — General-purpose digital input/output pin.
I/O FC2_RXD_SDA_MOSI — Flexcomm Interface 2: USART RXD, I2C SDA, SPI
MOSI.
OSCT0_OUT1 — SCT0 output 1. PWM output 1.
OCTimer0_MAT3 — 32-bit CTimer0 match output 3.
PIO0_9 E7 44 [2] PU I/O PIO0_9 — General-purpose digital input/output pin.
I/O FC2_TXD_SCL_MISO — Flexcomm Interface 2: USART TXD, I2C SCL, SPI MISO.
OSCT0_OUT2 — SCT0 output 2. PWM output 2.
ICTimer3_CAP0 — 32-bit CTimer3 capture input 0.
R — Reserved.
I/O FC3_CTS_SDA_SSEL0 — Flexcomm Interface 3: USART CTS, I2C SDA, SPI
SSEL0.
PIO0_10 E6 45 [2] PU I/O PIO0_10 — General-purpose digital input/output pin.
I/O FC2_SCK — Flexcomm Interface 2: USART or SPI clock.
OSCT0_OUT3 — SCT0 output 3. PWM output 3.
OCTimer3_MAT0 — 32-bit CTimer3 match output 0.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 12 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO0_11 E5 46 [2] PU I/O PIO0_11 — General-purpose digital input/output pin. In ISP mode, this pin is set to
the Flexcomm 3 SPI SCK function.
I/O FC3_SCK — Flexcomm Interface 3: USART or SPI clock.
I/O FC6_RXD_SDA_MOSI_DATA — Flexcomm Interface 6: USART RXD, I2C SDA,
SPI MOSI, I2S DATA.
OCTimer2_MAT1 — 32-bit CTimer2 match output 1.
PIO0_12 F7 47 [2] PU I/O PIO0_12 — General-purpose digital input/output pin. In ISP mode, this pin is set to
the Flexcomm 3 SPI MOSI function.
I/O FC3_RXD_SDA_MOSI — Flexcomm Interface 3: USART RXD, I2C SDA, SPI
MOSI.
I/O FC6_TXD_SCL_MISO_WS — Flexcomm Interface 6: USART TXD, I2C SCL, SPI
MISO, I2S WS.
OCTimer2_MAT3 — 32-bit CTimer2 match output 3.
PIO0_13 G7 48 [2] PU I/O PIO0_13 — General-purpose digital input/output pin. In ISP mode, this pin is set to
the Flexcomm 3 SPI MISO function.
I/O FC3_TXD_SCL_MISO — Flexcomm Interface 3: USART TXD, I2C SCL, SPI MISO.
OSCT0_OUT4 — SCT0 output 4. PWM output 4.
OCTimer2_MAT0 — 32-bit CTimer2 match output 0.
PIO0_14/
TCK
F6 49 [2] PU I/O PIO0_14 — General-purpose digital input/output pin. In boundary scan mode: TCK
(Test Clock In). In ISP mode, this pin is set to the Flexcomm 3 SPI SSELN0 function.
I/O FC3_CTS_SDA_SSEL0 — Flexcomm Interface 3: USART CTS, I2C SDA, SPI
SSEL0.
OSCT0_OUT5 — SCT0 output 5. PWM output 5.
OCTimer2_MAT1 — 32-bit CTimer2 match output 1.
R — Reserved.
I/O FC1_SCK — Flexcomm Interface 1: USART or SPI clock.
PIO0_15/
TDO
G6 50 [2] PU I/O PIO0_15 — General-purpose digital input/output pin. In boundary scan mode: TDO
(Test Data Out).
I/O FC3_RTS_SCL_SSEL1 — Flexcomm Interface 3: USART RTS, I2C SCL, SPI
SSEL1.
I/O SWO — Serial wire trace output.
OCTimer2_MAT2 — 32-bit CTimer2 match output 2.
R — Reserved.
I/O FC4_SCK — Flexcomm Interface 4: USART or SPI clock.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 13 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
SWCLK/
PIO0_16
F5 52 [2] PU I/O PIO0_16 — General-purpose digital input/output pin.
I/O FC3_SSEL2 — Flexcomm Interface 3: SPI SSEL2.
I/O FC6_CTS_SDA_SSEL0 — Flexcomm Interface 6: USART CTS, I2C SDA, SPI
SSEL0.
OCTimer3_MAT1 — 32-bit CTimer3 match output 1.
R — Reserved.
I/O SWCLK — Serial Wire Clock. JTAG Test Clock. This is the default function after
booting.
R — Reserved.
SWDIO/
PIO0_17
G5 53 [2] PU I/O PIO0_17 — General-purpose digital input/output pin.
I/O FC3_SSEL3 — Flexcomm Interface 3: SPI SSEL3.
I/O FC6_RTS_SCL_SSEL1 — Flexcomm Interface 6: USART RTS, I2C SCL, SPI
SSEL1.
OCTimer3_MAT2 — 32-bit CTimer3 match output 2.
R — Reserved.
I/O SWDIO — Serial Wire Debug I/O. This is the default function after booting.
PIO0_18/
TRST
G4 58 [2] PU I/O PIO0_18 — General-purpose digital input/output pin. In boundary scan mode: TRST
(Test Reset).
I/O FC5_TXD_SCL_MISO — Flexcomm Interface 5: USART TXD, I2C SCL, SPI MISO.
OSCT0_OUT0 — SCT0 output 0. PWM output 0.
OCTimer0_MAT0 — 32-bit CTimer0 match output 0.
PIO0_19/
TDI
G3 59 [2] PU I/O PIO0_19 — General-purpose digital input/output pin. In boundary scan mode: TDI
(Test Data In).
I/O FC5_SCK — Flexcomm Interface 5: USART or SPI clock.
OSCT0_OUT1 — SCT0 output 1. PWM output 1.
OCTimer0_MAT1 — 32-bit CTimer0 match output 1.
PIO0_20/
TMS
F3 60 [2] PU I/O PIO0_20 — General-purpose digital input/output pin. In boundary scan mode: TMS
(Test Mode Select).
I/O FC5_RXD_SDA_MOSI — Flexcomm Interface 5: USART RXD, I2C SDA, SPI
MOSI.
I/O FC0_SCK — Flexcomm Interface 0: USART or SPI clock.
ICTimer3_CAP0 — 32-bit CTimer3 capture input 0.
PIO0_21 E3 61 [2] PU I/O PIO0_21 — General-purpose digital input/output pin.
OCLKOUT — Clock output.
I/O FC0_TXD_SCL_MISO — Flexcomm Interface 0: USART TXD, I2C SCL, SPI MISO.
OCTimer3_MAT0 — 32-bit CTimer3 match output 0.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 14 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO0_22 G2 63 [2] PU I/O PIO0_22 — General-purpose digital input/output pin.
ICLKIN — Clock input.
I/O FC0_RXD_SDA_MOSI — Flexcomm Interface 0: USART RXD, I2C SDA, SPI
MOSI.
OCTimer3_MAT3 — 32-bit CTimer3 match output 3.
PIO0_23 F2 1 [3] ZI/OPIO0_23 — General-purpose digital input/output pin. In ISP mode, this pin is set to
the Flexcomm 1 I2C SCL function.
I/O FC1_RTS_SCL_SSEL1 — Flexcomm Interface 1: USART CTS, I2C SCL, SPI
SSEL1.
R — Reserved.
ICTimer0_CAP0 — 32-bit CTimer0 capture input 0.
R — Reserved.
IUTICK_CAP1 — Micro-tick timer capture input 1.
PIO0_24 F1 2 [3] ZI/OPIO0_24 — General-purpose digital input/output pin. In ISP mode, this pin is set to
the Flexcomm 1 I2C SDA function.
I/O FC1_CTS_SDA_SSEL0 — Flexcomm Interface 1: USART CTS, I2C SDA, SPI
SSEL0.
R — Reserved.
ICTimer0_CAP1 — 32-bit CTimer0 capture input 1.
R — Reserved.
OCTimer0_MAT0 — 32-bit CTimer0 match output 0.
PIO0_25 E2 3 [3] ZI/OPIO0_25 — General-purpose digital input/output pin.
I/O FC4_RTS_SCL_SSEL1 — Flexcomm Interface 4: USART CTS, I2C SCL, SPI
SSEL1.
I/O FC6_CTS_SDA_SSEL0 — Flexcomm Interface 6: USART CTS, I2C SDA, SPI
SSEL0.
ICTimer0_CAP2 — 32-bit CTimer0 capture input 2.
R — Reserved.
ICTimer1_CAP1 — 32-bit CTimer1 capture input 1.
PIO0_26 E1 4 [3] ZI/OPIO0_26 — General-purpose digital input/output pin.
I/O FC4_CTS_SDA_SSEL0 — Flexcomm Interface 4: USART CTS, I2C SDA, SPI
SSEL0.
R — Reserved.
ICTimer0_CAP3 — 32-bit CTimer0 capture input 3.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 15 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO0_29/
ADC0_0
D3 11 [4] PU I/O;
AI
PIO0_29/ADC0_0 — General-purpose digital input/output pin. ADC input channel 0
if the DIGIMODE bit is set to 0 in the IOCON register for this pin.
I/O FC1_RXD_SDA_MOSI — Flexcomm Interface 1: USART RXD, I2C SDA, SPI
MOSI.
OSCT0_OUT2 — SCT0 output 2. PWM output 2.
OCTimer0_MAT3 — 32-bit CTimer0 match output 3.
R — Reserved.
ICTimer0_CAP1 — 32-bit CTimer0 capture input 1.
R — Reserved.
OCTimer0_MAT1 — 32-bit CTimer0 match output 1.
PIO0_30/
ADC0_1
C1 12 [4] PU I/O;
AI
PIO0_30/ADC0_1 — General-purpose digital input/output pin. ADC input channel 1
if the DIGIMODE bit is set to 0 in the IOCON register for this pin.
I/O FC1_TXD_SCL_MISO — Flexcomm Interface 1: USART TXD, I2C SCL, SPI MISO.
OSCT0_OUT3 — SCT0 output 3. PWM output 3.
OCTimer0_MAT2 — 32-bit CTimer0 match output 2.
R — Reserved.
ICTimer0_CAP2 — 32-bit CTimer0 capture input 2.
PIO0_31/
ADC0_2
C2 13 [4] PU I/O;
AI
PIO0_31/ADC0_2 — General-purpose digital input/output pin. ADC input channel 2
if the DIGIMODE bit is set to 0 in the IOCON register for this pin.
Remark: This pin is also used to invoke ISP mode after device reset. Secondary
selection of boot source for ISP mode also uses PIO0_4 and PIO1_6. See the Boot
Process chapter in UM10914 for more details.
OPDM0_CLK — Clock for PDM interface 0, for digital microphone.
I/O FC2_CTS_SDA_SSEL0 — Flexcomm Interface 2: USART CTS, I2C SDA, SPI
SSEL0.
ICTimer2_CAP2 — 32-bit CTimer2 capture input 2.
R — Reserved.
ICTimer0_CAP3 — 32-bit CTimer0 capture input 3.
OCTimer0_MAT3 — 32-bit CTimer0 match output 3.
PIO1_0/
ADC0_3
C3 14 [4] PU I/O;
AI
PIO1_0/ADC0_3 — General-purpose digital input/output pin. ADC input channel 3 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
IPDM0_DATA — Data for PDM interface 0, digital microphone input.
I/O FC2_RTS_SCL_SSEL1 — Flexcomm Interface 2: USART RTS, I2C SCL, SPI
SSEL1.
OCTimer3_MAT1 — 32-bit CTimer3 match output 1.
R — Reserved.
ICTimer0_CAP0 — 32-bit CTimer0 capture input 0.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 16 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO1_1/
ADC0_4
B1 15 [4] PU I/O;
AI
PIO1_1/ADC0_4 — General-purpose digital input/output pin. ADC input channel 4 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
R — Reserved.
I/O SWO — Serial wire trace output.
OSCT0_OUT4 — SCT0 output 4. PWM output 4.
I/O FC5_SSEL2 — Flexcomm Interface 5: SPI SSEL2.
I/O FC4_TXD_SCL_MISO — Flexcomm Interface 4: USART TXD, I2C SCL, SPI MISO.
PIO1_2/
ADC0_5
A1 16 [4] PU I/O;
AI
PIO1_2/ADC0_5 — General-purpose digital input/output pin. ADC input channel 5 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
I/O MCLK — MCLK input or output for I2S and/or digital microphone.
I/O FC7_SSEL3 — Flexcomm Interface 7: SPI SSEL3.
OSCT0_OUT5 — SCT0 output 5. PWM output 5.
I/O FC5_SSEL3 — Flexcomm Interface 5: SPI SSEL3.
I/O FC4_RXD_SDA_MOSI — Flexcomm Interface 4: USART RXD, I2C SDA, SPI
MOSI.
PIO1_3/
ADC0_6
B2 17 [4] PU I/O;
AI
PIO1_3/ADC0_6 — General-purpose digital input/output pin. ADC input channel 6 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
R — Reserved.
I/O FC7_SSEL2 — Flexcomm Interface 7: SPI SSEL2.
OSCT0_OUT6 — SCT0 output 6. PWM output 6.
R — Reserved.
I/O FC3_SCK — Flexcomm Interface 3: USART or SPI clock.
ICTimer0_CAP1 — 32-bit CTimer0 capture input 1.
OUSB_UP_LED — USB port 2 GoodLink LED indicator. It is LOW when the device is
configured (non-control endpoints enabled). It is HIGH when the device is not
configured or during global suspend.
PIO1_4/
ADC0_7
A2 18 [4] PU I/O;
AI
PIO1_4/ADC0_7 — General-purpose digital input/output pin. ADC input channel 7 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
OPDM1_CLK — Clock for PDM interface 1, for digital microphone.
I/O FC7_RTS_SCL_SSEL1 — Flexcomm Interface 7: USART RTS, I2C SCL, SPI
SSEL1.
OSCT0_OUT7 — SCT0 output 7. PWM output 7.
R — Reserved.
I/O FC3_TXD_SCL_MISO — Flexcomm Interface 3: USART TXD, I2C SCL, SPI MISO.
OCTimer0_MAT1 — 32-bit CTimer0 match output 1.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 17 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO1_5/
ADC0_8
B3 19 [4] PU I/O;
AI
PIO1_5/ADC0_8 — General-purpose digital input/output pin. ADC input channel 8 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
IPDM1_DATA — Data for PDM interface 1, digital microphone input. Also PDM clock
input in bypass mode.
I/O FC7_CTS_SDA_SSEL0 — Flexcomm Interface 7: USART CTS, I2C SDA, SPI
SSEL0.
ICTimer1_CAP0 — 32-bit CTimer1 capture input 0.
R — Reserved.
OCTimer1_MAT3 — 32-bit CTimer1 match output 3.
R — Reserved.
OUSB_FRAME — USB start-of-frame signal derived from host signaling.
PIO1_6/
ADC0_9
A5 26 [4] PU I/O;
AI
PIO1_6/ADC0_9 — General-purpose digital input/output pin. ADC input channel 9 if
the DIGIMODE bit is set to 0 in the IOCON register for this pin.
Remark: This pin is also used as part of secondary selection of boot source for ISP
mode after device reset, in connection with PIO0_31 and PIO0_4. See the Boot
Process chapter in UM10914 for more details.
R — Reserved.
I/O FC7_SCK — Flexcomm Interface 7: USART, SPI, or I2S clock.
ICTimer1_CAP2 — 32-bit CTimer1 capture input 2.
R — Reserved.
OCTimer1_MAT2 — 32-bit CTimer1 match output 2.
R — Reserved.
IUSB_VBUS — Monitors the presence of USB bus power. This signal must be HIGH
for USB reset to occur.
PIO1_7/
ADC0_10
B5 27 [4] PU I/O;
AI
PIO1_7/ADC0_10 — General-purpose digital input/output pin. ADC input channel
10 if the DIGIMODE bit is set to 0 in the IOCON register for this pin.
R — Reserved.
I/O FC7_RXD_SDA_MOSI_DATA — Flexcomm Interface 7: USART RXD, I2C SDA,
SPI MOSI, I2S DATA.
OCTimer1_MAT2 — 32-bit CTimer1 match output 2.
R — Reserved.
ICTimer1_CAP2 — 32-bit CTimer1 capture input 2.
PIO1_8/
ADC0_11
C5 28 [4] PU I/O;
AI
PIO1_8/ADC0_11 — General-purpose digital input/output pin. ADC input channel 11
if the DIGIMODE bit is set to 0 in the IOCON register for this pin.
R — Reserved.
I/O FC7_TXD_SCL_MISO_WS — Flexcomm Interface 7: USART TXD, I2C SCL, SPI
MISO, I2S WS.
OCTimer1_MAT3 — 32-bit CTimer1 match output 3.
R — Reserved.
ICTimer1_CAP3 — 32-bit CTimer1 capture input 3.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 18 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO1_9 - 29 [2] PU I/O PIO1_9 — General-purpose digital input/output pin.
R — Reserved.
I/O FC3_RXD_SDA_MOSI — Flexcomm Interface 3: USART RXD, I2C SDA, SPI
MOSI.
ICTimer0_CAP2 — 32-bit CTimer0 capture input 2.
R — Reserved.
R — Reserved.
OUSB_UP_LED — USB port 2 GoodLink LED indicator. It is LOW when the device is
configured (non-control endpoints enabled). It is HIGH when the device is not
configured or during global suspend.
PIO1_10 - 30 [2] PU I/O PIO1_10 — General-purpose digital input/output pin.
R — Reserved.
I/O FC6_TXD_SCL_MISO_WS — Flexcomm Interface 6: USART TXD, I2C SCL, SPI
MISO, I2S WS.
OSCT0_OUT4 — SCT0 output 4. PWM output 4.
I/O FC1_SCK — Flexcomm Interface 1: USART or SPI clock.
R — Reserved.
R — Reserved.
IUSB_FRAME — USB start-of-frame signal derived from host signaling.
PIO1_11 - 42 [2] PU I/O PIO1_11 — General-purpose digital input/output pin.
R — Reserved.
I/O FC6_RTS_SCL_SSEL1 — Flexcomm Interface 6: USART RTS, I2C SCL, SPI
SSEL1.
ICTimer1_CAP0 — 32-bit CTimer1 capture input 0.
I/O FC4_SCK — Flexcomm Interface 4: USART or SPI clock.
R — Reserved.
R — Reserved.
IUSB_VBUS — Monitors the presence of USB bus power. This signal must be HIGH
for USB reset to occur.
PIO1_12 - 51 [2] PU I/O PIO1_12 — General-purpose digital input/output pin.
R — Reserved.
I/O FC5_RXD_SDA_MOSI — Flexcomm Interface 5: USART RXD, I2C SDA, SPI
MOSI.
OCTimer1_MAT0 — 32-bit CTimer1 match output 0.
I/O FC7_SCK — Flexcomm Interface 7: USART, SPI, or I2S clock.
IUTICK_CAP2 — Micro-tick timer capture input 2.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 19 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
PIO1_13 - 54 [2] PU I/O PIO1_13 — General-purpose digital input/output pin.
R — Reserved.
I/O FC5_TXD_SCL_MISO — Flexcomm Interface 5: USART TXD, I2C SCL, SPI MISO.
OCTimer1_MAT1 — 32-bit CTimer1 match output 1.
I/O FC7_RXD_SDA_MOSI_DATA — Flexcomm Interface 7: USART RXD, I2C SDA,
SPI MOSI, I2S DATA.
PIO1_14 - 57 [2] PU I/O PIO1_14 — General-purpose digital input/output pin.
R — Reserved.
I/O FC2_RXD_SDA_MOSI — Flexcomm Interface 2: USART RXD, I2C SDA, SPI
MOSI.
OSCT0_OUT7 — SCT0 output 7. PWM output 7.
I/O FC7_TXD_SCL_MISO_WS — Flexcomm Interface 7: USART TXD, I2C SCL, SPI
MISO, I2S WS.
PIO1_15 - 62 [2] PU I/O PIO1_15 — General-purpose digital input/output pin.
OPDM0_CLK — Clock for PDM interface 0, for digital microphone.
OSCT0_OUT5 — SCT0 output 5. PWM output 5.
ICTimer1_CAP3 — 32-bit CTimer1 capture input 3.
I/O FC7_CTS_SDA_SSEL0 — Flexcomm Interface 7: USART CTS, I2C SDA, SPI
SSEL0.
PIO1_16 - 7 [2] PU I/O PIO1_16 — General-purpose digital input/output pin.
IPDM0_DATA — Data for PDM interface 0, digital microphone input.
OCTimer0_MAT0 — 32-bit CTimer0 match output 0.
ICTimer0_CAP0 — 32-bit CTimer0 capture input 0.
I/O FC7_RTS_SCL_SSEL1 — Flexcomm Interface 7: USART RTS, I2C SCL, SPI
SSEL1.
PIO1_17 - 10 [2] PU I/O PIO1_17 — General-purpose digital input/output pin.
R — Reserved.
R — Reserved.
R — Reserved.
I/O MCLK — MCLK input or output for I2S and/or digital microphone.
IUTICK_CAP3 — Micro-tick timer capture input 3.
USB_DP D2 5 [6] F I/O USB0 bidirectional D+ line.
USB_DM D1 6 [6] F I/O USB0 bidirectional D- line.
RESETN G1 64 [5] PU I External reset input: A LOW on this pin resets the device, causing I/O ports and
peripherals to take on their default states, and processor execution to begin at
address 0. Wakes up the part from deep power-down mode.
RTCXIN A7 33 - - RTC oscillator input.
RTCXOUT B7 35 - - RTC oscillator output.
VREFP B4 22 - - ADC positive reference voltage.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description

LPC5411x All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet Rev. 2.1 — 9 May 2018 20 of 105
NXP Semiconductors LPC5411x
32-bit ARM Cortex-M4/M0+ microcontroller
[1] PU = input mode, pull-up enabled (pull-up resistor pulls up pin to VDD). Z = high impedance; pull-up or pull-down disabled, AI = analog
input, I = input, O = output, F = floating. Reset state reflects the pin state at reset without boot code operation. For pin states in the
different power modes, see Section 6.2.2 “Pin states in different power modes”. For termination on unused pins, see Section 6.2.1
“Termination of unused pins”.
[2] 5 V tolerant pad with programmable glitch filter (5 V tolerant if VDD present; if VDD not present, do not exceed 3.6 V); provides digital I/O
functions with TTL levels and hysteresis; normal drive strength. See Figure 31. Pulse width of spikes or glitches suppressed by input
filter is from 3 ns to 16 ns (simulated value).
[3] True open-drain pin. I2C-bus pins compliant with the I2C-bus specification for I2C standard mode, I2C Fast-mode, and I2C Fast-mode
Plus. The pin requires an external pull-up to provide output functionality. When power is switched off, this pin is floating and does not
disturb the I2C lines. Open-drain configuration applies to all functions on this pin.
[4] 5 V tolerant pin providing standard digital I/O functions with configurable modes, configurable hysteresis, and analog input. When
configured as an analog input, the digital section of the pin is disabled, and the pin is not 5 V tolerant.
[5] Reset pad.5 V tolerant pad with glitch filter with hysteresis. Pulse width of spikes or glitches suppressed by input filter is from 3 ns to
20 ns (simulated value)
[6] 5 V tolerant transparent analog pad.
VREFN - 21 - - ADC negative reference voltage.
VDDA A4 23 - - Analog supply voltage.
VDD C4,
F4
8,
24,
34,
56
- - Single 1.62 V to 3.6 V power supply powers internal digital functions and I/Os.
VSS D4,
E4
9,
25,
55
- - Ground.
VSSA A3 20 - - Analog ground.
Table 4. Pin description …continued
Symbol
49-pin 64-pin Reset state [1] Type
Description
