O2 X1b User manual

1 2
1 2
1 2
o2.co.uk
O2 (UK) Limited, 260 Bath Road, Slough, Berkshire SL1 4DX
Registered in England No. 1743099. Registered Office as above.
© O2 (UK) Limited 2003. Correct at time of going to press (June 2005)
O2 X1b is a trademark of the O2 Group of companies.
O2C2450N KGL 06/05
O2X1b™
How to use it

ii
Setting up
• Insert the SIM into the slot on the back of the O2X1b
handset, connect the battery and slide on the outer cover
• Check these items are securely in place, then press
until the screen turns on. Then enter a PIN if necessary*
• You’re now ready to use the O2X1b
Charging the handset
• Insert the lead from the charger to the base of the handset
into the charging socket
• Connect the charger to the correct electrical socket. The
phone will start charging
• When the phone is fully charged disconnect the charger
from the socket and then from the phone
Quick start guide
i
Just a tick
Before you start exploring your new mobile we’d like to say
thanks for choosing an O2X1b. Everything you need to know
to get you started is explained briefly in this first chapter.
The O2X1b has a range of features including an integrated
camera, picture messaging, Bluetooth connectivity, polyphonic
ringtones, a 65,000 colour screen, access to O2Active and all
the other features you’d expect from an O2mobile.
The main thing is that you enjoy discovering everything you
can do.
* The default PIN code is 4321 or 5555. If you enter an incorrect PIN code three
times in succession, your SIM card will lock and you must enter the PUK code to
unlock it. Please contact O2 Customer Service or visit www.o2.co.uk/PUK and follow
the instructions.

iv
How to create and send a text message
• Press to enter the text message screen
• You can now start typing your message using the keypad.
The O2X1b uses ITAP, a predictive text input. Press to
change between input options
• Once you’ve finished typing your text, press
• Type the number of the person that you wish to send the
text to or select their contact number from your
phonebook
• Press and your message will be sent to the recipient
Quick start guide
iii
Basic navigation
Here’s how to navigate when using the O2X1b.
• Use to move up, down, left or right
• Press or to select an item
• Press to go Back or delete digits entered
• Press to go back to the standby screen
How to make a call
• Type the number of the person you wish to call by using the
numbered keypad or press to select Contacts and
scroll up and down to find the contact
• Press to dial the number. Your O2X1b will start to dial
the number
• After you’ve connected, press to end the call

vi
Top tips
• You can assign a picture to a caller’s name, so when the
contact calls you their photo appears on screen.
See page 40 for details
• To take a picture of yourself, select Camera in idle mode,
then turn the handset over. The mirror will then act as a
viewfinder. Once you’re ready to take your picture, press
to capture the image
• You can set a picture as your wallpaper. See page 134
for details
• To access the profiles menu press . For further
information on profiles see page 128
• To lock your keypad, press and hold .
To unlock your keypad, press to select Unlock and
then press
Quick start guide
v
How to take a picture
• From the idle screen press to enter the
viewfinder mode
• Focus the camera on the picture subject
• Select Option to amend the Quality and Mode of
your photo
• Once you’re ready, press to take a picture
• Press to select Save or to select Discard and
return to the viewfinder screen and take another picture
How to access O2Active
• In the standby screen press to access O2Active
• Your O2X1b will access O2Active and the O2Active
homepage will load onto your screen
• Scroll through the menu – there’s so much you can do
• When you’ve finished press to disconnect
For further information on O2Active see page 84.

O2 X1b is a trademark of the O2 Group of companies.
viii
vii
Contents
Welcome xiii
Chapter 1 – Before using your mobile 1
What’s in the box 2
Handset description 4
Main display 6
Icons 8
Function keys 10
Navigation key 12
Chapter 2 – Preparing your mobile for use 15
Plug in your SIM 16
The battery 18
Charging your battery 19
Important battery information 21
Chapter 3 – Basic functions 23
Turning your mobile on and off 24
The menu 26
The basics 30
Making a call 30
Ending a call 30
Receiving calls 30
Making an international call 31
Emergency calls 31
Voicemail 901 32

x
Text 58
– Write a text message 58
– Read messages 60
– Inbox 62
– Sent items 62
– Drafts 64
– Delete 65
– Settings 65
Multimedia 66
– Create a media message 66
– Read messages 71
– Inbox 73
– Sent items 74
– Drafts 74
– Delete 75
– Settings 75
Camera 76
Camera settings 77
Take a picture 78
Managing your pictures 79
View your pictures 83
ix
Chapter 4 – Main menu 35
Contacts 36
Adding contacts to your phonebook 36
Finding contacts in your phonebook 41
Copy 42
Delete 42
Groups 43
Business card 44
My number 44
Memory status 44
Calls 45
Missed, dialled and received calls 45
Delete 47
Duration 48
Call cost 49
During a call 51
In-call menu 53
Messaging 56
Text 56
Multimedia 56
Voicemail 56
Broadcast 57
Memory 57

xii
Settings 127
Date and time 127
Profiles 128
Display 134
Audio 139
Call settings 140
Network 145
Security 147
Language 153
Factory reset 153
Chapter 5 – Don’t panic 155
In plain English 156
Trouble shooting 159
Vital statistics 163
Chapter 6 – The important safety bit at the back 165
Safety information for mobiles 166
Mobile care 167
Driving safety 171
Electronic devices 172
Other safety guidelines 175
Cautions 177
About this guide 178
xi
Escape into O2Active 84
Do more with O2Active 86
One touch and you’re there 88
Games 100
Monkey Mayhem 100
Eda Mouse 102
Media Centre 103
Images 103
Ringtones 105
Wallpaper 107
Delete all 108
Memory 108
Tools 109
O2109
Bluetooth®110
Alarm 113
World clock 116
Calendar 117
Calculator 122
Currency converter 123
Stopwatch 126

xiv
This guide will help you get the most from your new mobile –
and all the fantastic features of the O2network.
All in all, we’re pretty pleased with the O2X1b. We hope you
feel the same way.
About the user guide
This user guide relates only to the O2X1b.
Please note that a small proportion of the functions available
differ between Pay & Go and Pay Monthly customers.
Welcome
xiii
Welcome
Well here it is, your new O2X1b mobile – you won‘t
be disappointed.
As well as a 65,000 colour screen, your new mobile features
an integrated camera, picture messaging, Bluetooth
connectivity, polyphonic ringtones and is also a tri-band
handset so you can use your O2X1b in the USA and Canada.
You can also access the O2Active™service using the latest
technology. Up-to-the-minute information is at your fingertips
wherever you are and whenever you need it*. Access
O2Active†by pressing and holding and you can enjoy the
following and much more.
• Plan your night out with Time Out
• Download the latest pictures from
the O2Media Messaging gallery
and send them to your friends
• Be the first to hear the latest gossip
from the music and movie worlds
O2 do not suggest in any way that the celebrities featured in this guide are
endorsing O2 products or services.
* Subject to network coverage.
†Terms and conditions apply. See www.o2.co.uk

Before using your mobile
What’s in the box
Handset description
Main display
Icons
Function keys
Navigation key
Chapter 1
1
xv

3
2
What’s in the box
Thank you for purchasing your O2X1b. Take a look in the box
for the following items. Please check the product contents to
see if you have all the available items as shown.
Your O2X1b
– How to use
it guide
Mobile
phone Charger
Battery Hands-free
kit
Battery cover

5
Before using your mobile
4
Handset description
Front view
Earpiece
65,000 colour
main display
Back view
Microphone
Left soft key
Dial/Answer key
Navigation key OK key
Bluetooth on/off
(once paired)
Keypad –
alphanumeric
Right soft key
Power on/off key
Mirror Speaker
Camera
Battery

7
Please note
• To set the time on the display, please refer to page 127
• Photos taken using your mobile’s camera can also be set as
wallpapers. See page 134 for details
• After 30 seconds of inactivity the screen on your O2X1b
changes from displaying O2into ‘Sleep mode’. This means
that it looks almost black. Your mobile has not turned off
but it is in ‘Sleep mode’. By tilting your phone, you can see
the clock displayed. By pressing any key your mobile’s display
will start up again. This is normal operation and designed to
maintain battery life
Before using your mobile
6
Main display
The main display will show icons for network signal strength,
battery power, alarm (if active), the current time and the
current profile in use. The screen can also alert you to
incoming calls, text messages and missed calls.
Date/Time
Signal
Name of operator
Wallpaper
Press to enter
the main menu
Battery power
Current profile
Press to access
your contacts
Press to
access O2Active

9
Silent Appears when vibration is set as a ringtone. In
the standby screen, press and hold to activate the
Silent profile
Normal Shows the Normal profile is in use. To set a
different profile please refer to page 128
Meeting Shows that the Meeting profile is in use
Outdoors Shows that the Outdoors profile is in use
Personal Shows that the Personal profile is in use
Divert Appears when the call divert function is active
Roaming Indicates roaming has been activated
(It is not your regular network)
Before using your mobile
8
Icons
The icons below appear on your mobile’s display.
Signal strength The number of bars shows
signal strength
Battery Current battery charge level
GPRS network GPRS services have been activated on
your SIM card
Message Shows that a text message or media message
has been received or that there are unread messages. If
the icon appears in red on the main display then your
message memory is full
WAP message You’ve a WAP message (This icon will
only appear when there are no incoming or unread text
and media messages)
Alarm Appears when an alarm is set
Line in use Shows the number of the line currently
in use

11
Before using your mobile
10
Function keys
Power on/ • Long press to turn your mobile on/off
off key • Press to reject an incoming call or cancel
a call being dialled
• Press to return to the standby screen
Send/Answer key • Press to dial or answer a call
• Press to access the list of the last
missed/dialled/received calls
OK key • Press to open up the main menu
• Press to select when browsing through
the menu
Left soft key • To access O2Active
• Press to select when browsing through
lower menu levels from standby mode
Right soft key • Press to access your contacts
• Press and hold to turn the silent profile
on or off
• Press to delete entered digits
Navigation key • To browse through the menu
Asterisk key • To insert an asterisk
• Press and hold to select +
Voicemail • Press and hold to access
your voicemail
# key • To insert #
• Press, when creating a message, to
access predictive text (ITAP) or manual
text imput
• Press and hold to activate the phone
keypad lock
Alphanumeric • Press to enter a digit
• Shortcut keys – press and hold to
immediately access a function

When in standby mode, the navigation key
can be used to access shortcuts we’ve set up
for you.
Left To create a text message
Right To access your profiles
Up To access the main menu
Down To access the camera function
13
12
Navigation key

Chapter 2
Preparing your mobile for use
Plug in your SIM
The battery
Charging your battery
Important battery information
1514

17
Preparing your mobile for use
16
To use your mobile, your SIM card needs to be inserted at all
times – this contains important information about your mobile
and network. The message Insert SIM appears when the SIM
card is not installed.
Please take care of your SIM card and don’t keep it near
magnetic and electronic devices as this can interfere with data
storage and network operations.
• Turn your mobile over and slide the cover off
• Release the battery latch and lift the battery off the mobile
Please note
Don’t remove the battery when the mobile is on. This could
mean losing personal settings or data stored either on your
SIM card or in the mobile’s memory.
• Slide the SIM card in under the metal grooves in the SIM
card slot, with the SIM card’s metal contacts facing down
and the cut corner at the top left
Please note
A SIM card can be easily damaged if its metal contacts become
scratched, so take special care when holding or inserting it.
If you wish to remove the SIM
card, you must first press down
the stay, then push the SIM
card out of the slot.
Plug in your SIM
Battery latch
SIM card
SIM card
Stay
➔
➔

19
Preparing your mobile for use
18
Power connection
Insert the charger into the slot and plug the charger into the
socket. Please ensure you insert the charger the right side up
and that after insertion the connector is snug to the phone.
An audio tone plays when you have connected the
charger properly.
Before you use your phone for the first time, charge your
battery for at least four hours. Charging the battery fully each
time will help prolong its life – and is much better than
frequent short bursts of charging.
Charging the battery
Installing the battery
Insert the bottom of the battery into the groove at the top of
the mobile. Push down the battery until it locks into place and
then slide the cover back on.
Removing the battery
Slide the cover off. Push the battery latch inwards and then lift
the battery to separate from the mobile.
Please note
The battery must be securely placed in the battery compartment.
If the battery’s not in place your mobile won’t turn on.
The battery
Charger socket
Charger connector
➔

21
Preparing your mobile for use
20
• Don’t remove the battery while your mobile is charging
• Don’t overcharge the Li-Ion battery, as this can result in a
reduction in battery performance and life span. The
recommended maximum charge time is 6-8 hours
• Never store a battery near a fire
• Don’t attempt to take the battery apart. Only use the battery
approved by the manufacturer
• Never touch the battery terminals with a metallic object, as
this can lead to short circuiting. Take special care when
carrying a battery in your pocket
• Misuse of the battery can lead to burns from hot
temperatures and even explosion. Never drop or apply any
physical shock to the battery as it may damage it and even
cause fire
• Please keep your battery out of children’s reach and in a dry
and cool area
• Store and charge your battery at room temperature.
Extremes of temperature can prevent full charging and affect
battery life and performance
• Keep the terminals of the battery clean and dry
• When there is risk of lightning, remove the charger’s
plug from the socket to protect the mobile
Important battery information
Charging status
If you charge your mobile
• While it is turned off, the main display shows the
following animation
• While it is turned on, the display shows the icon.
The lines showing the battery power will scroll until the
battery is fully charged
When the battery is out of power, you’ll hear an alert
sound to remind you to recharge it. Eventually, it will turn
off automatically.
Please note
If the battery is very low only the keymat will turn on and
will be lit blue. The screen will not turn on until the battery
is sufficiently charged.

Chapter 3
Basic functions
Turning your mobile on and off
The menu
The basics
Voicemail 901
22 23
