O2 Xda Atom User manual

1
Contents
Chapter 1 Before using your O2Xda Atom 8
1.1 What’s in the box? 8
1.2 Familiarizing yourself with your Xda Atom 9
1.3 Features 11
1.4 Key functions 12
1.5 Display information 13
Chapter 2 Getting started 26
2.1 Insert the battery & SIM card 26
2.2 SIM card 27
2.3 Battery 27
2.4 Switching the device on or off 29
2.5 Screen taping & calibration 29
2.6 Screen Orientation 30
2.7 Entering information 30
2.8 Recording a message 34
2.9 Data backup 35

2
2.10 Memory expansion 35
2.11 Resetting your Xda Atom 35
2.12 Power management 36
Chapter 3 Synchronization 38
3.1 About synchronization 38
3.2 Installing ActiveSync 39
3.3 Choose your connection type 40
3.4 Synchronizing information 41
3.5 ActiveSync Errors 44
Chapter 4 Getting connected 46
4.1 Making a connection 46
4.2 Connecting to the Internet 60
Chapter 5 Basic phone functions 62
5.1 Making a call 65
5.2 Ending a call 68
5.3 Receiving/Ignoring a call 68
5.4 International calls 68

3
5.5 Emergency calls 69
5.6 In-call options 69
5.7 Contacts information 71
5.8 Device security 74
Chapter 6 Messaging 78
6.1 Text 79
6.2 Multimedia messages (MMS) 84
6.3 Voicemail 92
6.4 E-mail 93
6.5 Pocket MSN 103
Chapter 7 Camera 106
7.1 Capture mode 107
7.2 Setup menu 110
7.3 Photo Album 113
7.4 View mode 115
7.5 Edit mode 118

4
Chapter 8 O2MediaPlus & Equalizer 126
8.1 My Radio 128
8.2 My Music 130
8.3 My Pictures 132
8.4 My Videos 133
8.5 My Settings 134
8.6 Equalizer 138
Chapter 9 Windows mobile applications 142
9.1 Outlook 142
9.2 Word Mobile 149
9.3 Excel Mobile 150
9.4 PowerPoint Mobile 151
9.5 Pictures & Videos 153
9.6 Calculator 154
9.7 Games 154
9.8 File Explorer 155
9.9 Searching Files 155

5
Chapter 10 Applications 158
10.1 O2Connect 158
10.2 O2SMS Plus 160
10.3 ClearVue PDF 162
10.4 JAVA Midlet 163
Chapter 11 Settings 166
11.1 Personal settings 167
11.2 System settings 176
11.3 Connections settings 178
Chapter 12 Managing your Xda Atom 180
12.1 Self Diagnostics 180
12.2 Auto-Configurator 180
12.3 Setup Wizard 181
12.4 Download Agent 182
12.5 Installing my own applications 182

6
Chapter 13 Don’t panic 186
13.1 In plain English 186
13.2 Troubleshooting 187
13.3 Vital statistics 188
Chapter 14 The important safety bit at the back 190
14.1 Safety information 190
14.2 Phone care 190
14.3 Driving safety 192
14.4 Electronic devices 192
14.5 Other safety guidelines 193
14.6 Cautions 194
14.7 About this guide 194
Index 195

Chapter 1
Before using your O2Xda Atom
1.1 What’s in the box?
1.2 Familiarizing yourself with your Xda Atom
1.3 Features
1.4 Key functions
1.5 Display information

8
1
Before using your O2Xda Atom
1. Before using your O2Xda Atom
1.1 What’s in the box?
Thank you for selecting O2Xda Atom. Please check if your package comes with the following
items. If any of them is missing, please contact your retailer.
• Xda Atom – your Windows
Mobile-based Pocket PC
phone
• Universal AC adapter with
four plugs for different
countries
#ONTENTS
-ICROSOFT/UTLOOK
-ICROSOFT!CTIVE3YNC
8DA!TOMUSERMANUAL
8DA!TOM
#OMPANION#$


(









6
E
R




/
C
T
O
B
E
R





• Companion CD
• Warranty Card
Xda Atom
LIMITED WARRANTY STATEMENT
-¨«ÃÁ©®ÑúnÒOî-
PERNYATAAN JAMINAN TERBATAS
8DA!TOM
• Quick Start Guide
8DA!TOM
5SERMANUAL
• User Manual
• Additional Stylus
• USB cable
• High quality stereo
wired headset
• Battery

9
1
Before using your O2Xda Atom
1.2 Familiarizing yourself with your Xda Atom
No. Item Description
1 Volume Press up/down to increase/decrease the volume.
2 Talk/Send Press to make or receive a call.
3 Windows Start menu Press to bring up the Start menu.
4 Stereo speakers Instead of using earphones, you can play sounds or music through
the built-in stereo speakers.
5 Notification LEDs Indicates charging, GSM/GPRS status, Bluetooth, WiFi and
notification for other phone events (e.g. message arrival).
6 Touch screen Use the stylus or pointed objects to select items on the screen.
7 Navigation pad
Press to move up/down and right/left through any of the drop-down
menus or program instructions; confirm your selection by pressing
the centre key (See 1.4 Keypad functions).
8 End Press to end a call.
9O
2MediaPlus Quick access key to O2MediaPlus.
10 Infrared port Enables you to exchange files or data with other devices without
cables or wires.
11 Record Press and hold to record a voice note. Press and release
immediately to access Notes.
12 Camera Press the button to launch Camera.

10
1
Before using your O2Xda Atom
No. Item Description
13 Camera lens The CMOS camera supports 2-mega-pixel color.
14 Self-portrait mirror The preview mirror for self-portrait.
15 Flash light White LED strobe flash.
16 Battery cover Push and slide out the battery cover to replace the Li-ion battery.
17 Stylus & stylus holder The stylus slot holds your stylus when it is not in use.
18 Power Press to turn your Xda Atom on/off.
19 Mini SD card slot Insert Mini SD card here. This is an optional accessory. For more
information, please see 2.10 Memory Expansion.
20 Strap hole You can hook your strap.
21 Soft reset
Press here with the stylus to soft reset your Xda Atom. For more
information about hard reset, please see 2.11 Resetting your Xda
Atom.
22 Mini USB connector Use this connector to synchronize information with your desktop
PC, transmit data or recharge the battery.
23 Earphone plug Plug in stereo headset and allows you to listen to audio files or use
the phone’s hands-free kit.

11
1
Before using your O2Xda Atom
1.3 Features
Like a standard cell phone, your Xda Atom supports basic dialing features. However, it also
integrates Personal Digital Assistant (PDA) capability. The following section provides more
information about the phone’s features:
• Touch screen: 2.7” TFT LCD display with 65536 colours effective. (Hardware support 262K
colours).
• 5-way navigation key.
• Windows Start menu key and O2MediaPlus key.
• Stereo speaker (with receiver) & Omni-directional mono microphone.
• Mini-USB connector for connection and battery charging.
• Camera: 2 mega pixels.
• Connections: IrDA, Bluetooth, and Wireless LAN.
• Microsoft Windows Mobile 5.0: Pocket MSN, Pocket Outlook, Pocket Explorer, and Office
tools (Word, Excel, and PowerPoint). Also features Windows Media Player 10, Terminal
Service Client, Pictures & Videos, calculator, games, ActiveSync, and File Explorer.
• O2programs: O2connect, O2SMS Plus and O2MediaPlus.
• Other programs: FM Radio, Java, Equalizer DirectShow plug-in, AutoConfigurator, Setup
Wizard, Self Diagnostics, GPRS Monitor, and ClearVue PDF viewer.

12
1
Before using your O2Xda Atom
1.4 Key functions
Key Description
Scroll up or move the cursor up on the screen.
Scroll down or move the cursor down on the screen.
Move the cursor to the right.
Move the cursor to the left.
Confirm your selection.
Pick up calls and make new calls.
Hang up calls or press and immediately release to return to the Today screen.
Bring up the program list.
Press to access O2MediaPlus.

13
1
Before using your O2Xda Atom
1.5 Display information
The screen displays the following information:
Start menu Status & icon area
Main
Display
Command
bar
Pop up
menu
Windows Start menu
Tap on the Windows Start menu on top left of
the screen to bring up a menu. To return to the
Today screen at any time, Tap Start > Today.
Status & icon area
This area shows your current mode, for
example, whether you are under Phone mode
or MSN –Sign In mode. The rest of the area
displays notification icons such as time, signal
strength, message arrival, etc.
Main Display
Depending on the current mode or program, this
area shows the major features of the mode. On
the Today screen, this area contains shortcuts to
certain programs. To change the Today screen
settings, tap Start > Settings > Today.
Command bar
Depending on the mode, this area contains
different features such as input panel and
commands to create or edit a file.
Pop up menu
This feature allows you to quickly access an
item. To access a pop up menu, simply tap on
the icon on the screen and tap again to perform
an action. To cancel it, tap other places on the
screen.

14
1
Before using your O2Xda Atom
Start menu area
Tap Start to bring up a list of menu options.
No. Description
1 Quick access to a program.
2 Recently accessed programs.
3Access programs folder. Please refer to the following Programs table for a detailed
program list.
4 Device settings. Please refer to the following Settings tabe for a detailed setting list.
5 Help information.

15
1
Before using your O2Xda Atom
Programs
Your Xda Atom contains a list of programs, allowing you to get the most out of your phone.
Icons Programs Description
Games Provides games such as Bubblebreaker and Solitaire.
ActiveSync Synchronize information between your Xda Atom and a PC.
Auto Configurator Configures your network operator setting.
Calculator Perform mathematical calculations.
Camera Take photos and shoot video clips.
ClearVue PDF Support viewing of PDF files.
Download Agent Manages your downloaded content for installation.
Equalizer Edit your sound profile to play back songs.
Excel Mobile Create, view and edit Excel files.
File Explorer View all the files on your Xda Atom.
FM Radio Enables you to listen to the radio.
Modem Link Links your Xda Atom to a modem.
Notes Create notes, drawing, and recordings manually or by typing.
O2Connect Connect to O2website and download the latest software
updates.

16
1
Before using your O2Xda Atom
Icons Programs Description
O2MediaPlus
Integrate Windows MediaPlayer with Radio and Pictures &
Photos programs. An outstanding integrated interface for quick
access.
O2SMS Plus Besides SMS messaging services, also provides chat and
vCard sending features.
Pictures & Videos View your images and videos.
Pocket MSN Access for MSN services.
PowerPoint
Mobile View PowerPoint files on your Xda Atom.
Voice Speed Dial Record a voice speed dial.
Search Search for a program or file on your Xda Atom.
Self Diagnostics Runs diagnostic to test your system.
Setup Wizard Set up your personal information.
SIM Contacts Copies Contacts on your SIM card to your Xda Atom.
Spb GPRS
Monitor Keeps track of your GPRS daily traffic.
Tasks Keeps track of your appointments and creates meeting
requests.
Terminal Service Allows you to connect to a defined terminal server.
Word Mobile Create, view and edit Word files.
Photo Album View your photos and videos on your Xda Atom.

17
1
Before using your O2Xda Atom
Icons Programs Description
Photo Editor Edit your photos on your Xda Atom.
Java Install and run your Java applications.
Settings menu
The Settings menu lists a range of different applications.
Personal
Icons Settings Description
Buttons Assigns an application program to a hardware button.
Input Sets up the input method option of your Xda Atom.
Menus Customizes the Start menu list.
MSN Options Provides complete MSN settings such as passwords, Hotmail
account, and Messenger.
Owner Information Displays and set your personal information.
Password Restricts access to your Xda Atom and prevents
unauthorized use.
Phone Configures your Xda Atom settings.
Sounds &
Notifications Customizes the notification type, event and volume.
Today Arranges the appearance and items displayed on the Today
screen.
Voice Speed Dial Manages voice tags for contacts or applications.

18
1
Before using your O2Xda Atom
System
Icons Settings Description
About Shows important information relating to your Xda Atom.
Backlight Configures the backlight settings and adjusts the brightness
level to save power.
Certificates Information about the certificate issuer and the expiration
date.
Clock & Alarms Sets the time and alarms.
Error Reporting Reports your system errors to Microsoft help centre.
GPS Configures the GPS settings.
Memory Displays the memory allocation status and the programs that
are currently running.
Power Battery status and settings.
Regional Settings Customizes the formats and settings for the region you use.
Remove Programs Removes programs from your Xda Atom.
Screen Set orientation of your screen and re-calibrate for alignment.
System Info Displays your system information.

19
1
Before using your O2Xda Atom
Connections
Icons Settings Description
Band Switch
Select a different frequency band.
The changing of band selection from Automatic to any other
value may affect the ability of your handset to operate at
its optimal level and incorrect band selection may result in
reception failure.
Beam Set your Xda Atom to receive or disable IrDA signals.
Bluetooth Set up Bluetooth connection.
Connections Configure connection settings.
CSD Line Type Set up CSD line type and connection element.
GPRS Setting Select the GPRS authentication method.
Network Cards Configure the network adapters.
Wi-Fi Utility Connects with other device via Wireless LAN.

20
1
Before using your O2Xda Atom
Status and icons area
This area indicates the application or menu you are using:
When you go from the Today screen to the Calendar screen, the area changes from Start to
Calendar.
The icons display is on the top right of the Today screen. Please refer to the following table
for some of the more frequently encountered icons. Alternatively, tap the icon with your stylus
and its definition will be displays; this will also enable you to change its settings.
Type Icons Description
Battery
Battery full
Low battery
Battery alert
Battery charging
Calls
Call forward
Call on hold
Data call
Missed call
Voice call
Wi-Fi network in range
