Oakley DOUBLE TAP User manual

®

TABLE OF CONTENTS
ENGLISH 2-13
DEUTSCH 14-25
ESPAÑOL 28-40
FRANCAIS 41-53
ITALIANO 54-66
JAPANESE 67-79
MAGYAR 80-92
PORTUGUÊS 93-105

2 | DOUBLE TAP INSTRUCTION MANUAL

3 | DOUBLE TAP INSTRUCTION MANUAL
DOUBLE TAP™
The mechanical genius of military hardware inspired Double Tap,
™an array of timekeeping machines that prove the
beauty of design isn’t just how something looks -- it’s how it works. We tapped into form and function with a dual
approach that fuses the best of both, stripping down to the nuts and bolts of practical application with sculptures that
make an art of utility. Angular detailing stays low profile for purpose-driven architecture that lives up to its look, from
the intuitive dial face to the subtle highlights that include a red trigger button for activating the chronograph. Each
design in this Oakley timepiece family features surgical grade stainless steel, a locking screw-down crown and a true
sapphire crystal, and every edition is crafted with the uncompromising precision of Swiss Made movement.

4 | DOUBLE TAP INSTRUCTION MANUAL
a b
The timepiece has a locking screw-down crown for water
resistance. You must unscrew the crown before pulling it
out to the click positions that let you set the date and time.
The first click position is for setting the date. The second
click position is for setting the time.
To set the timepiece the first time (or to reset the date
and time after the battery is replaced), do the following:
1. Unscrew the crown from the case. Pull the crown out
to the first click position (a).
2. Turn the crown clockwise until yesterday’s date
appears.
3. Pull the crown out to the second click position (b).
4. Turn the hands clockwise until today’s date appears,
then continue forward until the current time is
reached. If the current time is in the afternoon or
evening, move the hour hand all the way around the
dial to pass 12 o’clock noon.
5. Push the crown back in. Gently turn the crown
clockwise while pushing it inward toward the case,
until it screws back into the case. Be careful not
to over tighten the crown, as this will damage the
mechanism.
To set the exact second, wait until the hand on the
second-counting sub dial (at the right of the main dial
face) reaches “60” before you pull out the crown to
the second click position (b). Set the time then wait
until the exact second is reached before pushing the
crown back in.
SETTING THE DATE AND TIME
Date
Crown
S
W
I
S
S
M
A
D
E

5 | DOUBLE TAP INSTRUCTION MANUAL
TO SET THE TIME
1. Unscrew the crown from the case.
2. Pull the crown out to the second click position (b).
3. Turn the crown until you reach the correct time.
4. Push the crown back in. Gently turn the crown
clockwise while pushing it inward toward the case,
until it screws back into the case. Be careful not
to over tighten the crown, as this will damage the
mechanism.
TO SET THE DATE
1. Unscrew the crown from the case.
2. Pull the crown out to the first click position (a).
3. Turn the crown clockwise until you reach the correct date.
If the current time is between 9 PM and midnight, set
the date to the following day. (This is necessary to
ensure the display will normally change at midnight
instead of 12 noon.)
4. Push the crown back in. Gently turn the crown
clockwise while pushing it inward toward the case,
until it screws back into the case. Be careful not to over
tighten the crown, as this will damage the mechanism.
Setting the date too quickly can result in the incorrect
date being displayed. To restore synchronization, turn
the crown clockwise to go through the range of date
settings (from 01 to 31) when performing the instructions
above.
TO ADJUST THE TIME AND DATE FOR SUBSEQUENT SETTINGS, USE THESE SHORT PROCEDURES

6 | DOUBLE TAP INSTRUCTION MANUAL
USING THE CHRONOGRAPH
The chronograph includes two separate hands:
• The large, narrow hand on the main dial face counts
seconds. One full rotation is 60 seconds.
• The sub dial at the left of the dial face counts minutes.
One full rotation is 30 minutes.
The chronograph is controlled with two push buttons:
• Button “A” starts and stops the timer.
• Button “B” has several functions. It is used to pause
the display at the current split time (also called
“intermediate time”). It is also used to make the
chronograph hands move forward to the ongoing
time being measured. Finally, it is used to reset the
chronograph hands to the zero position.
Before using the chronograph, ensure the crown is
fully screwed in against the case and not at one of the
click positions used for setting time and date. The two
chronograph hands should align precisely at the zero
position. If they do not, see the section on Adjusting the
Chronograph Hands.
Date Button B
Button A
Minute Hand
Second Hand
Chronograph
Second Counter
Crown
Chronograph
Minutes
Counter
Hour Hand
S
W
I
S
S
M
A
D
E

7 | DOUBLE TAP INSTRUCTION MANUAL
TO MEASURE ADDED TIME
Added time (cumulative time) is a measure of how much time
has passed without including pauses. This feature lets you
exclude the time intervals you do not want to measure.
START TIMING
• Press button “A”.
STOP TIMING TEMPORARILY
• Press button “A” to stop timing temporarily.
• Press button “A” again to continue timing.
Continue to use button “A” to add additional time
intervals to the total measure of time. When using
button “A” only, the time that passes while the
chronograph hands are not moving IS NOT ADDED to
the total measure of time. See below if you wish to
include this “split time” in the total measure of time.
RESET
• While timing is stopped, press button “B”.
TO MEASURE SPLIT TIME
Split time (intermediate time) is a measure of the current
time total, taken without stopping the timing circuit. The
hands pause so you can read them, then they catch up to the
ongoing time total.
START TIMING
• Press button “A”.
PAUSE THE HANDS BUT CONTINUE TIMING
• Press button “B” to pause the chronograph hands and
read the current time total.
Although the hands are no longer moving, time is still
being measured.
• Press button “B” again to move the hands to the
currently running time total.
Continue to use button “B” to pause the hands when
desired. Time continues to be measured.
STOP TIMING AND DISPLAY THE FINAL TIME TOTAL
• While the hands are moving, press button “A” to fully
stop timing and display the total time measured.
RESET
• While timing is stopped, press button “B”.
USING THE CHRONOGRAPH - CON’T

8 | DOUBLE TAP INSTRUCTION MANUAL
TO ADJUST THE CHRONOGRAPH HANDS
1. If the chronograph hands currently show a measured
time, use button “B” to reset them near the zero position.
Note that the hands must be stopped before using
button “B” to reset them. If necessary, use button “A”
to stop the hands.
2. Unscrew the crown from the case. Pull the crown out
to the second click position (b).
3. Push button “A” and button “B” simultaneously and
keep them pressed for at least 2 seconds.
4. Adjust the chronograph hands by doing the following:
• Press button “A” to adjust the chronograph hand
that counts seconds. (Press and hold the button for
continuous movement.)
• Press button “B” to finish with that hand and move
on to the other hands.
5. Push the crown back in. Gently turn the crown
clockwise until it screws back into the case. Be
careful not to over tighten the crown, as this will
damage the mechanism.
ADJUSTING THE CHRONOGRAPH HANDS
When the chronograph is reset with button “B,” the two chronograph hands return to the zero position. If these hands
do not align precisely with the zero position (such as after the battery is replaced), use the following procedure to
adjust them.
Date Button B
Button A
Minute Hand
Second Hand
Chronograph
Second Counter
Crown
Chronograph
Minutes
Counter
Hour Hand
S
W
I
S
S
M
A
D
E

9 | DOUBLE TAP INSTRUCTION MANUAL
POWER SAVING MODE
When the timepiece is not in use, the battery life can be prolonged by pulling the crown out to the second click position
(b). This will stop the hands and reduce power consumption.
BATTERY REPLACEMENT
The miniature battery that powers the timepiece is designed to last approximately 48 months. However, because the
battery is inserted at the factory for extensive performance checks, its actual life, once in your possession, may be less.
Battery replacement may be performed only by an Authorized Oakley Service Center. Any attempt to open the watch
case by persons other than Authorized Oakley Service Professionals will void the product warranty.
Within the United States, call Oakley global headquarters at 1-800-403-7449 to find an Authorized Oakley Timepiece
Service Professional near you. Customers outside the United States should contact their local Authorized Oakley
Timepiece Dealer or visit the Oakley website at www.oakley.com for the number of the nearest Oakley distributor.
BAND ADJUSTMENT
Not all Oakley Timepieces are available with a metal bracelet, leather strap or rubber strap; refer to the information below
as it applies to your watch.
METAL BRACELET MODEL
If the links need to be added or removed from the band, the adjustment should be done by an Authorized Oakley Timepiece
Dealer. Do not attempt to shorten the bracelet by removing the links yourself, as this may result in damage.
RUBBER STRAP MODEL
For the right fit, some rubber strap models with deployant clasp closures may require trimming of the rubber strap itself.
An Authorized Oakley Timepiece Dealer should do the adjustment. Do not attempt to shorten the rubber strap
yourself, as this may result in damage.
LEATHER STRAP MODEL
The natural leather of the strap may stretch slightly during break-in, so adjust the fit accordingly.

10 | DOUBLE TAP INSTRUCTION MANUAL
LEATHER CARE
Even the hightest quality leather has a finite lifespan that may be reduced by excess wear and tear, exposure to the natural
acids in perspiration and exposure to the environment. To maximize the longevity of natural leather components in the
leather strap model, avoid direct contact with solvents and other chemicals; avoid prolonged exposure to sunlight; and
avoid soaking the components in water.
CLEANING
Failure to keep the case and band clean may result in a skin rash. Use a soft, clean cloth to wipe off any moisture
that adheres to the case or band.

11 | DOUBLE TAP INSTRUCTION MANUAL
COMPOSITION
CASE BODY..........................................................................................................................Impact-forged stainless steel
CASE BACK............................................................................................................................ Screw-down stainless steel
MANUFACTURING................................................................High-precision Computer Numeric Control (CNC) machining
CRYSTAL...................................................................................................... Sapphire crystal with anti-reflective coating
CROWN................................................................................................................Locking screw-down crown at 3 o’clock
BRACELET................................................................................................................... Stainless steel w/ deployant clasp
BAND...........................................................................................Unobtainium®strap with forged Stainless steel buckle
SPECIFICATIONS
MOVEMENT......................................................................... Swiss Made quartz movement, 10-jewel, metal gold plated
TYPE OF OSCILLATOR ............................................................................................................................Quartz tuning fork
FREQUENCY OF OSCILLATOR.......................................................................................................... 32,768 cycles per sec.
ACCURACY ...................................................................................................................................... -10 /+20 sec. per mo.
THERMAL OPERATING MIN................................................................................................................................0ºC (32ºF)
THERMAL OPERATING MAX........................................................................................................................... 50ºC (122ºF)
WATER RESISTANCE............................................................................................ 10 bars water resistance (100m/330ft)
BATTERY..................................................................................................................... Silver oxide: No. 395 / SR 927 SW
BATTERY ENDURANCE.........................................................................................................................Approx. 54 months

12 | DOUBLE TAP INSTRUCTION MANUAL
SAFEGUARDING
WATER EXPOSURE
Prior to exposing the timepiece to water, ensure the crown is pushed fully down against the case then turn it clockwise
to tighten the water seal. (Be careful not to over tighten the crown, as this will damage the mechanism.) Rated at 10-bar
hydrophobic, the timepiece may be worn during bathing, swimming and shallow diving. It is not designed for scuba or
saturation diving. Do not pull out the crown or use the buttons if the timepiece is wet. If used in seawater, rinse the
timepiece with fresh water and dry completely.
TEMPERATURE
For precision timekeeping, normal operating temperature is 0°C to 50°C (32°F to 122°F).
MAGNETISM
Strong magnetic fields can have an adverse effect on the timepiece. Keep it away from magnetic objects.
CHEMICALS
The timepiece may become discolored or damaged if exposed to cosmetic spray, detergents, adhesives, solvents or paints.
SHOCK WAVE
Although the timepiece resists shock damage, impact against a hard surface may cause damage to the movement or crystal.
PERIODIC MAINTENANCE
To ensure that the case, crown, crystal seal and gasket remain resistant to water exposure, it is recommended that the
timepiece be inspected once every two to three years by an Authorized Oakley Service Center.

13 | DOUBLE TAP INSTRUCTION MANUAL
OAKLEY WARRANTY POLICY
All authentic Oakley timepieces are warranted against manufacturer’s defects for two full years from the date of
purchase. Coverage is valid only with proof of purchase from an Authorized Oakley Timepiece Dealer.
IMPORTANT
This limited warranty does not cover the crystal, strap/band/bracelet, or attachments. The deterioration of leather
components is not covered, nor are scratches to the case caused by use, nor is moisture damage if the timepiece is a
non-hydrophobic model, nor is damage caused by natural disaster such as fire, flood or earthquake. We reserve the right
to relinquish all responsibility under this guarantee for repair of damage when misuse or abuse is evident, including
defects related to tampering or servicing done by agents other than Authorized Oakley Service Facilities. This warranty
does not affect specific legal rights of the consumer.
To qualify for service under the above guarantee, valid proof of purchase — which clearly shows the purchase date
and the name of the Authorized Oakley Timepiece Dealer — must be presented if a repair claim is made during the
warranty period.
HOW TO MAKE A WARRANTY CLAIM
Within the United States, telephone our global headquarters at 1 [phone] with your purchase information.
Customers outside the United States should contact their local Authorized Oakley Timepiece Dealer or visit the Oakley
website at www.oakley.com for the number of the nearest Oakley distributor.
Swiss Movement
Swiss Made

14 | DOUBLE TAP INSTRUCTION MANUAL
HOW TO MAKE A WARRANTY CLAIM
Within the United States, call the Oakley Global Headquarters number listed below. Please have your purchase
information ready.
Customers outside the United States should contact their local Authorized Oakley Timepiece Dealer or use the list
below to call the nearest Oakley headquarters.
Oakley Global Headquarters, USA: 1 [phone]
Oakley Africa: [phone]
Oakley Brasil Ltda.: [phone]
Oakley Canada: [phone]
Oakley Europe: 00 800 62 55 39 38
Oakley Japan: [phone]
Oakley UK: [phone]
Oakley South Pacific (Australia): [phone]
Oakley South Pacific (New Zealand): +0800 NZ OAKLEY (Toll Free) or [phone]

15 | DOUBLE TAP BEDIENUNGSANLEITUNG

16 | DOUBLE TAP BEDIENUNGSANLEITUNG
DOUBLE TAP™
Die mechanische Genialität militärischer Gerätetechnik liefert die Inspiration für Double Tap™, eine Serie von Uhren,
die beweist, dass die wahre Designschönheit nicht bloß im Aussehen, sondern auch in der Funktionsweise liegt. Über
einen dualen Ansatz, der das Beste beider Welten zusammenführt, haben wir Form und Funktion in Einklang gebracht.
Aus den Kernelementen der praktischen Anwendung haben wir Skulpturen geschaffen, die aus Nützlichkeit eine Kunst
machen. Kantige Details wahren ein flaches Profil für eine zweckgebundene Architektur, die ihrem Erscheinungsbild
gerecht wird, vom intuitiven Zifferblatt bis hin zu subtilen Akzenten wie dem roten Auslöseknopf zur Aktivierung des
Chronographen. Jedes Design dieser Oakley Uhrenfamilie zeichnet sich durch Edelstahl chirurgischer Güte, eine fest
schließende Schraubkrone und ein reines Saphirglas aus, und jede einzige Edition bietet die kompromisslose Präzision
eines Swiss Made-Uhrwerks.

17 | DOUBLE TAP BEDIENUNGSANLEITUNG
Die Uhr ist mit einer fest schließenden Schraubkrone
versehen, die eine optimale Wasserfestigkeit
gewährleistet. Sie müssen die Krone aufschrauben,
bevor Sie sie in die Klickpositionen herausziehen können,
mit denen Datum und Uhrzeit eingestellt werden.
Über die erste Klickposition wird das Datum eingestellt.
Über die zweite Klickposition wird die Uhrzeit eingestellt.
Gehen Sie folgendermaßen vor, um die Uhr erstmalig
einzurichten (oder um Datum und Uhrzeit neu
einzustellen, nachdem die Batterie ersetzt wurde):
1. Schrauben Sie die Krone vom Gehäuse ab. Ziehen Sie die
Krone in die erste Klickposition (a).
2. Drehen Sie die Krone im Uhrzeigersinn, bis das gestrige
Datum angezeigt wird.
3. Ziehen Sie die Krone in die zweite Klickposition (b).
4. Drehen Sie die Zeiger im Uhrzeigersinn, bis das heutige
Datum angezeigt wird. Drehen Sie ihn dann weiter
vorwärts, bis die aktuelle Zeit erreicht wurde. Wenn Sie
dies am Nachmittag oder Abend tun, bewegen Sie den
Stundenzeiger einmal um das Zifferblatt herum, an der
Position für 12 Uhr mittags vorbei.
5. Drücken Sie die Krone wieder hinein. Drehen Sie die
Krone sanft im Uhrzeigersinn, und drücken Sie sie dabei
gegen das Gehäuse, bis sie wieder an das Gehäuse
angeschraubt ist. Achten Sie darauf, die Krone nicht
zu stark anzuziehen, da hierdurch der Mechanismus
beschädigt werden kann.
Um die genaue Sekundenzeit einzustellen, warten Sie, bis
der Zeiger des Sekundenzifferblatts (auf der rechten Seite
des Hauptzifferblatts) “60” erreicht hat, bevor Sie die Krone
in die zweite Klickposition (b) herausziehen. Stellen Sie die
Zeit ein, warten Sie dann, bis die genaue Sekunde erreicht
wird, und drücken Sie die Krone dann wieder hinein.
DATUM UND UHRZEIT EINSTELLEN
a b
Datum
Krone
S
W
I
S
S
M
A
D
E

18 | DOUBLE TAP BEDIENUNGSANLEITUNG
EINSTELLUNG DER UHRZEIT
1. Schrauben Sie die Krone vom Gehäuse ab.
2. Ziehen Sie die Krone in die zweite Klickposition (b).
3. Drehen Sie die Krone, bis Sie die richtige Zeit erreicht
haben.
4. Drücken Sie die Krone wieder hinein. Drehen Sie die
Krone sanft im Uhrzeigersinn, und drücken Sie sie dabei
gegen das Gehäuse, bis sie wieder an das Gehäuse
angeschraubt ist. Achten Sie darauf, die Krone nicht
zu stark anzuziehen, da hierdurch der Mechanismus
beschädigt werden kann.
EINSTELLUNG DES DATUMS
1. Schrauben Sie die Krone vom Gehäuse ab.
2. Ziehen Sie die Krone in die erste Klickposition (a).
3. Drehen Sie die Krone im Uhrzeigersinn, bis Sie das
richtige Datum erreicht haben.
Wenn Sie dies zwischen 21:00 Uhr und Mitternacht tun,
richten Sie das Datum auf den folgenden Tag ein. (Dies
ist erforderlich, um sicherzustellen, dass die Anzeige
normal um Mitternacht und nicht mittags umspringt.)
4. Drücken Sie die Krone wieder hinein. Drehen Sie die
Krone sanft im Uhrzeigersinn, und drücken Sie sie dabei
gegen das Gehäuse, bis sie wieder an das Gehäuse
angeschraubt ist. Achten Sie darauf, die Krone nicht
zu stark anzuziehen, da hierdurch der Mechanismus
beschädigt werden kann.
Wird das Datum zu schnell eingestellt, so kann dies
dazu führen, dass das falsche Datum angezeigt wird.
Um die Synchronisierung wiederherzustellen, drehen Sie
bei Befolgung der obigen Anweisungen die Krone im
Uhrzeigersinn, um die Datumseinstellungen (von 01 bis
31) zu durchlaufen.
VERWENDEN SIE DIE NACHFOLGEND BESCHRIEBENEN SCHNELLVERFAHREN, UM DIE UHRZEIT UND
DAS DATUM IN DER ZUKUNFT ANZUPASSEN
