Oase Aquarius Fountain Set Eco 5500 User manual

41764/06-15
Aquarius Fountain Set Eco
5500 /7500 /9500
41764 GAW Aquarius_FountainSet_Eco_A5_end_. 18.06.15 18:12 Seite 2

--
2
A
ARS0014
B
ARS0015

--
3
C
ARS0016
D
ARS0017

--
4
E
ARS0022
F
ARS0018

--
5
G
ARS0019

-EN -
12
-EN -
Translation of the original Operating Instructions
WARNING
•This unit can be used by children aged 8 and above and by per-
sons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they are supervised or have been
instructed on how to use the unit in a safe way and they understand
the hazards involved.
•Do not allow children to play with the unit.
•Only allow children to carry out cleaning and user maintenance un-
der supervision.
•Ensure that the unit is fused for a rated fault current of max. 30 mA
by means of a fault current protection device.
•Only connect the unit if the electrical data of the unit and the power
supply correspond. The unit data is to be found on the unit type plate,
on the packaging or in this manual.
•Possible death or severe injury from electrocution! Before reaching
into the water, always disconnect all units in the water that have a
voltage of >12 V AC or >30 V DC from the power supply.
•Only operate the unit if no persons are in the water.
•Do not use the unit if electrical cables or housings are damaged.
•A damaged connection cable cannot be replaced. Dispose of the
unit.

-EN -
13
Safety information
Correct electrical installation
•Electrical installations must meet the national regulations and may only be carried out by a qualified electrician.
•A person is regarded as a qualified electrician if, due to his/her vocational education, knowledge and experience, he
or she is capable of and authorised to judge and carry out the work commissioned to him/her. This also includes the
recognition of possible hazards and the adherence to the pertinent regional and national standards, rules and regula-
tions.
•For your own safety, please consult a qualified electrician.
•Extension cables and power distributors (e.g. outlet strips) must be suitable for outdoor use (splash-proof).
•Protect the plug connection from moisture.
•Only connect the unit to a correctly fitted socket.
Safe operation
•Never carry or pull the unit by the electrical cable.
•Route cables such that they are protected from damage and do not present a tripping hazard.
•Never carry out technical changes to the unit.
•Only carry out work on the unit that is described in this manual. If problems cannot be overcome, please contact an
authorised customer service point or, if in doubt, the manufacturer.
•Only use original spare parts and accessories for the unit.
•The impeller unit in the pump contains a magnet with a strong magnetic field that may affect the operation of pace-
makers or implantable cardioverter defibrillators (ICDs). Always keep magnets at least 0.2 m away from implanted
devices.
Information about this operating manual
Welcome to OASE Living Water. You made a good choice with the purchase of this product Aquarius Fountain Set
Eco 5500/7500/9500.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself with the unit.
Ensure that all work on and with this unit is only carried out in accordance with these instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on to a new
owner.
Symbols used in these instructions
Warnings
The warning information is categorised by signal words, which indicate the extent of the hazard.
WARNING
•Indicates a possibly hazardous situation.
•Non-observance may lead to death or serious injuries.
CAUTION
•Indicates a possibly hazardous situation.
•Non-observance may lead to slight or minor injuries.
NOTE
Information for the purpose of clarification or for preventing possible damage to assets or to the environment.
Additional information
A Reference to a figure, e.g. Fig. A.
→Reference to another section.

-EN -
14
Scope of delivery
A
Aquarius Fountain Set Eco 5500/7500/9500
1
Fountain pump
2
Telescopic extension
3
Nozzles
4
Transition piece with fine filter screen
5
Flow regulator, ball joint with union nut, transition piece, sleeve, double nipple
6
Stepped hose adapter
Product Description
Aquarius Fountain Set Eco 5500/7500/9500 is a fountain pump for garden ponds, ornamental fountains and water
courses.
•Temperature protection by integrated temperature monitor.
•Pivoting telescopic extension with various nozzles.
•Second, separately adjustable outlet.
Intended use
Aquarius Fountain Set Eco 5500/7500/9500, referred to as "unit", may only be used as specified in the following:
•For pumping normal pond water for water features and fountains.
•Operate in accordance with instructions.
•Operation under observance of the permissible water quality. (→Water quality)
The following restrictions apply to the unit:
•Do not use in swimming ponds.
•Never use the unit to convey fluids other than water.
•Never run the unit without water.
•Do not use for commercial or industrial purposes.
•Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
•Do not connect to the domestic water supply.
Installation and connection
Reassembling the unit
How to proceed:
C
1. Fit the sleeve, flow regulator, double nipple, union nut, ball joint and transition piece together and screw onto the
pump outlet.
2. Screw the telescopic extension with the desired nozzle onto the flow regulator.
3. Screw the stepped hose adapter onto the flow regulator for feeding a water course if applicable.
4. Align the telescopic extension and hand tighten the union nut on the ball joint.

-EN -
15
Set-up the unit
B
WARNING
Death or serious injuries from hazardous electrical voltage due to operation of this unit in a swimming pond.
•Never operate this unit in a swimming pond.
NOTE
If the pump is used for conveying excessively soiled water, the impeller unit will be subject to increased wear
and will require earlier replacement.
Remedy:
•Thoroughly clean the pond or pool before installing the pump.
•Install the pump approx. 200 mm above the floor of the pond to avoid excessively soiled water from being
drawn into the pump.
•Install the unit in the pond in a horizontal position on firm, sludge-free ground and ensure that it is completely covered
with water.
Commissioning/start-up
CAUTION
Risk of injury due to fast rotating components.
A temperature monitor switches the unit off automatically in the event of overload and on again once it has
cooled down.
•Isolate the unit before starting any work.
NOTE
Sensitive electrical components. Incorrect connection will destroy the unit.
•Do not connect the unit to a dimmable power supply.
This is how to connect the power supply:
Switching on: Connect the unit to the mains. The unit switches on immediately.
Switching off: Disconnect the unit from the mains.
Environmental Function Control (EFC)
When started up, the pump automatically performs a pre-programmed self-test of approx. two minutes length (Envi-
ronmental Function Control (EFC)). The pump detects if it is running dry / blocked or submerged. The pump
switches off automatically after approx. 90 seconds if it runs dry (is blocked). In the event of a malfunction, disconnect
the power supply and flood the pump or remove the obstacle. Following this, the unit can be restarted.
Adjustments
D, E
Setting the spray pattern and flow rate:
•Adjust the flow regulator so that the nozzle produces the desired spray pattern.
•Adjust the flow regulator to achieve the desired flow rate for the water course.

-EN -
16
Remedy of faults
Malfunction
Cause
Remedy
Pump does not start
No mains voltage
•Check the mains voltage.
•Check supply lines.
Pump does not deliver.
Filter housing clogged
Clean strainer casings
Excessively soiled water
Clean the pump. The pump automatically
switches on again once the motor has cooled
down.
The impeller unit is blocked
Disconnect the power supply and remove ob-
stacle. Then switch the pump on again.
Fountain height insufficient or inconsistent
Filter/screen soiled or clogged
Clean filter/screen
Main flow regulator closed too far
Adjust main flow regulator
Nozzle blocked
Clean nozzle/screen
Impeller unit soiled
Clean
Hose clogged or defective
Clean/replace hose
Hose kinked
Check hose and replace if necessary
Excessive loss due to friction in the hose
Reduce hose length to reduce frictional loss
Rotor worn
Replace rotor
Pump switches off after a short running period.
Excessively soiled water
Clean the pump. The pump automatically
switches on again once the motor has cooled
down.
Water temperature too high
Note maximum water temperature of +35°C.
The pump automatically switches on again
once the motor has cooled down.
The impeller unit is blocked
Disconnect the power supply and remove ob-
stacle. Then switch the pump on again.
Pump has run dry.
Disconnect the power plug and flood the pump.
Fully submerge the pump for operation in the
pond. Then switch the pump on again.
Maintenance and cleaning
WARNING
Possible death or severe injury from hazardous electrical voltage!
•Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
•Isolate the device (disconnect from the power supply) before carrying out any work on it.
Cleaning the unit
NOTE
Recommendation regarding cleaning:
•Clean the unit as required but at least twice a year.
•When cleaning the pump, pay particular attention to the cleaning of the impeller unit and pump housing.
•Do not use aggressive cleaning agents or chemical solutions as they could attack the housing or impair the function
of the unit.
•Recommended cleaning agent for removing stubborn limescale deposits:
– Pump cleaning agent PumpClean from OASE.
– Vinegar- and chlorine-free household cleaning agent.
•After cleaning, thoroughly rinse all parts in clean water.

-EN -
17
Cleaning the pump
How to proceed:
F
1. Unscrew the transition piece.
2. Remove the two screws and open the filter housing.
3. Take out the pump.
4. Remove the screws of the pump casing and pull off the pump casing.
5. Pull out the impeller unit (magnetic resistance).
6. Clean all parts.
Reassembling the unit
How to proceed:
G
1. Place the pump into the strainer casing.
2. Route the connection cable through the cable opening in the filter housing.
3. Replace the filter cover, turn in the two screws and hand tighten.
4. Screw on the transition piece together with the flat seal.
Storage/overwintering
The unit is not frost-proof and has to be removed and put into storage if minus temperatures are expected.
How to correctly store the unit:
•Thoroughly clean the unit, check it for damage and replace any damaged parts.
•Store the pump submerged and in a frost-free environment.
•Protect open plug connections from moisture and dirt.
Wear parts
•Impeller unit
Spare parts
The use of original parts from OASE ensures continued
safe and reliable operation of the unit.
Please visit our website for spare parts drawings and spare
parts.
www.oase-livingwater.com/spareparts
Disposal
NOTE
Do not dispose of this unit with domestic waste.
•Render the unit unusable beforehand by cutting the cables and dispose of the unit via the return system
provided for this purpose.

138
DE
Typ
Anschlussspannung
Leistungsaufnahme
Förderleistung
Wassersäule
Anschlüsse
Kabellänge
Abmessungen
Gewicht
EN
Type
Mains voltage
Power consumption
Max. flow rate
Max. head height
Connections
Cable length
Dimensions
Weight
FR
Type
Tension de raccordement
Puissance absorbée
Capacité de refoulement
Colonne d'eau
Raccordements
Longueur de câble
Dimensions
Poids
NL
Type
Aansluitspanning
Vermogensopname
Pompcapaciteit
Waterkolom
Aansluitingen
Kabellengte
Afmetingen
Gewicht
ES
Tipo
Tensión de conexión
Consumo de potencia
Capacidad de elevación
Columna de agua
Conexiones
Longitud del cable
Dimensiones
Peso
PT
Tipo
Tensão de conexão
Potência absorvida
Débito
Coluna de água
Conexões
Comprimento do cabo
Dimensões
Peso
IT
Tipo
Tensione di attacco
Potenza assorbita
Portata
Colonna d'acqua
Allacciamenti
Lunghezza cavo
Dimensioni
Peso
DA
Type
Tilslutningsspænding
Effektforbrug
Pumpekapacitet
Vandsøjle
Tilslutninger
Ledningslængde
Dimensioner
Vægt
NO
Type
Nettspenning
Effektopptak
Kapasitet
Vannsøyle
Tilkoblinger
Kabellengde
Mål
Vekt
SV
Typ
Anslutningsspänning
Effekt
Matningsprestanda
Vattenpelare
Anslutningar
Kabellängd
Mått
Vikt
FI
Tyyppi
Verkkojännite
Tehonotto
Pumpun teho
Vesipatsas
Liitännät
Kaapelin pituus
Mitat
Paino
HU
Típus
Csatlakoztatási feszültség
Teljesítményfelvétel
Szállítási teljesítmény
Vízoszlop
Csatlakozók
Kábelhossz
Méretek
Súly
PL
Typ
Napięcie przyłączeniowe
Pobór mocy
Wydajność pompowania
Słup wody
Przyłącza
Długość kabla
Wymiary
Ciężar
CS
Typ
Připojovací napětí
Příkon
Dopravní výkon
Vodní sloupec
Přípojky
Délka kabelu
Rozměry
Hmotnost
SK
Typ
Napájacie napätie
Príkon
Dopravný výkon
Vodný stĺpec
Prípojky
Dĺžka kábla
Rozmery
Hmotnost’
SL
Tip
Priključna napetost
Poraba moči
Črpalna zmogljivost
Vodni steber
Priključki
Dolžina kabla
Dimenzije
Teža
HR
Tip
Priključni napon
Potrošnja energije
Protočni kapacitet
Vodeni stup
Priključci
Duljina kabela
Dimenzije
Težina
RO
Tip
Tensiune de conexiune
Putere consumată
Debit de pompare
Coloană de apă
Conexiuni
Lungime cablu
Dimensiuni
Greutate
BG
Тип
Напрежение в точката на
свързване
Потребявана мощност
Дебит
Воден стълб
връзки/изходи
Дължина на кабелите
Размери
Тегло
UK
Тип
Напруга мережі живлення
Споживання
електроенергії
Продуктивність
Водяний стовп
Підключення
Довжина кабелю
Розміри
Вага
RU
Тип
Напряжение питающей сети
Потребление мощности
Производительность
Водяной столб
Соединения
Длина кабеля
Размеры
Вес
CN
型号
输入电压
耗用功率
输送能力
水柱
接头
电缆长度
尺寸
重量
Aquarius
Fountain
Set Eco
5500
220 … 240 V AC, 50/60 Hz
70 W
≤5500 l/h
≤3.8 m
38 mm
(1½'') 10 m 290 × 230 × 180 mm
5.1 kg
7500
85 W
≤7500 l/h
≤4 m
5.3 kg
9500
125 W
≤9500 l/h
≤5.2 m
5.8 kg

139
DE
Staubdicht. Wasserdicht bis 2 m Tiefe
Bei Frost das Gerät deinstallieren
Mögliche Gefahren für Personen mit
Herzschrittmachern!
Nicht mit normalem Hausmüll entsor-
gen!
Achtung!
Lesen Sie die Gebrauchsanleitung
EN
Dust tight. Submersible to 2 m depth.
Remove the unit at temperatures below
zero (centigrade).
Possible hazard for persons wearing
pace makers!
Do not dispose of together with house-
hold waste!
Attention!
Read the operating instructions
FR
Imperméable aux poussières. Etanche
à l'eau jusqu'à une profondeur de 2 m
Retirer l’appareil en cas de gel
Dangers possibles pour des personnes
ayant des stimulateurs cardiaques !
Ne pas recycler dans les ordures mé-
nagères !
Attention !
Lire la notice d'emploi
NL
Stofdicht. Waterdicht tot een diepte van
2 m
Bij vorst het apparaat deïnstalleren
Mogelijke gevaren voor mensen met
een pacemaker!
Niet bij het normale huisvuil doen!
Let op!
Lees de gebruiksaanwijzing
ES
A prueba de polvo. Impermeable al
agua hasta 2 m de profundidad
Desinstale el equipo en caso de hela-
das
Posibles peligros para las personas
con marcapasos.
¡No deseche el equipo en la basura do-
méstica!
¡Atención!
Lea las instrucciones de uso
PT
À prova de pó. À prova de água até 2
m de profundidade.
Em caso de geada, desinstalar o apa-
relho
Eventuais perigos para pessoas com
pace-makers!
Não deitar ao lixo doméstico!
Atenção!
Leia as instruções de utilização
IT
A tenuta di polvere. Impermeabile
all'acqua fino a 2 m di profondità.
In caso di gelo disinstalllare l'apparec-
chio
Possibili pericoli per persone con pace-
maker!
Non smaltire con normali rifiuti dome-
stici!
Attenzione!
Leggete le istruzioni d'uso!
DA
Støvtæt. Vandtæt ned til 2 m dybde
Afmonter apparatet ved frostvejr
Mulig fare for personer med pacemaker
Må ikke bortskaffes med det alminde-
lige husholdningsaffald
OBS!
Læs brugsanvisningen
NO
Støvtett. Vanntett ned til 2 m dyp
Ved frost, demonter apparatet
Kan være farlig for personer med pace-
maker!
Ikke kast i alminnelig
husholdningsavfall!
NB!
Les bruksanvisningen
SV
Dammtät. Vattentät till 2 m djup
Demontera apparaten innan första fros-
ten.
Möjlig risk för personer med pacema-
ker!
Får inte kastas i hushållssoporna!
Varning!
Läs igenom bruksanvisningen
FI
Pölytiivis. Vesitiivis 2 m syvyyteen asti.
Laite purettava ennen pakkasia
Mahdollinen vaara sydämentahdistinta
käyttäville henkilöille!
Älä hävitä laitetta tavallisen talousjät-
teen kanssa!
Huomio!
Lue käyttöohje
HU
Portömített. Vízálló 2 m-es mélységig
Fagy esetén a készüléket szerelje le
A készülék veszélyes lehet szívritmus-
szabályozóval rendelkező személyekre!
A készüléket nem a normál háztartási
szeméttel együtt kell megsemmisíteni!
Figyelem!
Olvassa el a használati útmutatót
PL
Pyłoszczelny. Wodoszczelny do 2 m
głębokości.
W razie mrozu zdeinstalować urządze-
nie
Możliwość wystąpienia zagrożeń dla
osób ze stymulatorami
Nie wyrzucać wraz ze śmieciami domo-
wymi!
Uwaga!
Przeczytać instrukcję użytkowania!
CS
Prachotěsný. Vodotěsný do hloubky 2
m
Při mrazu přístroj odinstalovat
Možná nebezpečí pro osoby s kardio-
stimulátory!
Nelikvidovat v normálním komunálním
odpadu!
Pozor!
Přečtěte Návod k použití!
SK
Prachotesný. Vodotesný do hĺbky 2 m
Pri mraze prístroj odinštalovať
Možné nebezpečenstvo pre osoby
s kardiostimulátormi!
Nelikvidovať v normálnom komunálnom
odpade!
Pozor!
Prečítajte si Návod na použitie
SL
Ne prepušča prahu. Vodotesno do glo-
bine 2 m.
Ob zmrzali demontirajte napravo.
Obstaja nevarnost za ljudi s srčnim
spodbujevalnikom!
Ne zavrzite skupaj z gospodinjskimi od-
padki!
Pozor!
Preberite navodila za uporabo!
HR
Ne propušta prašinu. Ne propušta vodu
do 2 m dubine.
U slučaju mraza deinstalirajte uređaj.
Moguće opasnosti za nositelje elektro-
stimulatora!
Nemojte ga bacati u običan kućni ot-
pad!
Pažnja!
Pročitajte upute za upotrebu!
RO
Etanş la praf. Etanş la apă până la o
adâncime de 2 m.
Dezinstalaţi aparatul pe timp de îngheţ
Posibile pericole pentru persoane cu
by-pass cardiac !
Nu aruncaţi în gunoiul menajer !
Atenţie !
Citiţi instrucţiunile de utilizare !
BG
Защитено от прах. Водоустойчив до
дълбочина 2 м
При ниски температури и опасност от
замръзване деинсталирайте уреда
Възможен риск за хора с пейс-
мейкъри!
Не изхвърляйте заедно с обикнове-
ния домакински боклук!
Внимание!
Прочетете упътването
UK
Пилонепроникний. Водонепроникний
до 2 м
Перед морозами пристрій необхідно
демонтувати
Небезпека для осіб з кардіостимуля-
тором
Не викидайте разом із побутовим
сміттям!
Увага!
Читайте інструкцію.
RU
Пыленепроницаемый, водонепрони-
цаемый на глубине до 2 м
При наступлении морозов прибор де-
монтировать
Возможная опасность для лиц с кар-
диостимулятором!
Не утилизировать вместе с домаш-
ним мусором!
Внимание!
Прочитайте инструкцию по использо-
ванию
CN
防尘。防水水深至
2
米 霜冻时拆卸设备 可能对带有心脏起搏器人员有危险
!
不要同普通的家庭垃圾一起丢弃
!
注意
!
请阅读使用说明书。

140
DE
Empfohlene Wasserwerte
pH-Wert
Gesamthärte
Temperatur
EN
Recommended water quality
pH value
Total hardness
Temperature
FR
Valeurs d'eau recommandées
Valeur pH
Dureté totale
Température
NL
Aanbevolen waterwaarden
Valor pH
Totale hardheid
Temperatura
ES
Valores recomendados del agua
Valor pH
Dureza total
Temperatura
PT
Valores recomendados para a água
Valor pH
Dureza total
Temperatura
IT
Valori dell'acqua consigliati
Valore pH
Durezza totale
Temperatura
DA
Anbefalede vandværdier
pH-værdi
Samlet hårdhed
Temperatur
NO
Anbefalte vannverdier
pH-verdi
Samlet hardhet
Temperatur
SV
Rekommenderade vattenvärden
pH-värde
Total hårdhet
Temperatur
FI
Suositellut vesiarvot
pH-arvo
Kokonaiskovuus
Lämpötila
HU
A vízre vonatkozó ajánlott értékek
pH-érték
Teljes keménység
Hőmérséklet
PL
Zalecane parametry wody
Wartość pH
Twardość ogólna
Temperatura
CS
Doporučené hodnoty vody
Hodnota pH
Celková tvrdost
Teplota
SK
Odporúčané hodnoty vody
Hodnota pH
Celková tvrdosť
Teplota
SL
Priporočene vrednosti za vodo
pH vrednost
Skupna trdota vode
Temperatura
HR
Preporučene vrijednosti vode
pH vrijednost
Ukupna tvrdoća
Temperatura
RO
Valori recomandate pentru apă
Valoare pH
Duritate totală
Temperatură
BG
Препоръчани стойности на водата
pH-стойност
Обща твърдост
Температура
UK
Рекомендований вміст води
pH-показник
Загальна жорсткість (води)
Температура
RU
Рекомендуемые значения воды
Значение pH
Общая жесткость воды
Температура
CN
建议水当量值
pH 值
总硬度
温度
6.8 …7.6
8 …15 °dH
4…35 °C
