Ocean Matrix OMX-HDMI-2-IPV2 User manual

OMX-HDMI-2-IPV2
4K Multipoint to Multipoint Extender
Over IP Single CAT5/5e/6
INSTALLATION & SPECIFICATIONS
Rev1a
Ocean Matrix
812 Kings Highway •SaugerƟes, NY 12477
www.oceanmatrix.com
Includes:
 One Transmitter
 One Receiver
 Two 5VDC/2A Power Adapters
 One IR Receiver Cable, connects to transmitter
 One IR Blaster Extension Cable, connects to receiver
 Remote Control
 Four Mounting Ears

2
Ocean Matrix
www.oceanmatrix.com
Ocean Matrix OMX-HDMI-2-IPV2 Installation
SPECIFICATIONS
Signal HDMI 1.3, Compliant to HDCP
Resolutions 480p@60Hz, 576p@50Hz, 720p@60Hz, 1080p@60Hz
Audio Format PCM
HDMI Transmission Distance Cat5 263 Ft, Cat5E 328 Ft, Cat6 394 Ft
Network Bandwidth 18Mbps
IR Passback Supports 20-60KHz IR devices
Input Voltage 5VDC@2A
Power Consumption 4W each unit
Dimensions (LxWxH) 5.27x3.30x0.94 in/ 133.8x83.8x23.8 mm
Weight TX 9.17 oz / RX 8.81 oz
1 RX ID (non-functioning)
2 IR: Remote Control
3 Power Indicator
4 RX Channel Display
5 Reset Button
6 5VDC Power Input
7 Data Transmission Indicator
8 RJ45 Signal Input
9 Connection Indicator
10 IR Receiver Extension Port
11 HDMI Signal Output
1 IR: Remote Control
2 Power Indicator
3 TX Channel Display
4 Reset Button
5 5VDC Power Input
6 Data Transmission Indicator
7 RJ45 Signal Output
8 Connection Indicator
9 IR Blaster Extension Port
10 HDMI Signal Input
TRANSMITTER
7 8 9 106 11
7 8 9 1065
41 2 3
RECEIVER
4 51 2 3

3
INSTALLATION REQUIREMENTS
1. HDMI Sources with HDMI Output
2. Displays with HDMI Input
3. Cable: UTP/STP CAT5/5e/6 compliant to IEEE-568B Standard
4. IGMP Ethernet Switch and/or Wireless Router
Ocean Matrix OMX-HDMI-2-IPV2 Installation
INSTALLATION
1. Connect the HMDI video source to the splitter HDMI IN port
2. Connect the HDMI displays to the splitter HDMI out ports
3. Connect the power supply and plug into the power source
IR USER GUIDE
1. Plug the IR blaster extension cable into the IR-OUT port on the Transmitter.
2. Plug the IR receiver extension cable into the IR-IN port on the Receiver.
3. Place the IR blaster emitter as close as possible to the IR receiver of the signal source device.
4. Use the remote control to select and set the channel.
Ocean Matrix
www.oceanmatrix.com
INSTALLATION DIAGRAMS
Multipoint Configuration
RX
HDMI Source
RX
TX
TX
HDMI Display
IGMP
Switch
HDMI Display
Cat5/5E/6
HDMI Source
Point to Point Configuration
RX
TX HDMI Display
Cat5/5E/6
HDMI Source

4
Ocean Matrix
www.oceanmatrix.com
Ocean Matrix OMX-HDMI-2-IPV2 Installation
SETTING CHANNELS MANUALLY
To manually set the channel of the transmitter and the receiver, use the buttons on either side of each display.
TRANSMITTER
RECEIVER
Press a button to set the value from 0 to 9. A button to the left of the number changes that value and the button
to the right of a number changes that value. Each value is set separately. Each display can be set from 00 to 99.
To connect a transmitter and a receiver, set the TX Connected on the receiver to the same value displayed on the
TX ID screen on the transmitter.
NOTES:
1. The RX-ID feature on the receiver does not function in order to increase network performance and reliability
and to enable the ability to set 99 channel sources from independent transmitter units with virtually an
unlimited quantity of receivers.
2. Limiting factors of network bandwidth and infrastructure may impact total quantity of sources and destinations.
3. There will be no firmware updates to reinstate the RX ID functionality.

5
Ocean Matrix
www.oceanmatrix.com
Ocean Matrix OMX-HDMI-2-IPV2 Installation
SETTING CHANNELS IN REMOTE LOCATIONS
USER CONTROL GUIDE APP: MATRIX CONTROL LITE
1. Download the Matrix Control Lite App from Google Play or the App Store.
-Android: Google Play
-iOS: App Store
2. Connect a mobile phone to a wireless router. If your router does not have
an ethernet switch, connect the router to an IGMP ethernet switch.
4. Touch Name for either the Tx Device or Rx Device. Use the keyboard to name the device and touch ‘ok’.
3. Open the Matrix Control Lite App. Touch ‘scan’.
5. To select a channel number, touch Channel for either the Tx Device or Rx Device. Choose the appropriate number.
6. Device names and channels are set.

6
SAFETY PRECAUTIONS
 To prevent fire or shock hazard, do not expose this equipment to dust or high humidity. Do not use in an
unprotected outdoor installation or in areas classified as overly damp or wet.
 The installation temperature should be kept between 32°F to 140°F (0°C to 60°C). Avoid direct sunlight exposure or extreme
changes of temperature over a short period of time.
 Do not place the unit on an unstable base and avoid heavy impact.
 Proper ventilation is required for permanent installation. Do not block or cover enclosure openings as they protect the unit
from overheating.
 Prior to cleaning, turn the power off and unplug the unit from all connections. Use a damp cloth. Do not use liquid or aerosol
cleaners.
 Do not overload outlets and extension cords as this may result in a risk of fire or electric shock.
 Enclosure entry is dangerous. Never push objects of any kind, including liquids, through openings as they may touch danger-
ous voltage points or short-out parts that could result in a fire or electric shock.
 Do not open or service this unit yourself as opening or removing covers may expose you to dangerous voltage and other haz-
ards.
 There are no user-serviceable parts inside the unit. If the unit requires service contact your authorized dealer, or authorized
repair service company.
TROUBLESHOOTING
Display Message: “Waiting for Connection”
 Ensure that the power supply is firmly connected. Only use the 5VDC power adapter included.
 Confirm that all cables are securely connected.
 Determine that the receiver’s channel number is within the transmitter’s channel list.
 Check that all of the transmitter’s channels are different.
 Confirm resolution of source device.
Display Message: “Please Check the Transmitter Input Signal”
 Confirm that the input signal to the transmitter is HDMI.
 Connect the HDMI source directly to the display device to ensure there is a signal output.
 Change the signal source if necessary.
 Use only high-quality HDMI 1.4 and HDMI 2.0 cable for 4K×2K UHD transmission.
Display is Not Stable
 Confirm that you are using an IGMP switch.
No image on Displays
 Disconnect the source device. If “Please Check the Transmitter Input Signal” Message appears after 10 seconds on the
display, reconnect the source, and change to another resolution.
 If no message appears, then change source device.
Rev1a
