WARNING
The following safety information is provided as a guideline to help you operate your Transmission Jack under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe
handling instructions are not known or not followed. The following safety instructions are to provide the user with the
information necessary for safe use and operation. Please read and retain these instructions for the continued safe use
of your Transmission Jack. Failure to follow instructions listed below may result in serious injury. In addition, make sure
that anyone who uses the equipment understands and follows these safety instructions as well.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
Thank you very much for choosing an OEMTOOLS®Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this
product before you begin using it. This product is designed for certain applications only. OEMTOOLS®cannot be responsible
for issues arising from modification. We strongly recommend that this product is not modified and/or used for any application
other than that for which it was designed. If you have any questions relative to a particular application, DO NOT use the
product until you have first contacted customer service to determine if it can or should be performed on the product.
WARNING:Pursuant to California Proposition 65, this product contains chemicals known to the state of California to
cause cancer and birth defects or other reproductive harm. Wash hands after handling.
Operating Instructions and Parts Manual 24790
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself
and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in
personal injury and/or damage to product or property. Please retain instructions for future reference.
1
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
UNPACKING
After unpacking unit, inspect carefully for any damage
that may have occurred during transit. Check for loose,
missing, or damaged parts. If any damage is observed,
a shipping damage claim must be filed with carrier. DO
NOT use the OEMTOOLS
®
1,100 Lb. 2 Stage Telescoping
Transmission Jack if broken, bent, cracked or damaged
parts (including labels) are noted. Any Transmission Jack
that appears damaged in any way, operates abnormally or is
missing parts should be removed from service immediately.
If you suspect that the Transmission Jack was subjected
to a shock load (a load that was dropped suddenly,
unexpectedly, etc.), immediately discontinue use until it has
been checked by a factory authorized service center.
Open the Air Vent Valve on the side of the Jack Cylinder by
turning 2 full turns counterclockwise before using.

2
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn the
tool’s applications and limitations, as well as potential
hazards specific to it.
2. Maintain labels and nameplates on this product. These
carry important information. If unreadable or missing,
contact OEMTOOLS®for a replacement.
3. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
4. Keep children away. All children should be kept away
from the work area. Never let a child handle a tool
without strict adult supervision.
5. DO NOT operate this tool if under the influence of
alcohol or drugs. Read warning labels on prescriptions
to determine if your judgment or reflexes are impaired
while taking drugs. If there is any doubt, DO NOT
attempt to operate.
6. Use safety equipment. Eye protection should be
worn at all times when operating this tool. Use ANSI
approved safety glasses. Everyday eyeglasses are NOT
safety glasses. Dust mask, non-skid safety shoes, hard
hat or hearing protection should be used in appropriate
conditions.
7. Wear proper apparel. Loose clothing, gloves, neck-ties,
rings, bracelets or other jewelry may present a potential
hazard when operating this tool. Keep all apparel clear
of the tool.
8. DO NOT overreach. Keep proper footing and balance
at all times when operating this tool.
9. Check for damage. Check your tool regularly. If part of
the tool is damaged, it should be carefully inspected
to make sure that it can perform its intended function
correctly. If in doubt, the part should be repaired. Refer
all servicing to a qualified technician. Consult your
dealer for advice.
10. Keep away from flammables. DO NOT attempt
to operate this tool near flammable materials or
combustibles. Failure to comply may cause serious
injury or death.
11. Store idle tools out of the reach of children and
untrained persons. Tools may be dangerous in the
hands of untrained users.
12. Maintain tools with care.
13. Keep tools dry and clean.
14. Properly maintained tools are less likely to bind and
are easier to control. DO NOT use a damaged tool. Tag
damaged tools “DO NOT USE” until repaired.
15. Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the tool’s operation.
16. If damaged, have the tool serviced before using. Many
accidents are caused by poorly maintained tools.
17. Use only accessories that are recommended by the
manufacturer for your model. Accessories that may
be suitable for one tool may become hazardous when
used on another tool.
18. Tool service must be performed only by qualified repair
personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
19. When servicing a tool, use only identical replacement
parts. Use of unauthorized parts or failure to follow
maintenance instructions may create a risk of injury.
20. Maintain a safe working environment. Keep the work
area well lit. Make sure there is adequate surrounding
workspace. Keep the work area free of obstructions,
grease, oil, trash, and other debris. DO NOT use this
product in a damp or wet location.
21. Keep the handle dry, clean, and free from brake fluid,
oil, and grease.
22. Before use, read and understand all warnings, safety
precautions, and instructions as outlined in the vehicle
manufacturer’s service manual. It is beyond the
scope of this manual to properly describe the correct
procedure and test data for each vehicle.
23. Always perform vehicle service in a properly ventilated
area. Never run an engine without proper ventilation
for its exhaust. Stop work and take necessary steps
to improve ventilation in the work area if you develop
momentary eye, nose, or throat irritation as this
indicates inadequate ventilation.
24. Engine parts that are in motion and unexpected
movement of a vehicle can injure or kill. When working
near moving engine parts, wear snug fit clothing and
keep hands and fingers away from moving parts. Keep
hoses and tools clear of moving parts. Always stay
clear of moving engine parts. Hoses and tools can
be thrown through the air if not kept clear of moving
engine parts.
25. The unexpected movement of a vehicle can injure or
kill. When working on vehicles, always set the parking
brake or block the wheels.
26. Avoid accidental fire and/or explosion. DO NOT smoke
near engine fuel and battery components.
27. The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are factors
which cannot be built into this product, but must be
supplied by the operator.
28. For safety purposes and the prevention of damage to
expensive components, it is advised that the user have
an understanding of basic automotive repair and a
working knowledge of automotive systems.
29. We believe the information contained herein to be
reliable. However, general technical information is given
by us without charge and the user shall employ such
information at their own discretion and risk. We assume
no responsibility for results or damages incurred from
the use of such information in whole or in part. Always
refer to specific instructions and technical information
supplied by vehicle manufacturer.
30. The manufacturer declines any and all responsibility
for damage to vehicles or components if said damage
is the result of unskillful handling by the operator or of
failure to observe the basic safety rules set forth in the
instruction manual.

3
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
31. This equipment is intended only for professional use by
personnel trained in performing the service functions
for which it is designed.
32. This equipment is designed for servicing a variety
of vehicles in a safe, convenient manner. However,
differences in vehicle makes and models may make it
impossible to use this equipment as it is intended. DO
NOT attempt to force the use of this equipment on an
application for which it is not designed to perform.
33. The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
34. In addition to these guidelines, always follow the
manufacturer’s recommended procedures when
servicing each unique vehicle.
35. The use of this equipment is simple and straightforward
if you follow the instructions. When operating this
equipment, use common sense, and always stop to
think before using a Transmission Jack or lifting a
vehicle.
PRODUCT DESCRIPTION
The 1,100 Lb. 2 Stage Telescoping Transmission Jack
is designed to be used as an aid in the removal and
installation of automotive and light truck transmissions,
transfer cases and transaxles. This telescopic style
Transmission Jack is for use under an overhead lift or in a
garage pit.
PRODUCT SPECIFICATIONS
Weight Capacity 1,100 Lb.
Lift Range 37" - 76.4"
SPECIFIC SAFETY INSTRUCTIONS
AND WARNINGS
WARNING: NEVER use for any purpose other than
those uses outlined above!
1. Verify that the product and application are compatible;
if in doubt, call OEMTOOLS®at 1-866-458-2472.
2. Before using this product, read the operator’s manual
completely and familiarize yourself thoroughly with
the product and its components, and recognize the
hazards associated with its use.
3. Wear appropriate safety gear (including heavy duty
work gloves and ANSI-approved safety goggles) during
use.
4. Ensure the Transmission Jack rolls freely. Raise and
lower the unloaded Transmission Jack throughout the
lifting range before putting into service to ensure the
pump operates smoothly. Replace worn or damaged
parts.
5. DO NOT exceed the weight capacity of the
Transmission Jack. Make sure weight is evenly
distributed. Be aware of dynamic loading! Sudden load
movement may briefly create excess load causing
product failure. Exceeding the maximum capacity for
this product is dangerous and can lead to serious injury
or property damage.
6. Never use this device as a work/repair station. Transfer
the load immediately to a suitable work station.
7. Always evaluate your task before using this product.
This Transmission Jack is designed to support a
transmission or a differential as individual components.
Use only as intended.
8. Assemblies such as differential with axle, or
transmission with bell housing, can be bulky and
difficult to balance. Lifting or supporting such
assemblies, even within weight limit, can create an
off-balance situation, causing the Transmission Jack
to tip over and MAY lead to serious personal injury or
property damage.
9. The load should be evenly distributed on the
Transmission Jack, and should not extend beyond the
area of the caster wheelbase. Always use the chains
provided to secure the load. If extra support is required,
safety straps (not included) can also be used to secure
the work piece.
10. Use only a hard, level and flat surface capable of
bearing the combined weight of the Transmission Jack,
the load being lifted, the operator and any tools being
used.
11. If loaded Transmission Jack must be moved, make
certain that the load is secured by appropriate means,
is stable, is in the lowest possible position, is moved
over a smooth, hard level surface, and that the lifting
platform is level.
12. If you are working and the load becomes off-balance
and/or the Transmission Jack begins to tip over,
WARNING: DO NOT ATTEMPT TO CATCH OR LIFT
THE LOAD WHEN FALLING. SERIOUS PERSONAL
INJURY CAN RESULT! In this event, clear the area as
quickly and safely as possible in order to avoid injury from
the falling load, including getting hit with flying fragments.
13. Before each use, inspect the general condition of the
Transmission Jack. Check for oil leaks, Transmission
Jack operation, loose components, free rotation
and pivoting of saddle adjustment components. If a
problem occurs, have the problem corrected before
further use.
ASSEMBLY
1. Connect Bases (#43) to the pump frame by using a Flat
Washer (#48), Lock Washer (#49) and Bolt (#50).
2. Attach 2 pieces of Locking Castors (#47) and 2 Wheels
(#52) to the base by using Nut (#44), Flat Washer (#45)
and Lock Washer (#46).
3. Install the Saddle (#04) onto the Transmission Jack and
tighten the bolt on the saddle to secure the saddle.
WARNING: TO PREVENT SERIOUS INJURY: DO
NOT USE A DAMAGED OR MALFUNCTIONING JACK.
1. Make sure the casters are locked before use.
2. The Transmission Jack is not designed to lift or lower a
vehicle.
3. If in doubt about the safety of your project, we advise
you to have the work done by a professional familiar
with applicable safety practices.

4
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
OPERATION
Please bleed the Transmission Jack according to
the bleeding instructions before you start using the
Transmission Jack.
1. Follow the instructions for removal and installation of
transmission, transfer case or transaxle according to
the vehicle manufacturer’s service manual.
2. Prior to initial use, jack up the saddle and, using
the release valve, attempt to lower it. This will help
you become familiar with the control functions and
Transmission Jack.
3. Once the vehicle is safely and properly secured,
position the Transmission Jack underneath the vehicle.
4. Raise the Transmission Jack by operating the foot
pump until the saddle reaches the component. After
making contact with the transmission, make sure it is
centered within the brackets on the saddle plate. Use
adjustment knobs to position the saddle base.
5. Lift the Transmission Jack slightly to transfer the weight
of the transmission from the vehicle chassis to the
Transmission Jack. Secure the chain assembly around
the component.
6. Remove transmission fasteners, freeing it from the
vehicle. Make sure there is nothing to restrict the
movement of the transmission.
7. Back transmission away to free from engine.
8. Check the saddle, making sure it is securely holding
and aligned with the transmission and not showing any
signs of stress. Carefully lower transmission and saddle
by depressing the release valve. Always lower the
saddle slowly.
9. Once the transmission has been disconnected from
the engine, very slowly operate the release pedal.
Make sure the Transmission Jack’s saddle and
transmission do not hang up on any under vehicle
components, wiring, fuel lines, etc. Continue to lower
the Transmission Jack all the way down.
10. After removal, lower the Transmission Jack to the lowest
possible point before attempting to move the jack .
WARNING:The Transmission Jack is designed to
lift loads only for short periods of time. DO NOT use to
suspend a load for more than 30 minutes at a time.
11. To re-mount the transmission, reverse this procedure.
MAINTENANCE
BLEEDING
If the jack is not able to raise the load or raises very
slowly, follow these instructions:
1. Turn the Vent Screw (#26) counterclockwise to make it
open.
2. Use Allen wrench to open the following screw on the
foot pedal. (See Figure 1)
3. Operate the Pump Pedal (#38) until the hydraulic fluid
escapes from the screw hole and there are no air
bubbles.
4. Tighten the screw.
5. Test to see if the telescopic rams are working smoothly
or not.
6. Repeat steps 1 through 4 if the condition has not been
fully corrected.
If the jack’s telescopic rams do not raise or lower
smoothly, follow these instructions:
1. Turn the Vent Screw (#26) counterclockwise to make it
open.
2. Press the Pump Pedal (#38) until both rams are at
maximum extension.
3. Use an Allen wrench to turn the screw in the primary
cylinder nut counterclockwise 1/2 turn. (See Figure 2)
4. Press the Pump Pedal (#38) two or three times until the
hydraulic fluid escapes from the screw hole and there
are no air bubbles.
5. Tighten the screw.
6. Test to see if the telescopic rams are working smoothly
or not.
7. Repeat steps 1 through 4 if the condition has not been
fully corrected.
Figure 1 Figure 2
ADDING OIL
With saddle fully lowered, set Transmission Jack in its
upright, level position. Remove oil filler plug. Fill until oil is
level with the oil filler hole; re-install oil filler plug.
IMPORTANT: Use only good grade hydraulic
Transmission Jack oil. Avoid mixing different types of fluid
and NEVER use brake fluid, turbine oil, transmission fluid,
motor oil or glycerin. Improper fluid can cause premature
failure of the Transmission Jack and the potential for
sudden and immediate loss of load.
CHANGING OIL
For best performance and longest life, replace the
complete fluid supply at least once per year.
1. With saddle fully lowered, remove oil filler plug.
2. Lay the Transmission Jack on its side and drain the
fluid into a suitable container.
NOTE:Dispose of hydraulic fluid in accordance with
local regulations.
3. Set Transmission Jack in its level position. Fill until oil is
level with the oil filler hole, re-install oil filler plug.

5
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
LUBRICATION
A periodic coating of light lubricating oil to pivot points,
axles and hinges will help to prevent rust and ensure that
casters and pump assemblies move freely.
CLEANING
Periodically check the pump piston and ram for signs of
rust or corrosion. Clean as needed and wipe with an oily
cloth.
NOTE:Never use sandpaper or abrasive material on
these surfaces!
STORAGE
When not in use, store the Transmission Jack with saddle
fully lowered.
Always store the Transmission Jack in a well-protected
area where it will not be exposed to inclement weather,
corrosive vapors, abrasive dust, or any other harmful
elements.
CAUTION:
Use caution when troubleshooting a malfunctioning
Transmission Jack. Stay well clear of the supported
load. Completely resolve all problems before use. If the
Transmission Jack is malfunctioning, have a qualified
technician inspect and repair the Transmission Jack
before use. After the Transmission Jack is repaired, test it
carefully without a load by raising it and lowering it fully,
checking for proper operation.

6
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
PRODUCT LAYOUT
NOTE:The manufacturer and/or distributor have
provided the parts list and assembly diagram in this
manual as a reference tool only. Neither the manufacturer
nor distributor makes any representation or warranty of
any kind to the buyer that he or she is qualified to make
any repairs to the product, or that he or she is qualified to
replace any parts of the product. In fact, the manufacturer
and/or distributor expressly states that all repairs and
parts replacements should be undertaken by certified and
licensed technicians, and not by the buyer.
The buyer assumes all risk and liability arising out of
his or her repairs to the original product or replacement
parts thereto, or arising out of his or her installation of
replacement parts thereto.

7
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
Figure Description Qty.
01 Dust Ring 1
02 O Ring 1
03 Seal Ring 1
04 Saddle 1
05 2nd Stage Ram 1
06 Grease Fitting 1
07 Retainer Ring 1
08 Dust Ring 1
09 O Ring 1
10 Seal Ring 1
11 Ram Nut 1
12 O Ring 1
13 1st Stage Ram 1
14 Retainer Ring 1
15 End Cap 1
16 Screw 1
17 Steel Ball 1
18 O Ring 1
19 Nut Seat 1
20 Seal Ring 2
21 Oil Barrel 1
22 Pin 1
23 Pin 3
24 Handle 1
25 Handle Grip 1
26 Vent Screw 1
27 Seal Ring 1
28 Cylinder 1
29 Seal Ring 1
30 Pump 1
31 Limit 1
Figure Description Qty.
32 Lock Washer 1
33 Screw 1
34 Release Pedal 1
35 Pin 1
36 Pin 1
37 Flat Washer 2
38 Pump Pedal 1
39 Retainer Ring 4
40 Linkage 2
41 Pin 2
42 Pin 1
43 Base 2
44 Nut 4
45 Flat Washer 4
46 Lock Washer 4
47 Locking Castor 2
48 Flat Washer 4
49 Lock Washer 4
50 Bolt 4
51 Screw 2
52 Wheel 2
53 Washer 1
54 O Ring 1
55 Steel Ball 1
56 Spring 1
57 Valve Seat 1
58 Bar 1
59 Spring 1
60 Valve Core 1
61 Filter 1
62 Retainer Ring 1
PARTS LIST
NOTE:Not all components of the Transmission Jack
are replacement reference for location and posting in
the assembly sequence.

8
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS®90 DAY WARRANTY
For up to 90 days from the original purchase of this OEMTOOLS®product, if you find any defect in material or
workmanship (through normal usage), return it to the place of purchase or to OEMTOOLS®for repair or replacement at
our discretion. In order to obtain this service, send your tool and proof of purchase (transportation pre-paid) to:
OEMTOOLS®Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our
inspection verifies the defect, we will either repair or replace the product, or we may elect to refund the purchase price
if we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if
we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you
must bear the cost of returning the product.
OEMTOOLS®does not provide warranty for products labeled other than OEM®or OEMTOOLS®. OEMTOOLS®will
not provide any warranty for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse,
accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits,
blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits,
files, and batteries as necessary. OEMTOOLS®reserves the right to make any changes in construction or design at any
time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS®makes every effort to ensure that its products meet high quality and durability standards and warrants
to the original purchaser that this product is free from defects in materials and workmanship for the period of 90
days from the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear
and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY
IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Don’t forget to register your new OEMTOOLS®product at www.oem-tools.com.
CONTACT US
