UNPACKING
After unpacking unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing,
or damaged parts. If any damage is observed, a shipping
damage claim must be filed with carrier. DO NOT use the
OEMTOOLS®1,100 Lbs. High Lift Transmission Jack with
Hands-Free Foot Pump if broken, bent, cracked or damaged
parts (including labels) are noted. Any Transmission Jack
that appears damaged in any way, operates abnormally, or is
missing parts should be removed from service immediately.
If you suspect that the Transmission Jack was subjected to a
shock load (a load that was dropped suddenly, unexpectedly,
etc.), immediately discontinue use until it has been checked by
a factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
The following safety information is provided as guidelines to help you operate your Transmission Jack under the safest possible
conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are
not known or not followed. The following safety instructions are to provide the user with the information necessary for safe
use and operation. Please read and retain these instructions for the continued safe use of your Transmission Jack. Failure to
follow instructions listed below may result in serious injury. In addition, make certain that anyone who uses the equipment
understands and follows these safety instructions as well.
Operating Instructions and Parts Manual 24844
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
Thank you very much for choosing an OEMTOOLS®Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS®cannot be responsible for issues
arising from modification. We strongly recommend that this product is not modified and/or used for any application other than that
for which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first
contacted customer service to determine if it can or should be performed on the product.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
1
7/19
2019 OEMTOOLS®
24844
WARNING

2
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. This product is intended only for professional use by
personnel trained in performing the service functions
for which it is designed. For safety purposes and the
prevention of damage to expensive components, it
is advised that the user have an understanding of
basic automotive repair and a working knowledge of
automotive systems.
2. Know your product. Read this manual carefully.
Learn the applications and limitations, as well
as potential hazards. The use of this equipment
is simple and straightforward if you follow the
instructions. When operating this Transmission Jack,
only use it for its intended purpose. Use common
sense, and always stop to think before using a Jack
or lifting a vehicle.
3. Maintain labels and nameplates on this Transmission
Jack. They carry important information. If unreadable
or missing, contact OEMTOOLS®for a replacement.
4. Maintain this equipment with care. Keep it dry, clean,
and free from brake fluid, oil, and grease.
5. Check for damage. Check this equipment regularly.
If part of the product is damaged, it should be
carefully inspected to make sure that it can perform
its intended function correctly. If in doubt, the part
should be repaired. Refer all servicing to a qualified
technician. Consult your dealer for advice.
6. Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the product’s operation.
7. Properly maintained tools and equipment are less
likely to bind and are easier to control. DO NOT
use damaged equipment. Tag damaged equipment
“DO NOT USE” until repaired. If damaged, have the
equipment serviced before using. Many accidents
are caused by poorly maintained tools and
equipment.
8. Service must be performed only by qualified repair
personnel. Service or maintenance performed by
unqualified personnel could lead to personal injury
and/or property damage.
9. When servicing a tool, use only identical
replacement parts. Use of unauthorized parts or
failure to follow maintenance instructions may create
a risk of injury.
10. Use only accessories that are recommended by the
manufacturer for your model. Accessories that may
be suitable for one product may become hazardous
when used on another product.
11. Maintain a safe working environment. Keep the
work area well lit. Cluttered or dark work areas invite
accidents. Make sure there is adequate surrounding
workspace. Keep the work area free of obstructions,
grease, oil, trash, and other debris. DO NOT use this
product in a damp or wet location.
12. Keep children away. All children should be kept
away from the work area. Never let a child handle a
tool without strict adult supervision.
13. When not in use, store this product out of the
reach of children and untrained persons. Tools
and equipment may be dangerous in the hands of
untrained users.
14. DO NOT operate this equipment if under the
influence of alcohol or drugs. Read warning labels
on prescriptions to determine if your judgment or
reflexes are impaired while taking drugs. If there is
any doubt, DO NOT attempt to operate.
15. Use safety equipment. Eye protection should be
worn at all times when operating this equipment.
Use ANSI approved safety glasses. Everyday
eyeglasses are NOT safety glasses. Dust mask,
non-skid safety shoes, hard hat or hearing protection
should be used in appropriate situations.
16. Wear proper apparel. Loose clothing, gloves,
neck-ties, rings, bracelets or other jewelry may
present a potential hazard when operating this tool.
Keep all apparel clear of the equipment.
17. DO NOT overreach. Keep proper footing and
balance at all times when operating this equipment.
18. Keep away from flammables. DO NOT attempt
to operate this tool near flammable materials or
combustibles. Failure to comply may cause serious
injury or death.
19. Avoid accidental fire and/or explosion. DO NOT
smoke near engine fuel and battery components.
20. We believe the information contained herein to be
reliable. However, general technical information
is given by us without charge and the user shall
employ such information at their own discretion
and risk. We assume no responsibility for results or
damages incurred from the use of such information
in whole or in part. Always refer to specific
instructions and technical information supplied by
vehicle manufacturer.
21. The manufacturer declines any and all responsibility
for damage to vehicles or components if said
damage is the result of unskillful handling by the
operator or of failure to observe the basic safety
rules set forth in the instruction manual.
22. The warnings, precautions, and instructions
discussed in this manual cannot cover all possible
conditions and situations that may occur. The
operator must understand that common sense and
caution are factors which cannot be built into this
product, but must be supplied by the operator.
23. This equipment is designed for servicing a variety
of vehicles in a safe, convenient manner. However,
differences in vehicle makes and models may make
it impossible to use this equipment as it is intended.
DO NOT attempt to force the use of this equipment
on an application for which it is not designed to
perform.

3
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
24. The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
In addition to these guidelines, always follow the
manufacturer’s recommended procedures when
servicing each unique vehicle.
25. Before use, read and understand all warnings, safety
precautions, and instructions as outlined in the
vehicle manufacturer’s service manual. It is beyond
the scope of this manual to properly describe the
correct procedure and test data for each vehicle.
26. The unexpected movement of a vehicle can injure
or kill. When working on vehicles, always set the
parking brake or block the wheels.
27. Engine parts that are in motion and unexpected
movement of a vehicle can injure or kill. Always
stay clear of moving engine parts. Keep hoses and
tools clear of moving parts. Hoses and tools can be
thrown through the air if not kept clear of moving
engine parts.
28. Always perform vehicle service in a properly
ventilated area. Never run an engine without proper
ventilation for its exhaust. Stop work and take
necessary steps to improve ventilation in the work
area if you develop momentary eye, nose, or throat
irritation as this indicates inadequate ventilation.
PRODUCT DESCRIPTION
The Hydraulic Transmission Jack is designed to be used
as an aid in the removal and installation of automotive
and light truck transmissions, transfer cases and
transaxles. This telescopic style Transmission Jack is for
use under an overhead lift or in a garage pit.
PRODUCT SPECIFICATIONS
Weight 1,100 Lbs.
Lift 47" – 79"
Transmission Jack 93 Lbs.
WARNING:NEVER use for any purpose other than
those uses outlined above!
SPECIFIC SAFETY INSTRUCTIONS
AND WARNINGS
1. Before each use, inspect the general condition of
the Transmission Jack. Check for oil leaks, Jack
operation, loose components, free rotation and
pivoting of Saddle adjustment components. If a
problem occurs, have the problem corrected before
further use.
2. To prevent serious injury, DO NOT use a damaged or
malfunctioning Jack.
3. Always evaluate your task before using this Jack.
This Jack is designed to support a transmission or a
differential as individual components. Use as intended
only.
4. Verify that the product and application are
compatible; if in doubt, call OEMTOOLS at
1-866-458-2472.
5. Before using this product, read the operator’s
manual completely and familiarize yourself
thoroughly with the equipment and its components,
and recognize the hazards associated with its use.
6. Wear appropriate safety gear, including heavy duty
work gloves and ANSI-approved safety goggles
during use.
7. Ensure that the Jack rolls freely. Raise and lower the
unloaded Jack throughout the lifting range before
putting into service to ensure the pump operates
smoothly. Replace worn or damaged parts.
8. DO NOT exceed the weight capacity of the Jack.
Make sure weight is evenly distributed. Be aware
of dynamic loading! Sudden load movement may
briefly create excess load causing product failure.
Exceeding the maximum capacity for this product is
dangerous and can lead to serious injury or property
damage.
9. Never use this device as a work/repair station.
10. Transfer the load immediately to a suitable work
station.
11. Assemblies (such as differential with axle or
transmission with bell housing) can be bulky and
difficult to balance. Lifting or supporting such
assemblies, even within weight limit, can create an
off-balance situation, causing the Jack to tip over
and could lead to serious personal injury or property
damage.
12. The load should be evenly distributed on the Jack,
and should not extend beyond the area of the caster
wheelbase. Always use the chains provided to
secure the load. If extra support is required, safety
straps (not included) can also be used to secure the
work piece.
13. Use only on a hard, level and flat surface capable
of bearing the combined weight of the Transmission
Jack, the load being lifted, the operator, and any
tools being used.
14. If loaded Jack must be moved, be sure that the load
is secured by appropriate means, is stable, is in the
lowest possible position, is moved over a smooth,
hard level surface, and that the lifting platform is
level.
15. If you are working and the load becomes off-
balance and/or the Jack begins to tip over, DO NOT
attempt to catch or lift the load when falling. Serious
personal injury can result! In this event, clear the
area as quickly and safely as possible in order to
avoid injury from the falling load, including getting hit
with flying fragments.

4
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
16. To prevent serious injury, DO NOT use a damaged or
malfunctioning Jack.
17. Make sure the casters are blocked before use.
18. The Transmission Jack is not designed to lift or lower
a vehicle.
19. If in doubt about the safety of your project, we
advise you to have the work done by a professional
familiar with applicable safety practices.
ASSEMBLY INSTRUCTIONS
1. Fit each Caster (53) to the Legs (52) using Nuts (49),
Lock Washers (50), and Flat Washers (51), then
tighten.
2. Attach the 2 Legs (52) to the Transmission Jack Base
(18) using Bolts (56), Lock Washers (55), and Flat
Washers (54), then tighten.
3. Install the Saddle Assembly (17) onto the top of the
Piston Rod (9), then tighten Lock Bolt.
4. Remove the R Clips (36) and Pedal Pins (35) from
Foot Pedal (37). Attach the Foot Pedal to the Pump
Core (21) and Connecting Bar (39) using the Pedal
Pins and R Clips. Press the Foot Pedal and remove
the 2 Screws holding the Spacer in place (figure 1),
then release the Foot Pedal.
figure 1
spacing board
screws
Picture 1
OPERATION
1. Follow the instructions for removal and installation of
transmission, transfer case or transaxle according to
the vehicle manufacturer’s service manual.
2. Prior to initial use, jack up the Saddle and attempt
to lower it (using the Release Knob). Doing so will
familiarize you with the control functions and the
Jack.
3. Once the vehicle is safely and properly secured,
position the Transmission Jack underneath the
vehicle.
4. Raise the Jack by operating the Foot Pump until
the Saddle reaches the component. After making
contact with the transmission, make sure it is
centered within the brackets on the Saddle Plate.
Use Adjustment Knobs to position Saddle Base.
5. After contact, lift the Jack slightly to transfer the
weight of the transmission from the vehicle chassis
to the Transmission Jack. Secure the chain assembly
around the component and make sure the load is
centered on the adapter.
6. Remove transmission fasteners, freeing it from the
vehicle. Make sure there is nothing to restrict the
movement of the transmission.
7. Back transmission away to free from engine.
8. Check the Saddle, making sure it is securely holding
and aligned with the transmission and not showing
any signs of stress. Carefully lower transmission and
Saddle by turning the Release Knob.
NOTE:Before lowering load, check to ensure all tools
and personnel are clear and it is safe to lower the load.
9. Secure the Chain tightly over the transmission and
safely remove the Transmission Jack.
10. After removal, lower the Jack to the lowest possible
point.
WARNING:The Jack is designed to lift loads only for
short periods of time. DO NOT use it to suspend a load
for more than 30 minutes at a time.
The manufacturer and/or distributor have provided
the parts list and assembly diagram in this manual as
a reference tool only. Neither the manufacturer nor
distributor makes any representation or warranty of any
kind to the buyer that he or she is qualified to make any
repairs to the product, or that he or she is qualified to
replace any parts of the product. In fact, the manufacturer
and/or distributor expressly states that all repairs and
parts replacements should be undertaken by certified
and licensed technicians, and not by the buyer. The
buyer assumes all risk and liability arising out of his
or her repairs to the original product or replacement
parts thereto, or arising out of his or her installation of
replacement parts thereto.
MAINTENANCE
IMPORTANT: Use only good grade hydraulic Jack oil.
Avoid mixing different types of fluid and NEVER use brake
fluid, turbine oil, transmission fluid, motor oil or glycerin.
Improper fluid can cause premature failure of the Jack
and the potential for sudden and immediate loss of load.
ADDING OIL
1. With Saddle fully lowered, set Jack in its upright,
level position. Remove oil filler plug.
2. Fill until oil is level with the oil filler hole; reinstall oil
filler plug.

5
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
CHANGING OIL
For best performance and longest life, replace the
complete fluid supply at least once per year.
1. With Saddle fully lowered, remove oil filler plug.
2. Lay the Jack on its side and drain the fluid into a
suitable container.
NOTE:Dispose of hydraulic fluid in accordance with
local regulations.
3. Set the Jack in its level position. Fill until oil is level
with the oil filler hole; reinstall oil filler plug.
LUBRICATION
A periodic coating of light lubricating oil to pivot points,
axles and hinges will help prevent rust and ensure that
casters and pump assemblies move freely.
CLEANING
Periodically check the Pump Piston and Ram for signs of
rust or corrosion. Clean as needed and wipe with an oily
cloth.
NOTE:Never use sandpaper or abrasive material on
these surfaces!
STORAGE
When not in use, store the Jack with Saddle fully lowered.
Always store the Jack in a well-protected area where
it will not be exposed to inclement weather, corrosive
vapors, abrasive dust, or any other harmful elements.
INSPECTION
It is recommended that an annual inspection be done by
qualified technicians.

6
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
FIGURE DESCRIPTION QTY
1Dust Seal 1
2O-Ring 1
3U-Ring 1
4Round Nut 1
5O-Ring 1
6Cylinder Cover 1
7O-Ring 2
8Washer 1
9Piston Rod 1
10 Retaining Ring 1
11 Steel Ball 6
12 Screw 1
13 Spring Sleeve 1
14 Spring 1
15 O-Ring 1
16 Release Valve 1
17 Saddle Assembly 1
18 Base Assembly 1
19 O-Ring 1
20 Air Vent Screw 1
21 Pump Core 1
22 PTFE Washer 1
23 U-Ring 1
24 Pump Core Seat 1
25 Copper Pad 1
26 Retaining Ring 1
27 Washer 1
28 Small Piston 1
29 Nylon Ring 1
30 O-Ring 1
31 Spring 1
32 Pump Core Seat 1
33 Copper Pad 1
34 Cotter Pin 2
35 Pedal Pin 4
36 R Clip 2
37 Foot Pedal 1
38 Roller 1
39 Connecting Bar 1
40 Spring 1
41 O-Ring 2
42 Screw 2
43 Steel Ball 1
44 Ball Cup 1
45 Spring 1
46 Spring 2
47 Copper Pad 2
48 Screw 2
49 Nut 4
50 Lock Washer 4
51 Flat Washer 4
52 Leg 2
53 Caster 4
54 Flat Washer 4
55 Lock Washer 4
56 Bolt 4
BASE PARTS LIST BASE PRODUCT LAYOUT

7
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
FIGURE DESCRIPTION QTY
1Short Adjustable
Screw 1
2Adjustable Nut 1
3O-Ring 2
4Bearing 4
5Stationary Rod 1
6Nut 2
7Cotter Pin 2
8Retaining Ring 2
9Connecting Rod 1
10 Bolt 7
11 Bottom Plate 1
12 Saddle 1
13 Chain 2
14 D-type Buckle 2
15 Eye Bolt 2
16 Angle Plate 2
17 Side Plate 4
18 Hook Screw 2
19 Hook Bolt 2
20 Butterfly Nut 2
21 Flat Washer 17
22 Nut 10
23 Saddle Plate 1
24 Long Adjustable
Screw 1
SADDLE PARTS LIST SADDLE PRODUCT LAYOUT
NOTE: Not all components of the Transmission Jack are replacement items, but are illustrated as a convenient reference
for location and position in the assembly sequence.
Use caution when troubleshooting a malfunctioning Jack. Stay well clear of the supported load. Completely resolve all
problems before use. If the Jack is malfunctioning, have a qualified technician inspect and repair the Jack before use.
After the Jack is repaired: Test it carefully without a load by raising it and lowering it fully, checking for proper operation.

8
Operating Instructions and Parts Manual 24844
7/19
2019 OEMTOOLS®
1,100 LBS. HIGH LIFT TRANSMISSION
JACK WITH HANDS-FREE FOOT PUMP
