OHAUS TD52 User manual

TD52 Indicator
USB Host Option
(For Wireless Communication Option)
Instruction Manual
Interfaz de host USB
(Para conexiones inalá mbricas)
Manual de instrucciones
Interface hô te USB
(Pour connexion sans fil)
Manuel d’instruction
USB Host-Schnittstelle
(fü r drahtlose Verbindung)
Bedienungsanleitung
Interfaccia Host USB
(Per collegamento wireless)
Manuale di Istruzioni
USB 主设备选件
（用于无线连接）
使用说明书
USB 호스트 인터페이스 키트
(Wi-Fi 동글용입니다)
사용 설명서
ディフェンダー5000
USB ホスト インターフェイス
（ワイヤレス接続用）
取扱説明書
Дополнительный интерфейс USB Host для весового терминала TD52
(для подключения адаптера беспроводной связи)
Руководство по эксплуатации
Manual_TD52_USB_V1

EN-1
INTRODUCTION
This Interface Kit is for use with Ohaus TD52 products and Wi-Fi dongle.
KIT CONTENTS
INTERFACE INSTALLATION
For TD52P version
1. Separate the indicator from the base by loosening load cell cable male connector.
Remove the Interface option cover.
Load cell cable male connector
Interface option cover

EN-2
2. Break off the rib of the interface option cover as shown.
3. Connect the 9 pin USB Host Board cable to the main board connector.
4. Install the USB Host board. Secure it with the 2 screws.
Cable
Main board
connector
Rib

EN-3
5. Connect the USB Host cable to the 9 Pin connector on the option board.
6. Plug the USB dongle in and put the interface option cover back on the terminal.
Screw
9 Pin
connector
USB Dongle

EN-4
For TD52XW version:
1. Remove the 6 sealing screws to open the rear housing. Remove the M25 hole plug as
shown.
2. Rotate the rear housing down away from the front housing as shown.
Screw
M25 hole plug
Load cell cable male
connector

EN-5
3. Connect 9 pin USB Host Board cable to the main board connector.
4. Install the USB host board. Secure it with 2 screws. (Note: Boss Post is 2 and 4.)
Cable
Main board connector
Boss Post 2, 4

EN-6
5. Connect the USB Host cable to the 9 Pin connector on the option board.
6. Put the rear housing back on the front housing. Fasten 6 screws with sealed washer
(Torque is 1.8N*m± 0.5). Plug the USB Dongle through M25 hole.
7. Fasten the USB dongle cover.
Screw
9 Pin connector
USB Dongle
USB dongle cover

EN-7
For TD52XW with reversed rear cover:
1. Remove the 6 sealing screws to open the rear housing. Remove the M25 hole plug as
shown.
2. Rotate the rear housing down away from the front housing as shown.
Screw
Load cell cable connector
M25 hole plug

EN-8
3. Connect the USB Host cable to the main board connector.
4. Install the USB host board. Secure it with 2 screws. (Note: Boss Post is 1, 3)
Cable
Main board
connector
Boss post 1, 3
