C9600 Printing Guide
2
Copyright Information
Copyright © 2007 by Oki Data. All Rights Reserved
Document Information ________________________________
C9600 Printing Guide
P/N 59373001
Revision 3.0
February, 2007
Disclaimer__________________________________________
Every effort has been made to ensure that the information in this document is
complete, accurate, and up-to-date. The manufacturer assumes no responsibility
for the results of errors beyond its control. The manufacturer also cannot guarantee
that changes in software and equipment made by other manufacturers and referred
to in this guide will not affect the applicability of the information in it. Mention of
software products manufactured by other companies does not necessarily
constitute endorsement by the manufacturer .
While al l r easo n a b le eff o r t s have b e e n made t o make t h i s docume n t a s acc u r a t e and
helpful as possible, we make no warranty of any kind, expressed or implied, as to
the accuracy or completeness of the information contained herein.
The most up-to-date drivers and manuals are available from the web site:
http://www.okiprintingsolutions.com
Trademark Information _______________________________
Oki and Oki Printing Solutions are registered trademarks of Oki Electric Industry
Company Ltd.
Adobe and PostScript are registered trademarks of Adobe Systems.
Apple, Macintosh, Mac, and Mac OS are registered trademarks of Apple Computers
Inc.
Hewlett-Packard, HP, and LaserJet are registered trademarks of Hewlett-Packard
Company.
Microsoft, MS-DOS and Windows are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
Other product names and brand names are registered trademarks or trademarks of
their proprietors.

C9600 Printing Guide> 3
C ONTENTS
Chapter 1: Introduction .........................................................5
About this book ....................................................5
How to access the driver screens ............................6
Windows drivers...............................................6
PCL saved driver settings...................................8
Setting the driver device options.............................9
Windows .........................................................9
Mac OS9 .........................................................9
Mac OS X in Classic Mode ................................ 11
Mac OS X ...................................................... 11
Chapter 2: Blacks and greys ................................................ 13
Black overprint ................................................... 13
Black printing (black generation) .......................... 15
Composite black ............................................. 15
True (pure) black ........................................... 15
Fine lines enhancement ....................................... 19
Greyscale printing............................................... 20
Chapter 3: color matching ................................................... 24
Basics ............................................................... 24
What this guide describes .................................... 25
Printer color management.................................... 26
Introduction................................................... 26
About RGB and CMYK color .............................. 27
Office color ........................................................ 28
Office color - RGB options................................ 29
Customizing RGB office color
with the color correct utility (Windows) ............ 34
Graphic pro........................................................ 35
Types of ICC profile supported ......................... 36
Graphic pro workflow – overview ...................... 37
Matching the color of
a monitor, scanner or camera......................... 40
Simulating another printer – RGB source data .... 47
CMYK ink simulations – CMYK source data ......... 55
Rendering intents ........................................... 61
Pure black text / graphics ................................ 62
color match precision ...................................... 62
Printer driver settings for
ICC profile creation or no color matching ......... 63

C9600 Printing Guide> 4
Chapter 4: Finishing options................................................. 66
Booklet printing (imposition) ................................ 67
Collating............................................................ 70
color separation.................................................. 74
Separating queued print jobs................................ 77
Windows separator page ................................. 77
Mac OS 9 cover page ...................................... 78
Mac OS X cover page ...................................... 78
Cover print ........................................................ 79
Custom page size ............................................... 81
Duplex (double-sided) printing ............................. 87
Mac OS X ...................................................... 89
Printing multiple pages on one sheet (N-up) ........... 90
Poster printing.................................................... 93
Scale to page ..................................................... 94
Watermarks ....................................................... 95
Chapter 5: Secure printing................................................... 98
Sending the document......................................... 99
Windows ....................................................... 99
Mac OS 9 .................................................... 100
Printing the document ....................................... 101
Deleting a secure print document........................ 102
Chapter 6: Store to hard disk ............................................. 103
Sending the document....................................... 104
Printing the document ....................................... 104
Deleting a stored document ............................... 104
Index ............................................................................... 105

C9600 Printing Guide> 5
C HAPTER 1: I NTRODUCTION
A BOUT THIS BOOK
This book is delivered as an Adobe Acrobat PDF file. It provides a
convenient on-screen reference to the many features of the driver
software supplied with your C9600.
There are many cross-references within this book, each highlighted
as blue text. When you click on a cross-reference within Adobe
Acrobat or Adobe Reader (also supplied on the Manuals CD) the
display will instantly jump to the part of the manual containing the
referenced material.
By using the button in Adobe Reader, you can navigate directly
back to where you were before.
If you need to print a part of this manual, use Adobe Reader’s print
command, and choose which pages you want to print. Some pages
are deliberately left blank so that the page format is appropriate for
duplex (double-sided) printing if you wish.

C9600 Printing Guide> 6
H OW TO ACCESS THE DRIVER SCREENS
Most of the features described are accessed via the printer driver
screens. How you access them depends on your computer and its
operating system.
W INDOWS DRIVERS
The driver windows are tabbed dialogue boxes, offering a wide range
choices about how you want to print your documents.
There are two ways to access the driver features from within
Windows:
1. Directly from the Windows “Printers” folder (“Printers and
Faxes” folder in Windows XP).
If you choose this method any changes you make will become
the driver defaults. This means they will remain active for all
your applications unless you specifically change them from
within the application’s Print dialogue.
2. From your application’s Print dialogue.
If you choose this method any changes you make will usually
only last for as long as the particular application is running, or
until you change them again. In most cases, once you quit the
application the driver defaults will return.
IMPORTANT!
Settings made from the printer’s own control panel are
the printer defaults. They determine how your printer
will behave unless you specify otherwise from your
computer.
The driver defaults override the printer defaults.
Application Print settings override both the printer
defaults and the driver defaults.

C9600 Printing Guide> 7
C HANGING THE DRIVER DEFAULTS
Windows XP/2000/Server 2003
1. Click [Start] →[Settings] →[Printers and Faxes] to open the
Printers and Faxes window.
2. In the Printers and Faxes window, right-click on the
appropriate printer driver icon, and choose [Printing
Preferences] from the context menu.
Windows 98/Me/NT
1. Click [Start] →[Settings] →[Printers] to open the Printers
window.
2. In the Printers window, right-click on the appropriate printer
driver icon, and choose [Properties] from the context menu.
C HANGING THE APPLICATION ’ S DRIVER SETTINGS
Windows
1. In your application, open the file you want to print.
2. On the [File] menu, choose [Print…].
3. In the application’s Print dialogue, make sure the printer
shown is the appropriate one, and click [Properties].
Macintosh
The Mac user interface is very different to that in Windows. In
particular, OS X differs considerably from previous versions. Full
instructions are therefore included with each procedure.

C9600 Printing Guide> 8
PCL SAVED DRIVER SETTINGS
This feature, unique to the Windows PCL drivers, allows you to save
the printer driver settings and reuse them later. This could be useful
if you frequently print many different types of document that require
different printer driver settings.
Recalling saved settings in the PCL drivers is a simple task that must
be done first, before any job-specific changes are made. Rather than
repeat the procedure throughout this manual, it is described here.
S AVING A SET OF DRIVER SETTINGS
1. Make any changes to the driver settings you want, as
described in the relevant section of this manual.
2. In the driver’s [Setup] tab, click [Save…].
3. Enter a meaningful name for the settings you are saving, and
click [OK].
R ECALLING SAVED DRIVER SETTINGS
1. In the driver’s [Setup] tab, choose any previously saved
[driver settings] you need.
2. Proceed to make any other adjustments for this job, as
described in the relevant section in this manual.

C9600 Printing Guide> 9
S ETTING THE DRIVER DEVICE OPTIONS
This section explains how to ensure that your printer driver can
utilize all of the hardware features installed in your printer.
Accessories such as hard disk, duplex unit (two sided printing),
additional paper trays, etc., will only be usable if the printer driver
on your computer knows they are there.
In some cases the hardware configuration of your printer is
automatically detected when the driver is installed. However, it is
advisable to at least check whether all of the available hardware
features are listed in the driver.
This procedure is essential if you subsequently add extra hardware
features to your printer after the drivers have been installed and set
up.
W INDOWS
1. Access the driver’s [Properties] window. (See “Changing the
driver defaults” on page 7.)
2. Select the [Device Options] tab.
In the Windows XP PostScript driver the tab may be called
“Device Settings”.
3. Set the options for any devices you have installed, including
the correct number of paper trays, high capacity feeder,
duplex unit, etc.
4. Click [OK] to close the window and save your changes.
M AC OS9
There are 2 methods to configure printer hardware options,
depending on whether or not you use Desktop Printing:
> Use the desktop printer icon if you use desktop printing;
or…
> Use the Chooser if you do not use desktop printing and print
via AppleTalk.

C9600 Printing Guide> 10
C ONFIGURING HARDWARE OPTIONS FROM THE DESKTOP
Use this method if you have a printer icon on your desktop.
1. Select the printer icon on the Desktop for your printer.
2. From the [Printing] menu, choose [Change Setup…].
3. In the [Change] menu, select the hardware item(s) that you
have installed, and change the [To] values as appropriate.
Tip—If your printer is connected via USB or AppleTalk, click
the [Auto Setup] button. This queries the printer, and sets the
options automatically.
4. Click [OK] to save your settings.
C ONFIGURING HARDWARE OPTIONS FROM CHOOSER
(A PPLE T ALK ONLY )
Use this method if you do not use Desktop Printing.
1. In the Apple menu, select [Chooser].
2. Select the printer driver that you use (LaserWriter or
AdobePS) in the left-hand side of the Chooser window.
3. If you are on a network with multiple AppleTalk zones, select
the appropriate zone for the printer in the bottom left side of
the Chooser.
If your network does not have multiple AppleTalk zones, this
option will not be visible.
4. Select the name of your printer in the right-hand side of the
Chooser.
5. Click [Setup…].
6. Click [Configure].
7. Make changes to the installed hardware options as
appropriate for your printer.

C9600 Printing Guide> 11
8. Click [OK], and close the Chooser window to save your
settings.
M AC OS X IN C LASSIC M ODE
Printers connected via AppleTalk:
1. Launch a Classic application (such as SimpleText).
2. Click the Apple menu and point to [Chooser].
3. Select your printer driver on the left-hand pane of Chooser
(for example “LaserWriter 8”).
4. Select your printer model in the right-hand pane of Chooser.
5. Click [Setup…].
6. Click [Auto Setup].
The printer is queried and additional hardware options are
automatically detected.
Printers connected via USB:
It is not possible to change printer hardware options for printers
connected via USB in Classic Mode. If you change the hardware
configuration of your printer, you must delete the existing printer
and set it up again. When the printer is set up, hardware device
options are automatically detected.
Printers connected via LPR (TCP/IP):
It is not possible to change printer hardware options for printers
connected via LPR (TCP/IP) in Classic Mode. It is recommended you
connect to your printer via AppleTalk instead.
M AC OS X
1. Open the Printer Setup Utility (OS X 10.3) or Printer Center
(OS X earlier versions), and ensure that your printer model is
selected.
2. Choose [Printers] →[Show Info] →[Installable Options].

C9600 Printing Guide> 12
3. Select all hardware options appropriate to your printer, and
click [Apply Changes].

C9600 Printing Guide> 13
C HAPTER 2: B LACKS AND GREYS
B LACK OVERPRINT
Black overprint eliminates the white edge between the printed fonts
and the colored background.
Black overprint can only be used when printing 100 percent black
text over a background color.
Black Overprint may not be available with some software
applications.
NOTES
1. The Black Overprint feature is not included in the Windows PCL 6
driver.
2. When the background color is very dark, the toner may not fuse
correctly. Change the background to a lighter color.
W INDOWS
1. On the [Job Options] tab, click [Advanced].
2. Check [Black Overprint].

C9600 Printing Guide> 14
M AC OS 9
1. Choose [File] →[Print].
2. From the [Printer] menu (1), select your printer model.
3. Select [color Options] (2).
4. Select the [Black Overprint] checkbox (3).
M AC OS X
1. Choose [File] →[Print].
2. From the [Printer] menu (1), select your printer model.
3. Select [Printer Features] (2).
4. From the [Feature Sets] menu (3), select [color Options].
5. Select the [Black Overprint] checkbox (4).
1
2
3
1
2
3
4

C9600 Printing Guide> 15
B LACK PRINTING ( BLACK GENERATION )
To use Black Generation, Office color or Graphic Pro must be the
selected Print Mode.
Your printer prints the color black in one of two ways: Composite
Black or True Black.
C OMPOSITE BLACK
The cyan, magenta, yellow, and black toners are combined to create
composite black.
This will sometimes give a glossier finish, due to the increased
amount of toner. It can also sometimes appear as a slightly
brownish black.
Use composite black when printing photographs.
T RUE ( PURE ) BLACK
Only black toner is used to print true black.
Use True Black when printing a combination of text and graphics. If
you use True Black to print photographs, dark sections of the photos
may appear black.

C9600 Printing Guide> 16
W INDOWS (O FFICE COLOR )
1. On the driver’s [color] tab, select [Office color] (1) and click
the [Options] button.
2. On [Black Finish] (2), make your selection: [Auto] (allow
printer to choose the best method depending on page
content), [True Black] or [Composite Black].
W INDOWS (G RAPHIC P RO )
1. On the driver’s [color] tab, select [Graphic Pro] (1) and click
the [Options] button.
2. From the [Black Finish] menu (2), choose your preferred
setting.
1
2
1
2

C9600 Printing Guide> 17
M AC OS 9 (O FFICE COLOR )
1. From the [File] menu, select [Print].
2. From the [Printer] menu (1) select your printer.
3. In the next menu (2), select [color – Office color].
4. For [Black Finish] menu, choose your preferred setting.
M AC OS 9 (G RAPHIC P RO )
1. From the [File] menu, select [Print].
2. From the [Printer] menu (1) select your printer.
3. In the next menu (2), select [color – Graphic Pro 2].
4. For [Black Finish] menu (3), choose your preferred setting.
1
2
3
1
2
3

C9600 Printing Guide> 18
M AC OS X (O FFICE COLOR )
1. From the [File] menu, select [Print].
2. From the [Printer] menu (1), select your printer.
3. In the next menu (2), select [Printer Features].
4. From the [Feature Sets] menu (3), select [color – Office
color].
5. For [Black Finish] menu (4), choose your preferred setting.
M AC OS X (G RAPHIC P RO )
1. From the [File] menu, select [Print].
2. From the [Printer] menu (1), select your printer.
3. In the next menu (2), select [Printer Features].
4. From the [Feature Sets] menu (3), select [color – Graphic
Pro 3].
5. For [Black Finish] menu (4), choose your preferred setting.
1
2
4
3
1
2
3
4

C9600 Printing Guide> 19
F INE LINES ENHANCEMENT
This feature can be used to emphasize the pen width of very fine
lines (minimum line width).
With some software applications, if this feature is turned ON, the
spaces in bar codes may become too narrow. If this happens, turn
[Adjust Ultra Fine Lines] OFF.
NOTE
This is a feature of the Windows PCL 5c driver only.
1. In the driver’s [Job Options] tab, click [Advanced].
2. Click the checkbox to turn on [Adjust Ultra Fine Lines].
If the option is turned on, a check mark appears in the box.

C9600 Printing Guide> 20
G REYSCALE PRINTING
If you select Greyscale, the printer converts all colors into shades of
grey, and prints using only black toner.
Use Grayscale to speed up printing of proof copies or when you do
not need to print a color document in color.
W INDOWS
1. If using the PCL driver, in the driver’s [Setup] tab, choose
any previously saved [driver settings] you need. See
“Recalling saved driver settings” on page 8.
2. On the driver’s [color] tab, click [Greyscale], then click
[Advanced].
Some applications will attempt to set the halftone screen
information for the printer. If the option to [use printer
halftones] is left at ON, the printer will set its own halftone
screen value, giving a smoother result. It is recommended to
leave this option on.
[optimized greyscale halftones] may take slightly longer to
print but will give best quality.
