olympia electronics GRL-38/90/M User manual

Page 1 from 4923038000_09_001
SELF TESTING NON MAINTAINED EMERGENCY LUMINAIRES
TECHNICAL CHARACTERISTICS (for LED MODULE Specifications see page 4)
220-240V AC/50-60Hz
90 min.
<24 h
POWER-CHARGE indicator, LAMP FAULT–BATT. FAULT indicator, TEST button
From overcharge and deep discharge
IP42
2x12V/7Ah
White Power LEDs
13.3W/14VA
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
5 to 40 C
o
Up to 95%
Aluminum, ABS/PC, PC
3 years (1 year for the battery)
3000lm
302 x 94 x 350 mm.
6358gr.
Thank you for your trust in our products
Olympia Electronics - European manufacturer
GRL-38/180/M
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERIES (Pb)
CHARGING TIME
INDICATIONS - CONTROLS
BATTERY PROTECTION
MINIMUM AUTONOMOUS DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
EMERGENCY ILLUMINATION
LIGHT SOURCE
12V/7Ah
180 min.
4182gr.
GRL-38/90/M
GENERAL
o
These luminaires are used (ta 40 C) where
emergency light is needed. Each luminaire
must be connected permanently to the
mains power supply.
OPERATION DESCRIPTION
When the unit is connected to the mains power
supply (after connecting the battery) the
indicator LAMP FAULT – BATT. FAULT remains
OFF whereas the indicator POWER CHARGE
blinks to indicate that the batteries are charging.
When the batteries are fully charged this
indicator will light permanently. If this indicator
does not light then probably the battery has not
been connected. If the batteries are connected
and the indicator does not light then contact a
qualified service technician for assistance. The
charging procedure is monitored by a
microprocessor and is based on a 3 stage cycle
thus ensuring a fast and full charge of the
battery. The charge current is supplied by a high
efficiency switch mode power supply which
ensures perfect charging even during the
fluctuations of the mains power supply.
BATTERY CUTOFF
The unit enters this state during the power
supply failure and when the battery has been
fully discharged. In this state the luminaire draws
the least power from the battery in order to
prevent
deep discharge.
MANUAL TESTING
Is accomplished by briefly (<1 sec.) pressing the
TEST button. This permits the user to test the
good operation of the luminaire’s emergency
circuit. The unit simulates a power failure and the
lamps are lit using the batteries. This manual test
does not affect the automatic test.
DIMMING OPTION
When the luminaire is in emergency mode, with
corresponding pressings of the button, we can
choose the illumination of 100%, 50%, 33% or
turned off, either to increase the autonomy time
or not to consume the battery power
unnecessarily. This option is canceled when the
network is restored.
LAMP TESTING
The luminaire tests the good condition of the
lamps in emergency mode and warns the user
for probable malfunction. If a lamp is found faulty
then the LAMP FAULT indicator starts to blink. To
verify which lamp is faulty use the TEST button. If

INDICATION LED STATUS (with the mains power supply connected)
Indicator ON Indicator Blinking Indicator OFF
POWER / CHARGE LAMP FAULT / BATT. FAULT
Disconnected battery / not charging Normal operation mode
Charged battery Low emergency duration (replace battery)
Battery under charge Lamp fault (Check lamps and replace if needed)
the faulty lamp is replaced then the error is
automatically restored and the indicator is
turned OFF.
AUTOMATIC EMERGENCY CIRCUIT TEST
The unit automatically tests the emergency
circuit every 15 days (if the battery and mains
power are connected) . During this test the
lamps are turned ON for 3 seconds using the
batteries. In some cases this function might not
be acceptable (i.e in cases this function might
not be acceptable (i.e in cinema theaters) so the
installer must take this into account during the
installation.
AUTOMATIC DURATION TEST
This test is conducted every 6 months by
simulating a power failure, if the battery and
mains power supply are connected. The unit
lights the lamps using the charged battery and
counts the time until the stated duration. If the
lamps are ON during the end of the test then the
unit is restored to its normal operation (lamps
OFF and battery charging). If the lamps go OFF
before the end of the test then the unit is
restored to its normal operation but the LAMP
FAULT / BATT. FAULT indicator is lit to show
that there is a problem with the battery and that
the battery must be replaced. Let it be noted that
this duration test is also done during every long
power failure. If the power failure lasts for a long
time and the luminaire has entered the
BATTERY CUTOFF mode and the duration
measured is not correct then the fault indicator
will light when the power is restored.
ERASING ERRORS
Erasing errors is accomplished with a
prolonged pressing of the TEST button (>5 sec)
when the unit is connected to the mains power
supply. The fault indicated with the indicator
LAMP FAULT / BATT. FAULT will be erased. If
the cause of the fault has not been restored (i.e
burned lamp) then the indicator will light again.
If the fault was caused by a low emergency
duration and you erase the error then this will be
indicated again during the next duration test
after 6 months. In this case (for duration errors)
it is vital to replace the battery before erasing
the error (the error is automatically erased if the
mains power and the battery are disconnected).
WARNING !!!
1. Every test, installation or maintenance
procedure must be done only by qualified
personnel.
2. The unit must be connected to the mains
power supply using a line fuse rated
accordingly.
3. The replacement of the battery and the
light source must be done using parts of
the same type, by the manufacturer or by
a competent person.
t i
in battery recycling
points. Do not incinerate.
Battery replacement
It can be done only by a competent person
and after the mains interruption.
1. Follow the step 2 of the installation
procedure.
2. Disconnect the cables and remove the
old battery.
3. Connect the new battery with the same
type (step 3 of the installation procedure)
and place it in the position of the old one.
4. Follow the step 6 of the installation
procedure and power the device.
Connection to module (After request)
This luminary can be connected to any of the
following modules: Remote module, address
module, wireless module and fault relay
module. If you connect it to a module that
supports inhibit or rest mode, you should
know that these commands can be cancelled
only during normal mode (ie. not in
emergency). For installation refer to step 5 of
the istallation procedure in page 3.
Also refer to the user manual of each module
for additional information.
4. If the luminaire must be isolated from the
mains power supply for more than 2
months then the batteries must be
disconnected by removing the battery
connectors.
5. I s not allowed to discard batteries in to
common trash bins, they must be
discarded only
Page 2 from 4923038000_09_001

1. Install the included mounting accessories to hook the device from the mounting holes (Fig.1).
2. Unfasten the 4 mounting screws to remove the front plastic cover (Fig.1).
3. Make sure that the battery’s cables are connected to the respective poles. Black cable to (-) pole
and red cable to (+) pole (Fig. 2).
4. Install the included cable gland or the rubber o-ring. Pass through the mains cable and stabilize it
by fastening the cable gland. Connect the wires to the terminal blocks L for live wire and Ν for
neutral (Fig. 2).
signal +L, A are also connected, while signals -L, B in the terminal NO (Fig.4).
6. Refit with care the front plastic cover, by fastening the 4 mounting screws (tightening torque
1N*m).
WARNING!!
After the installation has finished, charge the batteries for at least 24 hours so as to obtain the
rated autonomy duration.
5. If you use a module, open a hole in one of the two sides of the luminaire (Fig.3). Install the cable
grommet and pass the 2 signal cables on the C,NO terminal (Fig. 4), minding the correct
polarity. Depending on the module that will be used, the cables, have different names. In C,
INSTALLATION PROCEDURE (For wall mounting only)
4
N
L
3
Fig.2
Fig. 3
5
Module
position
Fig.4
5
Page 3 from 4923038000_09_001
TEST
button
Fig. 1
POWER
CHARGE
indicator
Mounting holes
LAMP FAULT
BATT. FAULT
indicator
Cover
retaining
screws

Page 4 from 4923038000_09_001
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.gr
[email protected]
The light source contained in this luminaire shall only be replaced by the manufacturer, or his
agent, or a similar qualified person.
NOTE! The light source is non-user replaceable.
(*) Non Maintained operation: The luminaire lights
its illumination source, only in power supply’s
failure.
NOTE: LED= Light Emitting Diode
LABELING EXPLANATION:
X: Self contained
0: Non Maintained (*)
A: Including test device
F: Automatic test gear complying
with IEC 61347-2-7 denoted EL-T
90: 1.5 hour duration
180: 3 hours duration
Note!! If a module
relay module), then t , on
the specification label, the letters B C.
will be used (except the fault
he installer should fill in
9 0X 0AF
LED MODULE CHARACTERISTICS
Olympia Electronics S.A.
75 °C max. across the board
Cable connection between main pcb and led module
17.2-19V
14W
CXB1512-0000-000F0HN457E COB LED CREE
Manufacturer
Manufacturer
Voltage Range
Connections
Nominal Power
Temperature (tc)
GRL-38/90/M GRL-38/180/M
