VorticCatchV Retrieval Basket
Quick Reference Guide
Below are steps for VorticCatchV Retrieval Basket (FG-V451P). This instrument has been designed to be used with
Olympus endoscopes to retrieve stones from the biliary tract.
CAUTION: This guide is only a summary of the VorticCatchV Retrieval Basket Instructions for Use. For detailed operating instructions, be sure to
follow the VorticCatchV Retrieval Basket instruction manual included in the device package.
CONTINUED ON NEXT PAGE
1.
Flush contrast injection port.
2.
Close basket by pulling back on the control grip.
3.
Backload basket on to guidewire. Take care to keep the distal tip of the basket parallel to the guidewire.
Using the VorticCatchV Retrieval Basket
4. Advance basket to stone location within the biliary tract.

CONTINUED ON NEXT PAGE
VorticCatchV Retrieval Basket
Quick Reference Guide
CAUTION: This guide is only a summary of the VorticCatchV Retrieval Basket Instructions for Use. For detailed operating instructions, be sure to
follow the VorticCatchV Retrieval Basket instruction manual included in the device package.
5. Separate basket tip from guidewire to minimize interference with basket closure.
Using the VorticCatchV Retrieval Basket (continued)
7.
8.
Pull the basket sheath to capture and withdraw stone under fluoroscopic visualization. Basket does not need to be fully closed during retrieval.
Open and close the basket to remove the retrieved stone
6.
Open basket within the duct by pushing the control grip against the handle.

VorticCatchV Retrieval Basket
Quick Reference Guide
CAUTION: This guide is only a summary of the VorticCatchV Retrieval Basket Instructions for Use. For detailed operating instructions, be sure to
follow the VorticCatchV Retrieval Basket instruction manual included in the device package.
For more information, contact your Olympus
sales representative, or call 800-848-9024.
www.medical.olympusamerica.com
©2020 Olympus America Inc. All rights reserved.
Printed in USA OAIET0420QRG35999
3500 Corporate Parkway, PO Box 610, Center Valley, PA 18034
Manufactured by: Olympus Medical Systems Corp. 2951 Ishikawa-cho, Hachioji-shi, Tokyo 192-8507, Japan.
Specifications, design and accessories are subject to change without any notice or obligation on the part of the manufacturer.
Olympus is a registered trademark of Olympus Corporation, Olympus America Inc., and/or their affiliates. I Medical devices listed may not be available for sale in all countries.
In Case of Stone Impaction (Emergency Lithotripsy Using MAJ-441 Handle)
1. 2.
Insert pin on VorticCatchV control grip into the hole on the
underside of the MAJ-441 lithotripsy handle.
Insert protrusion on VorticCatchV handle into recess on
back of MAJ-441 lithotripsy handle.
3a.
3c.
3b.
Slowly rotate the MAJ-441 rotatable knob until basket is free
from stone impaction.
Hold the VortichCatchV control grip against the MAJ-441
lithotripsy handle.
Set the MAJ-441 rachet to ON.
