Omcan 11003 User manual

Revised - 02/03/2017
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Meat Grinders
Items 11003, 11012, 11016
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 5
-------------------------------------------------------------------------- 5
-------------------------------------------------------------------------------------------- 6
----------------------------------------------------------------------------------------- 6
------------------------------------------------------------------------------- 7 - 9
------------------------------------------------------------------------------------------------ 10
---------------------------------------------------------------------------- 11
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Maintenance
Parts Breakdown
Notes
Warranty Registration
Item 11003 / Item 11012 / Item 11016

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
Safety and Warranty
General Information
WARNINGS AND PRECAUTIONS
1. Close supervision is necessary when any grinder is used near children.
2. Do not grind hard foods such as bones and nuts.
3. Do not disassemble the grinder or place anything (especially nger, spoon, fork, etc.) in the grinder during
operation.
4. Avoid contact with moving parts. Never feed food by hand. Always use food pusher.
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5
Safety and Warranty
5. Always be as thorough as possible when cleaning and sanitizing components. Any part exposed to raw
meat may harbor or develop bacteria causes illness or death.
6. When cleaning with sanitizers, always follow the manufacturer’s recommendations. Never use products
that cause exposed surfaces to render meat unsafe for consumption. Failure to follow this warning may
lead to sickness or death!
1 YEAR PARTS AND LABOUR BENCH WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see www.omcan.com/warranty.html for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!
Technical Specications
Item Number 11003 11012 11016
Description Stainless Steel Hand
Grinder # 10
Stainless Steel Hand
Grinder # 22
Stainless Steel Hand
Grinder # 32
Machine Plate Size 3/16” (4.8mm) / 3/8” (9.5mm)

6
ASSEMBLY
1. Your new manual grinder comes partially assembled and ready for use. However, you need to complete a
few steps to be ready to begin use.
2. Attach handle to grinder Body by inserting Wing screw through Handle frame and into rear of grinder body.
Turn wing nut until tight.
3. Meat auger slides into grinder body and seats into auger bushing.
4. Knife seats onto Square shaft on front of meat auger.
5. Medium or ne grinder plates seat in front of knife onto same square shaft.
6. Hand wheel threads onto front of grinder body and is tightened down to secure unit.
7. Stufng tubes attach to the grinder by removing hand wheel and threading chosen tube through the hand
wheel and then re-tightening the hand wheel onto the grinder body.
CLEANING & SANITATION
Cleaning and sanitization are critical to healthy use of the sausage stuffer. Promptly after each use, disassem-
ble and wash all the components in a sanitizing agent. Rinse with hot water.
REFERENCE
Item Number Model Number Description Manufacturer Model Number
11003 - Meat Grinder Manual #10 Stainless Steel
with Clamp 10HSS
11012 - Meat Grinder Manual #22 Stainless Steel 22HSS
11016 - Meat Grinder Manual #32 Stainless Steel 32HSS
Installation
Maintenance

7
Parts Breakdown
Item 11003

8
Parts Breakdown
Item 11012
Item 11016

9
Parts Breakdown
Item 11003
Item 11012
Item 11016
Item No. Description Position Item No. Description Position Item No. Description Position
41075 Hand Wheel for 10HSS 1 39511 Auger Bushing for 10HSS 7 74432 Stufng Tube (1/2 Inches) for 10HSS 15
74421 Grinder Plateφ3/8 Inches (Selective)
for 10HSS 2 41076 Body for 10HSS 8 74433 Stufng Tube (11/16 Inches) for 10HSS 16
74422 Grinder Plateφ3/16 Inches for 10HSS 3 74426 Handle Frame Assembly for 10HSS 9, 11-12 74434 Stufng Tube (3/4 Inches) for 10HSS 17
74423 Knife for 10HSS 4 74427 Wing Screw for 10HSS 10 74435 Stufng Tube Base for 10HSS 18
74424 Square Shaft for 10HSS 5 74430 Washer for 10HSS 13
74425 Meat Auger for 10HSS 6 74431 Big Eye Screw for 10HSS 14
Item No. Description Position Item No. Description Position Item No. Description Position
74436 Hand Wheel for 22HSS 1 74440 Meat Auger for 22HSS 6 74446 Stufng Tube (1/2 Inches) for 22HSS 13
31872 Grinder Plateφ3/8 Inches (Selective)
for 22HSS 2 31871 Bushing for 22HSS 7 74447 Stufng Tube (11/16 Inches) for 22HSS 14
74437 Grinder Plateφ3/16 Inches for 22HSS 3 74441 Body for 22HSS 8 74448 Stufng Tube (3/4 Inches) for 22HSS 15
74438 Knife for 22HSS 4 74442 Handle Frame for 22HSS 9, 11-12 74449 Stufng Tube Base for 22HSS 16
74439 Square Shaft for 22HSS 5 74443 Wing Screw for 22HSS 10
Item No. Description Position Item No. Description Position Item No. Description Position
74450 Hand Wheel for 32HSS 1 74454 Meat Auger for 32HSS 6 74460 Stufng Tube (1/2 Inches) for 32HSS 13
74451 Grinder Plateφ3/8 Inches (Selective)
for 32HSS 2 31820 Bushing for 32HSS 7 74461 Stufng Tube (11/16 Inches) for 32HSS 14
74452 Grinder Plateφ3/16 Inches for 32HSS 3 74455 Body for 32HSS 8 74462 Stufng Tube (3/4 Inches) for 32HSS 15
74453 Knife for 32HSS 4 74456 Handle Frame for 32HSS 9, 11-12 74463 Stufng Tube Base for 32HSS 16
31821 Square Shaft for 32HSS 5 74457 Wing Screw for 32HSS 10

10
Notes
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________

11
Warranty Registration
Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,
cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:
Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la
carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:
Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at
the perforation and then send to the address specied below. You can also register online by visiting:
OMCAN
PRODUCT WARRANTY REGISTRATION
3115 Pepper Mill Court,
Mississauga, Ontario
Canada, L5L 4X5
www.omcan.com/warrantyregistration.html
or email to: [email protected]
Purchaser’s Information
Name: Company Name:
Address:
Telephone:
City: Province or State: Postal or Zip: Email Address:
Country: Type of Company:
Restaurant Bakery Deli
Dealer from which Purchased: Butcher Supermarket Caterer
Dealer City: Dealer Province or State: Institution (specify):
Invoice: Other (specify):
Model Name: Model Number: Serial Number:
Machine Description:
Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):
Would you like to extend the warranty? Yes No

Por correo en Canadá
Pour postale au Canada
For mailing in Canada
Por correo en los EE.UU.
Pour diffusion aux États-Unis
For mailing in the US
OMCAN
PRODUCT WARRANTY REGISTRATION
4450 Witmer Industrial Estates, Unit 4,
Niagara Falls, New York
USA, 14305
Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North
American food service industry. Our success over these many years can be attributed to our commitment
to strengthen and develop new and existing relationships with our valued customers and manufacturers.
Today with partners in North America, Europe, Asia and South America, we continually work to improve
and grow the company. We strive to offer customers exceptional value through our qualied local sales
and service representatives who provide convenient access to over 3,500 globally sourced products.
Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et
matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces
nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles
et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en
Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et
développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à
nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 3500
produits provenant du monde entier.
Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros
de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir
a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos
clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan
continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor
excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un
fácil acceso a más de 3,500 productos con origen a nivel mundial.
