Omix-Ada 13551.23 User manual

Copyright © 2018 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Dash Multi-Mount System for Wrangler JL
Page 1/3
Part 13551.23
OMIX-ADA®TECHNICAL SUPPORT
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: [email protected]
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
1. Multi-Mount Tray (1)
2. Universal Ball Mount (1)
3. Cap Piece (1)
4. 17mm Ball Phone Mount (1)
Components
1
2
4
3
Four Congurations for Dash Multi-Mount System:
*Shown with Rugged Ridge Phone Mount (Part #13551.13)
No Accessory Camera/Tripod
Mount Only
Phone/GPS
Mount Only*
Phone and
Camera Mount*
JL Multi Mount System.indd 1 9/7/18 9:51 AM

Copyright © 2018 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Dash Multi-Mount System for Wrangler JL
Page 2/3
Step 1
Remove interior rubber liner. May need to pry
a corner to lift.
Step 2
Remove two Phillips screws from inside
compartment.
Step 3
Place Multi-Mount System into position. Assure
area is completely clean before installing.
Step 4
Reinstall Phillips screws removed from step 2
through multi-mount system into the dash.
JL Multi Mount System.indd 2 9/7/18 9:51 AM

Copyright © 2018 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Dash Multi-Mount System for Wrangler JL
Page 3/3
2. Press Phone Mount adapter piece into Ball Mount.
1. Place Outer Ring over end of Ball Mount.
3. Pull Outer Ring over Phone Mount adapter and
twist to secure.
JL Multi Mount System.indd 3 9/7/18 9:51 AM
