Omix-Ada Havoc Offroad HFB-06-003 User manual

Copyright © 2022 Omix-Ada®, Inc.
Nerf Step, Bronco 4-Door
Page 1/3
460 HORIZON DR. | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | www.Omix-ADA.com
Part # HFB-06-003
Rev. 0. 03/22
1. Nerf Step ......................................................... (2)
2. Bracket, Front.................................................. (2)
3. Bracket, Middle and Rear............................. (4)
4. M8 - 1.25 x 25mm Carriage Bolt.................. (12)
5. M8 - 1.25 Serrated Flange Nut .................... (12)
6. M10 - 1.25 x 25mm Serrated Flange Bolt ... (12)
Components
Havoc Offroad®TECHNICAL SUPPORT
PHONE: M-F 8am - 5pm EST 1-800-449-6649
FOR WARRANTY OR TECH CONCERNS EMAIL: [email protected]
2
1
3
4
5
6

Copyright © 2022 Omix-Ada®, Inc.
Nerf Step, Bronco 4-Door
Page 2/3
460 HORIZON DR. | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | www.Omix-ADA.com
Part # HFB-06-003
Rev. 0. 03/22
2. Mount the Middle and Rear brackets
to the rocker panel.
Attach the brackets (3) by threading the provided
serrated flange bolts (6) to the threaded holes of the
Bronco rocker panel. Do Not fully thighten at this time.
3. Attach the Nerf step (1) to the mounted brackets.
It’s best to have an assistant to help lift the step into
place. The tabs on the step mount in front of the bracket
tabs. Use the provided carriage bolts (4) to insert and
lock into the step tab and through the bracket tab.
Then secure with the serrated flange nuts (5). Hand
tighten this hardware at this time.
We suggest attaching the step to the middle bracket
first to help support the weight of the step.
1. Start by attaching the brackets to the Bronco
rocker panel.
The furthest front bracket (2) are a different shape
than the middle or rear brackets. Attach the front
bracket by threading the provided serrated flange
bolts (6) to the threaded holes of the Bronco rocker
panel. Do Not fully thighten at this time.

Copyright © 2022 Omix-Ada®, Inc.
Nerf Step, Bronco 4-Door
Page 3/3
460 HORIZON DR. | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | www.Omix-ADA.com
Part # HFB-06-003
Rev. 0. 03/22
5. Tighten the hardware attaching the step
to the brackets.
Avoid using power or air tools. Tighten to 20ft lbs torque
to secure the step to the bracket.
Repeat the same procedure to the other side.
4. Make any adjustments at this time, then fully tighten
the brackets to the body.
Avoid using power or air tools. Tighten to 20ft lbs torque
to secure the bracket to the Bronco.
