Omix-Ada Rugged Ridge Alloy 13216.03 User manual

Copyright © 2016 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 100 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Ballistic Front Seat Covers
Page 1/4
Part 13216.03
13216.04
OMIX-ADA®TECHNICAL SUPPORT
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: [email protected]
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
1. Ballistic Front Back Cover, RH (1)
2. Ballistic Front Back Cover, LH (1)
3. Ballistic Front Seat Cover, RH (1)
4. Ballistic Front Seat Cover, LH (1)
5. Ballistic Head Rest Cover (2)
Components
1
2
3
4
5

Copyright © 2016 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 100 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Ballistic Front Seat Covers
Page 2/4
3. Zip two zippers on back of seat cover.
To Install Front Seat Covers:
1. Remove headrest from seat.
2. Fully slide Front Back Cover over top portion of seat.
4. Push bottom fabric ap through crease in bottom
of seat toward rear of vehicle and secure to rear
fabric of back cover.

Copyright © 2016 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 100 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Ballistic Front Seat Covers
Page 3/4
6. Press fabric down around head rest buttons until
through cut outs in fabric.
5. Secure airbag fabric ap by pressing fabric into
corresponding cut out on side of seat.
7. For 2007-2010 models, slide Head Rest Covers over
head rests. For 2011-current models, slide Head Rest
Covers over head rests and secure with hook and
loop fabric.
8. Replace head rest on seat.

Copyright © 2016 Omix-Ada®, Inc.
460 HORIZON DR. SUITE 100 | SUWANEE, GA 30024 | PHONE: [phone] | FAX: [phone] | [email protected]
Ballistic Front Seat Covers
Page 4/4
11. Secure front and rear buckles underneath seat.
Tighten straps.
12. Hook side hooks underneath seat onto straps as
shown on right.
9. Place Front Seat Cover on bottom portion of seat.
10. Press rear buckles through crease in rear of seat.
13. Slide side fabric around seat adjustment bar and
secure with corresponding hook and loop fabric.
