NJ-Series Power Supply Unit
NJ-PA/PD
Powerful power supply unit to supply
stablepowerto the NJ-series controller.
Stable power supply is available from the NJ-series
CPU Unit to each I/O Unit via the dedicated bus.
Lineups are provided for AC and DC input types with 30 W output.
Features
•AC input type (100 to 240 VAC)/DC input type (24 VDC) with 30 W output allows power supply to large-scale congurations.
•Operating output contact indicates the CPU operation status (available in all models).
Ordering Information
International Standards
•The standards are abbreviated as follows: U: UL, U1: UL(Class I Division 2 Products for Hazardous Locations), C: CSA, UC: cULus , UC1: cULus
(Class I Division 2 Products for Haza rdous Locations), CU: cUL, N: NK, L: Lloyd, and CE: EC Directives.
•Contact your OMRON representative for further details and applicable conditions for these standards.
Power Supply Units
Note:Power supply units for the CJ-Series cannot be used as a power suppl y for a CPU rack of the NJ system or as a power supply for an
expansion rack.
Accessories
There is no accessory for the NJ-series Power Supply Unit.
Sysmac is a trademark or registered tra demark of OMRON Corporation in Japan and other countries for OMRON factory automation pr oducts.
Other company names and product names in this document are the trademarks or registered trademarks of their respective companie s.
NJ-PD3001
Product Name
Power
supply
voltage
Output
current
Output
capacity Options
Model Standards
5-VDC
output
capacity
24-VDC
output
capacity
Total power
consumption
24-VDC
service
power
supply
RUN
output
Maintenance
forecast
monitor
AC Power
Supply Unit
100 to 240
VAC
6.0 A 1.0 A 30 W No Yes No
NJ-PA3001
UC1, N, L,
CE
DC Power
Supply Unit 24 VDC NJ-PD3001
Intech Systems Chennai Pvt. Ltd, Chennai-600 032
Ph: [phone] Fax: [phone]
E-mail: [email protected] Website: www.intechchennai.com
Authorised Distributors:-

NJ-PA/PD
2
General Specification
*1. The AC and DC values above are given for a cold start, and the AC values are at room temperature. The AC inrush control circuit uses a
thermistor element with a low-temperature current control characteristic. If the ambient temperature is high or the Controller is hot-started, the
thermistor will not be sufficiently cool, and the inrush current given in the table may be exceeded by up to twice the given value. The DC inrush
control circuit uses a capacitor-charging delay circuit. If the power is OFF for only a short time for a hot-start, the capacitor will not sufficiently
discharge and the inrush current given in the table may be exceeded by up to twice the given value. An inrush current of approximately 4 A
may occur and continue for 1 s when the power is turned ON. When selecting fuses, breakers, and external DC power supply devices for
external circuits, allow sufficient margin in shut-off performance.
*2. Internal components in the Power Supply Unit will deteriorate or be damaged if the Power Supply Unit is used for an extended period of time
exceeding the power supply output capacity or if the outputs are shorted.
*3. Supported only when mounted to CPU Rack.
*4. The tests can also be performed with the LG terminal and GR terminal connected to each other.
*5. Change the applied voltage gradually using the adjuster on the Tester. If the full dielectric strength voltage is applied or turned OFF using the
switch on the Tester, the generated impulse voltage may damage the Power Supply Unit.
Item Specifications
Model NJ-PA3001 NJ-PD3001
Supply voltage 100 to 240 VAC (wide-range), 50/60 Hz 24 VDC
Operating voltage and
frequency ranges
85 to 264 VAC, 47 to 63 Hz 19.2 to 28.8 VDC
Power consumption 120 VA max. 60 W max.
Inrush current *1
At 100 VAC:
20 A/8 ms max. for cold start at room temperature
At 200 VAC:
40 A/8 ms max. for cold start at room temperature
At 24 VDC:
30 A/20 ms max. for cold start
Output capacity *2
5 VDC, 6.0 A (including supply to CPU Unit using CPU Rack)
5 VDC, 6.0 A (using Expansion Rack)
24 VDC, 1.0 A
Total: 30 W max.
Output terminal
(service supply)
Not provided
RUN output *3
Contact configuration: SPST-NO
Switch capacity: 250 VAC, 2 A (resistive load)
120 VAC, 0.5 A (inductive load), 24 VDC, 2A (resistive load)
Replacement notification
function
Not provided
Insulation resistance *420 MΩmin.
(at 500 VDC) between AC external and GR terminals
20 MΩmin.
(at 500 VDC) between DC external and GR terminals
Dielectric
strength *4*5
2,300 VAC 50/60 Hz for 1 min between AC external and GR
terminals
Leakage current: 10 mA max.
1,000 VAC 50/60 Hz for 1 min between DC external and GR
terminals
Leakage current: 10 mA max.
Noise immunity 2 kV on power supply line (Conforms to IEC 61000-4-4.)
Vibration resistance 5 to 8.4 Hz, 3.5-mm amplitude, 8.4 to 150 Hz, acceleration: 9.8 m/s2in X, Y, and Z directions for 100 min (Time coefficient: 10 min ×
coefficient factor 10 = total time 100 min) (according to IEC 60068-2-6)
Shock resistance 147 m/s23 times each in X, Y, and Z directions (Relay Output Unit: 100 m/s2) (according to IEC 60068-2-27)
Ambient operating
temperature
0 to 55°C
Ambient operating humidity 10% to 90% (with no condensation)
Atmosphere Must be free from corrosive gases.
Ambient storage
temperature
-20 to 75°C
Grounding Less than 100 Ω
Enclosure Mounted in panel
Weight 470 g max. 490 g max.
CPU Rack dimensions
174.7 to 484.7 × 90 × 90 mm (W × D × H) (not including cables)
W = 70 (Power Supply Unit) + 90 (CPU Unit) + 20 × n + 31 × m + 14.7 (end cover)
n is the number of 32-point I/O Units or I/O Control Units and m is the number of other Units.
Safety measures Conforms to cULus, EC Directives, NK and LR.

3
NJ-PA/PD
External Interface
NJ-PA3001
NJ-PD3001
AC Input
Supply 100 to 240 VAC (allowable: 85 to 264 VAC).
The NJ-PA3001 has a wide input range, so it does not have voltage switching terminals.
DC Input
Supply 24 VDC (allowable: 19.2 to 28.8 VDC.)
LG
Ground to a resistance of 100 Ωor less to increase noise resistance and avoid electric shock.
GR
Ground to a resistance of 100 Ωor less to avoid electric shock.
RUN Output
The internal contacts for the RUN output turn ON when the CPU Unit is in RUN status.
Connector
AC input
LG
GR
RUN output
POWER Indicator
(PWR LED)
Connector
+ (DC input)
– (DC input)
LG
GR
RUN output
POWER Indicator
(PWR LED)

NJ-PA/PD
4
Wiring
zAbout Power Supply
For AC/DC power supply
For grounding wire
zCrimp Terminals
The terminals on the Power Supply Unit are M4, self-raising terminals with screws.
Crimp Terminals for AC Power Supplies
Crimp Terminals for DC Power Supplies
Crimp terminal for the grounding wire
Precautions for Use
Compatible CPU Models
NJ-PA3001/NJ-PD3001 are dedicated for NJ-series.
Please make sure to use NJ-PA3001/NJ-PD3001 for all products including NJ-series CPU rack and expansion rack.
Power Supply Units Current Consumption
Checking Current Consumption and Power Consumption
After selecting a Power Supply Unit based on considerations such as the power supply voltage, calculate the current and power requirements for
each Rack.
Condition 1: Current Requirements
There are two voltage groups for internal power consumption: 5 V and 24 V.
Current consumption at 5 V (internal logic power supply)
Current consumption at 24 V (relay driving power supply)
Condition 2: Power Requirements
For each Rack, the upper limits are determined for the current and power that can be provided to the mounted Units. Design the system so that
the total current consumption for all the mounted Units does not exceed the maximum total power or the maximum current supplied for the voltage
groups shown in the following tables.
The maximum current and total power supplied for CPU Racks and Expansion Racks according to the Power Supply Unit model are shown below.
Note: 1. For CPU Racks, include the CPU Unit current and power consumption in the calculations. When expanding, also include the current and
power consumption of the I/O Control Unit in the calculations.
2. For Expansion Racks, include the I/O Interface Unit current and power consumption in the calculations.
*Including supply to the CPU Unit.
Recommended wire
diameter
AWG 14 to 20
(Cross section 0.517 to 2.08 mm2)
Recommended wire
diameter 2 mm2or thicker
Power
Supply
Units
Max. current supplied (C)
Max. total
power
supplied
(A) 5-VDC CPU
Racks*
(A)5-VDC
Expansion
Rack
(B) 24 VDC
NJ-PA3001 6.0 A 6.0 A 1.0 A 30 W
NJ-PD3001 6.0 A 6.0 A 1.0 A 30 W
7 mm max.
7 mm max. 7 mm max.
7 mm max. 7 mm max.
Conditions 1 and 2 below must be satisfied.
Condition 1: Maximum Current
(1) Total Unit current consumption at 5 V ≤(A) value
(2) Total Unit current consumption at 24 V ≤(B) value
Condition 2: Maximum Power
(1) × 5 V + (2) × 24 V ≤(C) value

NJ-PA/PD
5
Example: Calculating Total Current and Power Consumption
Example: When the Following Units are Mounted to a NJ-Series CPU Rack Using a NJ-PA3001 Power Supply Unit
Using the Sysmac Studio to Display Current Consumption and Width
CPU Rack and Expansion Rack current consumption and width can be displayed by selecting CPU/Expansion Racks from the Configurations
and Setup in the Multiview Explorer. If the capacity of the Power Supply Unit is exceeded, an error icon is displayed in the power supply unit of a
corresponding rack. For details, refer to Sysmac Studio Operation manual (W504).
Unit type Model Quantity Voltage group
5 V 24 V
CPU Unit NJ501-1500 1 1.90 A -
I/O Control Unit CJ1W-IC101 1 0.02 A -
Basic I/O Units (Input Units) CJ1W-ID211 2 0.08 A -
CJ1W-ID231 2 0.09 A -
Basic I/O Units (Output Units) CJ1W-OC201 2 0.09 A 0.048 A
Special I/O Unit CJ1W-DA041 1 0.12 A -
CPU Bus Unit CJ1W-SCU22 1 0.28 A -
Current consumption
Total
1.9 A+0.02 A+0.08 A ×
2+0.09 A × 2+0.09 A ×
2+0.12 A+0.28
0.048 A × 2
Result 2.84 A (≤6.0 A) 0.096 A (≤1.0 A)
Power consumption Total 2.84 × 5 V = 14.2 W 0.096 A × 24 V = 2.3 W
Result 14.2 W + 2.3 W = 16.5 W (≤30 W)
