Onespace 50-JN1301 User manual

7
ULTRAMODERN GLASS COMPUTER DESK WITH DRAWERS
ASSEMBLY INSTRUCTIONS
MODEL 50-JN1301
SUPPLIER CODE: JNFF
For fastest service on claims, requests for replacement parts,
www.comfortproducts.net/support
e-mail: [e-mail]
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
or questions, please visit our website at:
OneSpace is a Trademark of Comfort Products, Inc.
™

mumixampotelbaT
weight capacity
=
66lbs
mumixam
rewarD
weight capacity
=
sbl22
ASSEMBLY OVERVIEW (50-JN1301) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
2 of 13

ITEMS ARE NOT SHOWN TO SCALE.
PARTS LIST 1 OF2 (50-JN1301) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
#
DESCRIPTION
STOCK #
QTY.
1 Leg 51-JN1301LG 2
2Foot 51-JN1301FT 4
3 Support Board 51-JN1301SB 1
4Left Board 51-JN1301LB 1
5Right Board 51-JN1301RB 1
6Middle Board 51-JN1301MB 1
7 Bottom Board 51-JN1301BM 1
8 Back Board 51-JN1301BB 1
10 Crossbar 51-JN1301CR 2
3 of 13
9a Outer Rollers
51-JN1301DS 2 sets
of 4
9b Inner Rollers
Left Right
Left Right

ITEMS ARE NOT SHOWN TO SCALE.
PARTSLIST 2OF2 (50-JN1301) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
#
DESCRIPTION
STOCK #
QTY.
11 Desktop 51-JN1301DT 1
12 Glass Side Panel 51-JN1301SP 2
13 Drawer Back 51-JN1301DB 2
14 Drawer Left
Panel 51-JN1301DL 2
15 Drawer Right
Panel 51-JN1301DR 2
16 Drawer Front 51-JN1301DF 2
17 Drawer Bottom 51-JN1301DBM 2
4 of 13

5 of 13
EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
HARDWARE LIST (50-JN1301)
PART DESCRIPTION QT Y.
A M6 X 70MM 4
GM6 X 45MM 2
K
M4 X 18MM 4
L
M4 X 35MM 8
C 21
IF YOU ARE MISSING ANY OF THESE PARTS,
OR IF YOU HAVE A DAMAGED PART, PLEASE
VISIT WWW.COMFORTPRODUCTS.NET/SUPPORT
REFERENCE THE MODEL # ON THE FRONT OF
THIS MANUAL. SIMPLY COMPLETE THE INFORMATION,
INCLUDING THE PART YOU NEED. THE PART WILL
NORMALLY BE SHIPPED WITHIN 48 HOURS.
- READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING.
- REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION.
- OPEN THE HARDWARE AS NEEDED .
- ASSEMBLE IN AN AREA WITH PLENTY OF SPACE.
- READ EACH STEP BEFORE BEGINNING CONSTRUCTION.
- HAVE A SCREWDRIVER BEFORE YOU BEGIN ASSEMBLING
(NOT INCLUDED).
- NEVER FORCE THE SCREWS OR FITTINGS.
- KEEP THIS MANUAL FOR FUTURE REFERENCE.
- TIGHTEN ALL THE SCREWS EVERY 6 MONTHS.
CLEANING AND CARE
- CLEAN SURFACES WITH A DRY OR DAMP CLOTH.
- DO NOT USE ABRASIVE CLEANERS.
- DO NOT USE A POWER DRILL.
HARDWARE KIT
STOCK # 51-JN1301HA
D
M
N
Cam
Drawer Handle
Allen Wrench
21
B Dowel 6
E M4 x 14MM 16
F M6 x 30MM 8
H M6 x 25MM 4
I M4 x 14MM 4
J Cap & Washers 4
1
2
Extra Hardware (A - L) 1 set

ASSEMBLY INSTRUCTIONS (50-JN1301)
6 of 13
STEP 1
Attach the feet (2) to the bottom of the legs (1).
STEP 2
Attach the legs to the support board (3) with four screws (A), tightening with the Allen wrench (N).
A
A
A x 4
N

ASSEMBLY INSTRUCTIONS (50-JN1301)
7 of 13
STEP 3
Screw six Minix Bolts (C) into the corner holes of the Bottom Board (7) and insert the six Dowels (B) into the
middle holes.
STEP 4
Place six Cams (D) into the lower holes of the Left Board (4), Right Board (5), and Middle Board (6). Note the
arrow on the face of each Cam. It should be pointing toward the nearest edge of the board where the
Minix Bolt (C) will go in.
Before attaching the Left, Right, and Middle Boards to the Bottom Board (7), make sure the unused Cam holes
are all positioned on the same side. Then, align the boards with the six Minix Bolts (C) and six Dowels (B) and
push them down until tight. Tighten the six Cams (D) clockwise half a turn to lock the boards into place.
B x 6
D x 6
C x 6
4
6
7
7
5
The unused holes should be
on the same side.
CAUTION:
Do not overtighten
cams.
C
D

ASSEMBLY INSTRUCTIONS (50-JN1301)
8 of 13
STEP 5
Screw seven Minix Bolts (C) into the Back Board (8). Place seven Cams (D) in the remaining holes of the boards
assembled in Step 4. Attach the Back Board (8) by aligning the Minix Bolts (B) with the holes. Tighten the
Cams clockwise half a turn to lock the boards into place.
STEP 6
Attach two Right Outer Rollers (9a) to the Right Board (5) and Middle Board (6) using four screws (E). Refer to the
drawing below for which holes in the rollers to use.
C x 7
E x 4
D x 7
CAUTION:
Do not overtighten
cams.
C
D
9a RIGHT

ASSEMBLY INSTRUCTIONS (50-JN1301)
9 of 13
STEP 7
Attach two Left Outer Rollers (9a) to the Left Board (4) and Middle Board (6) using four screws (E). Refer to the
used for the right roller.
Attach two Crossbars (10) to the Left, Middle, and Right Boards using four Screws (F) at the ends and
two Screws (G) in the middle.
STEP 8
E x 4
F x 4
F
F
G x 2
G
10
9a LEFT
N

ASSEMBLY INSTRUCTIONS (50-JN1301)
10 of 13
STEP 9
Attach the legs to the Bottom Board (7)
using four Screws (F).
Attach the glass Desktop (11) to the Crossbars
using four Screws (H).
STEP 10
F x 4
H x 4 10
N
N
