Orion VALUE SERIES User manual

Installation and User’s Guide
Installation and User’s Guide
VALUE SERIES LCD MONITOR
TFT-LCD MONITOR
(SECURITY)
http://www.orionimages.com
All contents of this document may change without prior notice, and actual product appearance may differ
from that depicted herein

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
Warning Statements
* Follow this safety instruction to use the monitor properly and prevent the damages.
* This safety instruction has “ Warning” and “ Caution” as below.
WARNING: If the user does not follow this instruction,
it may cause the serious damage to the user.
CAUTION: If the user does not follow this instruction, it may cause the slight
damage to the user or cause some damages to the monitor.
* Keep this user’s guide book for later use.
Never remove the back over and touch
the inside of the monitor. If you need a
service, please contact the service center.
Keep away the monitor from the
direct sunlight and a heating appliance.
Connect the power code to the wall
outlet tightly. If the power code or plug are
defective and the wall outlet is not tight,
p
lease do not use them.
Never push objects of any kind into this
product as they may result in a risk of fire
or electric shock.
2 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg2

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
Warning Statements
Do not install this monitor on the outside
and near water. If may cause damage to
the product, electric shock and fire.
For cleaning do not use liquid cleaners.
Never touch the power plug with wet-
hands.
When lightning and thundering, unplug
the monitor from the wall outlet and never
touch it.
Unplug this product from the wall outlet,
when It does not operate for a long time.
When smoking and noising from the
monitor, unplug the product from the wall
outlet and contact a service center.
How to fix
1. Do not open this product as it contains high voltage inside.
2. It may create an electric shock.
3. It the user disassembles and remove the back cover, it does not make sure
4. To make up for the damages and do a service and exchange the monitor..
3 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg3

4
Installation and User’s Guide
htt
p
://www.orionima
g
es.com
7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg4
Cautions
Install this monitor some distance
From the wall and do not install unless
Proper ventilation is provided.
Place this product on a stable place.
If not, it may fall, causing serious
Damages to the monitor and people.
The openings must not be blocked by
curtain, rug or other similar surface. When carrying this monitor, be careful
not to damage the panel and drop it
It may cause some trouble.
Before carrying the monitor, tum it off
and Unplug the signal cables and the
power code From the wall outlet.
Take the power plug out from the wall
outlet. Do not pull the cable. It may
snap the inner wires and cause
overheating and fire.
Install this monitor about 50cm far from
the eyes and an angle of 0~15 degrees
below eyes. Too close installation may
cause having weak sight.
Do not press the LCD panel with hands
or the sharpened material hardly.
For cleaning, unplug the monitor from
the Wall outlet. Do net use the liquid
cloth. Use the soft cloth.
Do not use the chemical liquid for
cleaning. It may cause fading and
breakage.

5
Installation and User’s Guide
htt
p
://www.orionima
g
es.com
7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg5
TABLE OF CONTENTS
1. INSTALLATION .................................................................................................................
1.1 Parts ……....................................................................................................................
2. FEATURES …..................................................................................................................
2.1 Display Mode …….……..............................................................................................
3. OSD SETTING .........................................................................................................
6. TROUBLESHOOTING
..
....
.
.......................................................
.................
....................
7. LIMITED LIFETIME WARRANTY
..
....
.
.......................................................
.................
...
4. CONTROL BUTTON
..
....
.
.......................................................
................
.........................
1.2 How to Install …….........................................................................................................
5. INFORMATION TO THE USER
..
....
.
.......................................................
................
.........
2.2 Specifications (17INCH) .............................................................................................
2.3 Specifications (19INCH) .............................................................................................
6
6
8
8
10-17
20
21
18
7
19
8
9

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
INSTALLATION
1.1 P
a
r
ts
6 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg6

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
INSTALLATION
1.2 How to Install
WARNING: Tilting more than 10 degrees to the front or 30 degrees to the back
may cause collapse of the product.
7 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg7

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
FEATURES
2.1 Display Mode
2.2 Specifications (17 INCH)
8 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg8

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
FEATURES
2.3 Specification (19 INCH)
9 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg9

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.1 OSD MENU in PC
Menu PC
Contrast: To adjust the brightness and darkness of the object and backgrounds.
Brightness: To adjust the brightness of the entire picture.
H-Position: To adjust the horizontal position of picture.
V-Position: To adjust the vertical position fo picture.
Clock: To adjust the horizontal size of the entire screen image.
Color Mode: To select color tone of the entire picture.
Auto Colo
r
: To adjust color (brightness / contrast, etc) automatically.
Auto Adjust: Horizontal/vertical positions and phase, clock are automatically
adjusted.
10 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg10

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.2 Color Mode
For a general color tone.
Normal:
For warm colors with reddish tone.
Warm:
For cool colors with bluish tone.
Cool:
User: Adjust the color tone with R / G / B control.
11 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg11

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.3 OSD MENU in PC
Menu OSD
To select the
p
referred lan
g
ua
g
e.
Lan
g
ua
g
e:
To adjust the horizontal position of OSD window.
H-Position:
To ad
j
ust the vertical
p
osition of OSD window.
V
-Position:
OSD Timer: To adjust the time of OSD window display.
Transparent: To adjust the transparency of OSD window.
Recall: To recall the initial setting.
12 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg12

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.4 OSD MENU in PC
Menu Function
select the sleep time if you want automatically power
off on a certain time.
Sleep Timer:
To lock the key function.
Ke
y
Lock:
Exit from ke
y
lock: Please AC power off and on with
pushing the menu key.
To alternate Video1 and Video2 at the set time.
Time C
y
cle:
13 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg13

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.5 Sound
Menu Sound
Volume: A
djust
aud
i
o
v
o
l
u
m
e
Bass: A
djust
aud
i
o
bass
Treble: A
djust
aud
i
o
t
r
eb
l
e
Balance: Adjust audio balance (left-right)
Mute: Select the sound on and off
14 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg14

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.6 OSD MENU in Video or S-Video
Menu Picure
Contrast: To adjust the brightness and darkness of the object and
back
g
rounds.
Brightness: To adjust the brightness of the entire picture.
Hue: To adjust colors naturally. This function is activated at
NTSC video signal.
Saturation: To adjust colors to deeper or lighter color.
Sharpness: To adjust the sharpness of video image.
Color Temp: Normal: For a
g
eneral color tone.
Warm: For warm colors with reddish tone.
Cool: For cool colors with bluish tone.
Scaling:
4.3: For general picture size
Zoom: Zoom in vertical direction.
Picture Mode: Standard: For general contents. It fits most contents.
Vivid: For a clear display
Movie: For movies.
User: When the user wants to set the value.
15 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg15

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.7 OSD MENU in Video or S-Video
The control is same as PC.
Menu OSD
16 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg16

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
OSD (On Screen Display) SETTING
3.7 OSD MENU in Video or S-Video
The control is same as PC.
Menu Function
17 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg17

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
CONTROLL BUTTON
Auto / Source / Exit:
Select Mode (Hot Key).
At the PC mode, Push the key over about 1set.
View the previous function in the Main menu.
Exit from Main menu.
Auto adjust (Hot Key, PC mode).
Select Video 1 or 2mode during “Time cycle”
Action (Hot Key).
Menu / Select: Activate the Main Menu.
View the next function in the Main Menu.
Select the sub menu.
V
olume control (Hot Key): Push the key over about 1 set.
Increase the value of the specific function which has been
selected.
Freezer function (Hot Key)
A
djust Contrast / Brightness (Hot Key): OSD Item Down.
Decrease the value of the specific function which has been
selected.
Turn On / Off monitor
18 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg18

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one more
of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
zConsult the dealer or an experienced radio / TV technician for help.
WARNING:
The manufacturer is not responsible for any Radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate
the equipment."
19 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg19

Installation and User’s Guide
htt
p
://www.orionima
g
es.com
TROUBLESHOOTING
* When the following troubles are occurred, follow the trouble shooting. Before contacting a
service center.
20 7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone] pg20
