Otto Bock Kimba neo User manual

Kimba Neo, Kimba Cross, Kimba Inline
Instructions for use ............................................................................................... 3

2 Kimba Neo, Kimba Cross, Kimba Inline

Foreword1 6..............................................................................................................................................................
Product description2 6............................................................................................................................................
Function2.1 6..............................................................................................................................................
Product overview2.2 6..................................................................................................................................
Kimba Neo2.2.1 6...........................................................................................................................................
Kimba Cross2.2.2 8........................................................................................................................................
Kimba Inline2.2.3 9.........................................................................................................................................
Intended use3 9........................................................................................................................................................
Indications for use3.1 9................................................................................................................................
Indications3.2 10.........................................................................................................................................
Contraindications3.3 10................................................................................................................................
Absolute Contraindications3.3.1 10..................................................................................................................
Relative Contraindications3.3.2 10....................................................................................................................
Qualification3.4 10.......................................................................................................................................
Safety4 10..................................................................................................................................................................
Explanation of warning symbols4.1 10............................................................................................................
Safety instructions for assembly and adjustments4.2 10....................................................................................
Safety instructions for use4.3 10....................................................................................................................
Side effects4.4 14........................................................................................................................................
Further information4.5 14..............................................................................................................................
Nameplate and warning labels4.6 14..............................................................................................................
Nameplate4.6.1 14..........................................................................................................................................
Kimba Neo4.6.1.1 14.........................................................................................................................................
Kimba Cross, Kimba Inline4.6.1.2 15...................................................................................................................
Warning labels4.6.2 15...................................................................................................................................
Delivery5 16...............................................................................................................................................................
Scope of delivery5.1 16................................................................................................................................
Kimba Neo5.1.1 16.........................................................................................................................................
Kimba Cross5.1.2 16......................................................................................................................................
Kimba Inline5.1.3 16.......................................................................................................................................
Options5.2 16.............................................................................................................................................
Storage5.3 16..............................................................................................................................................
Storage during daily use5.3.1 16......................................................................................................................
Storage during extended disuse5.3.2 17............................................................................................................
Preparing the product for use6 17.........................................................................................................................
Assembly6.1 17...........................................................................................................................................
Kimba Neo6.1.1 17.........................................................................................................................................
Kimba Cross6.1.2 18......................................................................................................................................
Equipment package6.1.2.1 19.............................................................................................................................
Kimba Inline6.1.3 20.......................................................................................................................................
Retrofitting the respirator platform (Kimba Neo only)6.2 20................................................................................
Installation with a seat facing opposite to direction of travel6.2.1 21......................................................................
Installation with a seat facing in the direction of travel6.2.2 23..............................................................................
Delivery7 24...............................................................................................................................................................
Transport to the customer7.1 24....................................................................................................................
Handing over the product7.2 24.....................................................................................................................
Use8 25......................................................................................................................................................................
Instructions for use8.1 25..............................................................................................................................
Kimba Neo8.2 25.........................................................................................................................................
Seating unit8.2.1 25........................................................................................................................................
Kimba Neo seating unit8.2.1.1 25........................................................................................................................
Alternative seating systems without own seat angle adjustment8.2.1.2 26.................................................................
Seating shell interface8.2.2 27.........................................................................................................................
Table of contents
3Kimba Neo, Kimba Cross, Kimba Inline
Table of contents

Push bar8.2.3 28............................................................................................................................................
Adjusting the push bar8.2.3.1 28.........................................................................................................................
Wheel lock8.2.4 28.........................................................................................................................................
Operating the wheel lock8.2.4.1 29.....................................................................................................................
Front wheels8.2.5 29......................................................................................................................................
Suspension8.2.6 29........................................................................................................................................
Additional options8.2.7 30...............................................................................................................................
Tip-assist8.2.7.1 30...........................................................................................................................................
Frame padding8.2.7.2 30...................................................................................................................................
Storage bag8.2.7.3 31.......................................................................................................................................
Buggy board8.2.7.4 31......................................................................................................................................
Platform for respirator8.2.7.5 32..........................................................................................................................
Cup holder8.2.7.6 33.........................................................................................................................................
Disassembly and transport8.2.8 33...................................................................................................................
Use in vehicles for transporting persons with reduced mobility8.2.9 34..................................................................
Required accessories8.2.9.1 35..........................................................................................................................
Using the product in a vehicle8.2.9.2 36...............................................................................................................
Adjusting the seating unit8.2.9.3 36.....................................................................................................................
Adjusting and securing the seat angle8.2.9.4 36...................................................................................................
Kimba Neo seating unit8.2.9.4.1 36........................................................................................................................
Alternative seating systems8.2.9.4.2 37...................................................................................................................
Adjusting and securing the back angle8.2.9.5 37..................................................................................................
Kimba Neo seating unit8.2.9.5.1 37........................................................................................................................
Alternative seating systems8.2.9.5.2 38...................................................................................................................
Securing the product in the vehicle8.2.9.6 38.......................................................................................................
Securing the user in the product8.2.9.7 39...........................................................................................................
Restrictions for use8.2.9.8 40.............................................................................................................................
Kimba Cross8.3 40......................................................................................................................................
Seating unit8.3.1 40........................................................................................................................................
Seating shell interface8.3.2 41.........................................................................................................................
Push bar8.3.3 41............................................................................................................................................
Adjusting the push bar height8.3.3.1 42...............................................................................................................
Adjusting the push bar angle8.3.3.2 42................................................................................................................
Wheel lock8.3.4 42.........................................................................................................................................
Engaging the wheel lock8.3.4.1 42......................................................................................................................
Adjusting the wheel lock8.3.4.2 43......................................................................................................................
Adjusting the seat angle8.3.5 43.......................................................................................................................
Adjusting the wheelbase8.3.6 43......................................................................................................................
Use as a bicycle trailer8.3.7 44.........................................................................................................................
Mounting the coupling on the bicycle8.3.7.1 44.....................................................................................................
Coupling the trailer to the bicycle8.3.7.2 45..........................................................................................................
Equipment package8.3.7.3 45.............................................................................................................................
Additional options8.3.8 45...............................................................................................................................
Swivelling front wheel8.3.8.1 45..........................................................................................................................
Splash guard for rear wheels/clothing protectors8.3.8.2 45....................................................................................
Anti-tipper8.3.8.3 45..........................................................................................................................................
Storage bag8.3.8.4 46.......................................................................................................................................
Spoke protector8.3.8.5 46..................................................................................................................................
Disassembly and transport8.3.9 46...................................................................................................................
Folding the chassis8.3.9.1 46.............................................................................................................................
Use in vehicles for transporting persons with reduced mobility8.3.10 47..................................................................
Kimba Inline8.4 48.......................................................................................................................................
Seating unit8.4.1 48........................................................................................................................................
Seating shell interface8.4.2 48.........................................................................................................................
Adjusting the seat tilt8.4.3 49...........................................................................................................................
Push bar8.4.4 49............................................................................................................................................
Adjusting the push bar8.4.4.1 49.........................................................................................................................
Wheel lock8.4.5 50.........................................................................................................................................
Engaging the wheel lock8.4.5.1 50......................................................................................................................
4 Kimba Neo, Kimba Cross, Kimba Inline
Table of contents

Adjusting the wheel lock8.4.5.2 50......................................................................................................................
Adjusting the wheelbase8.4.6 51......................................................................................................................
Disassembly and transport8.4.7 51...................................................................................................................
Use in vehicles for transporting persons with reduced mobility8.4.8 52..................................................................
Care8.5 52..................................................................................................................................................
Detaching/attaching the frame padding for cleaning (Kimba Neo only, option)8.5.1 52............................................
Cleaning8.5.2 53............................................................................................................................................
Cleaning by hand8.5.2.1 53................................................................................................................................
Cleaning in a washing chamber8.5.2.2 53............................................................................................................
Disinfection8.5.3 53........................................................................................................................................
Maintenance and repair9 53...................................................................................................................................
Maintenance9.1 53.......................................................................................................................................
Maintenance intervals9.1.1 54..........................................................................................................................
Maintenance tasks9.1.2 54..............................................................................................................................
Repair9.2 54...............................................................................................................................................
Disposal10 54.............................................................................................................................................................
Disposal information10.1 54............................................................................................................................
Information on re-use10.2 55...........................................................................................................................
Legal information11 55..............................................................................................................................................
Liability11.1 55..............................................................................................................................................
Warranty11.2 55............................................................................................................................................
Service life11.3 55.........................................................................................................................................
Technical data12 56...................................................................................................................................................
Kimba Neo12.1 56.........................................................................................................................................
Kimba Cross12.2 56......................................................................................................................................
Kimba Inline12.3 57.......................................................................................................................................
Appendices13 57........................................................................................................................................................
Threshold values for rehab buggies transportable by train13.1 57........................................................................
5Kimba Neo, Kimba Cross, Kimba Inline
Table of contents

1 Foreword
INFORMATION
Date of last update: 2020-03-27
►Please read this document carefully before using the product and observe the safety notices.
►Obtain instruction from the qualified personnel in the safe use of the product.
►Please contact the qualified personnel if you have questions about the product or in case of problems.
►Report each serious incident in connection with the product, in particular a worsening of the state of health, to
the manufacturer and to the relevant authority in your country.
►Please keep this document for your records.
INFORMATION
►New information regarding product safety and product recalls as well as the declaration of conformity can be
obtained at [email protected] or from the manufacturer’s service department (see inside or outside of back
cover for addresses).
►You can request this document as a PDF file at [email protected] or from the manufacturer’s service depart
ment (see inside or outside of back cover for addresses). The PDF file can also be displayed in a larger size.
You have received a product that is very versatile for everyday use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and intended use of the
product before using it. These instructions for use provide you with the related necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product. In particular,
users and/or attendants must be informed of the residual risks with the aid of the safety notices in the instruc
tions for use (user).
• The product was adapted to the needs of the user. Subsequent changes may be made only by qualified per
sonnel. We recommend checking the product settings onceper year to ensure optimal treatment over the long
term. Especially for users with a changing anatomy (forexample body dimensions, weight), an adjustment at
least onceevery six months is recommended.
• Your product may differ from the models shown. In particular, not all the options described in these instruc
tions for use will be installed on your product.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
2 Product description
2.1 Function
The product is intended exclusively for holding seating systems to transport one child on the seat (Kimba Inline:
two seats).
The product can be used on solid ground both indoors and outdoors.
2.2 Product overview
2.2.1 Kimba Neo
INFORMATION
The Kimba Neo outdoor mobility base is available with and without separate seat angle adjustment (see fig.1 and
##03432). On an outdoor mobility base without separate seat angle adjustment (##03432), the Kimba Neo seat
ing unit must be used in order to use the seat tilt.
6 Kimba Neo, Kimba Cross, Kimba Inline
Foreword

1
Kimba Neo – outdoor mobility base for alternative seating systems with “swivelling” front wheels option
1 Plug-on rear wheel 6 Adjustable push bar
2 “Swivelling” front wheel (option) 7 Release handle, folding mechanism
3 Swivel lock 8 Separate seat angle adjustment on frame
4 Front lashing point 9 Rear lashing point
5 Seat adapter 10 Suspension
7Kimba Neo, Kimba Cross, Kimba Inline
Product description

2.2.2 Kimba Cross
2
Kimba Cross – outdoor mobility base for Kimba Neo seating unit and alternative seating systems
1 Frame
2 Front wheel (swivelling)
3 Front wheel (fixed)
4 Plug-on rear wheel/drum brake
5 Push bar
8
Product description
Kimba Neo, Kimba Cross, Kimba Inline

2.2.3 Kimba Inline
3
Kimba Inline – outdoor mobility base for Kimba Neo seating unit and alternative seating systems
1 Frame
2 Front wheel (swivelling)
3 Drum brake
4 Push bar
3 Intended use
The safe use of the product can only be ensured in case of intended use in accordance with the information con
tained in these instructions for use. The user is ultimately responsible for accident-free operation.
3.1 Indications for use
The product is intended for everyday indoor and outdoor use, by an attendant, of children with temporary or per
manent limitations of the ability to walk, inability to walk or difficulty standing up.
The product is suitable for users with intact skin whose anatomy (suchas body dimensions and weight) permits the
intended use of the product. It is operated by an attendant.
9Kimba Neo, Kimba Cross, Kimba Inline
Intended use

The product may only be used with the options that are listed on the product order form. Ottobock assumes no
liability for combinations with medical devices and/or accessories from other manufacturers outside the modular
system.
Combinations based on a combination agreement that have been evaluated for effectiveness and safety are an
exception to this.
3.2 Indications
• Minor to pronounced or complete restrictions of mobility
3.3 Contraindications
3.3.1 Absolute Contraindications
• None known
3.3.2 Relative Contraindications
• Failure to meet physical or mental requirements
3.4 Qualification
Installation and adjustment tasks may only be carried out by qualified personnel. Compliance with all manufacturer
specifications and all applicable legal provisions is required. Please contact the manufacturer’s service department
for further information (see inside or outside of rear cover for addresses).
4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Safety instructions for assembly and adjustments
WARNING
Making incorrect adjustments
Risk of falling, tipping over or malposition of the user due to incorrect settings
►Settings may only be changed by qualified personnel unless otherwise prescribed.
►Before testing setting changes with the user seated, all screw connections must be firmly tightened.
►Check the product for safety and functionality after changing the settings.
CAUTION
Unsecured screw connections
Pinching, crushing, tipping over, falling of user due to assembly errors
►After all adjusting/readjusting work, retighten the attachment screws/nuts firmly.
►Please note that all adjustment levers are tightened by hand without the help of tools.
4.3 Safety instructions for use
Hazards during preparation for use
WARNING
Independent modification of settings
Serious injuries to the user due to improper changes to the product
►Do not modify the settings established by the qualified personnel. Only the settings described in the section
“Use” in these instructions for use may be adjusted independently.
►In case of problems with the settings, please contact the qualified personnel who adjusted your product.
10
Safety
Kimba Neo, Kimba Cross, Kimba Inline

WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
Hazards when getting in
CAUTION
Wheel lock not engaged when getting in or out
Falling, tipping over of the user due to user error
►Before the user gets in or out, always engage and check the wheel lock.
►Engage the wheel lock to prevent the rehab buggy from moving on uneven ground or during transfers (e.g.
into a car).
Hazards while driving
WARNING
Pushing too fast
Tipping over, falling of the user due to caster wheel wobble
►The swivelling front wheels may begin to wobble at higher speeds and lead to an abrupt stop, causing the
rehab buggy to tip over forwards.
►Therefore, push the rehab buggy only at normal walking speed or engage the swivel lock (see section "Use").
It is not permissible to let go of the push bar while pushing the buggy or to thrust it away from you.
WARNING
Unsupervised parking
Falling out, falling of the user due to neglect of the duty to supervise
►Never leave the user unattended, not even when the positioning belts or safety belts are secured and the
wheel locks are activated.
WARNING
Impermissible use
Tipping over, rolling over of the user due to failure to observe specifications
►Using a rehab buggy beyond normal conditions may be dangerous.
►Please note that this product is not suitable for jogging, running, skating, etc. (not Kimba Cross).
►Do not exceed the maximum load capacity (see the section "Technical data").
CAUTION
Lack of driving experience
Tipping over, falling due to errors in handling the product
►Practice on level, open ground first.
►Learn with the support of an assistant how the rehab buggy reacts to changes in the centre of gravity, e.g.
downward or upward slopes, inclines or when overcoming obstacles.
►Always activate the anti-tipper (if any).
CAUTION
Improper loading
Tipping over, falling of the user due to shift in centre of gravity
►Please note that any additional load may have a negative impact on the stability of the rehab buggy.
►Do not hang heavy bags or the like on the push bar/push handles.
11Kimba Neo, Kimba Cross, Kimba Inline
Safety

CAUTION
Incorrect centre of gravity setting
Falling of the user due to extreme settings
►Check the standard adjustments of the rehab buggy for stability against tipping and the ergonomically correct
sitting position of the user. Avoid any extreme settings.
CAUTION
Changed centre of gravity after operating the seat tilt
Tipping over, falling out of the user due to adjustment error
►Check the tip resistance each time after changing the seat tilt, especially in combination with a back support
angle setting. To do so, hold the product with both hands by the push handle/push bar.
CAUTION
Change in centre of gravity following back angle adjustment
Falling over, falling out of the user due to adjustment errors
►After each modification of the back angle, check the tilt stability. To do so, hold the product with both hands
by the push handle/push bar.
CAUTION
Risky operation
Falling, tipping over backwards due to approaching obstacles incorrectly
►Push slowly when crossing obstacles (e.g. steps, curbs) and negotiating uphill or downhill slopes and
inclines.
►Never cross obstacles at an angle. Always approach obstacles head on (at an angle of 90°).
►Raise the front wheels before crossing obstacles.
►Avoid collisions with obstacles and dropping off curbs/ledges.
►Avoid riding cross-country.
Hazards when overcoming obstacles
WARNING
Overcoming steps and obstacles without assistance
Tipping over, falling of the user due to failure to observe transportation instructions
►Always have accompanying persons help you negotiate steps and other obstacles.
►Use available facilities (e.g. access ramps or lifts).
CAUTION
Improper lifting by attendants
Tipping over, falling of the user due to lifting by removable components
►Attendants may lift the buggy only by welded or permanently attached components (e.g.front frame tube
above the front wheels, rear axle).
►It is particularly dangerous to lift the buggy by the unfixed push handle/push bar.
Hazard in case of broken skin
CAUTION
Skin damage
Skin damage or pressure points due to overloading
►Check your skin for intactness before and during use of the product.
►Pay attention to diligent skin care and pressure redistribution during interruptions in using the product.
►If skin damage or other problems occur during use, stop using the product. Consult the qualified personnel.
12
Safety
Kimba Neo, Kimba Cross, Kimba Inline

Hazards due to fire, heat and cold
CAUTION
Extreme temperatures
Hypothermia or burns due to contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g.direct sunlight, sauna, extreme cold).
►Do not leave the product in the immediate vicinity of heaters.
Hazards due to improper use of the product
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain accessories and add-on components will reduce the remaining load capacity.
WARNING
Loss of stability due to overloading
Falling, tipping over of the user due to changed centre of gravity
►Please note that any additional load may have a negative impact on the stability of the rehab buggy.
►Never hang heavy bags or the like on the push bar.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer’s requirements
►Using the product beyond the specified expected service life leads to increased residual risk.
►Observe the specified service life.
WARNING
Failure to inspect the seating unit before each use
User may fall, tip over or fall out of the product due to failure to carry out checks
►In the interest of user safety, make the following checks before using the product:
→Check that the seat tilt and back support angle mechanisms are firmly locked.
→Check that the buckles on the positioning belts and positioning aids are working correctly.
CAUTION
Use of the product during diagnostic examinations and therapeutic treatment
Impairment of the examination results or the effectiveness of treatment due to interactions of the product with
devices that are used
►Make sure that examinations and treatments are carried out exclusively under the prescribed conditions.
CAUTION
Uncontrolled driving behaviour, unexpected sounds or odours
Falling, tipping, collision with persons or nearby objects due to defects
►If any faults, defects or other hazards that can lead to personal injury are detected, the product must be taken
out of service immediately. This includes uncontrolled movements as well as sounds that are unexpected or
previously not noted or odours that deviate significantly from the state of the product at the time of delivery.
►Contact the qualified personnel.
CAUTION
Lack of maintenance
User falling or tipping over due to lack of maintenance
►Check that the product is working correctly before each use.
►Observe the specified maintenance intervals (see Page53, "Maintenance" section).
13Kimba Neo, Kimba Cross, Kimba Inline
Safety

NOTICE
Use under incorrect environmental conditions
Damage to product due to corrosion or abrasion
►Do not use the product in salt water.
►Make sure that the wheel bearings are not damaged by sand or other particles.
4.4 Side effects
The following side effects may occur during use of the product:
• Neck, muscle and joint pain
• Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
4.5 Further information
INFORMATION
Even in the event of compliance with all applicable guidelines and standards, alarm systems (e.g. in department
stores) may respond to your product. Should this happen, remove your product from the area where the alarm
was triggered.
INFORMATION
Please note that all options and add-on components will reduce the remaining load capacity.
INFORMATION
The serial number required for enquiries and orders can be found on the nameplate. For explanations of the
nameplate, see the section "Nameplate" (see Page14).
4.6 Nameplate and warning labels
4.6.1 Nameplate
The nameplates are found on the frame.
4.6.1.1 Kimba Neo
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DManufacturer information/address
ESerial number1)
FManufacturing date2)
GSymbol for medical device
HWARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
IManufacturer’s reference number for the product variant
JSerial number (PI)3),1)
KGlobal Trade Item Number (DI)4)
1)YYYY = year of manufacture; WW = week of manufacture; PP = production site; XXXX = sequential production
number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
14
Safety
Kimba Neo, Kimba Cross, Kimba Inline

4.6.1.2 Kimba Cross, Kimba Inline
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DManufacturer information/address
ESerial number1)
FManufacturing date2)
GSymbol for medical device
HWARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
IThe product has not been approved by the manufacturer for use
as a seat in vehicles for transporting persons with reduced
mobility
JManufacturer’s reference number for the product variant
KSerial number (PI)3),1)
LGlobal Trade Item Number (DI)4)
1)YYYY = year of manufacture; WW = week of manufacture; PP = production site; XXXX = sequential production
number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
4.6.2 Warning labels
Label Meaning
Attention: Please observe the maximum load capacity of the
outdoor mobility base!
(See the section "Technical data".)
Fixation point to attach the product in vehicles for transporting
persons with reduced mobility
15Kimba Neo, Kimba Cross, Kimba Inline
Safety

Label Meaning
WARNUNG/WARNING
ATTENTION! Never leave your child unattended!
ATTENTION! Never leave your child unattended!
ATTENTION! This seating unit is unsuitable for children aged
below 6 months!
ATTENTION! This seating unit is unsuitable for children aged
below 6 months!
5 Delivery
5.1 Scope of delivery
5.1.1 Kimba Neo
• Frame, folded
• Options according to the order
• Instructions for use
• Instructions for use for accessories (depending on equipment)
5.1.2 Kimba Cross
• Frame, folded
• 2 rear wheels with quick-release axle
• One front wheel with quick-release lock and mounted splash guard
• Options according to the order
• Instructions for use (user)
• Instructions for use for accessories (depending on equipment)
5.1.3 Kimba Inline
• Frame, folded
• Options according to the order
• Instructions for use (user)
• Instructions for use for accessories (depending on equipment)
5.2 Options
The standard model can be fitted to the user's personal requirements thanks to a large range of options. For use of
these options: see Page25 ff.
5.3 Storage
5.3.1 Storage during daily use
The product should always be stored so it is protected against external influences.
16
Delivery
Kimba Neo, Kimba Cross, Kimba Inline

5.3.2 Storage during extended disuse
The product must be stored in a dry place. Specific information for extended storage: see Page56.
It is not necessary to disassemble the product.
Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or the
tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the tyres may
become permanently deformed.
Direct exposure to sunlight or UV radiation causes the tyres to age more quickly. As a result, the tread surface
hardens and corner pieces break out of the tread.
The tyres should be replaced every 2years regardless of wear and tear.
6 Preparing the product for use
6.1 Assembly
CAUTION
Exposed pinch points
Crushing, pinching due to incorrect handling
►When folding out the backrest, only grip by the specified components.
CAUTION
Improper assembly
Falling, tipping over of the user due to components coming off
►After each assembly, verify the proper fit of the removable wheels. The quick-release axles must be firmly
locked in the wheel attachment.
►Before using the product, the folding mechanism must be firmly locked in place.
►When attaching the seating unit, make sure you hear it engage into the outdoor mobility base.
►Secure the seating unit using the seat lock.
6.1.1 Kimba Neo
CAUTION
Incorrect adjustment of the tilt-limiter on the outdoor mobility base
User falls out due to user error
►Before mounting the seating unit on the outdoor mobility base, adjust the tilt-limiter as appropriate for the dir
ection in which the seating unit will face.
►The tilt-limiter is adjusted on the outdoor mobility base. For information on adjusting the tilt-limiter, see the
instructions for use for the outdoor mobility base.
Attaching the rear wheels
1) If wheel locks are engaged: disengage wheel locks.
2) Depress the locks on the wheels (see fig.4, item 1).
3) Push the rear wheels onto the axle until the lock clicks into place audibly.
Unfolding the rehab buggy (when the seating unit is detached)
1) Unfold the push bar (see fig.5, item 1). To unfold the push bar: see Page.
2) Unfold the rehab buggy by pulling on the push bar (see fig.5, item 2; see fig.6).
→The release handles of the folding mechanism engage automatically after unfolding (see fig.5, item3).
17Kimba Neo, Kimba Cross, Kimba Inline
Preparing the product for use

4 5
6
INFORMATION
Putting on the seat is described in the seating unit instructions for use (user).
6.1.2 Kimba Cross
Unfolding the rehab buggy
1) Remove the transport locks and packaging material.
2) Remove the locking pin from the frame lug (see fig.7).
3) Fold up the push bar and guide the back brace into the adapter (see fig.8).
4) Adjust the desired angle of the push bar using the hole in the back brace (see fig.9).
5) Insert the locking pin through the hole in the back brace and through the lug of the adapter.
6) Secure with the clip (see fig.10).
7 8
18
Preparing the product for use
Kimba Neo, Kimba Cross, Kimba Inline

9 10
Installing the rear wheels
►Press the quick-release axle and the wheel together into the axle retainer (see fig.11).
11
Installing the front wheel
1) Insert the front wheel with the splash guard into the fork and push it all the way to the rear and up (see fig.12).
2) Close the eccentric lever of the quick-release axle. Optional: Adjust the clamping pressure by turning the
quick-release lever or the counter nut.
12
6.1.2.1 Equipment package
The equipment package includes:
• Roll bar
• Pennant
• Lighting (taillight red; rear reflector red)
• Reflectors, self-adhesive, white
• Spoke reflectors
19Kimba Neo, Kimba Cross, Kimba Inline
Preparing the product for use

Some parts of the equipment package are installed at the factory. The following components are included and have
to be installed by qualified personnel:
Roll bar
1) Mount the roll bar on the push bar (see fig.13).
2) Insert and tighten the Allen head screws (see fig.13).
Pennant
1) Loosen the left cap nut of the push bar mounting (see fig.14, item1).
2) Insert the fork of the fibreglass rod behind the spacer washer (see fig.14, item2).
3) Tighten the left cap nut of the push bar mounting (see fig.14, item1).
Lighting (taillight red, rear reflector red)
1) Mount the battery-operated taillight on the rear cross tube according to the manufacturer’s instructions.
2) Mount the rear reflector on the rear cross tube using the pipe clamps.
13 14
6.1.3 Kimba Inline
Unfolding the rehab buggy
1) Fold the push bar forward (see fig.106).
2) Pull up the lock slide and allow it to engage on the frame (see fig.105).
6.2 Retrofitting the respirator platform (Kimba Neo only)
WARNING
Improper use in vehicles for transporting persons with reduced mobility
Severe accidental injuries caused by use with untested product combinations
►Use of the product in vehicles for transporting persons with reduced mobility in combination with the artificial
respiration platform option is not permitted.
INFORMATION
The respirator platform cannot be installed on a product with fixed front wheels.
The respirator platform can be installed as follows:
• Installation of the large T1 respirator platform over the front wheels (see fig.15) – the user sits in the seat
facing away from the direction of travel
• Installation of the large T1 respirator platform over the rear wheels (see fig.16) – the user sits in the seat facing
in the direction of travel
The respirator is attached to the respirator platform using straps through the slots.
Using an anti-slip mat is recommended.
The seating unit can only be turned around if the respirator platform is moved.
20
Preparing the product for use
Kimba Neo, Kimba Cross, Kimba Inline
