Ozito HGN-2100U User manual

HEAT GUN
2000W
ORIGINAL INSTRUCTIONS
SPECIFICATIONS
Power: 2000W
Input: 230-240V~50Hz
Airflow: Fan Setting 1: 250 l/min
Fan Setting 2: 500 l/min
Temperature Control: Variable (50-450º/90-600º)
Weight: 0.81kg
HGN-2100U
WHAT’S IN THE BOX
Heat Gun
Nozzles x 4
ozito-diy.co.uk
Scrapers x 2
WARRANTY
OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG 0716
All of our products undergo strict quality checks to ensure that they reach
you in perfect condition. In the unlikely event that your device develops a
fault, please contact our service department at the address shown on this
guarantee card. You can also contact us by telephone using the customer
service number shown. Please note the following terms under which
guarantee claims can be made:
1. These warranty terms regulate additional warranty services, which the
manufacturer mentioned below promises to buyers of its new products
in addition to their statutory guarantee claims are not affected by this
guarantee. Our guarantee is free of charge to you.
2. The warranty services only covers defects due to material or
manufacturing faults on a product which you have bought from the
manufacturer mentioned below are limited to either the rectication of said
defects on the product or the replacement of the product, whichever we
prefer.
Please note that our devices are not designed for use in commercial, trade
or professional applications. A guarantee contract will not be created if the
device has been used by commercial, trade or industrial business or has
been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly
instructions or due to incorrect installation, a failure to follow the operating
instructions (for example connecting it to an incorrect mains voltage or
current type) or a failure to follow the maintenance and safety instructions
or by exposing the device to abnormal environmental conditions or by lack
of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example
overloading the device or the use or unapproved tools or accessories),
ingress of foreign bodies into the device (such as sand, stones or dust,
transport damage), the use of force or damage caused by external forces
(for example by dropping it).
- Damage to the device or parts of the device caused by normal or natural
wear or tear or by normal use of the device.
4. Your Product is guaranteed for a period of 36 months from the original
date of purchase and is intended for DIY (Do It Yourself) use only. Lithium
Ion batteries and chargers are covered by a 12 month warranty. Warranty
excludes consumable parts. Guarantee claims should be submitted
before the end of the guarantee period within two weeks of the defect
being noticed. No guarantee claims will be accepted after the end of the
guarantee period. The original guarantee period remains applicable to the
device even if repairs are carried out or parts are replaced. In such cases,
the work performed or parts tted will not result in an extension of the
guarantee period, and no new guarantee will become active for the work
performed or parts tted. This also applies if an on-site service is used.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR
REGISTER RECEIPT.
Please refer to the restrictions of this warranty concerning wearing parts,
consumables and missing parts as set out in the service information in
these operating instructions.
CUSTOMER SERVICE HELPLINE
GB: 0151 294 4488
IRL: 1850 882711
Ozito-diy.co.uk

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT
1 Heating Element
2 2 Speed On/off Switch
3 Temperature Control Dial
4 Sure Grip Handle
5 Flat Base Stand
6 Cone Nozzle
7 Glass Protector Nozzle
8 Fish Tail Nozzle
9 Reector Nozzle
10 Scraper
11 Corner Scraper
1. ASSEMBLY
1. Push the open end of the
nozzle onto the heat gun.
1. Unscrew and remove the
rst nut on the scraper
handle.
ACCESSORIES
SETUP & PREPARATION
Nozzles
Scraper
2. Place the scraper blade
onto the handle and then
replace and tighten the rst
nut.
3. Tighten the second nut
until the scraper blade is
rmly secured between the
two nuts.
HEAT GUN

OPERATION
2. CONTROLS 3. OPERATING THE HEAT GUN
1. Slide the on/off switch up
one position for fan setting
1 or up two positions for
fan setting 2.
1. To increase the
temperature rotate the
temperature control dial
clockwise.
2. To lower the
temperature rotate the
temperature control dial
anti-clockwise.
2. Point the heat gun to the
work surface, then turn on
by selecting a fan setting.
1. Select the appropriate
heat setting.
WARNING: THIS TOOL IS DESIGNED FOR INDOOR
USE ONLY. USING THIS TOOL FOR PROLONGED
PERIODS MAY CAUSE IT TO OVERHEAT AND
MALFUNCTION. TO ENSURE THE TOOL DOES NOT
OVERHEAT, FREQUENT BREAKS ARE SUGGESTED
TO ALLOW THE TOLL TO COOL DOWN.
The tool is recommended for use with a residual current
device with a rated residual current of 30mA or less.
On/Off Switch
Temperature Control Dial
Caution: THE HEATGUN HAS A BUILT-IN THERMAL
PROTECTION OVERLOAD SWITCH. THE HEATGUN
STOPS IF AN OVERLOAD OCCURS. THE HEAT
GUN RESTARTS AUTOMATICALLY AFTER IT HAS
COOLED DOWN.
Note: Ensure the heat gun is in the off position ‘0’ before
conecting to a power supply.
2. Lower switch to “0” to
turn off.
3. Keep the heat gun
consistantly moving to
avoid having it pointed at
the one place for more
than 5 seconds.

HGN-2100U
4. APPLICATIONS 5. APPLICATIONS CONT.
1. Position nozzle 10cm from surface. Work the heat gun from side
to side until the paint blisters.
2. Use the scraper to remove the softend paint.
1. Fit the reector nozzle and
rest the heat gun on its stand.
2. Heat the tubing evenly by
moving from side to side.
Paint Removal / Dissolving Adhesives
Note: Do not keep the heat gun pointed at one place or overheat
the paint as this may burn the paint, making it more difcult to
remove.
Paint Removal on Windows
1. Fit the glass protector
nozzle.
2. Heat the surface until the
paint blisters.
2. Remove paint with the corner scraper.
Shaping Plastic Tubing
Shrink Fitting
1. Fit the cone nozzle. 2. Cover the workpiece with a
heat-shrinkable sleeve and
heat evenly.
Defrosting Water Pipes
1. Fit the reector nozzle. 2. Heat frozen area inwards,
from the edge to the centre.
10cm

MAINTENANCE
DESCRIPTION OF SYMBOLS
• Keep the ventilation vents of the heat gun clean at all times, if possible, prevent
foreign matter from entering the vents.
• After each use, blow air through the heat gun housing to ensure it is free from all
dust particles which may build up. Build up of dust particles may cause the heat
gun to overheat and fail.
• If the enclosure of the heat gun requires cleaning, do not use solvents but a
moist soft cloth only. Never let any liquid get inside the heat gun; never immerse
any part of the heat gun into a liquid.
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse or Homebase store.
For further information, or any parts visit
www.ozito-diy.co.uk or contact Ozito Customer Service:
Great Britain: 0151 294 4488
Ireland: 1850 882711
E-mail: [e-mail]
V Volts Hz Hertz
~Alternating current WWatts
°C Degrees Celsius Read instruction manual
Double insulated

WARNING! This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
WARNING! A re may result if the appliance is not used with care, therefore:
• be careful when using the appliance in places where there are combustible
materials
• do not apply to the same place for a long time
• do not use in the presence of an explosive atmosphere
• be aware that heat may be conducted to combustible materials that are out of
sight
• place the appliance on its stand after use and allow it to cool down before
storage
• do not leave the appliance unattended when it is switched on.
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, re and/or serious
injury.
Save all warnings and instructions for future reference. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f. If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your nger on the switch or energising power tools
that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to
be performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power tool is
maintained.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of re, electric shock,
personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the equipment to the mains supply make sure that the data on the rating plate are
identical to the mains data.
This tool is double insulated therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order
to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool. The insulation system is for added protection against injury resulting from a possible electrical
insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged
or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or which is damaged or defective may result in a risk
of re and electric shock.
HEAT GUN SAFETY WARNINGS

size 445 x 210 mm
Danger! - Read the operating instructions to
reduce the risk of inquiry.
7 cm
The nozzle outlet must be kept a minimum distan-
ce of 7 cm from the workpiece you are working on
or the accumulating air may cause damage to the
equipment.
The reprinting or reproduction by any other
means, in whole or in part, of documentation and
papers accompanying products is permitted only
with the express consent of the iSC GmbH.
Subject to technical changes
HGN-2100U
GB Additonal operating & safety instructions Heat Gun
Service information
We have competent service partners in all countries named on the guarantee certicate whose contact
details can also be found on the guarantee certicate. These partners will help you with all service re-
quests such as repairs, spare and wearing part orders or the purchase of consumables.
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts*
Consumables* Nozzles
Missing parts
* Not necessarily included in the scope of delivery!
In the eect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Plea-
se ensure that you provide a precise description of the problem and answer the following questions in all
cases:
• Did the equipment work at all or was it defective from the beginning?
• Did you notice anything (symptom or defect) prior to the failure?
• What malfunction does the equipment have in your opinion (main symptom)?
Describe this malfunction.
Mayr/Product-ManagementWeichselgartner/General-Manager
- 135 -
explains the following conformity according to EU directives and norms for
the following product
Heat Gun HGN-2100U (Ozito)
2014/29/EU
2005/32/EC_2009/125/EC
X2014/35/EU
2006/28/EC
X2014/30/EU
2014/32/EU
2014/53/EC
2014/68/EU
90/396/EC_2009/142/EC
89/686/EC_96/58/EC
X2011/65/EU
2006/42/EC
Annex IV
Noti ed Body:
Noti ed Body No.:
Reg. No.:
2000/14/EC_2005/88/EC
Annex V
Annex VI
Noise: measured LWA = dB (A); guaranteed LWA = dB (A)
P = KW; L/Ø = cm
Noti ed Body:
2012/46/EU
Emission No.:
Standard references: EN 60335-1; EN 60335-2-45; EN 62233;
EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3
Landau/Isar, den 25.07.2016
First CE: 16 Archive-File/Record: NAPR014315
Art.-No.: 44.722.39 I.-No.: 11016 Documents registrar: R. Gehard
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
ISC GmbH · Eschenstraße 6 · D-94405 Landau/Isar
Declaration of conrmity

size 445 x 210 mm
Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suocating!
Proper use
The heat gun is designed for heating shrink-t
hoses, for removing paint and for welding and
shaping plastics.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Technical data
Mains voltage: .........................220-240 V~ 50 Hz
Power input: ............................................ 2000 W
Temperature Control: ..........................................
...............................Variable (50-450°C / 90-600°)
Air volume: ........................... 250 l/min / Setting 1
.............................................. 500 l/min / Setting 2
Protection class: ............................................ II/&
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2012/19/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to
the manufacturer, the owner of the electrical
equipment must make sure that the equipment
is properly disposed of if he no longer wants to
keep the equipment.The old equipment can be
returned to a suitable collection point that will
dispose of the equipment in accordance with the
national recycling and waste disposal regulations.
This does not apply to any accessories or aids
without electrical components supplied with the
old equipment.
