Ozito ROTARY TOOL SET User manual

ROTARY
TOOL SET
170W
ORIGINAL INSTRUCTIONS
SPECIFICATIONS
Voltage: 230-240V ~ 50Hz
Power: 170W
No Load Speed: 8,000 - 35,000/min
Collet Chuck Size: ø 1.5 - 3.2mm
Flexible Shaft Length: 1.0m
Tool Weight: 1.5kg
RTR-2000U
WHAT’S IN THE BOX
Rotary Tool
Flexible Shaft
Spanner
Spindle Lock Key
Rotary Bits x 106
ozito-diy.co.uk
WARRANTY
OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG 0516
All of our products undergo strict quality checks to ensure that they reach
you in perfect condition. In the unlikely event that your device develops a
fault, please contact our service department at the address shown on this
guarantee card. You can also contact us by telephone using the customer
service number shown. Please note the following terms under which
guarantee claims can be made:
1. These warranty terms regulate additional warranty services, which the
manufacturer mentioned below promises to buyers of its new products
in addition to their statutory guarantee claims are not affected by this
guarantee. Our guarantee is free of charge to you.
2. The warranty services only covers defects due to material or
manufacturing faults on a product which you have bought from the
manufacturer mentioned below are limited to either the rectication of said
defects on the product or the replacement of the product, whichever we
prefer.
Please note that our devices are not designed for use in commercial, trade
or professional applications. A guarantee contract will not be created if the
device has been used by commercial, trade or industrial business or has
been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly
instructions or due to incorrect installation, a failure to follow the operating
instructions (for example connecting it to an incorrect mains voltage or
current type) or a failure to follow the maintenance and safety instructions
or by exposing the device to abnormal environmental conditions or by lack
of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example
overloading the device or the use or unapproved tools or accessories),
ingress of foreign bodies into the device (such as sand, stones or dust,
transport damage), the use of force or damage caused by external forces
(for example by dropping it).
- Damage to the device or parts of the device caused by normal or natural
wear or tear or by normal use of the device.
4. Your Product is guaranteed for a period of 36 months from the original
date of purchase and is intended for DIY (Do It Yourself) use only. Lithium
Ion batteries and chargers are covered by a 12 month warranty. Warranty
excludes consumable parts. Guarantee claims should be submitted
before the end of the guarantee period within two weeks of the defect
being noticed. No guarantee claims will be accepted after the end of the
guarantee period. The original guarantee period remains applicable to the
device even if repairs are carried out or parts are replaced. In such cases,
the work performed or parts tted will not result in an extension of the
guarantee period, and no new guarantee will become active for the work
performed or parts tted. This also applies if an on-site service is used.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR
REGISTER RECEIPT.
Please refer to the restrictions of this warranty concerning wearing parts,
consumables and missing parts as set out in the service information in
these operating instructions.
CUSTOMER SERVICE HELPLINE
GB: 0151 294 4488
IRL: 1850 882711
Ozito-diy.co.uk

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 Collet Nut
2 Shaft Collar
3 Spindle Lock Button
4 Accessible Brushes
5 Variable Speed Dial
6 On/off Switch
7 Hanging Ring
8 Power Cord
ROTARY TOOL
KNOW YOUR PRODUCT
1. CHANGING ACCESSORIES
9 Flexible Shaft
10 Locking Chuck
11 Spindle Lock
12 Fitting Collar
13 Spindle Lock Key
14 Rotary Bits x 106
15 Spanner
ACCESSORIES
SETUP & PREPARATION
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
WARNING! ENSURE THE TOOL IS DISCONNECTED
FROM THE POWER SUPPLY BEFORE PERFORMING ANY
OF THE FOLLOWING OPERATIONS.
1 Press and hold the spindle
lock button.
2 Unscrew the collet nut and
remove completely.
3 Select a suitable collet for
the accessory to be used
and insert. Then cover
with collet nut.
4 Lightly tighten the collet nut so
that it stays in place.
5 Insert shaft of accessory
into the collet.
6 Tighten collet nut using spindle
lock and spanner.

2. CHANGING ACCESSORIES CONT. 3. FLEXIBLE SHAFT
Locating a cutting/sanding disc
Locating a sanding drum
2 Fit the bre ange either side
of the cutting disc, then insert
the screw.
1 Loosen the screw on the top
of the sanding drum holder.
3 Tighten the cutting disc onto
the cutting disc holder.
2 Slide the sanding drum onto
the sanding drum holder.
1 Remove the screw from
the end of the disc holder.
Note: Do not over-tighten the screw as it could result in damage to the
cutting disc.
3 Tighten the screw until
the sanding drum sleeve
is secured.
1 Remove the shaft collar.
6 Insert the spindle lock key into
the hole on the handle.
2 Loosen the collet nut.
7 Loosen collet nut then insert
shank of accessory into collet.
3 Raise the handle end of
the exible shaft & shake
gently until the inner
exible shaft protrudes
from the tting collar.
5 Screw the exible shaft
tting collar onto the
rotary tool.
8 Tighten collet nut and check all ttings to ensure they are securely
fastened.
4 Insert the inner exible shaft into the collet then tighten the collet
nut.
a
b
ab

OPERATION
The speed of the tool can be regulated to suit a variety of applications
and materials.
Low speed use: Best for polishing applications and delicate projects
such as fragile model parts. It is recommended that the various shape
grinding stones be used at low speed to prevent them from becoming
too hot and deteriorating.
High speed use: Best for carving and shaping materials. Metal and
glass projects require high speed drilling.
1 Rotate the variable speed dial
to select the desired speed.
1 To turn on, push the on/off
switch to on position “I”.
2 To turn off, push the on/off
switch to the off position “0”.
Note: The higher the number on
the variable speed dial, the faster
the speed of the rotary tool.
Variable Speed Dial
On/Off Switch
4. CONTROLS
WARNING! THE TOOL IS RECOMMENDED FOR USE
WITH A RESIDUAL CURRENT DEVICE (RATED AT 30mA
OR LESS).

RTR-2000U
5. OPERATING THE ROTARY TOOL
1 Turn the rotary tool on. 2 Select the appropriate speed
for the application.
3 For high precision
applications such as
engraving or milling, hold
the rotary tool like a pen.
5 Gently apply the tip of the
accessory to the work piece.
4 For heavy work like
cutting or grinding,
hold the rotary tool
in the palm of your
hand.
WARNING! PLACING EXCESSIVE LOAD ON THE ROTARY
TOOL WHILE IT IS RUNNING AT LOW SPEEDS MAY
CAUSE IT TO OVERHEAT AND THE MOTOR TO FAIL.

ROTARY BITS ACCESSORY GUIDE
Collet
1.6mm x1
2.4mm x1
3.2mm x1
different shank sizes, to your rotary tool.
Mandrel x1
A mandrel is a shank to which polishing
accessories, cutting wheels and sanding
Screw Mandrel x1 A shank which screws into the felt
polishing tip and wheels.
Sanding Drum Various Sizes x2 A shank used with sanding paper drums
Sanding Bands Various Sizes x8
places.
Cutting Wheels 24mm Cut-off Wheels x30 slicing and cutting applications. Use them
for cutting off frozen bolt heads and nuts
etc.
Sanding Wheels 20mm Sanding Wheels x30
Engraving Cutters High Speed Cutter x1
Diamond Wheel Points x3
Made for intricate work on ceramics, wood
carvings, jewelry and scrimshaw. Available
in a wide variety of shapes and sizes.
Dressing Stone x1 grinding accessories after they have been
used.
Grinding Stones &
Wheels
Wheels x4
Stones x5
Suitable for various kinds of grinding and
sharpening applications. Available in a
wide range of sizes and shapes - round,
Wire Brushes Steel x2 The steel wire brush is good for
general purpose cleaning.
Bristle Brush Nylon x2
Useful for cleaning silverware, jewelley
and antiques. Use with polishing
compound for faster cleaning or polishing.
Fabric Tips and
Wheels
Felt Wheel x6
Felt Tip x1
Used for bringing metal surfaces to
compound to bring a high shine to the
Drill Bits
1.5mm x1
2.3mm x1
3.17mm x1
Used to drill through all types of plastic
and wood.
ASSEMBLY
SANDING ACCESSORIES
CUTTING ACCESSORIES
GRINDING ACCESSORIES
MISCELLANEOUS
POLISHING ACCESSORIES
TYPE QTY/ SIZES INCLUDED APPLICATIONS
Polishing
Compound x1 Compound used for polishing.
Thin discs of sand paper used for sanding.
Rubber Wheel x1 Thin discs of rubber used for polishing.
3.2mm x1 (Fitted)

MAINTENANCE
DESCRIPTION OF SYMBOLS TROUBLESHOOTING
• Keep the ventilation vents of the rotary tool clean at all times, if possible,
prevent foreign matter from entering the vents.
• After each use, blow air through the rotary tool housing to ensure it is free
from all dust particles which may build up. Build up of dust particles may
cause the rotary tool to overheat and fail.
• If the enclosure of the rotary tool requires cleaning, do not use solvents but
a moist soft cloth only. Never let any liquid get inside the rotary tool; never
immerse any part of the rotary tool into a liquid.
•If the replacement of the supply cord is necessary, this has to be done by the
manufacturer or his agent in order to avoid a safety hazard.
Carbon Brushes
When the carbon brushes wear out, the rotary tool will spark and/or stop.
Discontinue use as soon as this happens. They should be replaced prior to
recommencing use of the rotary tool. Carbon brushes are a wearing component
of the rotary tool therefore not covered under warranty. Continuing to use the
rotary tool when carbon brushes need to be replaced may cause permanent
damage to the rotary tool. Carbon brushes will wear out after many uses but
when the carbon brushes need to be replaced,
take the rotary tool to an electrician or a power tool
repairer for a quick and low cost replacement. Always
replace both carbon brushes at the same time.
Note: Ozito Industries will not be responsible for any
damage or injuries caused by the repair of the rotary
tool by an unauthorised person or by mishandling of
the rotary tool.
Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents.
This is normal and does not indicate a problem.
Excessive sparking visible through the housing air vents
and/or the rotary tool failing to operate
May indicate the carbon brushes have worn out and need to be
replaced. Carbon brushes should only be replaced by a qualied
electrician or power tool repairer.
SPARE PARTS
WARNING! When using mains-powered tools, basic safety precautions,
including the following, should always be followed to reduce risk of
re, electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off
in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future
reference.
Before you connect the equipment to the mains supply make sure that the data on
the rating plate are identical to the mains data.
This tool is double insulated therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool
repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury
resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of
an extension lead not suitable for the power input of the tool or which is damaged or
defective may result in a risk of re and electric shock.
ELECTRICAL SAFETY
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse or Homebase store.
For further information, or any parts visit
www.ozito-diy.co.uk or contact Ozito Customer Service:
Great Britain: 0151 294 4488
Ireland: 1850 882711
E-mail: enquires@ozito-diy.co.uk
Warning
Read instruction manual
Wear eye protection
Double insulated
/min Revolutions or
reciprocation per minute no No load speed
V Volts Hz Hertz
~ Alternating current W Watts
Diameter
Wear ear protection
mm Millimetres

This appliance is not intended for use by young or inrm persons unless supervised by a responsible
person to ensure that they can use the appliance safely. Young children should be supervised to
ensure that they do not play with the appliance.
WARNING!
Safety Warnings Common for Grinding, Sanding, Wire Brushing, Polishing or Abrasive
Cutting-Off Operations:
a) This power tool is intended to function as a grinder, sander, wire brush, polisher or cut-off tool.
Read all safety warnings, instructions, illustrations and specications provided with this power tool.
Failure to follow all instructions listed below may result in electric shock, re and/or serious injury.
b)Operations such as grinding, sanding, wire brushing, polishing or cutting-off are not recommended
to be performed with this power tool. Operations for which the power tool was not designed may create
a hazard and cause personal injury.
c) Do not use accessories which are not specically designed and recommended by the tool
manufacturer. Just because the accessory can be attached to your power tool, it does not assure safe
operation.
d)The rated speed of the accessory must be at least equal to the maximum speed marked on the
power tool. Accessories running faster than their rated speed can break and y apart.
e)The outside diameter and the thickness of your accessory must be within the capacity rating of
your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled.
f) Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted
by anges, the arbour hole of the accessory must t the locating diameter of the ange. Accessories
that do not match the mounting hardware of the power tool will run out of balance, vibrate excessively and
may cause loss of control.
g) Do not use a damaged accessory. Before each use inspect the accessory such as abrasive
wheels for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or
cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged
accessory. After inspecting and installing an accessory, position yourself and bystanders away
from the plane of the rotating accessory and run the power tool at maximum no-load speed for one
minute. Damaged accessories will normally break apart during this test time.
h) Wear personal protective equipment. Depending on application, use face shield, safety goggles or
safety glasses. As appropriate, wear dust mask, hearing protectors, gloves and workshop apron
capable of stopping small abrasive or workpiece fragments. The eye protection must be capable of
stopping ying debris generated by various operations . The dust mask or respirator must be capable of
ltrating particles generated by your operation. Prolonged exposure to high intensity noise may cause
hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear
personal protective equipment. Fragments of workpiece or of a broken accessory may y away and
cause injury beyond immediate area of operation.
j) Hold the power tool by insulated gripping surfaces only, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live” wire
may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
k) Position the cord clear of the spinning accessory. If you lose control, the cord may be cut or snagged
and your hand or arm may be pulled into the spinning accessory.
l) Never lay the power tool down until the accessory has come to a complete stop. The spinning
accessory may grab the surface and pull the power tool out of your control.
m) Do not run the power tool while carrying it at your side. Accidental contact with the spinning accessory
could snag your clothing, pulling the accessory into your body.
n) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing and
excessive accumulation of powdered metal may cause electrical hazards.
o) Do not operate the power tool near ammable materials. Sparks could ignite these materials.
p) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in
electrocution or shock.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other
accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the
uncontrolled power tool to be forced in the direction opposite of the accessory’s rotation at the point of the
binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the wheel that is
entering into the pinch point can dig into the surface of the material causing the wheel to climb out or kick
out. The wheel may either jump toward or away from the operator, depending on direction of the wheel’s
movement at the point of pinching. Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be
avoided by taking proper precautions as given below.
a) Maintain a rm grip on the power tool and position your body and arm to allow you to resist
kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or
torque reaction during start-up. The operator can control torque reactions or kickback forces, if proper
precautions are taken.
b) Never place your hand near the rotating accessory. Accessory may kickback over your hand.
c) Do not position your body in the area where power tool will move if kickback occurs. Kickback will
propel the tool in direction opposite to the wheel’s movement at the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause
loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent
kickback and loss of control.
Safety Warnings Specic for Grinding and Abrasive Cutting-Off Operations:
a) Use only wheel types that are recommended for your power tool and the specic guard designed
for the selected wheel. Wheels for which the power tool was not designed cannot be adequately guarded
and are unsafe.
b)The grinding surface of centre depressed wheels must be mounted below the plane of the guard
lip. An improperly mounted wheel that projects through the plane of the guard lip cannot be adequately
protected.
c) Wheels must be used only for recommended applications. For example: do not grind with the side
of cut-off wheel. Abrasive cut-off wheels are intended for peripheral grinding, side forces applied to these
wheels may cause them to shatter.
d) Always use undamaged wheel anges that are of correct size and shape for your selected wheel.
Proper wheel anges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off
wheels may be different from grinding wheel anges.
e) Do not use worn down wheels from larger power tools. Wheel intended for larger power tool is not
suitable for the higher speed of a smaller tool and may burst.
Additional Safety Warnings Specic for Abrasive Cutting-Off Operations:
a) Do not “jam” the cut-off wheel or apply excessive pressure. Do not attempt to make an excessive
depth of cut. Over stressing the wheel increases the loading and susceptibility to twisting or binding of the
wheel in the cut and the possibility of kickback or wheel breakage.
b) Do not position your body in line with and behind the rotating wheel. When the wheel, at the point of
operation, is moving away from your body, the possible kickback may propel the spinning wheel and the
power tool directly at you.
c)When wheel is binding or when interrupting a cut for any reason, switch off the power tool and hold
the power tool motionless until the wheel comes to a complete stop. Never attempt to remove the
cut-off wheel from the cut while the wheel is in motion otherwise kickback may occur. Investigate
and take corrective action to eliminate the cause of wheel binding.
d) Do not restart the cutting operation in the workpiece. Let the wheel reach full speed and carefully
re-enter the cut. The wheel may bind, walk up or kickback if the power tool is restarted in the workpiece.
e) Support panels or any oversized workpiece to minimize the risk of wheel pinching and kickback.
Large workpieces tend to sag under their own weight. Supports must be placed under the workpiece near
the line of cut and near the edge of the workpiece on both sides of the wheel.
f) Use extra caution when making a “pocket cut” into existing walls or other blind areas. The protruding
wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback.
Safety Warnings Specic for Sanding Operations:
a) Do not use excessively oversized sanding disc paper. Follow manufacturers recommendations,
when selecting sanding paper. Larger sanding paper extending beyond the sanding pad presents a
laceration hazard and may cause snagging, tearing of the disc or kickback.
Safety Warnings Specic for Polishing Operations:
a) Do not allow any loose portion of the polishing bonnet or its attachment strings to spin freely. Tuck
away or trim any loose attachment strings. Loose and spinning attachment strings can entangle your
ngers or snag on the workpiece.
Safety Warnings Specic for Wire Brushing Operations:
a) Be aware that wire bristles are thrown by the brush even during ordinary operation. Do not
overstress the wires by applying excessive load to the brush. The wire bristles can easily penetrate
light clothing and/or skin.
b)If the use of a guard is recommended for wire brushing, do not allow any interference of the wire
wheel or brush with the guard. Wire wheel or brush may expand in diameter due to work load and
centrifugal forces.
ROTARY TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY

size 445 x 210 mm
Danger! - Read the operating instructions to
reduce the risk of inquiry
Caution! Wear ear-mus. The impact of noise
can cause damage to hearing.
Caution! Wear a breathing mask. Dust which
is injurious to health can be generated when
working on wood and other materials. Never use
the device to work on any materials containing
asbestos!
Caution! Wear safety goggles. Sparks gene-
rated during working or splinters, chips and dust
emitted by the device can cause loss of sight.
The reprinting or reproduction by any other me-
ans, in whole or in part, of documentation and
papers accompanying products is permitted only
with the express consent of the iSC GmbH.
Subject to technical changes
RTR-2000U
GB Additonal operating & safety instructions Rotary Tool
Service information
We have competent service partners in all countries named on the guarantee certi cate whose contact
details can also be found on the guarantee certi cate. These partners will help you with all service re-
quests such as repairs, spare and wearing part orders or the purchase of consumables.
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts* Carbon brushes, clamping spindles, arbors,
sleeves, exible shafts
Consumables* grinding wheels, grinding/sanding belts, cutters
(routers), felt polishers, drill bits, grinding pins,
cutting-o wheels, grinding heads, wire brushes
Missing parts
* Not necessarily included in the scope of delivery!
In the e ect of defects or faults, please register the problem on the internet at www.isc-gmbh.info.
Please ensure that you provide a precise description of the problem and answer the following questions
in all cases:
• Did the equipment work at all or was it defective from the beginning?
• Did you notice anything (symptom or defect) prior to the failure?
• What malfunction does the equipment have in your opinion (main symptom)?
Describe this malfunction.
Yang/Product-ManagementWeichselgartner/General-Manager
- 135 -
explains the following conformity according to EU directives and norms for
the following product
Rotary Tool RTR-2000U (Ozito)
2014/29/EU
2005/32/EC_2009/125/EC
2014/35/EU
2006/28/EC
X2014/30/EU
2014/32/EU
2014/53/EC
2014/68/EU
90/396/EC_2009/142/EC
89/686/EC_96/58/EC
X2011/65/EU
X2006/42/EC
Annex IV
Noti ed Body:
Noti ed Body No.:
Reg. No.:
2000/14/EC_2005/88/EC
Annex V
Annex VI
Noise: measured LWA = dB (A); guaranteed LWA = dB (A)
P = KW; L/Ø = cm
Noti ed Body:
2004/26/EC
Emission No.:
Standard references: EN 60745-1; EN 60745-2-1; EN 60745-2-23;
EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3
Landau/Isar, den 09.06.2016
First CE: 16 Archive-File/Record: NAPR014307
Art.-No.: 44.722.13 I.-No.: 11016 Documents registrar: R. Gehard
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
ISC GmbH · Eschenstraße 6 · D-94405 Landau/Isar
Declaration of conrmity

size 445 x 210 mm
Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suocating!
Proper use
The Grinding and Engraving Set is designed to
perform drilling, grinding, deburring, polishing,
engraving, cutting, milling and cleaning jobs
on wood, metal and plastic in model-making,
workshop and household applications. Use the
tool and accessories only for those applications
described.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Technical data
Operating voltage of the drive unit:.......................
.................................................230-240 V~ 50 Hz
Power input: .............................................. 170 W
Idle speed n0:........................... 8,000-35,000/min
Clamping range:................................. 1.5-3.2 mm
Protection class: ...........................................II / &
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level ........................ 73 dB(A)
KpA uncertainty ............................................. 3 dB
LWA sound power level .......................... 84 dB(A)
KWA uncertainty ............................................. 3 dB
Wear ear-mus.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 60745.
Vibration emission value ah ≤ 3.74 m/s2
K uncertainty = 1.5 m/s2
The specied vibration value was established in
accordance with a standardized testing method.
It may change according to how the electric
equipment is used and may exceed the specied
value in exceptional circumstances.
The specied vibration value can be used to
compare the equipment with other electric power
tools.
The specied vibration value can be used for initi-
al assessment of a harmful eect.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect wor-
king order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever
necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in ac-
cordance with instructions, certain residual
risks cannot be rules out. The following ha-
zards may arise in connection with the equip-
ment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protecti-
on is used.
3. Health damage caused by hand-arm vibra-
tions if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2012/19/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to
the manufacturer, the owner of the electrical
equipment must make sure that the equipment
is properly disposed of if he no longer wants to
keep the equipment.The old equipment can be
returned to a suitable collection point that will
dispose of the equipment in accordance with the
national recycling and waste disposal regulations.
This does not apply to any accessories or aids
without electrical components supplied with the
old equipment.
Table of contents
Other Ozito Power Tools manuals

Ozito
Ozito ROU-5000 User manual

Ozito
Ozito OWBK-30 User manual

Ozito
Ozito PXMFTS-100 User manual

Ozito
Ozito PXC PXHPCS-018 User manual

Ozito
Ozito PXCSS-500 User manual

Ozito
Ozito ACG-PRO User manual

Ozito
Ozito RTR-040U Installation instructions

Ozito
Ozito WSS-200 User manual

Ozito
Ozito DP-350U User manual

Ozito
Ozito HGN-2100 User manual

Ozito
Ozito MTC-0123 User manual

Ozito
Ozito DP-350 User manual

Ozito
Ozito PXC PXRTS-018 User manual

Ozito
Ozito MFR-2100 User manual

Ozito
Ozito JSW-6800 User manual

Ozito
Ozito OZHG2000WAK User manual

Ozito
Ozito OZJS400A User manual

Ozito
Ozito MFR-250 User manual

Ozito
Ozito ZLGGS-012 User manual

Ozito
Ozito MFR-2200U User manual
