Compact electric heater
The Compact electric heater is available with outputs from 3kW to 18kW, see identity plate placed on the body. It shall by safety reasons
be equipped with a ow switch or a pressure switch. In the connection box a thermostat and/or an overheating limit control can be
mounted. The standard heater must not be used in aggressive water, salt water or in pools where a salt/chlorinator is used. In such
circumstances a Compact electric heater Titanium/Nic-tech is required.
Stainless steel/Incoloy Titanium/Nic-Tech
Follow these instructions: Chlorine content: max 3 mg/l (ppm) max 3 mg/l (ppm)
Chloride (salt) content: max 250 mg /l -
pH-value: 7,2 - 7,8 7,2 - 7,8
Alkalinity: 60-120 mg/l (ppm) 60-120 mg(l (ppm)
Calcium hardness: 200-1000 mg/l (ppm) 200-1000 mg/l (ppm)
Max temperature: 110°C 110°C
Max pressure without pressure switch: 10 bar 10 bar
Max pressure with pressure switch: 2,5 bar 2,5 bar
Minimum ow without ow switch: 20 l/min 20 l/min
Minimum ow with ow switch: 85 l/min 85 l/min
Safety
If the heater is mounted against inammable material the installer must place a gypsam wallboard between the heater and the inam-
mable wall. The board must protrude a minimum of 10 cm outside the body of the heater. The heater must not be covered, enclosed
in or placed near inammable material.
Assembly the heater
The connection box shall be mounted on the body/heating element as shown in picture 2. Accessories like overheating limit control
and/or thermostat shall be mounted in the box according to the separate instruction included in the kits.
The ow switch shall be mounted so the direction of the arrow on the ow switch housing comply with the direction of the water ow.
The pressure switch shall be connected to terminal block 1 and 3.
Pipe installation
The pipe installation must be done before the electric installation. The electric heater must be installed in a horizontal position on the
return pipe to the pool, after the lter, so that it is ooded at all times, see installation illustration. The heater may be installed in a vertical
position only if there is a positive pressure of water in the tubes of at least 50 cm.
Do not install a gate valve between heater and pool. If a valve is required, install a check valve.
Dosage of chlorine, acid or similar, must be done after the heater in the ow direction to avoid corrosion.
In case of climates with sub-zero temperatures the heater must be installed so that it can be emptied.
Electric installation
The electric installation must be done by a licenced electrician.
The heater shall be connected over one or two contactors, depending on type of heater, see wiring diagram.
Connect earth to heating element according to picture 2.
The heater shall be installed in such way that it cannot be activated if the circulation pump is not working (sufcient ow), i.e. the power
supply to the contactor must be guided over the motor protection of the pump.
Start 1. Start the pump of the pool water circulation.
2. Check that the water circulation is normal before the heater is turned on.
3. Test the heater by turning the thermostat knob back and forth and check that the contactor of the thermostat turns on and off.
Check any ow switch or pressure switch by turning off the ow through the heater with a gate valve and control that the
contactor is beeing deenergized.
4. Set desired pool water temperature by turning the thermostat knob.
5. The heater will now heat the pool water to desired temperature.
Management
When back-washing and cleaning the lter, the power to the heater must be turned off.
The heater must be drained before it is exposed to sub-zero temperatures or if the pool system is closed for a longer time.
If the heater does not start
a) Check the fuses.
b) The overheating limit control is released:
-Losen the protective cap, see g beside.
-Press the reset button on the connection box.
-Put the cap back.
c) Any pressure switch is not closed: The pressure switch is pre-installed on 0,2 bar. If a correct pressure is not attainable, the return
pipe to the pool shall be somewhat cut down in order to increase the back pressure in the return pipe.
d) Check that the direction of the arrow on the ow switch housing agree to the direction of the water ow.
e) Reset the thermostat to a higher temperature.
Flow switch here
Picture 1
Pressure switch here
