Light Emitting Diodes
LN49YPX
Round Type
φ4.0 mm
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Power dissipation PD90 mW
Forward current IF30 mA
Pulse forward current *IFP 150 mA
Reverse voltage VR4 V
Operating ambient temperature Topr –25 to +85 °C
Storage temperature Tstg –30 to +100 °C
Note) *: The condition of IFP is duty 10%, Pulse width 1 msec.
Electro-Optical Characteristics Ta= 25°C
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity IO3.5 10.0 mcd
Reverse current IRVR= 4 V 10 µA
Forward voltage VFIF= 20 mA 2.2 2.8 V
Peak emission wavelength λPIF= 20 mA 590 nm
Spectral half band width Δλ IF= 20 mA 30 nm
Directive characteristics
IOIFIFVF
IFTa
Relative luminous intensity (%) Ambient temperature Ta(°C)
Ambient temperature Ta(°C)
Forward current IF(mA)
Forward voltage VF(V)
Forward current IF(mA)
Luminous intensity IO(mcd)
Relative luminous intensity (%)
Forward current IF(mA)
Relative luminous intensity (%)
Relative luminous intensity Ta
Relative luminous intensity λP
Peak emission wavelength λP(nm)
500
1000
300
30
50
100
10 0−20 80 100604020
1.6 1.8 2.0 2.42.2
31 5 10 50 10030
100
50
30
5
3
10
1
10
5
3
0.5
0.3
1
0.1
20°
30°
40°
50°
10°
0°
60°
70°
80°
90°
90°
80°
20°
30°
40°
50°
10°
60°
70°
80°
20°
40°
60°
020
20
10
0
30
40
50
40 60 80 100
100
500 600 700 800
80
60
40
20
0
0 20 40 60 80 10020406080100
Lighting Color
Amber

SHD00394BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
LN49YPX
2
Package (Unit: mm)
LLXLTN2SK090
0.45 ±0.1
5
4
.
3±
±0.6 ±2.
0
8
.
0
2.1
φ 0.5
±2
.
0
1 2
2.54
5
.
1
2− 0.7 Max
2− 0.45 ± 0.1
0
.
1
φ 5.0 ± 0.2φ 4.0 ± 0.2
DEREDL
O
S
T
ON.
xa
M0.2
0.3
26.5 1.0
Pin name
1: Anode
2: Cathode
