Panasonic MA2YD17 User manual

Schottky Barrier Diodes (SBD)
1
Publication date: April 2004 SKH00032BED
MA2YD17
Silicon epitaxial planar type
For high frequency rectification
■Features
•Reverse voltage VR=100 V is guaranteed
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Rating Unit
Reverse voltage VR100 V
Maximum peak reverse voltage VRM 100 V
Forward current (Average) IF(AV) 300 mA
Non-repetitive peak forward IFSM 1.5 A
surge current *
Junction temperature Tj125 °C
Storage temperature Tstg −55 to +125 °C
Note) *: The peak-to-peak value in one cycle of 50 Hz sine wave (non-repetitive)
Marking Symbol: 2T
1: Anode
2: Cathode Mini2-F1 Package
Unit: mm
5˚
1.6
±0.1
1
2
0.80
±0.05
0.55 ±0.1
0.16
+0.1
–0.06
3.5
±0.1
2.6
±0.1
0.45 ±0.1
5˚
0 to 0.1
0 to 0.3
0 to 0.1
Parameter Symbol Conditions Min Typ Max Unit
Forward voltage VFIF=300 mA 0.50 0.58 V
Reverse current IRVR=100 V 200 µA
Terminal capacitance CtVR=0 V, f =1 MHz 100 pF
Reverse recovery time *trr IF=IR=100 mA 7 ns
Irr =0.1 IR , RL=100 Ω
■Electrical Characteristics Ta=25°C ±3°C
Bias Application Unit (N-50BU)
90%
Pulse Generator
(PG-10N)
Rs= 50 Ω
Wave Form Analyzer
(SAS-8130)
Ri= 50 Ω
tp= 2 µs
tr= 0.35 ns
δ = 0.05
IF=100 mA
IR=100 mA
RL=100 Ω
10%
Input Pulse Output Pulse
Irr =0.1 IR
trtp
trr
VR
IF
t
t
A
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. This product is sensitive to electric shock (static electricity, etc.). Due attention must be paid on the charge of a human body
and the leakage of current from the operating equipment.
3. *: trr measurement circuit
This product complies with the RoHS Directive (EU 2002/95/EC).

2
MA2YD17
SKH00032BED
IFVFIRVRCtVR
10
−2
0 0.2 0.4 0.6
10
−1
10
2
10
3
1
10
Forward voltage V
F
(V)
Forward current I
F
(mA)
T
a
=125°C
75°C
25°C
−20°C
10
10 40 80 120
10
2
10
3
10
4
10
5
Reverse voltage V
R
(V)
Reverse current I
R
(µA)
T
a
=125°C
75°C
25°C
0
80
40
0 40 80 120
Reverse voltage VR(V)
Terminal capacitance C
t
(pF)
T
a = 25°C
This product complies with the RoHS Directive (EU 2002/95/EC).
