2SC4656G
Silicon NPN epitaxial planar type
For high-frequency amplification
Complementary to 2SA1791G
■Features
•High transition frequency fT
•Small collector output capacitance (Common base, input open cir-
cuited) Cob
•SS-Mini type package, allowing downsizing of the equipment
and automatic insertion through the tape packing
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO 50 V
Collector-emitter voltage (Base open) VCEO 50 V
Emitter-base voltage (Collector open) VEBO 5V
Collector current IC50 mA
Collector power dissipation PC125 mW
Junction temperature Tj125 °C
Storage temperature Tstg −55 to +125 °C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) VCBO IC=10 µA, IE=050V
Collector-emitter voltage (Base open) VCEO IC=1 mA, IB=050V
Emitter-base voltage (Collector open) VEBO IE=10 µA, IC=05V
Collector-base cutoff current (Emitter open) ICBO VCB =10 V, IE=0 0.1 µA
Collector-emitter cutoff current (Base open) ICEO VCE =10 V, IB=0 100 µA
Forward current transfer ratio *hFE VCE =10 V, IC=2 mA 200 500 
Collector-emitter saturation voltage VCE(sat) IC=10 mA, IB=1 mA 0.06 0.3 V
Transition frequency fTVCB =10 V, IE=−2 mA, f =200 MHz 250 MHz
Collector output capacitance Cob VCB =10 V, IE=0, f =1 MHz 1.5 pF
(Common base, input open circuited)
■Electrical Characteristics Ta=25°C ±3°C
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
Rank Q R
hFE 200 to 400 250 to 500
■Package
•Code
SSMini3-F3
•Marking Symbol: AM
•Pin Name
1. Base
2. Emitter
3. Collector

2SC4656G
2SJC00393AED
This product complies with the RoHS Directive (EU 2002/95/EC).
VCE(sat) IChFE ICCob VCB
PCTaICVCE ICVBE
040 80 120
0
20
40
60
80
100
120
140
Collector power dissipation P
C
(mW)
Ambient temperature T
a
(°C)
012108264
0
60
50
20
10
40
30
IB=100 µA
90 µ A
80 µ A
60 µ A
70 µ A
50 µ A
Ta=25°C
Collector current I
C
(mA)
Collector-emitter voltage V
CE
(V)
0 0.2 0.6 0.8 1.0 1.20.4 1.4
0
50
30
40
20
10
VCE = 10 V
Ta= 85°C
25°C
−25°C
Base-emitter voltage V
BE
(V)
Collector current I
C
(mA)
I
C
/ I
B
= 10
Collector current IC(mA)
Collector-emitter saturation voltage VCE(sat) (V)
0.01
0.1
0.1
1
1 10 100
T
a
=85°C
−25°C
25°C
Ta= 85°C
25°C
−25°C
VCE = 10 V
Collector current IC(mA)
Forward current transfer ratio hFE
1 10 100
0
700
400
500
600
300
200
100
04010 3020
f =1 MHz
T
a
= 25°C
Collector-base voltage V
CB
(V)
Collector output capacitance (Common base, input open circuited) C
ob
(pF)
10
1
0.1

This product complies with the RoHS Directive (EU 2002/95/EC).
SSMini3-F3 Unit: mm
1.00 ±0.05
(0.50) (0.50)
1.60 +0.05 −0.03
0.26 +0.05 −0.02
12
3
0.85 +0.05
−0.03
1.60 ±0.05
0.70 +0.05
−0.03
0 to 0.10
(5°)
(0.45)
0.13 +0.05
−0.02
0.375 ±0.05
(5°)
