Panasonic AW-RP60G User manual

DVQP2221ZA
W1219JW0 -PS
ENGLISH
For details of operating Remote Camera Controller AW-RP60G, please visit
the Panasonic website (https://pro-av.panasonic.net/manual/en/index.html),
and refer to the Operating Instructions (HTML or PDF).
Read this document when using the AW-RP60G Remote Camera Controller in
conjunction with AW-UE150 Series 4K Integrated Cameras.
Operating Guide
Remote Camera Controller
Model No. AW-RP60G

Connecting the Unit to AW-UE150 Series Cameras 3
Connection Example 3
Connections 4
Compatible Functions List 5
Menu (when AW-UE150 is connected) 7
Remote Controller Menu List 7
PAINT 8
SCENE 8
SHUTTER 8
CHROMA 9
GAIN 9
WHITE BALANCE 10
GAMMA 10
BLACK GAMMA 11
DRS 11
KNEE 12
WHITE CLIP 12
DTL 13
DOWNCON DTL 14
MATRIX 14
COLOR CORRECT 15
DNR 17
PEDESTAL 17
BRIGHTNESS 18
FUNCTION 19
USER ASSIGN 19
CAMERA INFO 19
PTZ INFO1 20
PTZ INFO2 20
HOUSING 20
CROP 20
MAINTENANCE 21
RP SETTING 21
RP INITIALIZE 21
RP VERSION 21
GPI TALLY 21
GPIO CAM SEL 21
GPO CAM.G 21
GPI PMEM 21
GPI PMEM.G 21
PMEM/TMEM 22
PMEM LIST 22
SETTING 22
SYSTEM 23
CAMERA 23
CONNECT SETTING 23
MANUAL IP SET/USER AUTH 23
AUTO IP SET 23
RP IP SET 23
TRACKING 23
- 2 -
Table of Contents

Connecting the Unit to AW-UE150 Series Cameras
Connection Example
Serial connection with AW-UE150
12 V IN
IR ID AUDIO IN
RS-422
SERVICE
MONI OUT 12G SDI OUT
3G SDI OUT G/L IN
LAN
LINK ACT
OPTICAL
External DC
power supply
LAN cable
(straight cable or cross cable)
PoE compatible switching hub
or injector
<RS-422> connector
LAN cable (straight cable)
4K Integrated Camera
AW-UE150
IP connection with AW-UE150
12 V IN
IR ID AUDIO IN
RS-422
SERVICE
MONI OUT 12G SDI OUT
3G SDI OUT G/L IN
LAN
LINK ACT
OPTICAL
External DC
power supply
LAN cable
(straight cable or cross cable)
LAN cable
(straight cable or cross cable)
PoE compatible
switching hub
<LAN LINK/ACT>
connector
4K Integrated Camera
AW-UE150
- 3 -
Connecting the Unit to AW-UE150 Series Cameras

Connections
Set the connection setting to “Serial” or “LAN” in the [CONNECT SETTING] menu.
&211(&76(77,1*
CAM SEL
&$0
6HULDO
6HULDO
121
121
121
121
121
121
121
CONNECT
MODE
CAM1 CAM3 CAM4CAM2
CAM5 CAM7 CAM8CAM6
$:8(
When connecting, observe the following points.
Serial connection
Connect the <SERIAL CONT 1 to 5> connector on this unit to the <RS-422> connector on the AW-UE150 using a LAN
cable (sold separately).
Use a straight cable (category 5e or higher; up to 1000 m (3280 ft) in length) for the LAN cable.
Do not connect a cable for PoE supply to the <SERIAL CONT 1 to 5> connector of this unit.
LAN connection
Connect the <IP CONT> connector on this unit to the <LAN LINK/ACT> connector on the AW-UE150 using a LAN cable
(sold separately).
Use a straight cable or cross cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).
Configure the camera IP address and port number settings of the connection destinations in [SYSTEM] menu as well.
This unit can be powered using PoE. Use a switching hub with PoE support.
For details on switching hubs and PoE injectors that have been verified to support PoE, consult with your dealer.
- 4 -
Connecting the Unit to AW-UE150 Series Cameras

Compatible Functions List
There will be functions that are limited or disabled for some of the unit's buttons, dials, and other controls. Be sure to refer to the following
table.
ヱヰヸユンヮユワヶヴヵヰンユュユロユヵユヱンユヴユヵモヸャモヶヵヰリンリヴ・ヰヰヮョヰヤヶヴモヶヵヰヱヵ・チヴヱユユュ
ロヰヸラリ
ヤモヮユンモチヴユロユヤヵリヰワヱンユヴユヵチヮユヮヰンヺチヴユロユヤヵリヰワ
ヰヵモョ
ヸリュユ
ヵユロユ
モャャョヒ
ヒビピフブヒビピフブプヘベペヒパ
ョビョピョフヴユロユヤヵヰワバヰョョヤモヮユンモチヰヴュユヹリヵョブヶヴユンチヒヶヴユンチビヶヴユンチピユワモャロユヴラリョヵヱモワヵリロヵヶヴユンチフャモンヴモロモンヮ
Color adjustment section User button section
Preset memory
selection section
Menu operation
section
Pan and tilt
section
Camera
selection section
Focus, zoom and iris
section
Control panel Buttons, dials
✓: Enabled
×: Disabled
Remarks
Menu operation section
[CAMERA OSD SELECT] dial ✓
[F5] dial ✓
[F1], [F2], [F3], [F4] dials ✓
[CAMERA OSD ON/OFF] button ✓
[EXIT] button ✓
Camera selection sec-
tion
[CAMERA SELECTION 1 to 5] buttons ✓
Camera status LED ✓
Pan and tilt section
[ENABLE] button ✓
[PTZ SPEED] dial ✓
[PAN/TILT] lever ✓
- 5 -
Connecting the Unit to AW-UE150 Series Cameras

Control panel Buttons, dials
✓: Enabled
×: Disabled
Remarks
Focus, zoom and iris
section
[IRIS] dial ✓
[ZOOM] button ✓
[IRIS AUTO] button ✓
[FOCUS] dial ✓
[FOCUS AUTO] button ✓
Color adjustment sec-
tion
[BARS] button ✓
[AWB] button ✓
[ABB] button ✓
Preset memory selec-
tion section
[PRESET STORE] button ✓
[PRESET DELETE] button ✓
[PRESET MEMORY SELECTION 1 to 10]
buttons
✓
User button section
[USER 1] to [USER 4] buttons ✓
[SHIFT] button ✓
- 6 -
Connecting the Unit to AW-UE150 Series Cameras

Menu (when AW-UE150 is connected)
Remote Controller Menu List
When an AW-UE150 4K Integrated Camera is connected, the menu will be as follows. The setting values will vary depending on the con-
nected model. Depending on the model, unsupported functions will be displayed as [-].
For details on menu operations, refer to the following sections in the Operating Instructions.
“Basic operations for the menus”
PAINT
SCENE “SCENE” (see page 8)
SHUTTER “SHUTTER” (see page 8)
CHROMA “CHROMA” (see page 9)
GAIN “GAIN” (see page 9)
WHITE BALANCE “WHITE BALANCE” (see page 10)
GAMMA “GAMMA” (see page 10)
BLACK GAMMA “BLACK GAMMA” (see page 11)
DRS “DRS” (see page 11)
KNEE “KNEE” (see page 12)
WHITE CLIP “WHITE CLIP” (see page 12)
DTL “DTL” (see page 13)
DOWNCON DTL “DOWNCON DTL” (see page 14)
MATRIX “MATRIX” (see page 14)
COLOR CORRECT “COLOR CORRECT” (see page 15)
DNR “DNR” (see page 17)
PEDESTAL “PEDESTAL” (see page 17)
BRIGHTNESS “BRIGHTNESS” (see page 18)
FUNCTION
USER ASSIGN Refer to the following section in the Operating Instructions.
“FUNCTION”
CAMERA INFO “CAMERA INFO” (see page 19)
PTZ INFO1 Refer to the following section in the Operating Instructions.
“FUNCTION”
PTZ INFO2
HOUSING
CROP “CROP” (see page 20)
MAINTENANCE
RP SETTING Refer to the following section in the Operating Instructions.
“MAINTENANCE”
RP INITIALIZE
RP VERSION
GPI TALLY
GPIO CAM SEL
GPO CAM.G
GPI PMEM
GPI PMEM.G
PMEM/TMEM
PMEM LIST Refer to the following section in the Operating Instructions.
“PMEM/TMEM”
SETTING
SYSTEM
CAMERA Refer to the following section in the Operating Instructions.
“SYSTEM”
CONNECT SETTING
MANUAL IP SET/USER AUTH
AUTO IP SET
RP IP SET
TRACKING
- 7 -
Menu (when AW-UE150 is connected)

PAINT
SCENE
$:8(
6&(1(
SCENE
6&(1(

Item Setting details
SCENE Switches the shooting mode that matches the shooting situation.
SHUTTER
$:8(
6+877(5
MODE
2))شSPEED ELC LIMIT 
Item Setting details
MODE Selects the shutter mode for the camera.
SPEED Selects the shutter speed for the camera.
ELC LIMIT Sets the maximum shutter value for ELC operation.
- 8 -
Menu (when AW-UE150 is connected)

CHROMA
$:8(
&+520$
LEVEL
PHASE 
Item Setting details
LEVEL Sets the color intensity of images.
PHASE Finely adjusts the color phase of images.
GAIN
$:8(
*$,1
S.GAIN AGC MAXGAIN
2))G%G%
Item Setting details
S.GAIN Sets the mode for super gain (increased sensitivity).
GAIN Adjusts the gain of images.
AGC MAX When “AUTO” is selected as the [GAIN] setting, the maximum gain-up amount can be set.
- 9 -
Menu (when AW-UE150 is connected)

WHITE BALANCE
$:8(
:+,7(%$/$1&(
MODE
$:%$
ش


R GAIN B GAIN
COLOR
TEMP
OFFSET
2))1250$/ATW
TARGET B
ATW
TARGET R
ATW
SPEED 
Item Setting details
MODE Sets the white balance mode.
COLOR TEMP Allows you to specify the color temperature between 2000K and 15000K.
R GAIN Adjusts the gain of the R channel.
B GAIN Adjusts the gain of the B channel.
OFFSET When auto white balance is performed by setting [MODE] to “AWB A” or “AWB B”, sets the values for Rch
gain and Bch gain.
ATW SPEED Sets the control speed of the ATW function.
ATW TARGET R Finely adjusts the Rch output when converged in the auto tracking white balance operation.
ATW TARGET B Finely adjusts the Bch output when converged in the auto tracking white balance operation.
GAMMA
$:8(
*$00$
MODE
+'GAMMA
V-REC
KNEE SLP V-REC KNEE PINT
F-REC
DYNAMIC
F-REC
BLK STR
Item Setting details
MODE Selects the type of gamma curve.
GAMMA Adjusts the gamma correction level. This is enabled only when [MODE] is set to other than “HLG”.
F-REC DYNAMIC Sets the dynamic range. This is enabled when [MODE] is “FREC” (FILM REC).
F-REC BLK STR Sets the black stretch. This is enabled when [MODE] is “FREC” (FILM REC).
V-REC KNEE SLP Sets the knee slope. This is enabled when [MODE] is “VREC” (VIDEO REC).
V-REC KNEE PINT Sets the knee point. This is enabled when [MODE] is “VREC” (VIDEO REC).
- 10 -
Menu (when AW-UE150 is connected)

BLACK GAMMA
$:8(
%/$&.*$00$
BLACK
GAMMA


RANGE 
Item Setting details
BLACK GAMMA Sets the gamma curve for dark areas.
RANGE Sets the maximum level for compression/expansion.
DRS
$:8(
'56
DRS
2))

Item Setting details
DRS Sets the DRS function which performs correction when video with high light/dark contrast is displayed.
- 11 -
Menu (when AW-UE150 is connected)

KNEE
$:8(
.1((
MODE
$872AT KNEE
RESPONSE
HLG
KNEE SLP
2))HLG
KNEE SW
HLG
KNEE PNT
POINT
SLOPE 
Item Setting details
MODE Sets the operating mode for gradation compression (knee).
AT KNEE RESPONSE Sets the auto knee response speed.
This is enabled only when [MODE] on the [GAMMA] menu is set to other than “HLG”.
POINT Sets the compression level (knee point) position for high-brightness video signals.
This is enabled only when [MODE] on the [GAMMA] menu is set to other than “HLG”.
This is enabled when [MODE] is “MANUAL”.
SLOPE Sets the knee slope.
This is enabled only when [MODE] on the [GAMMA] menu is set to other than “HLG”.
This is enabled when [MODE] is “MANUAL”.
HLG KNEE SW Enables/disables HLG knee operation.
This is enabled only when [MODE] on the [GAMMA] menu is set to “HLG”.
HLG KNEE PNT Sets the HLG knee point position.
This is enabled only when [MODE] on the [GAMMA] menu is set to “HLG”.
HLG KNEE SLP Sets the HLG knee slope.
This is enabled only when [MODE] on the [GAMMA] menu is set to “HLG”.
WHITE CLIP
$:8(
:+,7(&/,3
CLIP LEVEL
21
Item Setting details
CLIP Sets the white clip function to ON/OFF.
This is enabled only when [MODE] on the [GAMMA] menu is set to other than “HLG”.
LEVEL Sets the white clip level.
This is enabled only when [MODE] on the [GAMMA] menu is set to other than “HLG”.
This is enabled when [CLIP] is “ON”.
- 12 -
Menu (when AW-UE150 is connected)

DTL
$:8(
'7/
M.DTL FREQUENCY
GAIN(+) GAIN(-)
CORING V DTL
LEVEL
LEVEL
DEPEND.
KNEE APE.
LEVEL
SKIN
DTL
SKIN
EFFECT DTL SW
2))21
Item Setting details
M.DTL Adjusts the contour correction level (master).
This is enabled when [DTL SW] is “ON”.
CORING Sets the level of signal (including noise) that does not activate the detail effect.
This is enabled when [DTL SW] is “ON”.
V DTL LEVEL Adjusts the vertical contour correction level.
This is enabled when [DTL SW] is “ON”.
FREQUENCY Sets the boost frequency for detail.
This is enabled when [DTL SW] is “ON”.
LEVEL DEPEND. Compresses the detail in the dark areas when the detail of the bright signal is emphasized. The larger the
[LEVEL DEPEND.] setting, the more detail of bright parts is compressed.
This is enabled when [DTL SW] is “ON”.
KNEE APE. LEVEL Sets the detail level of high luminosity areas (extremely bright areas).
This is enabled when [DTL SW] is “ON”.
GAIN(+) Sets the detail level of the plus direction (direction to make brighter).
This is enabled when [DTL SW] is “ON”.
GAIN(-) Sets the detail level of the minus direction (direction to make darker).
SKIN DTL This function is selected to make the skin of the subjects to be shot appear to be smoother and more attract-
ive.
This is enabled when [DTL SW] is “ON”.
SKIN EFFECT The higher the setting value, the smoother the skin of the subjects you shoot appears.
This is enabled when [DTL SW] and [SKIN DTL] are “ON”.
DTL SW Sets image contour (image sharpness) adjustment to ON/OFF.
- 13 -
Menu (when AW-UE150 is connected)

DOWNCON DTL
$:8(
'2:1&21'7/
M.DTL FREQUENCYCORING V DTL
LEVEL
LEVEL
DEPEND.
KNEE APE.
LEVEL
DTL
SW
21
Item Setting details
M.DTL Adjusts the contour correction level (master) for images down-converted from 4K to HD.
This is enabled when [DTL SW] is “ON”.
CORING Sets the level of signal (including noise) that does not activate the detail effect for images down-converted
from 4K to HD.
This is enabled when [DTL SW] is “ON”.
V DTL LEVEL Adjusts the vertical contour correction level for images down-converted from 4K to HD.
This is enabled when [DTL SW] is “ON”.
FREQUENCY Sets the boost frequency of detail for images down-converted from 4K to HD.
This is enabled when [DTL SW] is “ON”.
LEVEL DEPEND. The larger the setting for images down-converted from 4K to HD, the more detail of bright parts is com-
pressed.
This is enabled when [DTL SW] is “ON”.
KNEE APE. LEVEL Sets the detail level of high luminosity areas (extremely bright areas) for images down-converted from 4K to
HD.
This is enabled when [DTL SW] is “ON”.
DTL SW Sets image contour (image sharpness) adjustment to ON/OFF for images down-converted from 4K to HD.
This is enabled when the output format is set as follows.
2160/59.94p, 2160/29.97p, 2160/23.98p, 2160/24p, 2160/50p, 2160/25p
MATRIX
$:8(
0$75,;
TYPE
1250$/G-RR-BR-G G-B
B-GB-R
Item Setting details
TYPE Selects the type of color matrix.
R-G, R-B, G-R, G-B, B-
R, B-G
Adjusts the color for each axis direction.
- 14 -
Menu (when AW-UE150 is connected)

COLOR CORRECT
$:8(
&2/25&255(&7
TYPE
%B0JCORRECT PHASESAT
SAT
B_Mg
SAT
Mg
PHASE
Mg
PHASE
B_Mg
1250$/
$:8(
&2/25&255(&7
SAT
Mg_R
SAT
Mg_R_R
PHASE
Mg_R_R
PHASE
Mg_R
SAT
R
SAT
R_R_Yl
PHASE
R_R_Yl
PHASE
R
SAT
R_Yl
SAT
R_YI_Yl
PHASE
R_Yl_Yl
PHASE
R_Yl
$:8(
&2/25&255(&7
SAT
Yl
SAT
Yl_Yl_G
PHASE
Yl_Yl_G
PHASE
Yl
SAT
Yl_G
SAT
G
PHASE
G
PHASE
Yl_G
SAT
G_Cy
SAT
Cy
PHASE
Cy
PHASE
G_Cy
- 15 -
Menu (when AW-UE150 is connected)

$:8(
&2/25&255(&7
SAT
Cy_B
SAT
B
PHASE
B
PHASE
Cy_B
Item Setting details
TYPE Selects the type of color matrix.
CORRECT Adjusts the saturation and hue.
SAT Adjusts the saturation for each color.
PHASE Adjusts the hue for each color.
SAT B_Mg Adjusts the saturation of the color between blue and magenta.
PHASE B_Mg Adjusts the hue of the color between blue and magenta.
SAT Mg Adjusts magenta saturation.
PHASE Mg Adjusts magenta hue.
SAT Mg_R Adjusts the saturation of the color between magenta and red.
PHASE Mg_R Adjusts the hue of the color between magenta and red.
SAT Mg_R_R Adjusts the saturation of the color with a 1:3 magenta to red ratio.
PHASE Mg_R_R Adjusts the hue of the color with a 1:3 magenta to red ratio.
SAT R Adjusts red saturation.
PHASE R Adjusts red hue.
SAT R_R_Yl Adjusts the saturation of the color with a 3:1 red to yellow ratio.
PHASE R_R_Yl Adjusts the hue of the color with a 3:1 red to yellow ratio.
SAT R_Yl Adjusts the saturation of the color between red and yellow.
PHASE R_Yl Adjusts the hue of the color between red and yellow.
SAT R_Yl_Yl Adjusts the saturation of the color with a 1:3 red to yellow ratio.
PHASE R_Yl_Yl Adjusts the hue of the color with a 1:3 red to yellow ratio.
SAT Yl Adjusts yellow saturation.
PHASE Yl Adjusts yellow hue.
SAT Yl_Yl_G Adjusts the saturation of the color with a 3:1 yellow to green ratio.
PHASE Yl_Yl_G Adjusts the hue of the color with a 3:1 yellow to green ratio.
SAT Yl_G Adjusts the saturation of the color between yellow and green.
PHASE Yl_G Adjusts the hue of the color between yellow and green.
SAT G Adjusts green saturation.
PHASE G Adjusts green hue.
SAT G_Cy Adjusts the saturation of the color between green and cyan.
PHASE G_Cy Adjusts the hue of the color between green and cyan.
SAT Cy Adjusts cyan saturation.
PHASE Cy Adjusts cyan hue.
SAT Cy_B Adjusts the saturation of the color between cyan and blue.
PHASE Cy_B Adjusts the hue of the color between cyan and blue.
- 16 -
Menu (when AW-UE150 is connected)

Item Setting details
SAT B Adjusts blue saturation.
PHASE B Adjusts blue hue.
DNR
$:8(
'15
DNR
/2:
Item Setting details
DNR Sets the level of the digital noise reduction effect for outputting bright, clear images without noise even at
night and in other low-brightness environments.
PEDESTAL
$:8(
3('(67$/
R PED
M.PED
OFFSET
G PED B PED
2))
Item Setting details
R PED Adjusts the pedestal of the R channel.
G PED Adjusts the pedestal of the G channel.
B PED Adjusts the pedestal of the B channel.
M.PED Adjusts the black level (pedestal).
OFFSET Sets the Rch, Gch, and Bch pedestal levels when the auto black balance is adjusted.
- 17 -
Menu (when AW-UE150 is connected)

BRIGHTNESS
$:8(
%5,*+71(66

2))
'$<
PICTURE
LEVEL
FRAME
MIX
DAY/
NIGHT
Item Setting details
PICTURE LEVEL Sets the target picture level for auto exposure correction.
Its setting takes effect when “AUTO” or “ELC” has been selected as the setting for any of the following auto-
matic exposure compensation functions.
When [IRIS AUTO] button is set to the auto iris (this button is lit)
When [MODE] in the [SHUTTER] menu is set to “ELC”
When [GAIN] in the [GAIN] menu is set to “AUTO”
FRAME MIX Selects for frame addition (gain-up using sensor storage) amount.
This is enabled only when [MODE] on the [SHUTTER] menu is set to “OFF”. When frame addition is per-
formed, it will appear as if the images are missing some frames.
This item is not available when the output format is set as follows.
2160/29.97p, 2160/23.98p, 2160/24p, 2160/25p, 1080/29.97p, 1080/23.98p(59.94i), 1080/23.98p,
1080/24p, 1080/29.97PsF, 1080/23.98PsF, 1080/25p, 1080/25PsF
DAY/NIGHT Switches between standard shooting (day mode) and night-vision shooting (night mode: shooting with
infrared light).
- 18 -
Menu (when AW-UE150 is connected)

FUNCTION
USER ASSIGN
For details on operations and settings, refer to the following section in the Operating Instructions.
“USER ASSIGN”
CAMERA INFO
$:8(
&$0(5$,1)2
ND
1'2))1250$/D.EXTD.ZOOM I.ZOOM
OPT SHOOTING D.ZOOM
MAX
2))[2))2))2))I.S.
$:8(
&$0(5$,1)2
A.IRIS
SPEED
A.IRIS
WINDOW
1250$/
1250$/

Item Setting details
ND Sets the transmittance of the lens’ built-in ND (neutral density) filter.
OPT Turns the night mode ON/OFF.
SHOOTING Selects the shooting mode according to the shooting environment (normal or high-sensitive shooting).
D.ZOOM Sets the digital zoom function to ON/OFF.
D.ZOOM MAX Sets the maximum digital zoom magnification.
This is enabled when [D.ZOOM] is “ON”.
D.EXT Sets the digital extender function.
This is enabled when [D.ZOOM] and [I.ZOOM] are “OFF”.
I.ZOOM Sets the i.Zoom function to ON/OFF.
I.S. Sets the image stabilization to ON/OFF.
A.IRIS SPEED Sets the control speed of the auto iris function.
A.IRIS WINDOW Selects the auto iris detection window.
- 19 -
Menu (when AW-UE150 is connected)

PTZ INFO1
For details on operations and settings, refer to the following section in the Operating Instructions.
“PTZ INFO1”
PTZ INFO2
For details on operations and settings, refer to the following section in the Operating Instructions.
“PTZ INFO2”
HOUSING
For details on operations and settings, refer to the following section in the Operating Instructions.
“HOUSING”
CROP
$:8(
&523
</</*0*H POS V POS
CROP
ADJUST
MARKER SW
2))</CROP
OUT
Item Setting details
SW Sets the Crop function which crops UHD (3840×2160) images to FHD (1920×1080) images to ON/OFF.
CROP ADJUST Selects for the crop frame to adjust positioning.
H POS Sets for the position in the horizontal direction for the crop frame specified in [CROP ADJUST].
0 is the left edge and 1920 is the right edge.
V POS Sets for the position in the vertical direction for the crop frame specified in [CROP ADJUST].
0 is the upper edge and 1080 is the lower edge.
CROP OUT Sets for the crop frame for images output to the <3G SDI OUT> connector and IP.
MARKER Sets for the crop frame displayed for images output to the <MONI OUT> connector.
- 20 -
Menu (when AW-UE150 is connected)
