Panasonic CZ-256ESMC2 User manual

Authorized representative in EU
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany Printed in Japan
Operation Manual
Bedienungsanleitung
Manuale di istruzioni
Manuel d’instructions
Manual de funcionamiento
CZ-256ESMC2
85464609080011
INTELLIGENT CONTROLLER
Access and Operation by Web Browser
CONTRÔLEUR INTELLIGENT
Accès et fonctionnement avec le navigateur Web
TOUCH SCREEN CONTROLLER
Zugriff und Betrieb über Webbrowser
CONTROLLORE INTELLIGENTE
Accesso e funzionamento tramite browser Web
CONTROLADOR INTELIGENTE
Acesso e funcionamento por browser da Web
CONTROLADOR INTELIGENTE
Acceso y funcionamiento a través del navegador Web
EN
UK
RU
ES
PT
IT
DE
FR
Heben Sie diese Anleitung nach dem
Durchlesen an einem günstigen Ort auf.
After reading this manual, store it in a
convenient place.
Dopo aver letto il presente manuale,
conservarlo in un luogo adeguato.
Après avoir lu ce manuel, conservez-le en
lieusûr.
Depois de ler este manual, guarde-o
num lugar queesteja sempre à mão.
Доступ иработа сиспользованием веб-браузера
Доступ ікерування звеб-браузера

Centralized Control
System
CZ-256ESMC2 INTELLIGENT CONTROLLER
Operation Manual Access and Operation by Web Browser
1. Computer Environment
Requirements..............................1
2. Log-in...............................................1
3. Screen Display and Operation .........2
3-1. [Each Tenant] Screen ...............2
3-2. [Each Tenant Details] Screen....5
3-3. [All Units] Screen.......................5
3-4. Distribution Ratio/Usage:
Data Download Screen .............6
3-5. Alarm Log Screen .....................7
3-6. Mail Send Log Screen...............9
3-7. Program Timer Screen............10
3-8. Tenant Holiday/
Timer Special Day Screen.......12
3-9. Prohibit Remote Control
Screen ....................................13
3-10. WEB Settings Screen ...........14
4. Supplementary Information ............18
Contents
Thank you for choosing the CZ-256ESMC2
Intelligent Controller.
Before using the system, be sure to read this
manual carefully.

Access and Operation by Web Browser
1
Access and Operation by Web Browser
Accessing the Intelligent Controller from your computer allows you to monitor/operate air-conditioning
equipment using a Web browser.
1. Computer Environment Requirements
In order to use the web browser of your computer to connect to the Intelligent Controller and
monitor/operate air-conditioning equipment, the following environment requirements must be met.
Supported browser : Internet Explorer 6.0 or later
Javaapplet : Sun Microsystems Java Plugin Ver 1.4.2 or later
Screen resolution : 1024 × 768 recommended
2. Log-in
To log in to the Intelligent Controller, enter the following into the address bar of the web browser:
http://[Intelligent Controller address]/SACWWW/index_[language code].asp
For example, if the Intelligent Controller address is 192.168.0.2 and you want to connect to the
English page, enter:
http://192.168.0.2/SACWWW/index_en.asp
If the DNS is used and ID name (device name) of the Intelligent Controller is “WindowsCE0”, enter:
http://WindowsCE0/SACWWW/index_en.asp.
The language codes are as follows.
This will cause the web browser to connect to the Intelligent Controller, and a screen such as shown
below appears.
Enter the user ID and password set for the Intelligent Controller to log in.
Shows the site name that was set for Intelligent Controller.
Enter the user ID that was set for Intelligent Controller.
Enter the password that was set for Intelligent Controller.
Click the Login button.


English : en French : fr German : de Italian: it
Portuguese: pt Spanish : es
Chinese : zh Japanese: ja Korean : ko



Screen Display and Operation
2
3. Screen Display and Operation
3-1. [Each Tenant] Screen
After you log in to the Intelligent Controller, or when you use the menu to select [1. Status/Control :
1. Each tenant], a screen such as shown below appears. (Screen details may differ depending on the
user logged in.)
New button
Updates the screen to the latest information.
Menu
(The menu may differ depending on the user logged in. The following menu appears when logged in as
an administrator.)
Lets you select one of the following screens.
★Administrator Menu
★Special User Menu
★General User Menu






Screen Display and Operation
3
eTenant list
Shows the indoor unit and tenant structure currently accessed by the Intelligent Controller in a list.
Select indoor units by clicking different parts of the list.
Clicking on the part highlighted in the screen example above will select the individual indoor unit, while
clicking on the tenant name (Tenant001, Tenant002, etc. in the example) will select all indoor units for
that tenant. Clicking on the top of the list (Tenant in the example) will select all indoor units of the site.
Only the tenants that can be operated by the user permission used to log in (administrator, special,
general) are displayed.
fIcon display area
Shows icons for indoor units connected to the Intelligent Controller.
Clicking on an icon whose frame is shown in reverse will select that unit. Clicking on a tenant name will
select that tenant.
gNotification column
Shows information about the connection status of web browser and Intelligent Controller, etc.
hAlarm code display
Shows the alarm code as a tooltip when the cursor is moved over the icon of the indoor unit for which
the alarm is occurring.
iSite name
The “Site name” set in the Intelligent Controller appears.
⑧Remote control window
Shows the Remote control window. When this window has been closed, clicking on the indoor unit or
making another selection will bring it up again.
A Status/Control screen section
Shows the status of the indoor unit and the operation
condition.
When a control operation is performed, the background
color of the respective field changes and the Send button
becomes available. Clicking the Send button will send all
operation steps performed up to this point to the Intelligent
Controller. If you instead click the Cancel button or
perform a step such as selecting another indoor unit,
operation steps performed up to this point will be canceled.
If an Interface Adaptor is used, the icon display becomes light purple during the ON operation.
A
D C B
E
Remote control window

Screen Display and Operation
4
B Control section
Shows controls for possible operation steps such as
start/stop switching, operation mode selection, temperature
selection, fan speed setting, fan direction setting etc.
If the logged in user has only general user privileges,
buttons for restricted operation steps will be grayed out
(inactive).
The REMOTE CONTROL and CHECK buttons will not
be displayed.
C Send button
Sends the changes made to the
Intelligent Controller.
D Cancel button
Cancels the changes made.
E CHECK buttons
Used to check the timer setting and remote control
prohibition setting status.
(See “3-7. Program Timer Screen” and “3-9. Prohibit
Remote Control Screen”.)
Clicking the Return button will return the display to the
previous screen.
Remote control window for general user

Screen Display and Operation
5
3-2. [Each Tenant Details] Screen
When you use the menu to select [1. Status/Control : 2. Each tenant details], a screen such as shown
below appears. (Screen details may differ depending on the user logged in.) Operation principles for this
screen are similar to those of the “3-1. [Each tenant] screen”.
3-3. [All Units] Screen
When you use the menu to select [1. Status/Control : 5. All units], a screen such as shown below
appears. (Screen details may differ depending on the user logged in.) A maximum of 256 indoor units are
displayed in 1 screen. Operation principles for this screen are similar to those of the “3-1. [Each tenant]
screen”.

Screen Display and Operation
6
3-4. Distribution Ratio/Usage: Data Download Screen
When you use the menu to select [3. Distrib. ratio/Usage : 3. Download] while logged in as an
administrator, a screen such as shown below appears.
You can download files by selecting them and clicking the “Download” button.
A cut-off data file appears for each piece of cut-off data that appears on the Intelligent Controller unit. Be
aware, however, that the dates that appear on the Intelligent Controller unit appear as file names on this
screen.
For example, cut-off data that appears as “01/Apr-30/Apr” on the Intelligent Controller will appear as
“20070401-200704301.csv” on this screen.
When the following message appears after clicking the “Download” button, select “Open” or “Save”.
•“Open” ........ Open the selected CSV file using spreadsheet software.
•“Save” ......... Select a folder and save the CSV file.

Screen Display and Operation
7
3-5. Alarm Log Screen
When you use the menu to select [4. Maintenance/Test Run : 2. Alarm log] while logged in as an
administrator or special user, a screen such as shown below appears.
When an indoor unit is selected in the tree section, the previous 14 occurrences are displayed.
(Same as the display on the Intelligent Controller.)
“I/D alarm log”, “O/D comm. error log”, and “Adapter alarm log” can be selected from the drop-down list.

Screen Display and Operation
8
[O/D comm. error log] logs the history of errors in communication between the outdoor unit and the
Intelligent Controller or the Communication Adaptor.
[Adapter alarm log] logs the history of warnings as determined by the Intelligent Controller or the
Communication Adaptor.
(Duplicate adaptor addresses, communication error between the Intelligent Controller and adaptor, etc.)

Screen Display and Operation
9
3-6. Mail Send Log Screen
When you use the menu to select [4. Maintenance/Test Run : 4. Sent mail log] while logged in as an
administrator, a screen such as shown below appears.
No.
The entry numbers for the sent mail log. With a maximum of 20 (No. 1 to 20) possible entries, the
newest entries appear at the top of the list. When the number of entries exceeds 20, entries are
deleted starting with the oldest.
As up to three mail recipients can be specified, up to three log entries can be recorded for one alarm
occurrence.
Rslt
“OK” appears when an alarm mail is sent properly, and “NG” appears when sending fails.
Send T.
The date and time the alarm mail was sent (or sending was attempted).
To
The recipient address the alarm mail was sent to. If the address is too long, only part of the address
may appear.
Unit name
The name of the indoor unit for which the alarm occurred.
Alarm code
The code for the alarm that occurred.
Stat
“Occurrence” appears when a notification of an alarm occurrence is sent, and “Restoration” appears
when a notification of an alarm restoration is sent.
Address
The address of the indoor unit for which the alarm occurred.
The address follows the format, “adaptor number - link number - system (outdoor) number - indoor
number”.
When a test mail is sent, “TEST_MAIL” appears.
⑧


Screen Display and Operation
10
3-7. Program Timer Screen
When you use the menu to select [6. Auxiliary settings : 3. Program timer] while logged in as an
administrator, or use the “CHECK” button for timer operation in the remote control window, a screen such
as shown below appears. (As non-administrator users can only confirm settings and not configure them,
the “Cancel” and “Send” buttons only appear when logged in as an administrator.)
When the daily timer number is selected in the tree section, the current setting status is displayed.
Click the desired setting item, and you can select the setting from the drop-down list as shown below.
Drop-down lists are also displayed for the weekly timer in the same way as the daily timer number.
Tree section “Cancel”/”Send” buttons

Screen Display and Operation
11
You can only configure daily timer settings one number (D1, D2, etc.) at a time. If you attempt to switch
to D2 settings in the middle of configuring D1 settings, for example, the message “Send for each daily
timer.” appears.
In such a case, apply or cancel the current settings by clicking the “Send” or “Cancel” button, respectively,
before configuring the next daily timer number.
For details on the settings, refer to the operation manual for the Intelligent Controller.
The “Check RC prohib.” button appears in the above screen when logged in as an administrator or
special user. When you click on this button, a screen such as shown below appears.

Screen Display and Operation
12
3-8. Tenant Holiday/Timer Special Day Screen
When you use the menu to select [6. Auxiliary settings : 4. Ten.Ho/TimerSp.Day] while logged in as an
administrator, a screen such as shown below appears.
You can only configure tenant holiday/timer special day settings one tenant at a time. If you attempt to
switch to Tenant002 settings in the middle of configuring Tenant001 settings, for example, the message
“Send for each tenant.” appears.
In such a case, apply or cancel the current settings by clicking the “Send” or “Cancel” button, respectively,
before configuring the next tenant.
To copy changed settings, click the “Send” button and apply the settings before copying.
For details on the settings, refer to the operation manual for the Intelligent Controller.
Tree section “Cancel”/”Send” buttons
“Copy” button

Screen Display and Operation
13
3-9. Prohibit Remote Control Screen
When you use the menu to select [6. Auxiliary settings : 5. Prohibit R/C] while logged in as an
administrator, or click the “CHECK” button for prohibit remote control in the remote control window, a
screen such as shown below appears. (As non-administrator users can only confirm settings and not
configure them, the “Cancel” and “Send” buttons only appear when logged in as an administrator.)
For details on the settings, refer to the operation manual for the Intelligent Controller.

Screen Display and Operation
14
3-10. WEB Settings Screen
When you use the menu to select [6. Auxiliary settings” : 10. WEB settings] while logged in as an
administrator, a screen such as shown below appears.
For details on the settings, refer to the operation manual for the Intelligent Controller.
Input values have the following restrictions.
Setting Item Input Range Input Character Limitations
Site name Up to 40 characters One-byte “=” is prohibited
IP address（each block）Numbers 0 to 255 “0.0.0.0” and “255.255.255.255” are
prohibited
Subnet mask
Numbers 0 to 255 “0.0.0.0” is prohibited
Default Gateway
DNS (Primary, Secondary)
WINS (Primary, Secondary)
Device Name
Alphanumeric
characters, “–”, and “_”
Up to 15 characters
First character must be alphabetic
character.
“-” and “_” are prohibited as ending
characters
Sender's SMTP Up to 40 alphanumeric
characters and
symbols
Symbols are “@” “.” “_” “:“ only
Sender's account “=“ is prohibited
Recipient account 1 to 3
To [3.10.1. Server
details] screen
“Cancel”/”Send” buttons

Screen Display and Operation
15
If a value that is outside the input range or input limitations is set, the window below appears.
If the network settings have been changed when the “Send” button is clicked, the window below appears.
Always check there is no problem restarting the Intelligent Controller unit.
When “YES” is clicked for submission, the screen changes as shown below, and the Intelligent Controller
unit restarts.

Screen Display and Operation
16
When a mail test is sent, the window below appears when the mail settings have been changed.
In this case, either click the “Send” button to enable the mail setting changes or click the “Cancel” button
to disable the changes, and then send the mail test again.
If the Intelligent Controller unit is processing (check configuration, cut-off, backup, etc.), this screen
cannot be displayed or updated, mail test cannot be sent, and setting change “Send” cannot be
performed.
If the Intelligent Controller unit is displaying the initial setting screen (main menu 5) or the Settings screen
(main menu 6), setting change “Send” cannot be performed. In either case, the following window
appears.
3-10-1. Server details
When you click the “Server details” button from the [WEB settings] screen, a screen such as shown
below appears.
For details on the settings, refer to the operation manual for the Intelligent Controller.
To [3-10-1-1 Receiving
server settings] screen

Screen Display and Operation
17
Input values have the following restrictions.
Setting Item Input Range Input Character Limitations
Port number Numbers 0 to 999999
User ID Up to 50 alphanumeric
characters and symbols
Password
3-10-1-1. Receiving server settings
When you click the “Receiving server settings” button from the [Server details] screen, a screen such as
shown below appears.
For details on the settings, refer to the operation manual for the Intelligent Controller.
Input values have the following restrictions.
Setting Item Input Range Input Character Limitations
Recv. server address
(POP3)
Up to 40 alphanumeric characters
and symbols Symbols are “@” “.” “_” “:” only
User ID Up to 50 alphanumeric characters
and symbols
Password
Port number Numbers 0 to 999999

Screen Display and Operation
18
4. Supplementary Information
■When connecting the Intelligent Controller via Internet, consider implementing network security
measures, such as a firewall.
■Error Messages
Error Cause Remedy
System configuration change!
(when logged in with Administrator
privileges)
The system configuration
of the Intelligent
Controller has changed.
This is a warning message.
Wait a moment and resume
operation.
Intelligent Controller is now
processing, please wait.
Please try later.
The Intelligent Controller
is applying settings.
Access from the Web is
heavy.
If configuring settings with the
Intelligent Controller, switch to a
non-settings screen (such as screen
1-n).
Wait a moment and resume
operation.
Communication error
The Intelligent Controller
was turned off while
connected, or a cable
was unplugged or the
network failure.
Try the operation again.
Verify that the Intelligent Controller is
turned on, and that the network wiring
connections are correct.
Invalid user ID
The entered user ID is
different from the user ID
registered on the
Intelligent Controller.
Verify the user ID that was registered
to the Intelligent Controller.
Wrong password
The entered password is
different from the
password registered on
the Intelligent Controller.
Verify the password that was
registered to the Intelligent Controller.
All Stop!
All units were forced to stop.
Do not operate until unit operation
resumes.
The external all stop input
is switched on for the
Intelligent Controller unit.
When the external all stop input is
changed to OFF, the message
disappears. After changing to OFF,
wait for the message to disappear.
