Document Version 2016-08
Model No.
SIP Phone
KX-HDV100
Supplement for Administrator Guide
Please use this supplement manual together
with the latest English Administrator Guide.

1. Additional Information for Specifying the Server Address
1.1 Basic format
Format: <scheme>://<user>:<password>@<host>:<port>/<url-path>/<file name>
* The server name (<host>) may be the IP address or the domain.
* Maximum length: 384 characters
1.2 Macros used with file names
Macro Format {XXXX} Macro Expansion
{MAC}
If the URL contains {MAC}, it will be replaced with the
device’s MAC address in uppercase letters.
Example: {MAC} → 0080F0C571EB
{mac}
If the URL contains {mac}, it will be replaced with the
device’s MAC address in lowercase letters.
Example: {mac} → 0080f0c571eb
{MODEL}
If the URL contains {MODEL}, it will be replaced with
the device’s model name.
Example: {MODEL} → KX-HDV100
{fwver}
If the URL contains {fwver}, it will be replaced with the
device’s firmware version.
Example: {fwver} → 01.000
Note
• Macros distinguish between uppercase and lowercase letters.
• Macros not specified above will be treated as strings of characters.
1.3 Target WEB Settings/Configuration Parameters
WEB Setting Configuration Parameter
DHCP Host Name DHCP_HOST_NAME
Standard File URL CFG_STANDARD_FILE_PATH
Product File URL CFG_PRODUCT_FILE_PATH
Master File URL CFG_MASTER_FILE_PATH
- CFG_ROOT_CERTIFICATE_PATH
- CFG_CLIENT_CERT_PATH
- CFG_PKEY_PATH
Firmware File URL FIRM_FILE_PATH
HTTP User Agent HTTP_USER_AGENT
-LDAP_ROOT_CERT_PATH
-LDAP_CLIENT_CERT_PATH
-LDAP_PKEY_PATH
-LANGUAGE_PATHx
-WEB_LANGUAGE_PATHx
User Agent SIP_USER_AGENT
-SIP_TLS_ROOT_CERT_PATH
-SIP_TLS_CLIENT_CERT_PATH
-SIP_TLS_PKEY_PATH
-POWER_ON_DISPLAY_LOGO_PATH
2. Additional Information for Specifying the LDAP Server
Add "ldap://"or "ldaps://" before the LDAP server address.
(Example) LDAP_SERVER="ldap://141.170.10.178"

KX‐HDV100SoftwareFileVersion02.040orlater
1. 4.5.4 VoIP Settings [Line 1]
Change the followings in "SRTP Mode" on page 117
(Before)
Value Range
(After)
Value Range
2. 5.3.23 SRTP Settings
Change the followings in "SRTP_CONNECT_MODE_n" on page 235
(Before)
Value Range
(After)
Value Range
3. 5.3.28 Call Control Settings
Add the following configuration parameter.
VM_SUBSCRIBE_SPECIFIC_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
Add the following configuration parameter.
SHARED_STOP_LINE_SEIZE
Value Format
Description
Value Range
Default Value N
• SRTP
• RTP/SRTP
Note
• RTP/SRTP: Use only RTP for outgoing calls, and RTP or SRTP for incoming
calls.
VM_SUBSCRIBE_SPECIFIC_1
• SRTP
• RTP/SRTP
Note
• When RTP/SRTP is selected, operation is in RTP mode.
• 0: SRTP
• 1: RTP/SRTP
Note
• When RTP/SRTP is selected, operation is in RTP mode.
• 0: SRTP
• 1: RTP/SRTP
Note
• 0: Use only SRTP for outgoing and incoming calls.
• 1: Use only RTP for outgoing calls, and RTP or SRTP for incoming calls.
BOOLEAN
Specifies whether to stop seizing the line of the Shared Call at the unit side or
not.
・Ｙ: Stop seizing line
・N: Seize line
STRING
Specifies the defined name of a voice mail box.
Max. 32 characters
Empty string

KX‐HDV100SoftwareFileVersion02.067orlater
1. 5.3.1 System Settings
Add the following configuration parameter.
FWD_DND_MENU_ENABLE
Value Format
Description
Value Range
Default Value
BLOCK_ANONY_MENU_ENABLE
Value Format
Description
Value Range
Default Value
ANONY_CALL_MENU_ENABLE
Value Format
Description
Value Range
Default Value
TIME_ZONE_SET_ENABLE
Value Format
Description
Value Range
Default Value
2. 5.3.17 NAT Settings
Add the following configuration parameter.
EXTERNAL_RTP_PORTx
Value Format
Description
Value Range
Default Value
Y
BOOLEAN
Y
Specifies whether the "Time Zone" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
N
INTEGER
x=1-3
Specifies the port number of the router in Static NAT status.
0, 1024–59998 (only even ports)
0: Disable
0
BOOLEAN
Specifies whether the "Fwd/DND" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
Y
BOOLEAN
BOOLEAN
Specifies whether the "Anonymous Call" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
Specifies whether the "Block Anonymous" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed

3. 5.3.18 SIP Settings
Add the following configuration parameter.
SIP_REPLACE_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
SIP_INC_INVITE_RTP_MODE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
4. 5.3.19 SIP-TLS Settings
Add the following configuration parameter.
SIP_TLS_RANDOM_PORT
Value Format
Description
Value Range
Default Value
・0: Start receiving RTP after receiving a second INVITE
・1: Start sending/receiving RTP after receiving a second INVITE
SIP_INC_INVITE_RTP_MODE_1
SIP_REPLACE_ENABLE_1
BOOLEAN
Specifies whether to use "Replaces Header".
・Y: Use "Replaces Header"
・N: Do not use "Replaces Header"
Y
Specifies whether to assign a random port (ephemeral port) number or a static
port number.
Note
・All lines that use SIP-TLS are defined by this parameter.
・UDP/TCP ports are unaffected by this parameter.
・Y: Assign a random TLS port number
・N: Assign a static TLS port number (Refer to SIP_SRC_PORT_n)
Y
INTEGER
Specifies whether to send RTP after receiving a second INVITE.
0
BOOLEAN

5. 5.3.24 VQ Report by PUBLISH
Add the following configuration parameter.
VQREPORT_SEND_OPT_CODEC_ENABLE
Value Format
Description
Value Range
Default Value
VQREPORT_SEND_OPT_NW_CHANGE
Value Format
Description
Value Range
Default Value
6. 5.3.25 Telephone Settings
Add the following configuration parameter.
CNIP_FROM_ENABLE
Value Format
Description
Value Range
Default Value
IDLE_DISPLAY_TYPE
Value Format
Description
Value Range
Default Value
・Y: Use 'FROM' header
・N: Use 'PAI' header
N
BOOLEAN
3
INTEGER
Specifies what is shown on the display in standby mode.
・0:Off
・1:Phone Number
・2:Phone Number&Name
・3:Name
Note
"Name" is the display name for the line.
N
INTEGER
Specifies the number of consecutive times the MOS (Mean Opinion Score) value
may fall below the threshold value specified by either
ALERT_REPORT_MOSQ_CRITICAL or ALERT_REPORT_MOSQ_WARNING
before the phone sends VQREPORT.
The ALERT_REPORT_TRIGGER setting determines whether
ALERT_REPORT_MOSQ_CRITICAL or ALERT_REPORT_MOSQ_WARNING is
used as the threshold.
0–5
(The number of consecutive times. 0:Disable)
Note
If "2" is specified and the MOS value falls within the threshold 2 consecutive
times, VQREPORT is sent.
0
Specifies whether to use the 'FROM' header or the 'PAI' header in CNIP (Calling
Number Identification Presentation).
BOOLEAN
Specifies whether to enable the sending of VQREPORT (SIP-PUBLISH) when
the codec is changed.
・Y: Send VQREPORT when a change of codec is detected
・N: Send VQREPORT at the end of a conversation

7. 5.3.28 Call Control Settings
Add the following configuration parameter.
FWD_SYNCHRO_FORCE_DISABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
CONF_SERVER_HOLD_ENABLE
Value Format
Description
Value Range
Default Value
・Y: Hold the call
・N: Do not hold the call
N
BOOLEAN
Specifies whether to hold the call when connecting an N-party conference.
BOOLEAN
Specifies whether to synchronize the Call Forward settings in
FWD_DND_SYNCHRO_ENABLE_n.
・Y: Do not synchronize
・N: Synchronize
N
FWD_SYNCHRO_FORCE_DISABLE_1

KX‐HDV100SoftwareFileVersion02.100orlater
1. 4.2.2 Network Status
Change the followings in "Setting Mode" on page 71.
(Before)
Value Range
(After)
Value Range
2. 4.3.2 Ethernet Port Settings
Add the following WEB setting.
Enable CDP
Description
Value Range
Default Value
Configuration File Reference
Packet Interval
Description
Value Range
Default Value
Configuration File Reference
3. 4.6.1 Call Control
Add the following WEB setting.
Private Hold
Description
Value Range
Default Value
Configuration File Reference
• Disable
• LLDP
• Manual
• Disable
• LLDP
• CDP
• LLDP/CDP
• Manual
Selects whether to enable the CDP feature.
・Yes
・No
No
CDP_ENABLE
Specifies the interval, in seconds, between sending CDP frames.
1–3600
30
CDP_INTERVAL
Selects whether to enable or disable private hold.
・Yes
・No
No
PRIVATE_HOLD_ENABLE

4. 5.3.1 System Settings
Add the following configuration parameter.
CALL_SETTINGS_MENU_ENABLE
Value Format
Description
Value Range
Default Value
DELAY_RING_TIME_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
OFF_HOOK_MONITOR_ENABLE
Value Format
Description
Value Range
Default Value
PRIVATE_HOLD_ENABLE
Value Format
Description
Value Range
Default Value
Web User Interface Reference
CONF_OWNER_OUT_ENABLE
Value Format
Description
Value Range
Default Value
DELAY_RING_TIME_1
INTEGER
Specifies the length of time, in seconds, until the unit rings.
0–30
0: Disable
0
BOOLEAN
Specifies whether to enable or disable the Off-hook Monitor function.
・Y: Enable Off-hook Monitor
・N: Disable
Ｙ
BOOLEAN
Private Hold
BOOLEAN
Specifies whether the "Call Settings" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
Y
Specifies whether to enable or disable private hold.
・Y: Enable private hold
・N: Disable
N
BOOLEAN
Specifies whether to allow the remaining two parties in a three-party
conference to continue the conversation if the conference originator leaves the
conference call (Unattended Conference).
・Y: Enable Unattended Conference
・N: Disable
N

PCAP_ENABLE
Value Format
Description
Value Range
Default Value
PCAP_REMOTE_ID
Value Format
Description
Value Range
Default Value
PCAP_REMOTE_PASS
Value Format
Description
Value Range
Default Value
PCAP_REMOTE_PORT
Value Format
Description
Value Range
Default Value
DTMF_OUT_ENABLE
Value Format
Description
Value Range
Default Value
CANCEL_OPERATION_MODE
Value Format
Description
Value Range
Default Value
・Y: Enable PCAP Remote
・N: Disable
N
STRING
Specifies the ID of the IP phone whose packets will be captured using the
Wireshark utility (PCAP Remote).
1–16 characters
Empty string
STRING
Specifies the password of the IP phone whose packets will be captured using
the Wireshark utility (PCAP Remote).
0, 6–64 characters
BOOLEAN
Specifies whether received outband DTMF signals are output audibly.
・Y: Enable audible outband DTMF
・N: Disable
Y
INTEGER
Specifies the operation of the [CANCEL] button.when a line is in use.
0: Cancel the current operation
1: Return to standby mode
0
Empty string
INTEGER
Specifies the port of the IP phone to use for capturing packets using the
Wireshark utility (PCAP Remote).
1–65535
2002
BOOLEAN
Specifies whether to enable or disable packet capturing using the Wireshark
utility (PCAP Remote).

5. 5.3.3 Ethernet Port Settings
Add the following configuration parameter.
CDP_ENABLE
Value Format
Description
Value Range
Default Value
Web User Interface Reference
CDP_INTERVAL
Value Format
Description
Value Range
Default Value
Web User Interface Reference
6. 5.3.9 TR-069 Settings
Add the following configuration parameter.
TR069_REGISTERING
Value Format
Description
Value Range
Default Value
TR069_REGISTERED
Value Format
Description
Value Range
Default Value
7. 5.3.22 SIP Settings
Add the following configuration parameter.
SIP_183_TALK_ENABLE
Value Format
Description
Value Range
Default Value
Max.16 characters
Specifies the line status that TR-069 outputs when the line has been registered.
Max.16 characters
Registering
Error
STRING
BOOLEAN
Specifies whether to enable the CDP feature.
・Y: Enable CDP
・N: Disable
N
Enable CDP
INTEGER
Specifies the interval, in seconds, between sending CDP frames.
1–3600
30
Packet Interval
STRING
Specifies the line status that TR-069 outputs while the line is being registered.
BOOLEAN
Specifies whether the unit's sate is "Talking" or "Calling" when it receives a
SIP 183 message.
・Y: Talking
・N: Calling
N

8. 5.3.27 SRTP Settings
Add the following configuration parameter.
DISPLAY_SRTP_CALL_ENABLE
Value Format
Description
Value Range
Default Value
9. 5.3.28 Call Control Settings
Add the following configuration parameter.
DIALPLAN_REPLACE_LOG_ENABLE
Value Format
Description
Value Range
Default Value
DIALPLAN_MEMORY_DIAL_ENABLE
Value Format
Description
Value Range
Default Value
10. 5.3.29 Logging Settings
Add the following configuration parameter.
SYSLOG_OUT_START
Value Format
Description
Value Range
Default Value
PNQX8312XA PP0316SM2086
BOOLEAN
Specifies whether to enable or disable exporting of the Application Log
・Y: Enable export to syslog
・N: Disable
N
Specifies whether to enable Dial Plan processing for memory dialing.
・Y: Enable Dial Plan
・N: Disable
Y
Specifies whether to log the number after it was modified by the Dial Plan or the
number as it was input.
・Y: Log the number in the outgoing call log after it was modified by the Dial Plan
・N: Log the number in the outgoing call log as it was input
Y
BOOLEAN
BOOLEAN
N
BOOLEAN
Selects whether an icon is displayed when the unit is using encrypted call mode
(SRTP).
・Y: Display an icon for encrypted calls
・N: Disable
