Panasonic ET-PKB50 Installation instructions

1
ET-PKB50
Ceiling mount bracket
SPEC FILE
as of March 2006
Attachment plate
ø49
93.5
(3-11/16˝) 70 (2-12/16˝)
110 (4-11/32˝)
140 (5-/12˝)
160 (6-5/16˝)
Ø9.5 (3/8˝)
Ø8.5 (11/32˝)
67.5
65
(2-21/32˝)
(2-9/16˝) 328–408 (12-29/32˝–16-1/16˝)
(Adjustable in 20 mm (25/32˝) steps)
150 (5-29/32˝)
130 (5-1/8˝)
100 (3-15/16˝)
20 (25/32˝)
Projector
ø43
(1-15/16˝)
(1-11/16˝)
Attachment plate
ø49
93.5
(3-11/16˝) 70 (2-12/16˝)
110 (4-11/32˝)
140 (5-/12˝)
160 (6-5/16˝)
Ø9.5 (3/8˝)
Ø8.5 (11/32˝)
67.5
65
(2-21/32˝)
(2-9/16˝) 328–408 (12-29/32˝–16-1/16˝)
(Adjustable in 20 mm (25/32˝) steps)
150 (5-29/32˝)
130 (5-1/8˝)
100 (3-15/16˝)
20 (25/32˝)
Projector
ø43
(1-15/16˝)
(1-11/16˝)
Dimensions
unit: mm (inch)
Note: This illustration is not drawn to scale.
Description
This ceiling mount bracket is to be used when mounting LCD projectors to the ceiling.
Specifications
Vertical correction angle: +5°, -20°
Horizontal slant correction angle: ±10°
Horizontal turn correction angle: ±5°
Dimensions (W x H x D): 296 x 296–376 x 215 mm
(11-21/32˝ x 11-21/32˝–14-13/16˝ x 8˝-15/32˝)
Weight: 2.3 kg (5.1 lbs)
Weights and dimensions shown are approximate. Specifications subject to change without notice.
Attachment plate . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Projector mount bracket . . . . . . . . . . . . . . . . . . . . . .1
Adjuster pole A . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Adjuster pole B . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Angle adjuster A . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Angle adjuster B . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Washer-fitted hexagonal bolts (M6 x 12) . . . . . . .19
Washer-fitted screws (M4 x 8) . . . . . . . . . . . . . . . .4
Washer-fitted screws (M4 x 12) . . . . . . . . . . . . . . .4
Wire rope . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Flat wire clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Clamp tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Caution:
Mounting should be done by a qualified technician. Make sure that the mounting (ceiling) area has
sufficient strength. Read the enclosed mounting instructions thoroughly before starting.
Parts
Illustration shows the projector attached to the projector. Attachment plate
