Pandora Smart Moto User manual

Pandora would like to thank you
for choosing our service-security system
for motorcycles Pandora Smart Moto/Smart Moto Plus
Pandora Smart Moto / Smart Moto Plus is a service-security system built for motorcycles and
quads with on-board voltage of 12V.
It is a complex engineering device, which includes unique and modern technological software and
hardware solutions. While developing we were using the most up-to-date electronics from world’s
best manufacturers. The device is built using high-precision mounting and control machinery; thus,
we guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
The system is built for your convenience: it’s ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support. We are happy to provide
any support we can – feel free to use our online support.
!WARNING! ItIs stRoNGly RecommeNded to hAve ApRofessIoNAl cAR mechANIc to INstAll the system. ANy
cAR electRoNIcs INstAlleR should be Able to INstAll the system usING INstAllAtIoN scheme IN thIs mANuAl
ANd the AlARm studIo oR pANdoRA specIAlIst softWARe. most feAtuRes ARe hIGhly depeNdeNt oN competeNt
INstAllAtIoN. ouR systems ARe thoRouGhly tested foR quAlIty, so If AfeAtuRe fAIls to pRoduce expected Result,
most lIkely the pRoblem Is IN ImpRopeR INstAllAtIoN.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter.
The base unit is designed to operate at temperatures from -40°C to +85°, the degree of protection is IP54.
The control units (remotes, tags, etc.) are designed to operate at temperatures from -10°C to +40°C, the degree of protection is IP40.
See wiring diagram to find information about additional devices and options.
Our web-site: pandorainfo.com
Customer support: [email protected]
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC

3
2USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Table of contents
General information 4
System set 4
Read before using 5
PIN-codes of the system 6
System modules layout 6
Owner’s personal card 7
External VALET button 7
Base unit 8
Information signals of the system 9
System functions and modes 11
Security mode 11
Security zones 12
Owner authorization devices and functions 12
Checking the number of paired devices 14
Immobiliser radio tag 15
Functions of the button 15
Indication of the SEND LED 16
Installation/replacing a battery of the tag 16
Prompt entry/change of the main owner phone number 17
Updating firmware of the tag 17
Wrist bracelet PANDORA BAND 18
Switching on/off the Band 18
Charging the Band 18
Button’s functions 19
Firmware update 19
Information icons 20
Control the system by a phone 21
Changing settings via a phone 23
System installation 25
General installation requirements 25
Base unit connectors description 26
Wiring diagram 28
Online service and mobile application 30
Registration 31
Login 31
Adding a system to your account 31
Writing a mobile device to the system memory 32
Control the system 34
Arming 34
Disarming 35
PANIC mode 36
Vehicle search function 37
Season storage mode 37
Service mode 37
Control over the system in case of emergency 39
Emergency disarming 41
Emergency control of the anti-theft functions 41
Programming the system 43
Pandora Specialist Application 44
Pandora Alarm Studio 44
Updating firmware 45
Programming table 46
Additional devices 51
Warranty obligations 52
Installation certificate 55
Acceptance certificate 56
Warranty Card 56

5
4USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
GENERAL INFORMATION
System set Pandora Smart Moto and Pandora Smart Moto Plus
1. User and installation manual 1
2. Owner’s personal card 1
3. Immobiliser tag BT-780 1
4. External VALET button 1
5. Base unit with the main cable 1
6. Blocking relay 1
7. Magnetic reed sensor 2
8. Packaging 1
9. External temperature sensor 1
Pandora Smart Moto
10. Piezo siren PS-330 1
Pandora Smart Moto Plus
10. Wrist bracelet Pandora Band 1
11. Piezo siren PS-332BT 1
12. Door sensor DMS-100BT 1
!NOTE! ThE maNufacTurEr rEsErvEs ThE righT TO chaNgE ThE sysTEm sET aNd cONsTrucTiON Of ThE prOducT TO imprOvE
iT’sTEchNOlOgical aNd OpEraTiONal paramETErs wiThOuT NOTificaTiON.
Read before using
Carefully read this manual before starting installation and using the security-service system. Pay
attention to the text marked with !
!ThE sEcuriTy-sErvicE sysTEm is acOmplEx TEchNical prOducT. sysTEm iNsTallaTiON aNd cONfiguraTiON musT bE carriEd
OuT ONly by askillEd prOfEssiONal.
!fEaTurEs aNd sysTEm mOdEs, cONTrOl Of ThE vEhiclE’szONEs dEpENd ON ThE TypE Of cONNEcTiON aNd sysTEm sETTiNgs,
OrigiNal vEhiclE OpEraTiON lOgic aNd Trim.
!ThE sysTEm sET iNcludEs ThE «OwNEr’spErsONal card». This card cONTaiNs iNfOrmaTiON uNdEr ThE prOTEcTivE layEr
ThaT is iNTENdEd ONly fOr ThE OwNEr Of ThE sysTEm. makE surE ThaT ThE prOTEcTivE layEr ON ThE OwNEr’spErsONal card is
iNTacT afTEr ThE iNsTallaTiON Of ThE sysTEm. rEad ThE «OwNEr’spErsONal card» sEcTiON Of This maNual bEfOrE ErasiNg
ThE prOTEcTivE layEr.
!whEN sysTEm iNsTallaTiON is fiNishEd:
• chEck ThE sysTEm OpEraTiON aNd fuNcTiONs wiTh aspEcialisT.
wErEcOmmENd ThaT yOu mark Each wOrkiNg fuNcTiON wiTh asigN iN ThE «cONTrOl ThE sysTEm» sEcTiON.
• chEck ThaT ThE «iNsTallaTiON cErTificaTE» aNd «warraNTy card» arE fillEd OuT. ThEsE dOcumENTs may bE rEquirEd fOr
cONTacTiNg ThE cusTOmEr suppOrT.
• ask aN iNsTallEr TO mark ThE layOuT Of ThE sysTEm cOmpONENTs ON ThE diagram. This iNfOrmaTiON may bE rEquirEd fOr
diagNOsTic/cONfiguriNg Or EmErgENcy dEacTivaTiON Of ThE sysTEm.
• wErEcOmmENd ThaT yOu chaNgE ThE dEfaulT valuE Of ThE piN-cOdEs.

7
6USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Owner’s personal card
! ErasE ThE prOTEcTivE layEr carEfully. dONOT usE aNy sharp ObjEcTs
TO avOid damagiNg Of ahiddEN iNfOrmaTiON uNdEr ThE prOTEcTivE layEr.
ThE iNfOrmaTiON ON ThE OwNEr’spErsONal card cOuld NOT bE chaNgEd
Or rEsTOrEd iN casE Of damagE Or lOsE. ElimiNaTE Third-parTy accEss TO
This iNfOrmaTiON.
The owner’s personal card contains private information under a
protective layer:
• PIN (the «Secret PIN-code») is a 4-digit number. This code
can be used to disarm the system to deactivate Immobiliser
functions and to activate service mode. It can be also used to
enter programming mode.
• LOGIN is a 10-digit number. This information is used to add
the system to the online service and mobile applications.
• PASS contains 8 characters and can consist of digits, lower
and upper case letters). This information is used to add the
system to the online service and mobile applications.
• Phone number is a phone number of the preinstalled SIM card.
External VALET button
An external VALET button with a three-color status LED indicator
is placed inside a vehicle (see the System modules layout).
The button is used for programming the system, arming/
disarming, activating/deactivating Immobiliser mode.
PIN-codes of the system
The «Secret PIN-code»
(is written on the «Owner’s personal card»)
The «Service PIN-code»
(default value is 1-1-1-1)
The «Guest PIN-code»
(default value is 1-2-3-4)
The «Immobiliser PIN-code»
(is used for the Code Immobiliser (pin-to-drive) function)
! iTis rEcOmmENdEd ThaT yOu will wriTE dOwN ThE chaNgEd Or crEaTEd valuEs Of all piN-cOdEs. ElimiNaTE Third-parTy
accEss TO This iNfOrmaTiON.
System modules layout
CANNOT BE CHANGED
+7-9хх-ххх-хх-хх
1070000000 / Y34aC4vJ
2-2-2-2
LOGIN / PASS
PIN № PHONE NUMBER
External VALET button
Base unit
Siren
Circuit being blocked
1
2
3
4
5
6
7

9
8USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Base unit
Built-in LTE module (4G LTE/3G/2G | GPS/GLONASS) – provides a connection with our online-
service pandora-on.com and mobile applications), allows to control the system by a phone using DTMF-
commands, voice and SMS notifications, LBS-coordinates (only by DTMF–command), automatic date
and time detection, precise GPS location (with Tracking function).
Built-in nano-SIM port is used to work with the built-in GSM modem. The phone number of the
SIM-card installed in the base unit is written on the Owner’s personal card.
!ThE sim-card caN bE chaNgEd. ThE sim-card shOuld bE rEplacEd aNd ThE fOllOwiNg sETTiNgs shOuld bE pErfOrmEd
ONly by aqulifiEd spEcialisT.
2.4GHz radio channel, Bluetooth 5.0 protocol (BT5.0) - supports additional Bluetooth devices
(see the «Additional devices» section), including a mobile phone.
Built-in 3D accelerometer is used to detect shock/motion/tilt including 2 separate zones of shock
sensor (alarm and warning), the system allows to adjust sensitivity of each zone, to use data from the
accelerometer to block the engine on movement.
Temperature sensors allow the system to measure temperature of different zones: outside
temperature – built-in sensor of the main unit, engine temperature – external temperature sensor.
System allows to change default sensor’s settings, use the information from the temperature sensor of
the DMS-100 BT, program automatic engine start and stop.
Built-in battery allows to notify the owner in case of main power disconnection while system is
armed. The battery will be charged automatically when engine is running.
Built-in micro-USB port – update and configuration of the system using the Pandora Specialist
mobile app or Alarm Studio program.
Information signals of the system
SOUND / LIGHT SIGNALIZATION
SIGNALS
(sound / light) DESCRIPTION
1х /1х Arming
2х /2х Disarming
1х Activating Service mode*
Correct input of the «Immobiliser PIN-code»*
2х Deactivating Service mode*
3х (3 times) A battery in a radio tag is discharged (when turning on the ignition)*
4х (4 times) Absence of the authorization device (when turning on the ignition)*
5x /5x Vehicle search
25 sec /25 sec Engine blocking warning in Anti-Hi-Jack mode
30 sec /30 sec Alarm - alarm level of a sensor is triggered,
PANIC mode
3х /1х Warning level of a sensor is triggered
4х /4х «Sensors were triggered» signal when disarming /
«Sensors are triggered» signal when arming
* addiTiONal sETTiNg musT bE madE fOr ThE sOuNd NOTificaTiON (aN addiTiONal lOgic «bEEpEr» musT bE assigNEd TO ThE
OuTpuT Of ThE «sirEN» chaNNEl) - ThE cONfiguraTiON shOuld bE madE by aqualifiEd TEchNiciaN.

11
10 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
EXTERNAL BUTTON LED INDICATOR SIGNALS
SIGNALS DESCRIPTION
THE SYSTEM IS ARMED
Short red ashes System is armed
Short green ashes System is armed (authorization devices are in the coverage zone)
Fast red ashes Alarm
THE SYSTEM IS DISARMED
Faded System is disarmed
Red System is preparing for the automatic or delayed arming
Green (when turning
on the ignition) System is in Service mode
Orange ashes (when turning
on the ignition) Conrms the number of paired remotes, watches, bands
Green ashes (when turning
on the ignition) Conrms the number of paired radio tags
Red ash (when turning
on the ignition) Conrms a paired mobile device
WHEN ENTERING THE «SECRET PIN-CODE» OR THE «SERVICE PIN-CODE»
Orange ash Conrms a VALET button pressed
Short red ash Conrms a digit input
PIN-code is incorrect
Red and green ashes Conrms correct PIN-code
SYSTEM FUNCTIONS AND MODES
Security mode
The system confirms arming with 1х sound and 1х light signals. When the system is armed,
the system monitors security zones with separated warning and alarm level of triggering:
• Warning mode - this mode activates when there is a slight impact on the shock sensor or additional
senor. It is accompanied with 1х light and 3х sound signals;
• Alarm mode - this mode activates when a sensor or one of the security zones is triggered. It is 30
sec. light and 30 sec. sound signals. The alarm signals can be cancelled by an arming or
disarming command.
If one of the security zones is triggered the system:
• records this event in it’s non-volatile memory;
• activates the alarm or warning mode;
• informs an owner by all available means;
• blocks the engine (in accordance with the settings and connections).
• If one of the security zones is opened at the moment of arming, the system will produce 4х
sound and 4х light warning signals.
If one of the security zones fails, the system will forcibly turn off this zone. If a switch triggers
more than 9 times in a row, it will be disabled until the next arming. The shock/tilt/motion sensor is
temporarily deactivated (15 sec.) if it has been triggered more than 3 times in a row.
The system confirms disarming with 2х sound and 2х light signals. The system deactivates
engine blocking (if the Immobiliser function and additional blocking are not used). If there were alarm
events (except warning level) during the armed period, the system will produce 4х sound and
4х light warning signals. The system continues to display all zones when it is disarmed, but the
information is not saved in the memory.
!fOr EmErgENcy disarmiNg sEE «cONTrOl ThE sysTEm iN casE Of EmErgENcy». ENgiNE blOckiNg whilE driviNg pOsEs aN
iNcrEasEd risk. wEsTrONgly rEcOmmENd ThaT yOu bE parTicularly carEful whEN usiNg This mEThOd Of blOckiNg.

13
12 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Security zones
• Outside temperature (status)
• Engine temperature (status)
• Voltage of the on-board circuits (status)
• Additional sensor (security zone - alarm and warning level)*
• Shock sensor (security zone – alarm and warning level)
• Tilt sensor (security zone – alarm level)
• Motion sensor (security zone – alarm level)
• Turning ignition on (status, security zone – alarm level)
• Pressing brake (status, security zone – alarm level)
• Pressing clutch (status, security zone – alarm level)
• Opening a trunk (status, security zone – alarm level)
!cONTrOl Of ThE sTaTusEs aNd sEcuriTy zONEs dEpENds Of ThE sysTEm sETTiNgs aNd cONNEcTiONs.
* OpTiON.
Owner authorization devices and functions
Authorization devices
Authorization devices are Bluetooth devices paired with the system (radio tags, remote controls,
mobile phone with the app, band). The devices are used to recognize an owner in the radio coverage
zone of the base unit, to arm/disarm the system (Hands Free mode) and to implement Immobiliser or
Anti-Hi-Jack functions.
Arming/Disarming by clutch lever
You can arm/disarm the system by a clutch lever if an authorization device is in the coverage zone.
!This mOdE is ENablEd by dEfaulT. iTis rEquirEd TO makE addiTiONal cONNEcTiONs fOr This mOdE
Hands Free arming/disarming
This mode is used for automatic arming/disarming when an owner with an authorization device is
distancing or approaching a vehicle.
!This mOdE is disablEd by dEfaulT. ThE cONfiguraTiON shOuld bE madE by aqualifiEd TEchNiciaN.
Immobiliser mode
This mode is used to recognize an owner using authorization devices when the system is disarmed.
When turning on the ignition, the base unit performs a search for authorization devices in the radio
coverage zone. If there is no any authorization device in the radio coverage zone, the system will block
the engine. Engine blocking will occur immediately or at the time a motion sensor detects movement,
it depends on the system settings. When an authorization device appears in the coverage zone, the
system will exit blocking mode and will continue to work in normal mode.
!This mOdE is disablEd by dEfaulT. ThE cONfiguraTiON shOuld bE madE by aqualifiEd TEchNiciaN.
fOr EmErgENcy disarmiNg sEE «cONTrOl ThE sysTEm iN casE Of EmErgENcy». ENgiNE blOckiNg whilE driviNg pOsEs aN
iNcrEasEd risk. wEsTrONgly rEcOmmENd ThaT yOu bE parTicularly carEful whEN usiNg This mEThOd Of blOckiNg.
Anti-Hi-Jack mode
The Anti-Hi-Jack mode helps to prevent aggressive seizure of a vehicle in case of disappearance
of the authorization devices from the radio coverage zone when system is disarmed and ignition is
on. If the system cannot detect an authorization device, the base unit will perform a delayed engine
blocking. The siren will play the ‘Engine blocking warning’ ringtone before blocking. The engine will
be blocked immediately or at the time the vehicle starts moving, it depends on the system settings.
When an authorization device appears in the coverage zone, the system will exit blocking mode and
will continue to work in normal mode.
!This mOdE is disablEd by dEfaulT. ThE cONfiguraTiON shOuld bE madE by aqualifiEd TEchNiciaN.
fOr EmErgENcy disarmiNg sEE «cONTrOl ThE sysTEm iN casE Of EmErgENcy». ENgiNE blOckiNg whilE driviNg pOsEs aN
iNcrEasEd risk. wEsTrONgly rEcOmmENd ThaT yOu bE parTicularly carEful whEN usiNg This mEThOd Of blOckiNg.
Code Immobiliser (pin-to-drive) function
This function allows to use the pre-programmed «Immobiliser PIN-code» to disable the engine blocking,
service mode, disarming the security system. The code must be entered using original vehicle controls
(buttons/lever/pedal) and/or additionally installed elements.
AN EXAMPLE OF USING THE FUNCTION
• Turn on the ignition to disable engine blocking or service mode, turning on the ignition is not required if
you want to disarm the system or control time channels.
• Enter the «Immobiliser PIN-code», code can consist max of 4 digits from 1 to 9.
- Press the pre-programmed button/lever/pedal the number of times equals to the first digit.
- Pauses between presses should not exceed 1 second. More than 1 second pause will be interpreted
as the start of the next digit input.
• After entering the code correctly, the system will perform the programmed function.
!This mOdE is disablEd by dEfaulT. ThE cONfiguraTiON shOuld bE madE by aqualifiEd TEchNiciaN.

15
14 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Checking the number of paired devices
The number of paired radio tags/mobile devices can be checked by the number of flashes of the LED
indicator. The number of remotes/tags/mobile device can be checked when switching on the ignition
(system must be disarmed). The number of orange flashes will indicate the number of paired remotes/
bands/watches, the number of green flashes will indicate the number of paired radio tags, a following
red flash will indicate a paired mobile device.
You can also check the number of paired radio tags/mobile devices by taking off and putting back on
battery terminal. The system will emit short sound signals from a siren .
IMMOBILISER RADIO TAG
A radio tag is a device used to control a vehicle/system on a distance of a Bluetooth connection. The
tag is also used as an authorization device for «Immobiliser/Anti-Hi-Jack/Hands Free» modes. The
radio tag has: a control button for arming/disarming and activating/deactivating Service mode;
a built-in accelerometer, which allows the tag to go in the energy saving mode when there is no
movement; LED indicator SEND.
!fOr cOrrEcT OpEraTiON, iT is NOT rEcOmmENdEd
TO placE ThE radiO Tag NEar ThE mETal ObjEcTs,
magNETic aNd ElEcTrONic dEvicEs (crEdiT cards,
phONEs, kEys, rEmOTEs, ETc.). dONOT ExpOsE ThE
radiO Tag wiTh high TEmpEraTurEs, mOisTurE, Or
sTrONg impacTs. iTis rEcOmmENdEd TO placE ThE
radiO Tag ON ThE bElT iN aN iNdividual casE Or iN
ThE frONT pOckET Of clOThiNg.
Functions of the button
ACTION FUNCTION
- Short press when ignition is o Arm/disarm
- Press and hold for 2 sec (system
is disarmed) Change the «Main owner’s phone number»
- Press and hold for 3 sec
(ignition on) Activating/deactivating Service mode
- Press and hold for 6 sec
(programming mode) Pair a tag with the base unit
- Press and hold for 10 sec Firmware update
SEND
3D
LED indicator
Control button
Antenna 2.4GHz
(Bluetooth 4.2)
Built-in accelerometer
Battery CR2032

17
16 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Indication of the SEND LED
SIGNALS DESCRIPTION
one ash Arm/disarm
Conrmation of arming
Low battery level (when installing a battery)
two ashes Conrmation of disarming
three ashes High battery level (when installing a battery)
faded
constant light Battery is discharged (when installing a battery, when the button is pressed)
Installation/replacing a battery of the tag CR2032
To install or replace the battery (CR2032), carefully follow these steps:
1. Turn the battery cover in the «OPEN» direction;
2. Remove the battery cover;
3. Remove the battery from the battery compartment and, observing the polarity, install a new one
(when installing a high-quality battery, the SEND indicator light will produce three red flashes);
4. Install and rotate the battery cover in the «CLOSE» direction. After completing the procedure, you can
continue to operate the radio tag in normal mode.
Battery
СR 2032
(+) side
+
СR2032
1 4
3
2
Prompt entry/change of the main owner phone number
For a prompt entry/change of the main owner phone number follow next steps:
• Disarm the system, being near the vehicle call the system phone number, wait for the answer (Enter
the «Guest PIN-code if you are calling not from the owner phone number. Default value is 1-2-3-4);
• Press and hold button on the radio tag until two flashes of the SEND indicator, then release
button;
• System will save incoming phone number as the «Main owner phone number» and will repeat it;
• End call.
!ThE phONE NumbEr cOuld bE alsO chaNgE usiNg mObilE dEvicE (sEE «chaNgiNg sETTiNgs via phONE» sEcTiON).
Updating rmware of the tag
• Download the Pandora BT application (Android / iOS) or Pandora Specialist (Android) on the devices
equipped with a Bluetooth 4.0 Low Energy or higher module.
• Open the mobile app, find the system.
• Press and hold the button of the radio tag until the 10th flash of the «SEND» indicator, then
release the button.
• Select the found device and select one of the update option: FILE MANAGER – firmware will be
uploaded from the phone storage (only for Android). INTERNET – firmware will be uploaded by an
internet connection.

19
18 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
PANDORA BAND
* paNdOra baNd auTOmaTically syNchrONizEs ThE TimE wiTh ThE sysTEm basE uNiT aNd displays cOuNTEd sTEps (ThE
cOuNTEr is rEsET by TimE - 0:00 am).
!paNdOra baNd is iNcludEd iN ThE paNdOra smarT mOTO
plus sET.
Wrist-wearable band designed to conveniently control
vehicle equipped with Pandora Bluetooth system
• Display: OLED, 128х32 mm
• Interface: Bluetooth 5.0
• Sensors: accelerometer
• Accu: Li-Po, 85 mAh
• Charging input: micro-USB
• Control button
!paNdOra baNd is auNifiEd cONTrOl dEvicE - iTs OpEraTiON dEpENds
Of ThE sEcuriTy sysTEm fuNcTiONal. iTis NEccEssary TO ENablE
«usE d-030 as aradiO Tag» OpTiON TO usE baNd as aN OwNEr’s
auThOrizaTiON dEvicE.
Firmware update
Install Pandora BT (Android/iOS) or Pandora Specialist Apps on a smartphone or a tablet, equipped with
Bluetooth 4.0 or higher.
• open mobile app, search for a device;
• press and hold control button for 10 sec or connect micro-USB cable while holding control button;
• choose the BAND in the mobile App and start the update: «INTERNET» - software will be downloaded
from a server; «FILE MANAGER» - select previously downloaded software (Android only).
Switching on/o the Band
Press and hold the button for 3 sec to switch ON, 8 sec to switch OFF. Charge the battery if it will not
switch on.
Charging the Band
There is a battery charge indicator on the display. Charge the battery if the device does not turn on or
the charge indicator shows low level (10%).
• remove capsule from the band;
• connect the micro-USB connector of the cable to the capsule;
• connect the USB connector of the cable to the charger;
• charge the battery until the indicator is full (100%);
• disconnect the cable and insert the capsule into the band - device is ready for use.
! chargEr aNd usb cablE arE NOT iNcludEd iN ThE sET.
BUTTON’S FUNCTIONS FUNCTION
- briey (ignition o) Arming/disarming the security system
- 2 sec. (system disarmed) Change the «Main owner phone number»
- 3 sec. (ignition on) Activate/deactivate Service mode
- 3 sec. (band is switched o) Switch on the Band
- 6 sec. (programming) Pair the Band with a base unit
- 8 sec. (band is switched on) Switch o the Band
- 10 sec. Firmware update
Button’s functions

21
20 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
CONTROL THE SYSTEM BY A PHONE
! fOr ThE cOrrEcT OpEraTiON Of ThE gsm fuNcTiONs, aN OwNEr shOuld mONiTOr ThE sTaTus/balaNcE Of ThE sim card
iNsTallEd iN ThE sysTEm. ifThE sim card is blOckEd Or dEfEcTivE, gsm fuNcTiONs Of ThE sysTEm will bE uNavailablE.
Call the system’s phone number, wait for the answer. Enter a command code.
!*iTis rEquirEd TO ENTEr ThE «sEcrET piN-cOdE» afTEr dialiNg acOmmaNd.
Voice help
The system has a voice help menu. During a voice call to the system, dial 9* and listen to the
information about system control commands.
To end the session, hang up the phone.
Repeat the last message
To repeat any message, press * during a voice call to the system.
Request current coordinates
1. Call the system number. Wait for the answer.
1
10 00 0*
*
5
5
1
1*
*Tow truck mode
Request GSM balance
3
33 33 3*
*Additional function F via CAN
5
50 00 0*
*
7
75 53 3*
*
Request GPS coordinates
#
#
9
9*
*
*
*
Return to previous menu/state
Repeat the last message
Silent arming
Help
0
0
0
0*
*
0
0
1
1*
*
Silent disarming
1
1*
*Arming
0
0*
*Disarming
Connect to server
9
99 98 8*
*Отключение радиометки*
2
25 58 8*
*System information
6
66 66 6*
*
9
99 98 8*
*
Activate engine blocking
Deactivate authorization devices*
9
99 99 9*
*Deactivate engine blocking*
2
22 22 2*
*Disable HandsFree
2
22 23 3*
*Enable HandsFree arming
2
22 24 4*
*Enable HandsFree disarming
2
29 97 7*
*End call
5
55 51 1*
*Activate Service mode*
5
55 52 2*
*Deactivate Service mode
8
88 88 8*
*Activate authorization devices
4
45 56 6*
*
6
65 54 4*
*
Switch on additional channel
Switch o additional channel
Information icons
Connection state
Security system status
Charge indicator
Current time
Process scale
Counter
Low voltage
Shock sensor
(alarm level)
Shock sensor
(warning level)
12 48
Tilt sensor
(alarm level)
Motion sensor
(alarm level)
Ignition
(alarm)
Brake
(alarm)
Clutch
(alarm)
Trunk
(alarm)
Additional sensor
(alarm level)
Additional sensor
(warning level)
P

23
22 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Changing settings via a phone2. Dial 500*.
3. The system will confirm: «Current coordinates are sent via text message» and will send text
message with coordinates and a web link to a map to your phone.
To end the session, hang up the phone.
Request GSM balance
1. Call the system number. Wait for the answer.
2. Dial 100*.
3. The system will confirm: «Balance information is sent via text message» and will send text message
with account balance information to your phone.
To end the session, hang up the phone.
Tow truck mode
This mode is intended for car transportation with preservation of arming function. Tow truck mode
can be activated only when the system is armed, it will be deactivated automatically when disarming.
1. Call the system number. If the system is in PANIC mode, receive an emergency call. Wait for the
answer.
2. Dial 15* to enable the «Tow truck» mode, the system will disable motion, shock and tilt sensors.
To end the session, hung up the phone.
3. To disable this mode, disarm the system.
Activating/Deactivating engine blocking
You can block a vehicle engine using any phone. The engine will remain blocked until phone
command «Unlock engine» will be sent and the «Secret PIN-code» will be entered. This blocking cannot
be disabled by any other means.
1. Call the system number and wait for the answer.
2. Dial 666* to block an engine or 999* to unlock it (after dialing 999* you should enter the «Secret
PIN code» that is located on the owner’s personal card).
! all OThEr cOmmaNds caN bE ENTErEd iN ThE samE maNNEr.
System’s number -> «#»
5
5*
*
Set up date
Set up time
1
1*
*
2
2*
*
Phone
number settings
Owner number -> #
Additional owner number -> #
Second additional owner
number -> #
Account balance inquiry number -> #
1
1
*
*
1
1*
*
2
2*
*
3
3*
*
4
4*
*
Sensor
sensitivity settings
Settings of the warning level of the
shock sensor sensitivity
Settings of the alarm level of the
shock sensor sensitivity
Settings of the motion sensor
sensitivity
1
1*
*
2
2*
*
3
3*
*
4
4*
*Settings of the tilt sensor sensitivity
Settings of the warning level of the
supplementary sensor sensitivity
5
5*
*
Settings of the alarm level of the
supplementary sensor sensitivity
6
6*
*
7
7*
*
Settings
of the voice calls
Voice calls on alarm
Voice calls on triggering warning
level of the sensors
1
1*
*
2
2*
*
Voice calls on restoring GSM
connection
Voice calls on disarming
5
5*
*
6
6*
*
Voice calls on entering
programming mode
Voice calls when radio relay
connection is lost
7
7*
*
8
8*
*
Voice calls when on-board voltage
is low
9
9*
*
Voice calls on accident
0
0*
*
2
2*
*
Settings
of the text messages
Text messages on alarm
Text messages on triggering warning
level of the sensors
Text messages on restoring GSM
connection
Text messages on disarming
1
1*
*
2
2*
*
5
5*
*
6
6*
*
Text messages on entering
programming mode
Text messages when radio relay
connection is lost
7
7*
*
8
8*
*
Text messages when on-board
voltage is low
9
9*
*
Text messages on accident
0
0
*
*
3
3*
*
Additional
settings
Changing guest PIN-code
Entering as guest
1
1*
*
2
2*
*
Set threshold voltage for sending
text message
5
5*
*
5
5
*
*
Settings
of saving mode
GSM connection
Money saving mode of the GSM
connection
Voice calls in roaming service
1
1*
*
2
2*
*
3
3*
*
8
8*
*
Current time
and date settings
9
9*
*
Disarm the system, call the system
number, wait for the answer, switch on the
ignition for 1-3 seconds (but no more than
5 seconds), then switch it off. The system
will enter the settings mode.

25
24 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
An example of changing the owner main number:
1. Enter the setting menu via a phone according to the instruction above;
2. Dial DTMF command 1*(phone number settings) and 1*(owner main number);
3. Enter new owner number in the format *XXXXXXXXXXX # (the system recognizes «*» as «+»);
4. To confirm, dial 1*.
! ThErE arE 2 ways TO chaNgE maiN OwNEr phONE NumbEr
1. via aphONE, usiNg dTmf cOmmaNds sETTiNgs mOdE.
2. usiNg radiO Tags: TurN ON ThE igNiTiON whEN ThE sysTEm is disarmEd aNd call ThE sysTEm phONE NumbEr. waiT
fOr ThE aNswEr, dial ThE «guEsT piN-cOdE» (dEfaulT valuE is 1-2-3-4) if yOu arE calliNg NOT frOm ThE maiN OwNEr
NumbEr, ThEN prEss aNd hOld ThE buTTON ON ThE radiO Tag fOr 2 sEcONds (uNTil ThE sEcONd flash Of ThE sENd
iNdicaTOr). rElEasE ThE buTTON, ThE sysTEm will rEcOgNizE ThE iNcOmiNg phONE NumbEr as ThE «maiN OwNEr phONE
NumbEr».
SYSTEM INSTALLATION
General installation requirements
• Install the base unit in secured places with difficult access.
• Install securely each system’s component, as conditions of the vehicles standard operation can harm
functionality of the alarm system and cause damage to the vehicle original systems, including the
elements of safety in motion.
• The system installation should be performed when the system sockets and the negative battery
terminal are disconnected.
• The base unit power supply should be switched off when connecting to CAN-bus. The system
installation can be performed via twisting together or via lead tin soldering followed by isolation
of a switching place.
• When wiring, pay attention to sections and materials of switched conductors, if they are different,
bring electrochemical potentials to the minimal difference. The isolation should not allow for
moisture to reach wiring, as the presence of moisture will increase electrochemical destruction of
wires (this is especially important for the large current circuits).
• Switched connections should be placed as high as it is possible in the cavities so water condensate
will not form drops on the switching location.
• To avoid the destruction of compounds by vehicle vibration, ensure that there is a bit of free length
to the wiring, providing enough sagging.
• Do not allow wiring in places where the wires isolation can be destroyed by abrasion.
• Electronic system units should be placed sockets down and as high as possible to avoid condensate
reaching electronic components through the socket.
• When installing base unit, secure it to the vehicle body/frame for correct operation of in-built shock
sensor.
• All unused system wires during the installation must be insulated and secured to prevent accidental
touching of a vehicle body or other wires.

27
26 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Micro-USB connector
This connector is used to configure and update the system with Pandora Alarm Studio or Pandora
Specialist App.
Main cable
The main cable contains low-current programmable channels: inputs «INP» and outputs «CH» with a
preset logic. Changing the preset logic is available in the system settings «Inputs and outputs» or «Time
channels» menus. Additionally, in the «Input settings» submenu the «INP» channels can be reassigned
from the normally open type «NO» (the system reacts to the appearance of the potential corresponding
to the scheme) to the normally closed type «NC» (the system reacts to the disappearance of the
potential corresponding to the scheme).
• Wire 1 | Red | POWER SUPPLY (+12V) 10A — System power supply. It should be securely
connected to the reliable conductor with a constant voltage of +12V. The wire is equipped with a
10A fuse.
• Wire 2 | Black | GROUND (-) — ground. It should be connected to a vehicle grounding spot (-).
This wire should be connected FIRST during the installation.
• Wire 3 | White — channel for connecting of the external temperature sensor, default logic is
«Engine temperature sensor». It is connected to the red wire of the sensor, the black wire of the
sensor is connected to the ground (-).
• Wire 4 | White/red | LED/VALET — channel for connecting the external VALET button. It is
connected to the red wire of the external button.
• Wire 5 | Yellow | (+) | INP1 — default setting is positive status «Ignition» input. It is connected to
the ignition switch or other wire, where +12V appears when the ignition is turned on and does not
disappear until the ignition is turned off. This input is mandatory for connection.
• Wire 6 | Green | 200mA (-) | INP2/CH4 — default setting negative status «NC blocking» output.
Channel for controlling the blocking relay with a normally closed contact group (the channel is
enabled when: the system is armed and ignition being switched on, the system is disarmed but the
Immobiliser or Anti-hi-Jack mode is enabled and the ignition being switched on).
• Wire 7 | Grey | 200mA (-) | CH1/INP4 — default setting negative status «Clutch» input. Is used
for system arming/disarming in the presence of authorization devices (see 1.2.4 setting «Arming/
disarming by clutch lever»). It is connected to the wire what becomes grounded when the clutch
lever is pressed.
• Wire 8 | Orange/black | CAN-L - digital bus «CAN-Low». It is connected to the corresponding
CAN-Low wire of the vehicle. Before connecting the digital bus, you must select the vehicle model
(model code). Information available on www.loader.pandorainfo.com and in the Pandora Specialist
App and Pandora Alarm Studio.
• Wire 9 | Orange | 6A (+12V) | CH7 — default logic is «Turn indicators». Connect this wire to (+)
control wire of the left or right turn indicators. The wire is equipped with a 7.5A fuse.
• Wire 10 | Orange | 6A (+12V) | CH6 — default logic is «Turn indicators». Connect this wire to (+)
control wire of the left or right turn indicators. The wire is equipped with a 7.5A fuse.
• Wire 11 | Purple | 2A (+12V) | CH5 — default logic is «Siren». Connect this wire to +12V wire
of the siren. When using owner’s authorization devices and Immobiliser or Anti-hi-Jack modes, it is
recommended to set both «Siren» and «Beeper» logic in the settings.
• Wire 12 | White/Green | LED/VALET — channel for connecting the external VALET button. It is
connected to the black wire of the external button.
• Wire 13 | White/blue | (+) | INP3 — default logic is «Brake». Connect this wire to a wire where
+12V appears when the brake pedal or lever is pressed.
• Wire 14 | White/brown | 200mA (-) | CH2/INP5 — default logic is «Trunk». Connect this wire to a
wire that becomes grounded when the pannier opens. It is necessary to change the input type from
NO to NC in the «Inputs settings» if a magnetic reed sensor is used.
• Wire 15 | Brown | 200mA (-) | CH3/INP6 — default logic is «Trunk». Connect this wire to a wire that
becomes grounded when the pannier opens. It is necessary to change the input type from NO to NC
in the «Inputs settings» if a magnetic reed sensor is used.
• Wire 16 | Orange/black | CAN-H — digital bus «CAN-High». It is connected to the corresponding
CAN-High wire of the vehicle. Before connecting the digital bus, you must select the vehicle model
(model code). Information available on www.loader.pandorainfo.com and in the Pandora Specialist
App and Pandora Alarm Studio.

Pandora SMART MOTO
WIRING DIAGRAM
Antenna
4G LTE | GPS/GLONASS
micro-USB
Battery
Antenna
2.4GHz (BT 5.0)
nano-
SIM
WARNING! Do not shield
the built-in antennas when
installing the system and
additional devices. Keep
minimum distance of 2 cm
between the modules
and metal parts.
WARNING! Disconnect
the power supply before
installing/replacing
a SIM-card.
WARNING! Update rmware of the
base unit before installation. If the
CAN-bus connected, choose the vehicle
model code.
WARNING! The installation locations of
the base unit and system elements must
meet their temperature, dust- and
moisture-protection characteristics. The
base unit and blocking relay are
designed to operate at temperatures
from -40°C to +85°C, the degree of
protection is IP54.
WARNING! The base unit must be placed
vertically or horizontally, do not cover
the front side of the unit (the side with
the «Pandora» sign).
WARNING! The system is a
maintenance-free device. In case of
failure you must immediately contact
your local supplier.
WARNING! All wireless accessories from
the kit are already paired with the base
unit. The maximum number of paired
Bluetooth accessories is 14.
CAN-H
CAN-L
1 9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
Li-pol
3.7V 330mAh
INP2/CH4 – «NC blocking» output
200mA (—)
v 1.0
POWER SUPPLY (—)
POWER SUPPLY (+12V)
10A
CH6 – «Turn lights» output
7.5А
6A (+12V)
CH7 – «Turn lights» output
7.5А
6A (+12V)
CH1/INP4 – «Clutch» input
200mA (—)
clutch switch
to the original wiring
(+) INP3 – «Brake» input
CH5 – «Siren» output
2A (+12V)
INP1 – «Ignition» input
(+)
Engine temperature sensor
Magnetic reed sensor
when connecting the sensor,
set type of the «Trunk» input as NC
CH3/INP6 – «Trunk» input
CH2/INP5 – «Trunk» input
200mA (—)
200mA (—)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Red
Black
White
White/Red
Yellow
Green
Grey
Orange/Black
Orange
Orange
Violet
White/Green
White/Blue
White/Brown
Brown
White/Orange
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
86
85
30
87 87a
+12В
NC
COM
NО
External
button
Green/Black
Green/Red
Gren
BASE UNIT
PLACEMENT
IT IS FORBIDDEN to install the system
on a vehicle with normal voltage other
than 12V.
IT IS FORBIDDEN to install the system
with damaged output cables.
WARNING! Fixate the protective cap
using clamps when the installation is
nished. Isolate the protective cap and
wires with the insulating tape.
WARNING! All power circuits of
additional devices that are not powered
through the base unit of the system
should have their own fuses.
IS FORBIDDEN to change or bypass original
fuses of a system in the installation process.
IT IS FORBIDDEN to install the temperature
sensor at the place where temperature is
higher than the operating range of the
sensor (+125°C) and cable (+80°C).
IP40

31
30 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
ONLINE SERVICE AND MOBILE APPLICATIONS
Before using the online-service, it is required to create an account (Registration), login to your
account (using your email and password created on the registration step) and add the system to your
account (enter information from the «Owner’s personal card»).
Web-service: https://pandora-on.com.
The Pandora Connect mobile app is available for downloading from the corresponding app store:
pandora-on.com
LOGIN
PASS
e-mail
********
LOGIN
PASS
e-mail
********
PANDORA
CONNECT
!fOr ThE cOrrEcT OpEraTiON Of ThE gsm fuNcTiONs, aN OwNEr shOuld mONiTOr ThE
saTus/balaNcE Of ThE sim card iNsTallEd iN ThE sysTEm. ifThE sim card is blOckEd Or dEfEcTivE,
gsm fuNcTiONs Of ThE sysTEm will bE uNavailablE.
Telemetric functions of the system allow you
to control your vehicle using the online service
pandora-on.com or mobile app - Pandora Connect. A
SIM card with Internet access is installed in the system to
provide this functionality.
When approaching the vehicle or when Internet
connection is missing a mobile phone with the app
installed can work with the system via a Bluetooth
connection. The mobile phone must be paired with the
system.
App Store for iOS devices;
Google Play for Android devices.
!ThE maNufacTurEr rEsErvEs ThE righT TO makE chaNgEs Of ThE
iNTErfacE aNd fuNcTiONaliTy Of ThE iNTErNET sErvicE aNd mObilE
applicaTiON wiThOuT NOTifyiNg ThE cONsumEr.
Registration
Visit the website or open the mobile app to create an account. You will create the data to sign in: LOGIN
– your email, PASSWORD – a password entered during the registration. You will receive an email with a
confirmation link. Click the link to complete the registration procedure.
Login
After completing of the registration process, you can login to the online service via a computer’s web
browser or via the mobile app Pandora Connect. Use your previously created data:
Login - your e-mail;
Password - previously created password.
Adding a system to your account
The created account can support up to 3 telemetry systems. Use the information from the «Owner’s
personal card» to add the system to your account.
Go to the «Add a device/Add a system» window and enter the LOGIN and PASS from the «Owner’s
personal card», create a name for your vehicle and click «Add». If you need to use several systems/devices
on the same account: enter the application settings, click «Change», click «+», in the «Device
Registration» window, enter the data of a new system/device located on the «Owner’s personal card».
!ErasE ThE prOTEcTivE layEr carEfully. dONOT usE aNy sharp ObjEcTs TO avOid damagiNg Of hiddEN iNfOrmaTiON uNdEr
ThE prOTEcTivE layEr.
After this, you will be able to control, change setting and get information about the vehicle
state through the online-service.

33
32 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Writing a mobile device to the system memory
When approaching the vehicle or when Internet connection is missing a mobile phone with the
mobile application Pandora Connect installed can work with the system via a Bluetooth connection.
This type of connection allows you to control the system, receive status information and use your
mobile phone as an authorization device.
!ThE sysTEm suppOrTs bluETOOTh cONNEcTiON ONly wiTh ONE mObilE dEvicE. ThE sETTiNgs fOr usiNg ThE mObilE dEvicE as aN
OwNEr auThOrizaTiON dEvicE arE madE by aqualifiEd TEchNiciaN.
I. ENTER THE PROGRAMMING MODE
Use the VALET button to enter the «Service PIN-code» (default value is 1-1-1-1). See the detailed
instruction of code entering in the «Control over the system in case of emergency» section.
II. ENTER THE «PAIRING A MOBILE PHONE» PROGRAMMING LEVEL
After entering programming mode, press and hold the VALET button for 5 seconds (until the fifth
signal of the Siren). The system will enter the «Pairing a mobile phone» programming level. The LED
indicator will light green, the system is ready for pairing
!ThE prEviOusly pairEd dEvicE will bE ErasEd frOm ThE sysTEm mEmOry afTEr ENTEriNg ThE lEvEl
III. PAIR A MOBILE DEVICE
Enable the Bluetooth connection in the mobile device, enter the app settings, click «Bluetooth
control», click «Not defined». In the search box, establish a connection with the detected system. The
red and green flashes of the «LED» indicator light and a single siren sound will confirm the pairing.
! ifThErE is NO auTOmaTic pairiNg, ENablE ThE «piN rEquEsT fOr phONE pairiNg» iTEm iN ThE «radiO Tag aNd mObilE dEvicE
fuNcTiONs» sETTiNgs aNd makE ThE pairiNg prOcEdurE agaiN. a mObilE dEvicE will rEquEsT apiN-cOdE (facTOry prE-sET
is 0-0-1-1-1-1 whErE 4 lasT digiTs arE ThE «sErvicE piN-cOdE». This sETTiNg shOuld bE madE by aqualifiEd TEchNiciaN.
IV. EXIT PROGRAMMING MODE
Turn on the ignition and then turn off to exit programming mode.
VEHICLE/SYSTEM ZONES CONTROLLED ZONES SECURITY ZONES
NOTIFICATIONS
voice sms push
External temperature
Engine temperature
On-board voltage
Shock sensor (alarm)
Shock sensor (warning)
Tilt sensor (alarm)
Motion sensor (alarm)
Ignition (alarm)
Brake (alarm)
Clutch (alarm)
Trunk (alarm)
Additional sensor (alarm)
Additional sensor (warning)

35
34 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
CONTROL THE SYSTEM
Arming
To arm the system when the ignition is off, use one of the methods described below. The system
will confirm the command with 1х short sound signal and 1х flash of light signalization .
Clutch lever – Press the clutch lever when an owner authorization device (radio tag, phone, band,
watch) is in the coverage zone .
Radio tag – A radio tag must be in the Bluetooth coverage area. Shortly press the control button
on the tag.
Pandora Band (Smart Moto Plus kit) – the device must be in the Bluetooth coverage area. Shortly
press the control button on the Band.
Mobile app Pandora Connect – When the system is online (there is an Internet or Bluetooth
connection), press and hold the button on the control panel until the scale is fully loaded. The icon of
the current system mode will be changed .
Online-service PANDORA-ON.COM – When the system is online (there is an Internet connection)
press the button on the control panel.The icon of the current system mode will be changed .
Phone – Call the system number. Wait for the answer. Dial the 1 * command. To arm the system
without siren signals dial the 01 * . The system will confirm the completed command will a voice
notification «Command executed, security mode is switched on».
HANDS FREE
MOBILE APP
PANDORA-ON.COM
1х /1х
/1х
1 *
01 *
HandsFree mode – Move with an authorization device away from your vehicle .
VALET button – Press and hold the VALET button for 3 seconds. The system will be armed in 30
seconds. The LED indicator is lighting red during the countdown.
Disarming
To disarm the system, use one of the methods described below. The system will confirm the
command with 2 short sound signals 2х and 2 flashes of turn indicators 2х .
HANDS FREE
MOBILE APP
PRO.P-ON.RU
2х /2х
/2х
0 *
00 *
Clutch lever – Press the clutch lever when an owner authorization device (radio tag, phone, band,
watch) is in the coverage zone .
Radio tag – A radio tag must be in the Bluetooth coverage area. Shortly press the control button
on the tag.
Pandora Band (Smart Moto Plus kit) – the device must be in the Bluetooth coverage area. Shortly
press the control button on the Band.
Mobile app Pandora Connect – When the system is online (there is an Internet or Bluetooth
connection), press and hold the button on the control panel until the scale is fully loaded. The icon of
the current system mode will be changed .
Online-service PANDORA-ON.COM – When the system is online (there is an Internet connection)
press the button on the control panel. The icon of the current system mode will be changed .

37
36 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Phone – Call the system number. Wait for the answer. Dial the 0 * . command. To arm the system
without siren signals dial the 00 * . The system will confirm the completed command will a voice
notification «Command executed, security mode is switched off».
HandsFree mode – Move toward the vehicle with an authorization device .
VALET button – Enter the «Secret PIN-code» (see the «Emergency disarming using the VALET
button» section).
PANIC mode
If your vehicle or you are in danger and you want to draw attention to your vehicle, you can use
PANIC mode. In this mode the siren will sound and turn signals will flash repeatedly for
30 seconds. To activate this mode, use one of the methods described below.
Mobile app Pandora Connect – When the system is online (there is an Internet or Bluetooth
connection), press and hold the button on the control panel until the scale is fully loaded. To switch
this function off press and hold the button on the control panel until the scale is fully loaded.
!TOchaNgE ThE lOcaTiON Of ThE buTTONs ON ThE cONTrOl paNEl gO TO ThE app sETTiNgs aNd ENTEr ThE «cONTrOl
buTTONs» mENu.
Vehicle search function
There is a special mode to easily find your vehicle on a massive parking while the system is armed.
In this mode the system will sound the siren 5х and flash turn signals 5х .
Phone – Call the system number. Wait for the answer. Dial the 1 * command. To flash turn signals
without siren signals dial the 01 * . The system will confirm the completed command will a voice
notification «Command executed».
Season storage mode
A special mode designed for long-term parking or seasonal storage of the vehicles. This mode
significantly reduces the power consumption of the system by disabling the notification and
control interfaces.
• Season storage mode is activated via the mobile app or automatically, regardless of the security
mode. When the system is armed and Season storage enabled, the security zones are monitored. In
case of violation of the security zone (s), Season storage mode will be temporarily disabled (for 15
minutes) for the owner notification.
• Season storage mode is disabled depending on the security mode:
- if the system is armed, it is necessary to violate some security zone and disarm the system by any
available way within 15 minutes;
- if the system is disarmed, the ignition must be switched on.
Mobile app Pandora Connect – When the system is online (only Bluetooth connection), press and
hold the button on the control panel until the scale is fully loaded.
!TOchaNgE ThE lOcaTiON Of ThE buTTONs ON ThE cONTrOl paNEl gO TO ThE app sETTiNgs aNd ENTEr ThE «cONTrOl
buTTONs» mENu.
Automatic mode – the system allows automatically activate the Season storage mode after a
specified number of days after the last event (arming/disarming, changing the status of the security
zone). 15 minutes before the activation of the mode, the system will send an SMS notification to the
main owner phone number. If you call the system during this time (15 minutes), the activation of the
mode will be postponed for the specified number of days.
! This mOdE is disablEd by dEfaulT - cONfiguraTiON Of ThE sysTEm shOuld bE madE by aqualifiEd TEchNiciaN.
Service mode
It is recommended to put the system into the service mode before handing it to a service station or valet
parking. When this mode is switched on, security system stops interfering with built-in electronics and
disables all functions to ease maintenance.
To activate Service mode disarm the system , turn on the ignition, an authorization
device (radio tag, remotes, watches, band) must be in the Bluetooth coverage zone. Deactivation
of Service mode is carried out without conditions.

39
38 USER AND INSTALLATION MANUALPANDORA SMART MOTO / SMART MOTO PLUS
Use one of the methods described below. The confirmation of the executed command will be:
Service mode is enabled - one long sound signal of a Siren1х and LED of the external
button lights green while ignition is on ;
Service mode is disabled - two long sound signal of a Siren 2х and LED of the external
button faded while ignition is on.
!fOr ThE sOuNd NOTificaTiONs iT is NEccEssary TO makE aN addiTiONal sETTiNg (assigN aN addiTiONal lOgic «bEEpEr» TO
ThE «sirEN» OuTpuT chaNNEl) - sETTiNgs shOuld bE madE by aqualifiEd TEchNiciaN.
Radio tag – to activate/deactivate Service mode, press and hold the button on a radio tag until
the third flash of the LED. The device must be in the Bluetooth coverage area.
Pandora Band (Smart Moto Plus kit) – to activate/deactivate service mode, press and hold the
button for 3 seconds. The device must be in the Bluetooth coverage area.
Pandora Connect – To activate/deactivate service mode, open the mobile application. When
the system is online (there is an Internet or Bluetooth connection), press and hold the button
on the control panel until the scale is fully loaded. Activated Service mode is indicated by icon , it
will disappear after deactivation.
!TOchaNgE ThE lOcaTiON Of ThE buTTONs ON ThE cONTrOl paNEl gO TO ThE app sETTiNgs aNd ENTEr ThE «cONTrOl
buTTONs» mENu.
Online service PANDORA-ON.COM – to activate/deactivate Service mode when the system is
online (there is Internet connection) choose command:
• For the Service mode activation choose «Switch on Service mode» and push «Send» button.
Activated Service mode is indicated by icon .
• For the Service mode deactivation choose «Switch off Service mode» and push «Send» button. The
icon will disappear.
Phone – call the system number wait for the answer and enter the command.
• To activate Service mode, dial the command 155 * and then dial the «Secret PIN-code» from
the Owner’s personal card. The system will confirm the completed command with a voice notification
«Command executed, function is switched on».
• To deactivate service mode dial the command 255 * . The system will confirm the completed
command with a voice notification «Command executed, function is switched off».
THE SYSTEM CAN BE CONTROLLED FROM A PHONE
Call the system phone number and enter the command after the answer:
0* – Disarming
998*xxxх – Deactivate authorization devices, where хххх is the «Secret PIN- code» written on
the Owner’s personal card.
! ThE phONE NumbEr Of ThE sysTEm is lOcaTEd uNdEr ThE prOTEcTivE layEr ON ThE «OwNEr’spErsONal card». ifThE
call is madE frOm ThE «addiTiONal NumbEr», Or aNumbEr NOT savEd iN ThE mEmOry Of ThE basE uNiT, ThEN afTEr ThE
sOuNd sigNal, yOu will NEEd TO ENTEr ThE «guEsT piN cOdE» (facTOry valuE is 1-2-3-4). fOr acOmplETE lisT Of
cOmmaNds, sEE ThE sEcTiON «cONTrOl ThE sysTEm by a phONE».
The system has emergency ways to deactivate security and Anti-Hi-Jack functions (using the VALET
button and the «Secret PIN-code») in case of loss or failure of control devices or in case of discharge of a
battery (when you cannot replace it or charge).
• «Secret PIN-code» is located under protective layer on the «Owner’s personal card»;
• VALET button is located on the external VALET button or on the main unit.
CONTROL OVER THE SYSTEM IN CASE OF EMERGENCY
!bEfOrE usiNg EmErgENcy sysTEm cONTrOl, chEck ThE sysTEm aNd vEhiclE cONTrOl dEvicEs: chEck abaTTEry, TurN ON a
dEvicE iN accOrdaNcE wiTh iTs maNual (if rEquirEd).
ifall dEvicEs arE wOrkiNg, Try TO makE aprimary vEhiclE diagNOsis: chEck ThE vEhiclE OrigiNal cONTrOl
dEvicE, vEhiclE baTTEry chargE lEvEl, gEarbOx sElEcTOr pOsiTiON, chEck iNfOrmaTiON ON ThE dashbOard.
