Parker 404LXR Series User manual

Manual No. 100-5319-01
Rev. J
404LXR Series
Product Manual
Effective: June 13, 2018
Supersedes: December 20, 2017
Electromechanical
Positioning Systems
Automation

404LXR Series Product Manual
2
Important User Information
The information in the product manual, including any apparatus, methods, techniques, and concepts
described herein, are the proprietary property of Parker Hannifin Corporation or its licensors, and may
not be copied, disclosed, or used for any purpose not expressly authorized by the owner thereof.
Since Parker Hannifin Corporation constantly strives to improve all of its products, we reserve the right
to change this product manual and equipment mentioned therein at any time without notice.
For assistance contact:
Parker Hannifin Corporation
1140 Sandy Hill Road
Irwin, PA 15642
Phone: [phone]
800/245-6903
Fax: [phone]
E-mail:[email protected]m
Web site: www.parkermotion.com

404LXR Series Product Manual
3
404LXR Series Product Manual
Table of Contents
REVISION NOTES..............................................................................................................................................................4
CHAPTER 1 - INTRODUCTION ......................................................................................................................................... 5
PRODUCT DESCRIPTION......................................................................................................................................................5
UNPACKING.......................................................................................................................................................................5
RETURN INFORMATION........................................................................................................................................................6
REPAIR INFORMATION.........................................................................................................................................................6
WARNINGS AND PRECAUTIONS ............................................................................................................................................6
SPECIFICATION CONDITIONS AND CONVERSIONS ...................................................................................................................7
ASSEMBLY DIAGRAMS ........................................................................................................................................................8
Strip Seal Version............................................................................................................................................................................8
Hardcover Version...........................................................................................................................................................................9
CHAPTER 2 - 404LXR SERIES TABLE SPECIFICATIONS............................................................................................ 10
ORDER NUMBER NOMENCLATURE ..................................................................................................................................... 10
DIMENSIONAL DRAWINGS..................................................................................................................................................10
DIMENSIONAL DRAWINGS..................................................................................................................................................11
GENERAL TABLE SPECIFICATIONS......................................................................................................................................11
404LXR SERIES TECHNICAL DATA....................................................................................................................................17
Force/Speed Charts.......................................................................................................................................................................17
Clean Room Preparation ...............................................................................................................................................................18
ELECTRICAL SPECIFICATIONS............................................................................................................................................ 19
ELECTRICAL SPECIFICATIONS............................................................................................................................................ 19
CABLING AND WIRING DIAGRAMS....................................................................................................................................... 22
Connector Pin Out and Extension Cable Wire Color Codes...........................................................................................................22
OEM Cable Option.........................................................................................................................................................................24
CHAPTER 3 - HOW TO USE THE 404LXR ..................................................................................................................... 26
MOUNTING SURFACE REQUIREMENTS................................................................................................................................26
MOUNTING METHODS....................................................................................................................................................... 26
SIDE AND INVERTED MOUNTING CONCERNS........................................................................................................................27
SETTING TRAVEL LIMIT SENSORS ...................................................................................................................................... 27
SETTING HOME SENSOR...................................................................................................................................................27
ZCHANNEL POSITION REFERENCE .................................................................................................................................... 28
GROUNDING /SHIELDING ..................................................................................................................................................28
CABLING .........................................................................................................................................................................29
CHAPTER 4 - PERFORMANCE....................................................................................................................................... 30
ACCELERATION LIMITS...................................................................................................................................................... 30
SPEED LIMITS..................................................................................................................................................................31
ENCODER ACCURACY AND SLOPE CORRECTION.................................................................................................................. 31
THERMAL EFFECTS ON ACCURACY.....................................................................................................................................33
THERMAL EFFECTS ON REPEATABILITY...............................................................................................................................34
CAUSES OF TEMPERATURE INCREASES ..............................................................................................................................34
COMPENSATING FOR THERMAL EFFECTS............................................................................................................................35
CHAPTER 5 - CONNECTING THE DRIVE / AMPLIFIER ................................................................................................ 36
DRIVE /AMPLIFIER CONNECTION........................................................................................................................................36
CHAPTER 6 - MAINTENANCE AND LUBRICATION...................................................................................................... 39
INTERNAL ACCESS PROCEDURE ........................................................................................................................................ 39
SQUARE RAIL BEARING LUBRICATION.................................................................................................................................41
CABLE MANAGEMENT MODULE REPLACEMENT....................................................................................................................41
LIMIT AND HOME SENSOR MODULE REPLACEMENT..............................................................................................................43
APPENDIX A –UNDERSTANDING LINEAR MOTORS.................................................................................................. 44
THE LINEAR MOTOR CONCEPT ..........................................................................................................................................44
LINEAR MOTOR BENEFITS................................................................................................................................................. 44
SLOTLESS LINEAR MOTOR DESIGN ....................................................................................................................................44
ADVANTAGES/DISADVANTAGES OF SLOTLESS LINEAR MOTORS ............................................................................................45
APPENDIX B - INTERNAL PROTECTION....................................................................................................................... 46
INDEX............................................................................................................................................................................... 48

404LXR Series Product Manual Revision Notes
4
Revision Notes
Rev 3 April 11, 2003
Correction for Motor Wire 4 Pin Mat-N-Lok - p. 21
Limit and Home Sensor Module Adjustment Switch positions corrected. –p. 41
Rev 4 February 22, 2007
Update index page –p. 3
Changed Daedel Grease #1 to Multemp PS2 –p. 39
Removed Limit and Home Sensor Module Adjustement page from Chapter 6 (was page 41)
Updated connector release & torx screws. –p. 41
Rev 5 October 1, 2009
Added Aries and Compax3 Cable option –p. 23, 24
Updated Chapter 5 –Connecting the Drive / Amplifier to include Aries and Compax3 –p. 35
Rev 6 April 10,2013
Clarified warnings to sync with CE risk assessments
P.5 Unpacking, p. 6 General Safety
Rev 7 February 16, 2017
Updated Cable Management Module part numbers Page 41
Rev H December 20, 2017
Removed references to ribbon cables
Rev J Added Compax options

404LXR Series Product Manual Chapter 1 - Introduction
5
Chapter 1 - Introduction
Product Description
404LXR Positioner
The 404LXR is a slotless, brushless linear servo motor/square rail bearing positioner housed within
a high strength, extruded aluminum body with magnetically retained protective seals. The
positioner is powered by a single rail of high energy rare earth magnets. Load bearing members
provide heavy load and moment capacity, dynamic stiffness and precise straightness and flatness
of travel. The positioner’s integral linear encoder provides high precision, non-contact positional
feedback with selectable resolutions from 0.1 to 5.0 microns. The positioner is also offered with
inductive proximity limit & home sensors, a “Quick Connect”, extended life, and a cable transport
system.
Unpacking
Unpacking
Carefully remove the positioner from the shipping crate and inspect the unit for any evidence of
shipping damage. Report any damage immediately to your local authorized distributor. Please save
the shipping crate for damage inspection or future transportation.
Incorrect handling of the positioner may adversely affect the performance of the unit in its
application. Please observe the following guidelines for handling and mounting of your new
positioner.
•Product may be heavy. Standard handling and lifting practices should be employed.
•DO NOT allow the positioner to drop onto the mounting surface. Dropping the positioner can generate
impact loads that may result in flat spots on bearing surfaces or misalignment of drive components.
•DO NOT drill holes into the positioner. Drilling holes into the positioner can generate particles and
machining forces that may affect the operation of the positioner. Parker will drill holes if necessary;
contact your local authorized distributor.
•DO NOT subject the unit to impact loads such as hammering, riveting, etc. Impacts loads generated by
hammering or riveting may result in flat spots on bearing surfaces or misalignment of drive components.
•DO NOT lift the positioner by cables or cable management system. Lifting positioner by cables or cable
management system may affect electrical connections and/or cable management assembly. The unit
should be lifted by the base structure only.
•DO NOT push in magnetically retained strip seals when removing positioner from shipping crate.
Damaging strip seals may create additional friction during travel and may jeopardize the ability of the
strip seals to protect the interior of the positioner.
•DO NOT submerge the positioner in liquids.
•DO NOT disassemble positioner. Unauthorized adjustments may alter the positioner’s specifications and
void the product warranty.

404LXR Series Product Manual Chapter 1 - Introduction
6
Return Information
Returns
All returns must reference a “Return Material Authorization”, (RMA), number. Please call your local
authorized distributor or Parker Customer Service Department at 800-245-6903 to obtain a “RMA”
number.
Repair Information
Out-of-Warranty Repair
Our Customer Service Department repairs Out-of-Warranty products. All returns must reference a
“RMA” number. Please call your local authorized distributor or Parker Customer Service
Department at 800-245-6903 to obtain a “RMA” number. You will be notified of any cost prior to
making the repair.
Warnings and Precautions
Hot Surfaces
DO NOT touch ‘carriage forcer’, (see page 7, Assembly Diagram, for component location), after
high duty operation. Unit may be too HOT to handle.
Electrical Shock
DO NOT take apart or touch any internal components of the positioner while unit is plugged into an
electrical outlet. SHUT OFF power before replacing components to avoid electrical shock.
High Magnetic Field
Unit may be HAZARDOUS to people with Pace Makers or any other 'magnetically-sensitive'
medical devices. Unit may have an effect on 'magnetically-sensitive' applications.
Ferrous Materials
The positioner's 'protective seals' MAY NOT keep out all small ferrous materials in applications with
air born metallic particles. The customer must take additional precautions in these applications to
keep positioner free of these highly magnetic particles.
Vertical Operation
The 404LXR is NOT recommended for vertical operation. The carriage and customer's load will fall
in power loss situations potentially causing product damage or personal injury.
General Safety
Because linear motors can accelerate up to 5 g's, and sometimes positioners move without
warning, keep all personnel away form dynamic travel range of positioner.

404LXR Series Product Manual Chapter 1 - Introduction
7
Specification Conditions and Conversions
Specifications are Temperature Dependent
Catalog specifications are obtained and measured at 20 Degrees C. Specifications at any other
temperature may deviate from catalog specifications. Minimum to maximum continuous operating
temperature range (with NO guarantee of any specification except motion) of a standard unit before
failure is 5 - 40 Degrees C.
Specifications are Mounting Surface Dependent
Catalog specifications are obtained and measured when the positioner is fully supported, bolted
down (to eliminate any extrusion deviation), and is mounted to a work surface that has a maximum
flatness error of 0.013mm/300mm (0.0005”/ft).
Specifications are Point of Measurement Dependent
Catalog specifications and specifications in this manual are measured from the center of the
carriage, 38 mm above the carriage surface. All measurements taken at any other location may
deviate from these values.

404LXR Series Product Manual Chapter 1 - Introduction
8
Assembly Diagrams
Strip Seal Version

404LXR Series Product Manual Chapter 1 - Introduction
9
Hardcover Version

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
10
Chapter 2 - 404LXR Series Table Specifications
Order Number Nomenclature

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
11
Dimensional Drawings

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
12
General Table Specifications
Specifications
Motor Model
8 Pole
Rated Load
45 kg
Maximum Acceleration
5 Gs
Maximum Velocity
Resolution: 0.1 um
0.5 um
1.0 um
5.0 um
0.3 m/sec
1.5 m/sec
3.0 m/sec
3.0 m/sec
Positional Repeatability
Resolution: 0.1 um
0.5 um
1.0 um
5.0 um
+/- 1.0 um
+/- 1.0 um
+/- 2.0 um
+/- 10.0 um
Maximum Force (Peak)
180 N
40 lb.
Maximum Force (Continuous)
50 N
11 lb.
Carriage Weight
1.4 kg
Travel Dependent Specifications
Travel
(mm)
Accuracy*
Strip Seal
Version Unit
Weight (kg)
Hard Cover
Version Unit
Weight (kg)
Positional
Straightline
Accuracy*
(um)
0.1, 0.5, 1.0
resolution (um)
5.0 resolution
(um)
50
6
16
6
4.4
4.4
100
7
17
7
4.8
4.9
150
8
18
9
5.2
5.4
200
10
20
11
5.6
5.8
250
12
22
14
6.0
6.3
300
14
24
17
6.4
6.7
350
16
26
19
6.8
7.2
400
18
28
22
7.2
7.6
500
21
31
26
8.0
8.6
600
25
35
31
8.9
9.5
700
28
38
35
9.7
10.5
800
31
41
39
10.6
11.4
900
33
44
43
11.5
12.5
1000
35
45
47
12.4
13.6
* Accuracy stated is at 20 degrees C, utilizing slope correction factor provided.

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
13
404LXR Series Technical Data
The useful life of a linear table at full catalog specifications is dependent on the forces acting upon it. These forces include both
static components resulting from payload weight, and dynamic components due to acceleration/deceleration of the load. In
multi-axes applications, the primary positioner at the bottom of the stack usually establishes the load limits for the combined
axes. When determining load/life, it is critical to include the weight of all positioning elements that contribute to the load
supported by the primary axis. The life/load charts are used to establish the table life relative to the applied loads.
404LXRCARRIAGE LIFEVS LOAD
1000
10000
100000
1 3 5 7 9 11 13 15 17 19 21 23 25 28 30 32 34 36 38 40 42 44 46 48 50
LOAD (KG)
LIFE (KM)
NORMAL LOAD CONTINOUS 55 (N)
NORMAL LOAD CONTINUOS 28(N)
SIDE LOADCONTINUOS 55(N)
SIDE LOADCONTINUOUS 28(N)
BEARING LIFE NORMAL LOAD
1000
10000
100000
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
NORMAL LOAD PER BEARING (N)
BEARING LIFE (KM)
55(N) CONTINOUS
28 (N) CONTINUOS
Table Load Chart
The “Table Load” chart is
intended to provide a rough-
cut evaluation “life/load”
characteristics of the carriage
support bearings. This curve
is based on the applied load
being centered on the
carriage, normal to the
carriage mounting surface.
Bearing Load Chart
The “Bearing Load” chart
is to be used in conjunction
with the corresponding
formulas on the following
pages to establish the life/load
for each bearing (4 per table).
Several dimensions and the
load geometry are required
for these computations. The
dimensions are referenced
below.

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
14
Note: 55 (N) continuous is the life rating if the table is operated with a motor thrust force of 55 Newtons
(RMS). The reason that continuous motor force effects bearing life is due to forces applied to the bearing
caused by thermal expansion of the carriage. The 28 (N) rating is the life if only 28 Newtons (RMS) is used.
d1
d2
da
Strip Seal Model
108.5
60.0
48.5
Hardcover
Model
108.5
60.0
53.5
BEARING LIFE SIDE LOAD
1000
10000
100000
10 20 30 40 50 60 70 80
SIDE LOAD PER BEARING (N)
LIFE PER BEARING (KM)
55(N) CONTINUOS"
28(N) CONTINOUS
Side Bearing Load
Chart
The “Side Bearing Load”
chart is to be used in
conjunction with the
corresponding formulas on
the following pages to
establish the life/load for each
bearing (4 per table). Several
dimensions and the load
geometry are required for
these computations. The
dimensions are referenced
below.

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
15

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
16
Table A –Linear Motion Guide Bearing Life/Load Computation
Positioner
Loads
Compute
Evaluate Life On
404LXR
Side & tension Ps > Pt
Side & tension Ps ≤Pt
Pe = (0.5 x Pt) + Ps
Pe = (0.5 x Ps) + Pt
Side load chart
Tension chart
Side & compression Ps > Pc
Side & compression Ps ≤Pc
Pe = (0.5 x Pc) + Ps
Pe = (0.5 x Ps) + Pc
Side load chart
Compression chart
Example Computations
Example 1
Horizontal Translation
with Side Loads, 404LXR-
8 Pole Positioner
L = 10 Kgf
130 mm from
carriage surface;
50 mm from carriage
center.
Page 14 shows this
configuration with dimensions
given here.
9.14
22
4
21 =






== d
d
L
PP
(tension) Kgf
d1 = 108.5 mm
db = 130 mm
d2 = 60.0 mm
d3 = 50 mm
da = 48.5 mm
d4 = da + db = 178.5
9.14
22
4
43 −=






−== d
d
L
PP
(compression) Kgf
8.4
24 1
3
31 =





+== d
d
LL
PP ss
2.0
24 1
3
42 −=





−== d
d
LL
PP ss
The normal and side force
components on each bearing
block are computed from the
equations as shown:
Life for each bearing needs to be evaluated
independently. For bearings with a side load,
refer to the combined equivalent loading factors
(Table A above).
Example:
Bearing 3 had P3= 5.6 Kgf tension and P3s = 2.7
Kgf side load
KgfPcPsPePcPs 7)5.0( =+=
Refer to Bearing Life Normal Load (page 12)
Life @ 7 Kgf (69 Newtons) = 4200 km

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
17
404LXR Series Technical Data
Force/Speed Charts
The chart on this page illustrates the characteristics of the 404LXR linear motor. The force/speed chart
shows the characteristics of the motor with either a 170 VDC or 340 VDC bus voltage.
Peak
Peak
Peak
Continuous
Continuous

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
18
Clean Room Preparation
404LXR tables with clean room preparation were tested in Parker’s vertical laminar flow work station which
utilizes ULPA filters to produce an environment having a cleanliness of class 1 prior to testing. Tables were
tested in a variety of orientations with sampling both below the table and at the carriage mounting surface.
Laminar flow rate is 0.65 inches W.C.
Standard Clean Room Preparation
Stringent cleaning and handling measures
Clean room rated lubricant
Strip seal replaced with hard shell cover

404LXR Series Product Manual Chapter 2 - 404LXR Series Table Specifications
19
Electrical Specifications
Parameter
8 Pole
Units
Continuous Force 1
50
N
Continuous Current 1,4,8
2.3
Amps Peak
Continuous Current 1,7
2.0
Amps DC
Peak Force 6
180
N
Peak Current 4,6,8
8.3
Amps Peak
Peak Current 6,7
7.2
Amps DC
Voltage Constant 3,4
25.15
Volt/m/sec
Force Constant 9
21.78
N/Amps Peak
Force Constant 3,4
25.15
N/Amps DC
Resistance 3
10.2
Ohms
Inductance 5
2.63
mH
Maximum Bus Voltage
340
Volts DC
Thermal Resist. Winding-Ambient
1
C/watt
Viscous Damping
6.3
N/m/s
Static Friction 13
15
N
Intermit Force Duration 10
12
Seconds
Peak Force Duration 11
5
Seconds
Magnetic Attraction 2
280
N
Electrical Pitch 12
42
mm
Mass-Motor Carriage
1.5
Kg
Rated Winding Temp.
90
C/watt
Winding Class
H
-
1. @ 25oC ambient, 90oC winding temperature
2. Measured with a 0.70 mm gap
3. Measured line to line +/-10%
4. Value is measured peak of sine
5. +/-30% line to line, inductance bridge measurement @1Khz
6. Initial winding temperature must be 60oC or less before peak current is
applied
7. DC current through a pair of motor phases of a trapezoidal (six state)
commutated motor
8. Peak of the sinusoidal current in any phase for a sinusoidal commutated
motor
9. Total motor force per peak of the sinusoidal amps measured in any phase,
+/-10%
10. Maximum time duration with 2 times rated current applied with initial winding
temperature at 60oC
11. Maximum time duration with 3 times rated current applied with initial winding
temperature at 60oC
12. The distance from the leading edge of the north pole to the leading edge of
the next north pole
13. Average friction over total table travel

404LXR Series Product Manual Chapter 3 - How to Use the 404LXR
20
Encoder Specifications
Description
Specification
Input Power
5 VDC +/-5% 150 mA
Output (Incremental)
Square wave differential line driver (EIA RS422) 2 channels A and B in
quadrature (90) phase shift.
Reference (Z Channel)
Synchronized pulse, duration equal to one resolution bit. Repeatability of
position is unidirectional moving toward positive direction.
Maximum Speed
5.0 micron resolution = 3.0 meters/sec
1.0 micron resolution = 3.0 meters/sec
0.5 micron resolution = 1.5 meters/sec
0.1 micron resolution = 0.3 meters/sec
Hall Effect Specification
Description
Specifications
Input Power
+5 to +24 VDC, 30 mA
Output
Open collector, Current Sinking, 20 mA Max
Gemini Drive Specifications
Description
Specification
Drive Input Power
Voltage
Phase
Frequency
24V Keep Alive (Optional)
96-265 VAC
1Ø
50/60 Hz
24 VDC –20%
Drive Output Power
Bus Voltage
Switching Frequency
Continuous Current
Peak Current
Commutation
170 or 340 VDC
8 or 16 kHz
4.5 Amps
11.25 Amps
Sinusoidal
Command Inputs
Velocity and Torque
Position Mode
Encoder Track Mode
+/-10V
Step & Direction or CW & CCW
Allows post quadrature encoder to be used as command signals
Inputs
Enable (Required)
Reset
Pos/Neg Limits
User Faults
0-24 VDC
Outputs
Fault
At Limit
Position Error
Analog Monitors
Relay
Open collector, 300 mA sink capability
Open collector, 300 mA sink capability
Open collector, 300 mA sink capability
+/-10V scalable, 8 bit (not to be used as control functions)
Normally open, dry contact
Communications
Type
Baud Rate
Daisy Chain
RS232/RS485 (4 wire)
Fixed at 9600
Up to 98
Environmental
Temperature
Humidity
Shock/Vibration
Still air 32oF (0oC)-113oF (46oC), moving air: 32oF (0oC)-122oF (50oC)
0–95%, non-condensing
Shock: 15G half-sign @ 11 msec/vibration: 2G, 10-2000 Hz
Protection
