Parrot EVOLUTION User manual

Warning :
The manufacturer Parrot S.A. and its affiliates should not be held liable towards End-Users or third parties for prejudice caused by misuasage of the
product, nor for usage that would be in violation of local traffic regulations and laws.
Disclaimer :
The information in this document is subject to change without notice and does not represent a commitment on the part of vendor. No warranty or
representation, either expressed or implied, is made with respect of quality, accuracy or fitness for any particular purpose of this document. The associated
with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect,
special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of
such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted
in any forme, by any means or for any purpose without express written consent. Product names appearing in this document are mentioned for identification
purposes only. All trademarks, product names appearing in this document are registred property of their respective owners.
FCC Compliance Statement :
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions :
1- This device may not cause harmful interference.
2- This device must accept any interference received, including interference that may cause undesired operation.
Declaration of Conformity:
We, Parrot S.A. of 174 Quai de Jemmapes, 75010 Paris, France, declare under our sole responsibility that our product, Parrot EVOLUTION, to which this
declaration relates is in conformity with appropriate standards EN300328, EN301489-17, EN 60950 following the provision of Radio Equipment and
Telecommunication Equipment directive 1995/5/EC with requirements covering EMC directive 89/336/EEC and Low Voltage directive 73/23/EEC.
Bluetooth:
The Bluetooth®word mark and logos are owned by the Bluetooth®SIG, Inc. and any use of such marks by Parrot S.A is under license. Other
trademarks and trade names are those of their respective owners.
evolution3.qxp 10/02/2005 10:31 Page 1

ENGLISH SUMMARY
Introduction 6 Accessing the menus 12
Mouting 7 Special menu ERICSSON
Cable diagram connection 9 & SONY ERICSSON 14
Pairing 10
FRANCAIS SOMMAIRE
Introduction 18 Acces aux menus 24
Montage 19 Menu spécial ERICSSON
Schéma de montage 21 & SONY ERICSSON 26
Jumelage 22
ESPANOL RESUMEN
Introduction 30 Acceso a los menus 36
Instalacion 31 Modo menu ERICSSON
Grafico de connexion de cables 33 y SONY ERICSSON 38
Acoplamiento 34
DEUTSCH UBERSICHT
Einleitung 42 Zugang zu den menus 48
Das installieren 43 Menu ERICSSON &
Verbindungsschemakabel 45 SONY ERICSSON 50
Kopplung 46
IT ALIANO PUNTI PRINCIPALI
Introduzione 54 Esplorazione dei menu 60
Montaggio 55 Menu special ERICSSON
Connesione diagramma cavo 57 & SONY ERICSSON 62
Sincronizza zione 58
PORTUGUES LINHAS GERAIS
Introducao 66 Acesso aos menus 72
Montagem 67 Modo menu especial ERICSSON
Diagramma de coneccao de cabos 69 e SONY ERICSSON 74
Ligacao 70
NEDERLANDS OVERZICHT
Inleiding 78 Toegang tot de menu’s 83
Installatie 79 Menu special ERICSSON
Schema van montage 81 & SONY ERICSSON 86
Aansluiting 82
evolution3.qxp 10/02/2005 10:31 Page 2

English
User’s guide
evolution3.qxp 10/02/2005 10:31 Page 3

USER'S GUIDE
USER'S GUIDE
The Parrot EVOLUTION Car Kit allows you to use your cellular phone while driving your
car with the best of comfort and the best security possible.
- The voice recognition allows you to use it without letting go of your steering scroll
button.
- Your conversation is carried over the loud speakers in your vehicle.
ies
Parrot EVOLUTION offers you the following functions:
- Wireless radio connection with your telephone via Bluetooth®
- Full duplex hands-free conversation with echo cancellation and DSP
- Background noise reduction
- Voice recognition for up to 200 voice tags *
- Automatic mute of the car radio and connection to the speakers of your vehicule
- Pairing up to 3 phones
Contents of the package
- Keyboard
- Power cable
- Electronic box
- Microphone
- Mute cable
- Manual
* Only with specific phones
INTRODUCTION
6User’s guide
evolution3.qxp 10/02/2005 10:31 Page 4

ENGLISH
7
If your Parrot EVOLUTION was installed by a professional, go directly to the next
section, the Connection Phase.
The Parrot EVOLUTION consists of an electronic control box, a microphone, a keypad
with "On" and "Off" buttons and two ISO car radio connection harnesses.
Electronic control box :
Do not install the control box close to the heater or the air-conditioning system. Protect
the control box from direct sunlight. Avoid enclosing the unit inside of metal components
this will adversely affect the quality of the Bluetooth® connection.
Microphone :
The microphone should be directed towards the driver and should preferably be installed
in between the visor and rear-view mirror.
Keypad :
We recommend you install the Keypad in an easily accessible place, preferably on a
clean, flat surface. Connect the Keypad to the connector provided on the mute cable.
Check that the red and green lights come on and go off according to the position of the
ignition key.
Connecting the mute cable and power cable :
The mute cable is equipped with black ISO connectors. The power cable is equipped
with grey ISO connectors.
Car radio with ISO sockets:
Disconnect the car radio speaker and power harnesses. Connect the mute cable and
power cable female connectors to the car radio. Connect the vehicle speaker and power
harnesses to the male connectors.
MOUNTING
Parrot EVOLUTION
evolution3.qxp 10/02/2005 10:32 Page 5

8
If the car radio has a Mute input, connect the yellow wire on the mute cable to one of
the "Mute in" inputs 1, 2 or 3. Consult the car radio manual to determine the location of
the mute input.
Car radio without ISO sockets:
A specific adapter harness for the vehicle (not supplied) may be used
If you do not have an adapter, connect the wires one by one.
If the car radio has a "mute" input, connect the yellow wire on the mute cable to it.
IMPORTANT
- The red wire on the power cable must be connected to the
12V permanent, the orange wire to the 12V switched and the
black wire to the ground.
- Check the electrical diagram of the car radio's ISO power
harness.
- On some vehicles, the positions of the red and orange
wires must be inverted. It is done by simply inverting the
fuse holders.
-Do not connect the orange wire to the 12V permanent, you
run the risk of discharging the battery of the vehicle.
User’s guide
evolution3.qxp 10/02/2005 10:32 Page 6

ENGLISH
9
Parrot EVOLUTION
CABLE DIAGRAM CONNECTION
evolution3.qxp 10/02/2005 10:32 Page 7

10
Choosing the language to use on first use
- Press the center button leaving your finger on the button for two seconds (long click).
The kit announces the language being used by the kit.
- When you turn the knob the kit announces the languages available (French, English,
German, Spanish, Italian…).
- Once you hear the language that you wish to use, validate it by quickly pressing the
center button (short click).
Pairing
When you first power it up, you need to pair your telephone with the hands-free kit.
- Activate the Bluetooth mode on your mobile
- Search for Bluetooth devices
- Once detected, "Parrot EVOL" will be displayed by your telephone.
- Choose it.
- Enter pin code 1234 when prompted to do so by your telephone and validate.
Then Parrot EVOLUTION will connect to your telephone.
Now the menus will be accessible when you click on the center knob and their names
announced by the hands-free kit when you turn this knob.
You are now connected to the hands-free kit and can use it to communicate.
For further information, refer to the instructions with your
telephone (under the Pairing heading) or visit our web site :
www.parrot.biz
www.driveblue.com/guide_CHM/index.html
From the left hand side of the screen, click on Bluetooth
Phones and choose a telephone: you will be able to access
all of the configuration procedures.
PAIRING
User’s guide
evolution3.qxp 10/02/2005 10:32 Page 8

ENGLISH
11
First use
Making a call manually :
- Dial the number on the telephone keypad.
- Your call will be automatically connected in handsfree mode.
Answering a call :
- Press the green button on the hands-free kit to take the call.
- Press the red button if you do not want to receive a call.
Ending a call :
- Press the red button on the hands-free kit to end the call.
Voicemail :
You can access your voicemail service's features from your hands-free kit.
- Call your voice mail service.
- When you hear the messages, click (short click) on the center knob.
The kit pronounces 0.
- Then turn the knob until you hear the desired number (1, 2, 3 …).
- Validate by pressing the knob.
Redial function :
- Press and hold (long click: more than 2 seconds) the green button on the hands-free
kit to redial the last number dialed.
Call volume level :
- During a call, set the volume level by turning the center knob.
Making a call using voice recognition :
- Press on the green button
- Wait for the beep
- Pronounce your contact’s name
Parrot EVOLUTION
evolution3.qxp 10/02/2005 10:32 Page 9

12 User’s guide
- VOICE COMMANDS - Activated
- De-activated
- KEYWORDS
- Phone - Home - Cellular
- Hang up - Work
- LANGUAGE
- RECEIVE CONTACTS
To access kit menus:
- Press and hold (long click: more than 2 seconds) the center knob.
The kit pronounces "VOICE COMMANDS".
- When you turn the center knob, the kit calls out the different menus.
You can exit the menus by pressing the red button on the keypad or after the
keypad has been idle for more than 15 seconds
Keywords
- Press and hold (long click: more than 2 seconds) the center knob.
The kit pronounces "VOICE COMMANDS".
- Turn the knob until the kit pronounces "KEYWORDS".
Validate by pressing the knob.
The kit pronounces "PHONE".
- Turn the knob to access the keywords you wish to record.
- Validate by pressing the knob.
- Follow the kit's instructions.
Voice commands
- Press and hold (long click: more than 2 seconds) the center knob.
The kit pronounces "VOICE COMMANDS".
- Validate by pressing the knob.
If voice commands are activated, the kit pronounces "ACTIVATED" and if voice
commands are deactivated, the kit pronounces "DE-ACTIVATED".
- Turn the knob to select the state required.
- Validate by pressing the knob.
ACCESSING THE MENUS
evolution3.qxp 10/02/2005 10:32 Page 10

ENGLISH
13
Parrot EVOLUTION
Changing the language
Press and hold (long click: more than 2 seconds) the center knob.
The kit announces "VOICE COMMANDS".
- Turn the knob until the kit announces "LANGUAGE".
- Validate by pressing the knob.
The kit proposes the language currently used.
- When you turn the knob the kit states the languages available (French, English,
German, Spanish, Italian…).
- Once you hear the language that you wish to use, validate it by quickly pressing the
center button (short click).
Sending telephone contact from the telephone to the kit
- Press and hold (long click: more than 2 seconds) the center knob.
The kit pronounces "VOICE COMMANDS".
- Turn the knob until the kit pronounces "RECEIVE CONTACTS".
- Validate by pressing the knob.
The kit disconnects from the telephone and is now ready to receive contacts.
To send a contact, refer to your telephone's user guide or visit the web site at
www.parrot.biz to find out the procedure for your telephone.
As soon as a contact is received by the kit, it will tell you the instructions to follow.
Clearing the entire memory
- Simultaneously press the red and green buttons for three seconds.
Hot-line
- Our hot-line is at your service. It can be contacted by e-mail or by telephone (the hot-
line is open Monday to Friday from 09:00 AM to 06:00 PM French time).
- Visit our web site at www.parrot.biz for further information.
www.parrot.biz:
www.driveblue.com/guide_CHM/index.html
From the left hand side of the screen, click on Bluetooth
Phones and choose a telephone: you will be able to access
all of the configuration procedures.
evolution3.qxp 10/02/2005 10:32 Page 11

14 User’s guide
In the phone Menu go to "Extras" for T39/T39m/R520m, or "Connect" for
T68/T68m/T68i/T606/T608/T610/T616/T618/T630/Z600/Z608.
Press until "Accessories" and press on "Yes".
"Parrot Menu" is displayed, click "Yes"; menu headings are displayed.
Phonebook
- List :
Displays the list of names in your phone book. Names with associated active voice tags
are preceded by an asterisk (*).
- To learn and relearn a name :
Highlight the desired name and press "Yes" to confirm.
- Search:
Allows you to look for a name by its first letter(s). To do this, type a letter and confirm by
pressing "Yes".
Parameters
- Volume :
This function adjusts the volume of Parrot EVOLUTION. Click Yes and adjust using
or Press "Yes" to confirm.
- Auto answer :
This function enables or disables automatic answering of incoming calls. Click "Yes",
and then select "Enable" or "Disable".
The Main Menu consists of the following 4 sections:
"Phonebook", "Parameters", "Keywords" and "Reset
memory". You can access the menu items by selecting the
desired menu item using the key and confirm by pressing
"Yes".
SPECIAL MENU ERICSSON & SONY ERICSSON
evolution3.qxp 10/02/2005 10:32 Page 12

ENGLISH
15
- User :
When several telephones are connected to Parrot EVOLUTION, this function identifies
the telephone with priority. The phone with the highest priority is the first phone to which
the kit tries to connect to.
Click Yes, "Main user?" is displayed, confirm.
- Caller ID :
This function lets you know the identity of the caller. With this function enabled, when
you receive a call, the name of the person calling you is pronounced if it is already
stored in your phone book and corresponding voice tag is assigned.
Click Yes and select "Enable" or "Disable".
- Multi-Tel :
This function is available for Ericsson and Sony Ericsson phones equipped only with the
"Headset" profile. The affected phones are Ericsson R520, T39, T68m and the first Sony
Ericsson T68i phones (software version lower than R2E). This option allows the
simultaneous use of these different phones during a single session of use.
The first phone getting connected to the Parrot EVOLUTION is the main phone for the
use session of the car-kit (until extinction).
If the option "Multi-Tel" is activated for this phone, the Parrot EVOLUTION will accept
incoming calls from the other phones if they were previously paired with the Parrot
EVOLUTION.
- Warning :
The "Multi-Tel" function is now compatible with the T68i, T610, T616, T618, Z600 and
Z608 (with specific software versions). This function is available when the "Powersave"
mode is activated in the phone, i.e. "Headset" profile mode.
Once this mode activated, the Parrot EVOLUTION has to identify every phone in this
new mode. It should be necessary to connect separately each phone with the Parrot
EVOLUTION and restarting it between each identification.
Parrot EVOLUTION
evolution3.qxp 10/02/2005 10:32 Page 13

16
Voice recognition
- N° Phone :
Keywords for calling V-Cards ("Home", "Work" and "Cellular") can be accessed by
clicking "Yes", Tel. N°. The voice recognition learning sequence is exactly the same as
the one for the names.
- Key words :
Key words are "Phone" and "Hang Up". You need to record your own key words for use
with "Wordspotting" option.
- Wordspotting :
If activated, enables use of keywords to make a call and to hang up.
- Activated: use keywords or buttons
- Deactivated: use buttons only
- Pers. Dic :
The key words are pre-recorded in the car kit for French language only (the language
is determined by the language used by the menus of the phone).
You need to activate this option if you want to use your own recorded keywords.
Erasing the memory
Click "Yes", and "Clear memory?" is displayed.
Confirm by pressing "Yes" and "Memory erasing in progress. Please wait!" - is
announced. To cancel, press "No".
It is possible to erase the memory and reset the system without using the Parrot menu.
To do this, hold the red and the green buttons together.
User’s guide
evolution3.qxp 10/02/2005 10:32 Page 14

Français
Guide utilisateur
evolution3.qxp 10/02/2005 10:32 Page 15

USER'S GUIDE
USER'S GUIDE
Le Car Kit Parrot EVOLUTION vous permet d’utiliser votre téléphone en voiture avec le
meilleur confort et la meilleure sécurité possible.
- L’aide vocale et la reconnaissance vocale vous permettent de l’utiliser sans lâcher
votre volant.
- Votre conversation s’effectue à travers les haut-parleurs de votre véhicule.
Le Parrot EVOLUTION vous offre les fonctionnalités suivantes :
- Connexion radio sans fil avec votre téléphone
- Conversation mains-libres full duplex avec suppression d'écho
- Réduction du bruit de fond
- Reconnaissance vocale (jusqu'à 200 noms) *
- Coupure automatique de l'autoradio et connexion aux enceintes de votre véhicule.
- Jumelage jusqu'à 3 téléphones
Contenu de l'emballage
- Clavier
- Câble d'alimentation
- Boîtier électronique
- Microphone
- Câble mute
- Notice d'utilisation
* Fonction disponible uniquement avec certains téléphones
INTRODUCTION
18 Guide d’utilisateur
evolution3.qxp 10/02/2005 10:32 Page 16

FRANCAIS
Si votre Parrot EVOLUTION est installé par un professionnel, passez directement au
chapitre suivant, la phase de Jumelage.
Le Parrot EVOLUTION se compose d'un boîtier électronique, d'un microphone, d'une
télécommande à 2 touches et deux faisceaux de connexion ISO pour l'autoradio.
Boîtier électronique :
N'installez pas le boîtier près du chauffage ou de la climatisation.
Protégez le boîtier d'une exposition directe au soleil.
Evitez d'enfermer le boîtier entre des parois métalliques qui altèreraient la qualité de la
liaison Bluetooth®.
Microphone :
Le microphone doit être dirigé vers le conducteur et installé de préférence entre le pare
soleil et le rétroviseur intérieur.
Clavier :
Nous vous conseillons de l'installer à un endroit facilement accessible, de préférence
sur une surface plane nettoyée auparavant.
Reliez le clavier au connecteur prévu à cet effet sur le câble mute.
Vérifiez que les voyants rouge et vert s'allument et s'éteignent selon la position de la clé
de contact.
Connexion du câble mute et du câble d'alimentation :
Le câble mute est équipé de connecteurs ISO de couleur noire.
Le câble d'alimentation est équipé de connecteurs ISO de couleur grise.
Autoradio avec prises ISO :
Déconnectez les faisceaux audio et alimentation de l'autoradio
Reliez les connecteurs femelles du câble mute et du câble d'alimentation à l'autoradio
Reliez les faisceaux audio et alimentation du véhicule aux connecteurs mâles.
MONTAGE
19
Parrot EVOLUTION
evolution3.qxp 10/02/2005 10:32 Page 17

Si l'autoradio est équipée d'une entrée Mute, reliez le fil jaune du câble mute à l'une des
entrées " Mute in " 1, 2 ou 3. Consultez la documentation de l'autoradio pour déterminer
la position de l'entrée mute.
Autoradio sans prise ISO :
Vous pouvez utiliser un faisceau d'adaptation spécifique au véhicule (non fourni)
Si vous ne disposez pas d'un adaptateur, réalisez un montage fil à fil si la connectique
du véhicule n'est pas ISO.
Si l'autoradio possède une entrée " mute ", effectuez la connexion avec le fil jaune du
câble mute.
ATTENTION
- Le fil rouge du câble d'alimentation doit être connecté au
12V permanent, le fil orange au 12V après-contact et le fil
noir à la masse.
- Vérifiez le schéma électrique du faisceau d'alimentation
ISO de l'autoradio.
- Sur certains véhicules, il est nécessaire d'inverser les
positions des fils rouge et orange.
Cette opération s'effectue simplement en inversant les
porte-fusibles.
- Ne connectez pas le fil orange au 12V permanent, vous
risqueriez de provoquer la décharge de la batterie du
véhicule.
20 Guide d’utilisateur
evolution3.qxp 10/02/2005 10:32 Page 18

FRANCAIS
21
SCHEMA DE MONTAGE
Parrot EVOLUTION
evolution3.qxp 10/02/2005 10:32 Page 19

Choix de la langue lors de la 1ère utilisation
- Appuyez sur le bouton central en laissant le doigt appuyé 2 s (clic long)
Le kit annonce la langue en cours d'utilisation par le kit
- Lorsque vous tourner la molette le kit énonce les langues disponibles (français,
anglais, allemand, espagnol, italien…)
- Une fois que vous avez entendu la langue qui vous intéresse, valider en appuyant
rapidement sur le bouton central (clic court)
Jumelage
Lors de la première mise sous tension, il est nécessaire de jumeler votre téléphone avec
le kit mains-libres.
- Activez Bluetooth sur votre mobile
- Effectuez une recherche de périphériques
- Une fois détecté, "Parrot EVOL" s'affiche sur votre téléphone.
- Sélectionnez-le
- Entrez le code de liaison 1234 quand votre téléphone vous y invite puis validez.
Le Parrot EVOLUTION se connecte alors à votre téléphone.
Les menus sont désormais accessibles quand vous cliquez sur la molette centrale et
leur nom est énoncé par le kit mains-libres lorsque vous tournez cette molette.
Dès lors vous êtes connecté au kit mains-libres et pouvez l'utiliser pour communiquer
JUMELAGE
22 Guide d’utilisateur
Pour plus d'informations, référez vous à la notice de votre
téléphone (Chapitre jumelage) ou rendez-vous sur le site
www.parrot.biz
www.driveblue.com/guide_CHM/index.html
- Sur la gauche de l'écran, cliquez sur la rubrique Bluetooth
phones : en choisissant le téléphone que vous souhaitez ,
vous accédez à toute les procédures de paramétrage.
evolution3.qxp 10/02/2005 10:32 Page 20
