USER MANUAL
Parrot
PMK5800
HAND-FREE CAR KIT
FOR BLUETOOTH®ENABLED
MOBILE PHONES
FRA
ENG ESP
Audio
Streaming Pluggable
FM
Transmitter
ITA DEU NL POR

Contents
English.................. p. 7
Français................ p. 25
Spanish................. p. 43
Italiano.................. p. 59
Deutsch................ p. 77
Nederlands........... p. 97
Português............. p. 115

General Information
3
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1). this device may not cause harmful interference, and
(2). this device must accept any interference received, including
interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or tv interference caused
by unauthorized modifications to this equipment. Such modifications could void
the user’s authority to operate the equipment.
Declaration of Conformity
We, Parrot S.A. of 174 quai de Jemmapes, 75010 Paris, France,
declare under our sole responsibility that our product, the
Parrot PMK5800 to which this declaration relates in conformity
with appropriate standards EN300328, EN301 357 and CEPT
REC 70-03 Annex 13 as a Class 2 device and EN301489-
17, EN301489-9, EN60950 following the provision of Radio
Equipment and Telecommunication Equipment directive
(1999/5/EC R&TTE), with requirements covering EMC directive
89/336/EEC and Low Voltage directive 73/23/EEC.
Identification n° : 394 149 496 R.C.S. PARIS
Parrot S.A.
Licences
The Bluetooth word mark and logos are owned by the
Bluetooth® SIG, Inc. and any use of such marks by Parrot S.A.
is under license.
Bluetooth QDID : - B012641
- B012423
- B012424
MP3 audio coding technology licensed from Fraunhaufer IIS and
Thomson.
Correct Disposal of This Product (Waste Electrical &
Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems). This marking shown on the
product or its literature, indicates that it should not be disposed
with other household wastes at the end of its working life. To
prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources. Household users
should contact either the retailer where they purchased this
product, or their local government office, for details of where and
how they can take this item for environmentally safe recycling.
Business users should contract their supplier and the terms and
conditions of the purchase contract. This product should not be
mixed with other commercial wastes for disposal.

4
Compatibility problems
Some special edition cars can be released with some differences
from the original model. This could cause some compatibility
problems with the interfaces.
Our company is not responsible of compatibility problems
caused by new equipment or devices updated by the car
manufacturer without advise.
Copyrights
Copyright © 2007 Parrot. All rights reserved. The total or even
partial reproduction, transmission or storage of this guide in
any form or by any process whatsoever (electronic, mechanical,
photocopy, recording or otherwise) is strictly prohibited without
prior consent from Parrot.
Registered trademarks
All the names and trademarks mentioned in this document are
copyrightprotected and are the property of their respective
owners. MP3 audio coding technology licensed from
Fraunhaufer IIS and Thomson
Modifications
The explanations and specifications in this guide are given for
information purposes only and may be modified without prior
notice. They are deemed to be correct at time of going to press.
The utmost care has been taken when writing this guide, as part
of the aim to provide you with accurate information. However,
Parrot shall not be held responsible for any consequences
arising from any errors or omissions in the guide, nor for any
damage or accidental loss of data resulting directly or indirectly
from the use of the information herein. Parrot reserves the right
to amend or improve the product design or user guide without
any restrictions and without any obligation to notify users.
As part of our ongoing concern to upgrade and improve our
products, the product that you have purchased may differ
slightly from the model described in this guide.
if so, a later version of this guide might be available in electronic
format at Parrot’s website at www.parrot.com.

English

6
Contents
Introduction.........................................................................
Kit contents..........................................................................
Using for the first time.........................................................
1. Installing the Parrot PMK5800............................................
2. Syntonizing your car radio with the Parrot PMK5800..........
3. Pairing your phone with the Parrot PMK5800.....................
4. Selecting the language of the Parrot PMK5800..................
5. Setting the frequency.........................................................
6. Reversing the display orientation........................................
Description du Parrot PMK5800.........................................
1. Scrolling through the menus...............................................
2. Menu structure..................................................................
Features...............................................................................
1. Voice recognition................................................................
1.1 Recording keywords and magic words..............
1.2 Saving contacts in the Parrot PMK5800............
2. Telephony...........................................................................
2.1 Making a call manually from the phone..............
2.2 Making a call via the voice recognition feature...
2.3 Receiving a call..................................................
2.4 Ending a call......................................................
2.5 Redial function...................................................
2.6 Adjusting the volume.........................................
2.7 Changing to discreet mode................................
2.8 Sending DTMFs.......................................................
2.9 Clearing the memory................................................
2.10 Microphone mute..................................................
3. Audio Streaming
3.1 Pairing your audio player with the Parrot PMK5800.
3.2 Playing music files...................................................
3.3 Pausing during playback.........................................
3.4 Stopping playback..................................................
3.5 Adjusting the volume...............................................
3.6 Selecting music files................................................
3.7 Fast forwarding / fast rewinding the current track.....
4. Audio Streaming via audio cable..............................................
Updating the software...............................................................
Hotline........................................................................................
Specification..............................................................................
09
10
10
10
11
12
12
13
13
14
16
16
16
16
16
17
17
17
18
18
19
19
19
19
19
19
20
20
20
21
21
21
21
21
21
22
22
23

English
7
Introduction
The Bluetooth technology enables voice and data to be sent via
a short-distance radio link. It allows several electronic devices
to communicate with each other, particularly phones
and hands-free kits. Parrot is drawing on its long years
of experience in signal processing and voice recognition
technology to offer a hands-free kit with superior audio quality
during calls : the Parrot PMK5800.
Thanks to its FM transmitter the Parrot PMK5800 offers you a
faithful reproduction of your communication or music through
the speakers of your car. This will allow you to enjoy the listening
comfort of your cars’ audio system without installing anything.
With the Parrot PMK5800, you will be able to make phone calls
from your car while keeping your hands on the wheel.
You can also use the audio streaming function on your hands-
free kit to listen to the music files on your phone, PDA or audio
player over your vehicle’s speakers (if your phone, PDA or audio
player supports the audio streaming function). It will also allow
you to stream your music files from any audio player using the
USB/Jack audio cable. The Parrot PMK5800 acts as a real
extension of your mobile phone.

8
Kit contents
The kit includes :
• Parrot PMK5800
• USB/Jack audio cable
• Rubber tip
• User guide
• Parrot product guide
Using for the first time
1. Installing the Parrot PMK5800
Use the Parrot PMK5800
on your vehicle’s cigar lighter.
The rubber tip will allow you to fit
the Parrot PMK5800 to all types of
cigar lighter sockets. If this rubber tip
is necessary, screw it on the lower
part of the device.
You can position the screen
of the Parrot PMK5800 correctly
by adjusting the base
of the device or by pressing
the red button to reverse
the display orientation.
The use of a FM transmitter is forbidden in certain
countries. Please refer to national legislation or
Recommandation 70-03 implementation table for
current position http://www.ero.dk.

English
9
NOTE : YOU CAN USE THE PARROT PMK5800 IN ANY TYPE OF VEHICLE
EXCEPT IN HEAVY TRUCKS (24V).
In some rare occasions, depending on the depth at which
the cigar-lighter is placed, it is convenient to add an extender
(not provided), so that the driver has the Parrot PMK5800 in full
view. Make sure that the device stays stable and within reach if
you are using it while driving.
2. Syntonizing your car radio
with the Parrot PMK5800
Thanks to the FM transmitter of the Parrot PMK5800,
your communications as well as audio streaming and vocal
menus will be relayed through the vehicles speakers.
But you first have to syntonize your car radio and your cell
phone, that is to say to set your car radio and the Parrot
PMK5800 to the same frequency.
NOTE : DO NOT CHOOSE FREQUENCIES WHICH CORRESPOND
TO THE MAIN NATIONAL RADIO STATIONS.
After syntonization, set the volume of your car radio to a high
level and press the scroll wheel. The Parrot PMK5800 will send
out an audio signal that will be relayed through the speakers
of your vehicle. This will confirm the syntonization.
NOTE : IF THE PARROT PMK5800 AND YOUR CELL PHONE ARE NOT
CORRECTLY SYNTONIZED, THE SPEAKERS OF YOUR VEHICLE WON’T
RELAY ANY AUDIO SIGNALS. WE ADVISE YOU TO KEEP A FREQUENCY
ON YOUR CAR RADIO EXCLUSIVELY FOR THE PARROT PMK5800. FOR
MORE INFORMATION, REFER TO YOUR CAR RADIO’S USER GUIDE.
Geographical area Authorized frequencies
North America 88 / 108 MHz
Europe 87.6 / 107.9 MHz
Preset

10
3. Pairing your phone with the Parrot
PMK5800
Prior to use the Parrot PMK5800 with your phone for the very
first time, you must initially pair both devices.
1. Turn on your cell phone.
2. Plug the Parrot PMK5800 in the cigar lighter socket and
switch on the ignition.
> The Parrot PMK5800 says « Please Pair device ».
3. From your Bluetooth phone, search for Bluetooth peripherals
(consult your phone’s user guide or refer to the «Support»
heading on the www.parrot.com website).
4. Select «Parrot PMK5800».
5. Enter « 0000 » on your phone when prompted.
> The Parrot PMK5800 says « Pairing successfull »
when both devices are connected.
> The language is automatically selected if your cell phone
supports this feature. Otherwise, you can set the language
manually (for more information, refer to the “Selecting
the language” section).
NOTE : YOU CAN PAIR UP TO 10 PHONES WITH THE PARROT PMK5800.
4. Selecting the language
of the Parrot PMK5800
The default language of the Parrot PMK5800 is English.
Depending on your cell phone, the language can also be set
according to the information on your SIM card. If you set the
language manually, the automatic selection will be disabled until
the next memory erasing.
If you want to set the language of the Parrot PMK5800 manually:
1. On your car radio, select the same frequency you chose on
the Parrot PMK5800.
2. Quickly press the scroll wheel.
> The Parrot PMK5800 says the selected language
3. Press the scroll wheel once more to enter the «Language»
menu.
4. Use the scroll wheel to select the language.
5. Press the scroll wheel or the green button to confirm the
language you selected.

English
11
5. Setting the frequency
To get your communications as well as audio streaming relayed
through the vehicles speakers, you first have to set your car
radio and the Parrot PMK5800 to the same frequency.
To do so, the Parrot PMK5800 allows you to memorize
frequencies with the Preset button.
1. On your car radio, select the frequency you will attribute
to the Parrot PMK5800 and assign this frequency to a preset
button. For more information, refer to your car radio’s user
guide.
2. Press the Preset button for 2 seconds to switch to the
memorizing mode.
> The Preset area blinks.
3. Select the same frequency you chose on your car radio with
the scroll wheel.
4. Select the preset number you want to assign to this frequency
by quickly pressing the Preset button.
5. Press the Preset button for 2 seconds to assign the frequency
to the preset number you previously selected.
> The blinking in the preset area stops : the frequency has
been correctly assigned.
WARNING : FOR OBVIOUS REASONS OF SECURITY, DO NOT CHANGE
THIS FREQUENCY WHILE YOU ARE DRIVING.
NOTE :
- YOU CAN MEMORIZE UP TO 9 FREQUENCIES.
- IF YOU RECORD SEVERAL FREQUENCIES ON THE PARROT PMK5800,
A SHORT PRESS ON THE PRESET BUTTON WILL ALLOW YOU
TO CHANGE TO THE NEXT PRESET.
6. Reversing the display orientation
Press the red button for 2 seconds to reverse the display
orientation
Preset

12
Description of the Parrot PMK5800
Microphone
Speaker
Cigar lighter plug
User interface
2
3
1
4
7
6
5

English
13
1 Red button
Hang up
Exit the vocal menu
Exit the Voice recognition mode
Reject an incoming call
Reverse the display orientation
2 Green button
Answer an incoming call
Start a call
Redial the last number dialled
Confirm
Change to discreet mode during a call
Make a call via the voice recognition feature
3 Preset button
Select an already memorized frequency
Memorize a frequency
4 Scroll wheel
Set the frequency
Navigate through the vocal menu
Select/confirm
5 Seek + button
Play next track
6 Seek – button
Play previous track
7 Play/Pause button
Play the active track
Pause / resume playback
Stop playback (long press)
Suspend music from the analogical source

14
1. Scrolling through the menus
• On your car radio, select the same frequency you chose
on the Parrot PMK5800. For more information, refer to the
« Setting the frequency».
• Press the central scroll wheel to access the menus.
The kit says the name of the current menu.
• Browse through the menus by turning the wheel and confirm
with the green button or by pressing the scroll wheel.
• To exit the menu, press the red button or wait a few seconds.
2. Menu structure
• Language : This menu allows you to select the language of
the Parrot PMK5800. Refer to the « Selecting the language»
section.
• Add voice tags : This menu allows you to transfer a contact
via Bluetooth and add a voiceprint to this contact.
• Record magic words : This menu allows you to record
the « phone » magic word (to accept an incoming call or start
the voice recognition feature) and the « Hang up » magic word
(to terminate a call). It also allows you to activate/deactivate
these words if you already recorded them.
For more information, refer to the Voice recognition section.
• Record Keywords : This menu allows you to record
keywords (which are useful in the event of a contact
with several phone numbers). For more information,
refer to the Voice recognition” section.
• Software update: Enable this option before updating via
Bluetooth (www.parrot.com, Download section). Doing so will
increase the number of devices compatible with your
Parrot PMK5800.
Features
1. Voice recognition
The Parrot PMK5800 will allow you to enjoy the voice recognition
feature even if your phone does not support it.
Using the voice recognition feature is particularly appropriate
while you are driving.
1.1. Recording keywords and magic words
To offer you as many features as possible, the Parrot PMK5800
lets you record keywords: «general», «mobile», «work», «home»,
«other», as well as magic words: «phone» and «hang up».

English
15
• The magic word «phone» lets you accept an incoming call,
as well as start the voice recognition feature.
• The magic word «hang up» lets you terminate a call.
• In the event of a contact with several phone numbers,
the keywords allow you to choose the number to call.
To record keywords and magic words:
1. On your car radio, select the same frequency you chose
on the Parrot PMK5800. For more information, refer to the «
Setting the frequency».
2. Press the scroll wheel to enter the menu and select «Record
keywords».
3. Follow the prompts given by the kit. You will need to record
each keyword twice for better recognition.
> When a keyword is correctly recorded, you can choose
another keyword. Otherwise, it prompts you to record it again.
> You can exit the menu at any time by pressing the red
button and then go back to record or modify the keywords
whenever required.
1.2. Saving contacts in the Parrot PMK5800
To use the voice recognition feature, your contacts must first be
saved in the hands-free kit’s memory. Consequently you have
to send your contacts to the Parrot PMK5800 via Bluetooth. To
do so:
1. On your car radio, select the same frequency you chose
on the Parrot PMK5800. For more information, refer to the
«Setting the frequency» section.
2. Press the scroll wheel to enter the menu and select «Add
voice tags».
> The kit says “Awaiting a contact”
3. On your cell phone, select the contact and send it via
Bluetooth. For more information, refer to your phone’s
user guide.
4. Once received, add a voiceprint by following the prompts
NOTE: THE USE OF CERTAIN FEATURES (VOICE RECOGNITION, SEND
CONTACTS BY BLUETOOTH) DEPENDS EXCLUSIVELY ON YOUR PHONE.
REFER TO THE SUPPORT HEADING ON OUR WEBSITE AT WWW.PARROT.
COM FOR FURTHER INFORMATION.
2. Telephony
2.1 Making a call manually from the phone
• Dial the number using the phone’s keypad and start the call.
• The call automatically changes to hands-free mode. Otherwise,
press the green button on the Parrot PMK5800.

16
2.2 Making a call via
the voice recognition feature
IMPORTANT: YOU MUST HAVE FIRST RECORDED THE VOICE PRINTS
ON YOUR PHONE OR THE KIT (REFER TO THE CHAPTER ENTITLED
«VOICE RECOGNITION»).
1. On your car radio, select the same frequency you chose
on the Parrot PMK5800. For more information, refer to the «
Setting the frequency» section.
2. Quickly press the green button or say the “phone” magic word
(only if you already recorded this magic word –
refer to the Voice recognition section for more information).
3. Say the name of the person that you wish to call after the
«beep».
4. If your contact has several phone numbers and if you are
using the kit’s voice recognition feature, say «home», «work»,
«mobile», «general» or «other» after the second beep. If you do
not do so, the default number of this contact will be dialled.
NOTE: PRESS THE RED BUTTON TO EXIT THE VOICE RECOGNITION
MODE OR WAIT FOR 5 SECONDS.
NOTE: THE USE OF CERTAIN FEATURES (VOICE RECOGNITION,
SEND CONTACTS BY BLUETOOTH) DEPENDS EXCLUSIVELY
ON YOUR PHONE. REFER TO THE SUPPORT HEADING ON OUR WEBSITE
AT WWW.PARROT.COM FOR FURTHER INFORMATION.
2.3 Receiving a call
An incoming call is indicated by a ringtone and a blinking
of the red and green LEDs.
• If your car radio is already set on the frequency of the
Parrot PMK5800, then press the green button to answer the
call or the red button to reject it.
• If your car radio is not set to the frequency of the Parrot
PMK5800, switch to this frequency. By doing so, you
automatically answer the call.
• You can also answer this call with your phone (private
conversation).
Description du Parrot PMK5800
Preset

English
17
Preset
2.4 Ending a call
To end a call, press the red
button on the Parrot PMK5800
or say “hang up” (only
if you already recorded
this magic word – refer
to the Voice recognition
section for more information).
2.5 Redial function
Hold down the green key on the kit for two seconds
to redial the last number dialled.
2.6 Adjusting the volume
During the call, turn the volume control command
of your car radio or set it with your phone.
NOTE: THE USE OF CERTAIN FEATURES (VOLUME ADJUSTEMENT,
SEND CONTACTS BY BLUETOOTH) DEPENDS EXCLUSIVELY
ON YOUR PHONE. REFER TO THE SUPPORT HEADING ON OUR WEBSITE
AT WWW.PARROT.COM FOR FURTHER INFORMATION.
2.7 Changing to discreet mode
• During a call, if you want to continue the conversation
on your phone (private conversation), press the green button
on the Parrot PMK5800. The call is transferred to the phone.
• If you want to switch back to the kit,
press the green button again.
2.8 Sending DTMFs
During a call, you can send DTMFs (Dual-Tone Multi-Frequency)
for touch-tone dialling. This feature can be used for managing
your voicemail, for example.
1. Press the scroll wheel - the kit says «0».
2. Turn the wheel to scroll through the numbers.
3. Press the scroll wheel to send the selected number
to the phone.
4. Repeat this sequence to send other DTMFs.
2.9 Clearing the memory
You can pair up to 10 devices.
• If you attempt to pair a 11th device, the kit displays «memory
full».
• To pair a new phone, you must clear the memory by pressing
simultaneously the red and green buttons.
CAUTION: THIS WILL CLEAR ALL THE CONTACTS AND VOICEPRINTS
ASSOCIATED WITH THE PHONE AT THE SAME TIME.

18
NOTE: THE USE OF CERTAIN FEATURES (DISCREET MODE,
DTMF...) DEPENDS EXCLUSIVELY ON YOUR PHONE. REFER TO THE
SUPPORT HEADING ON OUR WEBSITE AT WWW.PARROT.COM FOR
FURTHER INFORMATION.
2.10 Microphone mute
During a call, if you do not want the person on the other
end of the line to hear you, quickly press the «Play» button
on the remote controls of the Parrot PMK5800.
Press the button again to cancel the mute.
3. Audio Streaming
The streaming audio feature lets you play the music tracks
recorded on your Bluetooth audio player over the vehicle’s
speakers. This feature depends on your audio player.
Some phones also incorporate this feature.
For further information, refer to our website: www.parrot.com.
Prior to use the Parrot PMK5800 with your audio player,
you will need to pair both devices.
3.1. Pairing your audio player
with the Parrot PMK5800
NOTE: IF YOU ARE USING YOUR PHONE FOR THE HANDS-FREE
AND STREAMING AUDIO FUNCTIONS AT THE SAME TIME, THE
FOLLOWING PHASE IS NOT REQUIRED.
YOUR PHONE IS ALREADY RECOGNISED BY THE KIT.
1. On your car radio, select the same frequency you chose
on the Parrot PMK5800. For more information, refer to the «
Setting the frequency».
2. From your Bluetooth audio player, search for Bluetooth
peripherals (consult your audio player’s user guide or refer to
the «Support» heading on the www.parrot.com website).
3. Select «Parrot PMK5800».
4. Enter «0000» on your audio player when prompted.
> The Parrot PMK5800 says «pairing successful»
when both devices are paired. The device sounds a beep
when connected.
3.2. Playing music files
1. On your car radio, select the same frequency you chose
on the Parrot PMK5800. For more information, refer to the
«Setting the frequency».
2. If a connection for Audio Streaming is active,
press the «Play / Pause» button to start
playing the music files stored
in your phone’s / player’s memory.
Preset

English
19
3.3. Pausing during playback
• When playing music files, quickly press the «Play / Pause»
button to momentarily stop playback.
• Quickly pressing the «Play / Pause» button resumes playback
of the music track.
3.4. Stopping playback
Hold down the «Play / Pause» button to stop playback.
The car stereo is once again played through the vehicle’s
speakers.
3.5. Adjusting the volume
Use the volume control command of your car radio
to adjust the volume for the audio streaming.
3.6. Selecting music files
When playing a music file, you can change to the next
or previous track by pressing the «Next» and «Previous»
buttons respectively.
NOTE : IF YOUR AUDIO PLAYER SUPPORTS THIS FEATURE, THE NEXT/
PREVIOUS ICONS ARE LIGHTENED.
3.7. Fast forwarding / fast rewinding
the current track
During playback, you can fast forward or rewind by holding
down the «Next» and «Previous» buttons respectively.
NOTE : IF YOUR AUDIO PLAYER SUPPORTS THIS FEATURE,
THE NEXT/PREVIOUS ICONS ARE LIGHTENED.
4. Audio Streaming via audio cable
The streaming audio feature lets you play the music tracks
recorded on your audio player over the vehicle’s speakers
even if it does not support Bluetooth technology.
To do so, simply connect your audio player to the Parrot
PMK5800 with the USB/Jack audio cable.
Preset

20
You will then have to use your audio player to control the music
playing (selection of music files, Fast forwarding/rewinding…).
Press the Play button of the Parrot PMK5800 to momentarily
stop playback (only if your car radio and your phone are correctly
syntonised).
Updating the software
You can update the software of your Parrot PMK5800 by
Bluetooth. Simply enable this mode before updating.
The update is performed by Bluetooth from a computer
equipped with Bluetooth.
Updating provides access to new features and improves
compatibility with an even wider range of phones.
For further information, visit our website to download the latest
software version: www.parrot.com.
Hotline
Our hotline is at your disposal. You can contact the hotline
by email or telephone. Visit our website at www.parrot.com
for further information.
Italie : [+39] 02 86 39 14 63
Espagne : [+34] 902 404 202
UK : [+44] (0)870 112 5872
Allemagne : 0900 172 77 68
USA : [+1] (877) 9 Parrot (toll-free)
Chine : [+86] (0)21 6460 1944
Hong Kong: [+852] 2736 1169
France : 01 48 03 60 69
Europe : [+33] 1 48 03 60 69 (spoken languages : English,
French, Spanish and German).
