Parrot MusicKit 6000 User manual

PARROT MK6000
User Guide
Parrot MusicKit 6000
For Bluetooth
Mobile Phone
ENG
FRA
CES
PYC
POL
CHI
JAP
HEB
TUR
ARA

www.parrot.biz
www.parrot.biz
English
Français
Česky
Русский
Рolski
Türkçe
Ελληνικά

汉语
日本語

3
15
27
39
51
63
75
98
99
111
134

English
Parrot MK6000
3
3
15
27
39
51
63
75
98
99
111
134

44
CONTENTS
INTRODUCTION
KIT CONTENTS
USING FOR THE FIRST TIME
Installing the Parrot MK6000
Description of the Parrot MK6000
Connecting your Bluetooth phone / PDA
FEATURES
Telephony
Voice menu structure
Description and use of the features
Voice recognition
Recording keywords and magic words
Saving contacts in the Parrot MK6000
Streaming audio
Pairing your audio player with the Parrot MK6000
Description and use of the features
UPDATING
HOTLINE
SPECIFICATIONS
NOTES
GENERAL INFORMATION
..............................................................................................................................................
...............................................................................................................................................
............................................................................................................................
.............................................................................................................
......................................................................................................
.............................................................................................
......................................................................................................................................................
..........................................................................................................................................
..............................................................................................................
.........................................................................................
................................................................................................................................
....................................................................................
....................................................................................
.................................................................................................................................
.................................................................
.........................................................................................
......................................................................................................................................................
.........................................................................................................................................................
.............................................................................................................................................
............................................................................................................................................................
................................................................................................................................
p 5
p 5
p 5
p 5
p 8
p 9
p 9
p 9
p 9
p 10
p 11
p 11
p 11
p 11
p 12
p 12
p 13
p 13
p 13
p 14
p 135

5
English
Parrot MK6000
INTRODUCTION
The Bluetooth® technology enables voice and data to be sent via a short-distance radio link.
It allows several electronic devices to communicate with each other, particularly phones and
hands-free kits.
Parrot is drawing on its long years of experience in signal processing and voice recognition
technology to offer a hands-free kit with superior audio quality during calls. The Parrot MK6000
is the first hands-free kit to incorporate the Beamforming technique by means of a double
microphone. This technology allows for greater call quality and improved noise reduction.
With the Parrot MK6000, you will be able to make phone calls from your car while keeping your
hands on the wheel. You can also use the streaming audio function on your hands-free kit to
listen to the music files on your phone, PDA or audio player over your vehicle’s speakers (if your
phone, PDA or audio player supports the streaming audio function). It acts as a real extension of
your mobile phone
KIT CONTENTS
• Control keypad
• Installation cables
• Electronic control unit
• Double microphone
• User guide
USING FOR THE FIRST TIME
INSTALLING THE PARROT MK6000
Prior to fixing the hands-free kit’s different components inside the car, connect the installation
cables, control keypad and double microphone to the electronic control unit.
Remove the original connectors from your vehicle’s audio system.
The cables supplied with the kit feature «ISO» connectors and two pairs of line-out jacks.The
line-out jacks can be used if your audio system features this option (use of an amplifier).
Several set-ups are therefore possible, depending on the type of car stereo and your vehicle:

Parrot MK6000
6
Car stereo with an «ISO» connector (refer to the following diagram):
• Connect the male connectors of the hands-free kit to the car stereo.
• Join the vehicle’s audio and power supply cables to the female connectors of the Parrot
MK6000.
• On the installation cable, connect the free yellow wire to one of the audio system’s
corresponding mute-in jacks if available (mute in 1, mute in 2 or mute in 3).
Note: the mute function is used to silence the sound from your car stereo to make way
for a call. The choice of the mute-in jack depends on your car stereo’s configuration.
Using ISO connectors
• A: Ignition 12V
• B: Constant 12V supply
• C: Ground
• D: Connection to the vehicle’s power supply
• E: Connection to the vehicle’s speakers
1.Rear right speaker (purple / purple-black)
2.Front right speaker (grey / grey-black)
3.Front left speaker (white / white-black)
4.Rear left speaker (green / green-black)
• F: This wiring is not used.

7
Parrot MK6000
Note: with this type of set-up, the original connectors of your vehicle’s audio system need not be removed.
Car stereo with line-in jacks (refer to the following diagram):
• Use this type of connection by wiring a line-out jack (brown & white wire or red & black
wire) to your car stereo’s line-in jack.
• Using the two pairs of line-out jacks will enable you to take advantage of the streaming
audio function in stereo over your vehicle’s speakers.
• On the installation cable, connect the free yellow wire to one of the audio system’s
corresponding mute-in jacks if available (mute in 1, mute in 2 or mute in 3).
Note: the mute function is used to silence the sound from your car stereo to make
way for a call. The choice of the mute-in jack depends on your car stereo’s confi--
guration.
Using line-in jacks
• A: Ignition 12V
• B: Constant 12V supply
• C: Ground
• D: Connection to the vehicle’s power supply
• E: Line-out 1
1: Line 1 +: white
2: Line 1 -: brown
• F: Line-out 2
1: Line 2 +: red
2: Line 2 -: black
• G: This wiring is not used.

Parrot MK6000
8
DESCRIPTION OF THE PARROT MK6000
Pick up / confirm button•
Call mute button
Play / pause during streaming audio •
• Hang up / cancel button
• Fast forward /
next track button
Fast rewind /
previous track button •
• Scroll wheel:
- Call / streaming audio volume adjustment
- Scrolling through the menus
- Press to confirm
Double microphone •
Car stereo without «ISO» connectors:
• To simplify the wiring procedure, you will need to purchase an «ISO adapter» cable.
• Refer to the range of ISO adapters on our website: www.parrot.biz
Installing the kit’s power cable:
• Refer to your car stereo’s wiring diagram.
• The red wire of the kit’s cable must correspond to the constant +12V supply, the orange
wire to the ignition +12V and the black wire to earth.
• Check that the orange wire is not connected to the constant +12V supply, as you could run
down the vehicle’s battery, preventing your hands-free kit from operating correctly.
• On some vehicles, the red and orange power supply wires may need to be reversed.
This can easily be done by reversing the two fuse holders on the Parrot MK6000
installation cable.
Note: on some vehicles, there is no ignition +12V on the vehicle’s connectors. You
must therefore connect the orange power supply wire to the fuse box or another
ignition power source.
Checking the wiring:
• When switching off your vehicle’s ignition, you should notice the following:
- The red and green LEDs should turn off
- The «Fast forward» and «Fast rewind» LEDs should light up for one second
- The «Play» LED should light up for one second
• When switching on the ignition, the opposite should happen.
Otherwise, the ignition +12V and the constant +12V supply have been reversed. In this case,
reverse the two fuse holders on the kit’s power supply lead.
Choose the place for the keypad inside your vehicle.We would advise you to fit it in the centre
of the dashboard or near you. The double microphone must be angled towards the driver and
preferably fitted between the sun visor and the rear-view mirror.

9
English
Parrot MK6000
CONNECTING YOUR BLUETOOTH PHONE / PDA
Prior to using your Parrot MK6000 with your phone for the very first time, you must initially
pair both devices.
PAIRING YOUR PHONE WITH THE PARROT MK6000
• From your Bluetooth phone, search for Bluetooth peripherals (consult your phone’s user
guide or refer to the «Support» heading on the www.parrot.biz website).
• Select «MK6000» in the list.
• Enter «0000» on your phone when prompted.
• The Parrot MK6000 says «pairing successful» when both devices are paired.
The hands-free kit sounds a beep when connected.
FEATURES
TELEPHONY
VOICE MENU STRUCTURE
Scrolling through the menus:
• Press the central scroll wheel to access the menus.
The kit says the name of the current menu.
• Browse through the menus by turning the wheel and confirm with the green button or by
pressing the scroll wheel.
• To exit the menu, press the red button or wait a few seconds.
Menu structure
• Phonebook: this menu enables you to access your contacts. You must first send your
contacts via the «Add voiceprints» menu.
• Language: select the language.
• Volume: adjust the volume of the voice menus.
• Add voiceprints: once enabled, the Parrot MK6000 is ready to receive contacts (sent one
by one - refer to the chapter entitled «Save contacts in the Parrot MK6000»). You must first
assign a voiceprint to the contact sent.
• Magic words activated / deactivated: activate / deactivate the magic words for
making calls via the voice recognition feature. The magic words («phone» and «hang up»)
must be recorded, so that they can be enabled. If necessary, recording will start
automatically.
• Record keywords: to use the voice recognition feature and all its possibilities, record
the keywords «general», «mobile», «work», «home» and «other», as well as the magic
words «phone» and «hang up».
• Software update by Bluetooth: enable this option before updating via Bluetooth

Parrot MK6000
10
(www.parrot.biz, Download section). Doing so will increase the number of devices compatible
with your hands-free kit.
DESCRIPTION AND USE OF THE FEATURES
Making a call manually from the phone
• Dial the number using the phone’s keypad and start the call.
• The call automatically changes to hands-free mode. Otherwise, press the green button on
the Parrot MK6000.
Making a call from the hands-free kit’s phonebook
• Click on the central scroll wheel and turn it until the kit says «Phonebook», and then
confirm.
• Turn the scroll wheel to change to the next letter. Press the scroll wheel or the green button
to consult the contact names beginning with that letter.
• Press the scroll wheel or the green button on the kit to select a contact.
• By turning the scroll wheel, the kit says the different types of phone number available for
that contact: «general», «mobile», «work», «home» and «other».
• Press the scroll wheel or the green button on the kit to start the call.
• The call is transmitted to the vehicle’s speakers.
• Important: you must first associate voiceprints with your contacts (refer to the chapter
entitled «Voice recognition»).
Making a call via the voice recognition feature
• Press the green button on the Parrot MK6000.
• Say the name of the person that you wish to call after the
«beep».
• IMPORTANT: you must have first recorded the voice
prints on your phone or the kit (refer to the chapter
entitled «Voice recognition»).
• When using the kit’s voice recognition feature, say «home»,
«work», «mobile», «general» or «other» after the second beep.
Receiving a call
• An incoming call is indicated by a ringtone and the LEDs flashing quickly on the
Parrot MK6000. If the caller’s name has been recorded, it will be played through the
vehicle’s speakers.
• Press the green button on the device to answer the call. The car stereo will automatically be
muted and the call reproduced through the vehicle’s front speakers.
Ending a call
• To end a call, press the red button on the Parrot MK6000.
The car stereo will automatically come back on.
Redial function
• Hold down the green key on the kit for two seconds to redial the
last number dialled.
Adjusting the volume
• During the call, turn the scroll wheel on the PARROT
MK6000. The volume setting is saved for subsequent calls.
Changing to discreet mode
• During a call, if you want to continue the conversation on
your phone (private conversation), press the green button on the
Parrot MK6000. The call is transferred to the phone.
• If you want to switch back to the kit, press the green button again.
Microphone mute
• During a call, if you do not want the person on the other end of the line to hear you, quickly
press the «Play» button on the Parrot MK6000. Press the button again to cancel the
mute.

11
English
Parrot MK6000
Sending DTMFs
• During a call, you can send DTMFs (Dual-Tone Multi-Frequency) for touch-tone dialling.This
feature can be used for managing your voicemail, for example.
• Press the scroll wheel - the kit says «0».
• Turn the wheel to scroll through the numbers.
• Press the scroll wheel to send the selected number to the phone.
• Repeat this sequence for sending other DTMFs.
Clearing the memory
• You can pair up to five devices.
• If you attempt to pair a sixth device, the kit says «memory full».
• To pair a new phone, you must clear the memory by holding down both the green and red
buttons for three seconds.
CAUTION: doing so also clears all the contacts and the associated voiceprints.
Note: the use of certain features (voice recognition, redial, discreet mode) depends
exclusively on your phone. Refer to the Support heading on our website at www.
parrot.biz for further information.
VOICE RECOGNITION
Recording keywords and magic words
To offer you as many features as possible, the Parrot MK6000 lets you record keywords: «gene--
ral», «mobile», «work», «home», «other», as well as magic words: «phone» and «hang up».
The magic word «phone» lets you accept an incoming call, as well as start the voice recognition
feature. The magic word «hang up» lets you terminate a call.
In the event of a contact with several phone numbers, the keywords allow you to choose the
number to call.
• Click on the central scroll wheel and turn it until the kit says «Record keywords», and then
confirm.
• The kit says «Record all keywords».
• If one or more keywords are already recorded, the kit selects the first keyword that has not
yet been recorded.
• Press the central scroll wheel or the green button to start recording. Follow the prompts
given by the kit. You will need to record each keyword twice for greater recognition.
• When a keyword is correctly recorded, the kit automatically goes to the next. Otherwise, it
prompts you to record it again.
• As soon as all keywords are correctly recorded, the kit enables them automatically.
• You can exit the menu at any time by pressing the red button and then go back to record or
modify the keywords whenever required.
• If you do not wish to record all the keywords, turn the scroll wheel to select the required
word.
Saving contacts in the Parrot MK6000
To use the voice recognition feature of the Parrot MK6000, you must send the contacts by
Bluetooth from your phone to the kit. Proceed as follows:
• Return to the «Add voiceprints» menu.
• Press the scroll wheel or the green button: the Parrot MK6000 and the phone disconnect
the kit is now ready to receive contacts.
• On your phone, select the contacts and send them by Bluetooth (refer to your phone’s user
guide or our website).
• Select «MK6000» from the list (enter 0000 as the PIN code if prompted by your
phone).
• Once received, the kit asks you to record the name corresponding to the contact. The voice
print is assigned to the contact.
Note: the use of certain features (voice recognition, send contacts by Bluetooth) de--
pends exclusively on your phone (support of the Hands-free or Headset profile). Refer
to the Support heading on our website at www.parrot.biz for further information.
STREAMING AUDIO
The streaming audio feature lets you play the music tracks recorded on your Bluetooth audio
player over the vehicle’s speakers. This feature depends on your audio player. Some phones also
incorporate this feature. For further information, refer to our website: www.parrot.biz
Prior to using the Parrot MK6000 with your audio player, you will need to pair both devices.

Parrot MK6000
12
Pairing your audio player with the Parrot MK6000
Note: if you are using your phone for the hands-free and streaming audio functions at
the same time, the following phase is not required. Your phone is already recognised
by the kit.
Pairing your Bluetooth audio player
• From your Bluetooth audio player, search for Bluetooth peripherals (consult your audio
player’s user guide or refer to the «Support» heading on the www.parrot.biz website).
• Select «MK6000».
• Enter «0000» on your audio player when prompted.
• The Parrot MK6000 says «pairing successful» when both devices are paired.The device
sounds a beep when connected.
• The LED of the blue «Play / Pause» button lights up when the connection between the
hands-free kit and the audio player is active.
Note: since some audio players do not have an interface for entering the pairing code,
simply enable the pairing mode on your audio player (refer to your device’s user guide)
and switch on your Parrot MK6000.
Description and use of the features

• If a connection for streaming audio is active, press the
«Play / Pause» button to start playing
the music files stored in your phone’s / player’s memory.

• When playing music files, quickly press the «Play /
Pause» button to momentarily stop playback. While
paused, your car stereo is still muted and the «Play»
LED flashes.
• Quickly pressing the «Play / Pause» button resumes
playback of the music track.

• Hold down the «Play / Pause» button to stop playback. The car stereo is once again played
through the vehicle’s speakers.

• When playing a music file, the scroll wheel on the hands-free kit can be used to adjust the
volume. You can also adjust the volume via the phone (refer to your phone’s user guide).
• The volume for calls and the volume for the streaming audio function work separately.

• When playing a music file, you can change to the next or
previous track by quickly pressing the «Next» and
«Previous» buttons respectively.
Note: if your audio player supports this feature, the
front/rear LEDs on your hands-free kit light up.
Fast forwarding / fast rewinding the current

• During playback, you can fast forward or rewind by
holding down the «Next» and «Previous» buttons respectively.
Note: if your audio player supports this feature, the front/rear LEDs on your hands-
free kit light up.
Note: the use of certain features (selecting music files, fast forward / fast rewind,
volume adjustment from the phone) depends exclusively on your phone. Refer to the
Support heading on our website at www.parrot.biz for further information.
When using the streaming audio function on your hands-free kit, you can still access the diffe--
rent menus: Phonebook, add voiceprints, and so on. Simply press and then turn the scroll wheel
on the Parrot MK6000. The streaming audio feature pauses when browsing through the menus.
The phone functions of your Parrot MK6000 remain active while streaming audio is being used
(except for use of the magic word «phone»). When using the Parrot MK6000 in phone mode, the
streaming audio feature is suspended.

13
English
Parrot MK6000
UPDATING
You can update the software version of your Parrot MK6000 by Bluetooth.
Simply enable this mode before updating.
The update is performed by Bluetooth from a computer equipped with Bluetooth.
Updating provides access to new features and improves compatibility with an even wider range
of phones.
For further information, visit our website to download the latest software version: www.parrot.
biz
HOTLINE
Our hotline is at your disposal to provide you with any assistance required. You can contact the
hotline by email or telephone. Open from Monday to Friday between 9 am and 6 pm (GMT+1).
• Europe: + 33 (0) 1 48 03 60 69
• Italy: [phone]
• Spain: [phone]
• UK: + 44 (0) 870 112 5872
• Germany: [phone]
• USA: +1 (877) 9 PARROT (toll-free)
• China: + 862 164 601 944
Visit our website at www.parrot.biz to download the latest software version.
SPECIFICATIONS
BLUETOOTH
• Bluetooth 1.2 qualified
• Hands-free profile 1.0 and 1.5
• Headset profile 1.1
• Object Push Profile 1.1
• Advanced Audio Distribution Profile 1.0
• Audio/Video Remote Control Profile 1.0
• Bluetooth PIN code «0000»
• Maximum range: around 10 m
• Pairing of up to five phones
• 150 contacts per phone
• 150 voiceprints per phone
MECHANICS
• Dimensions: 65 x 28 x 138 mm
• Weight: 130 g
CONNECTIONS
• ISO connector
• ISO adapter available at: www.parrot.biz
SIGNAL PROCESSING
• Beamforming and noise reduction
• Echo cancellation
• Built-in voice recognition
COMPLIANCE
• FCC
• E2
• Bluetooth
• CE
• Environment qualified

Parrot MK6000
14
NOTES

Français
Parrot MK6000
15

1616
SOMMAIRE
INTRODUCTION
CONTENU DE L’EMBALLAGE
PREMIÈRE UTILISATION
Installation du Parrot MK6000
Description du Parrot MK6000
Connecter son téléphone / PDA Bluetooth
FONCTIONNALITÉS
Téléphonie
Arborescence des menus vocaux
Description et utilisation des fonctionnalités
Reconnaissance vocale
Enregistrer les mots clés et les mots magiques
Enregistrer des contacts dans le Parrot MK6000
Streaming audio
Jumelage de votre lecteur audio avec le Parrot MK6000
Description et utilisation des fonctionnalités
MISE À JOUR
HOTLINE
SPECIFICATIONS TECHNIQUES
NOTES
INFORMATIONS GÉNÉRALES
..............................................................................................................................................
............................................................................................................................
..................................................................................................................................
............................................................................................................
............................................................................................................
...........................................................................................
.........................................................................................................................................
..........................................................................................................................................
.............................................................................................
............................................................................
.......................................................................................................................
.........................................................................
......................................................................
.................................................................................................................................
.........................................................
............................................................................
.. ..................................................................................................................................................
.........................................................................................................................................................
........................................................................................................................
............................................................................................................................................................
.. ...........................................................................................................................
p 17
p 17
p 17
p 17
p 20
p 21
p 21
p 21
p 21
p 22
p 23
p 23
p 23
p 23
p 24
p 24
p 25
p 25
p 25
p 26
p 135

17
Parrot MK6000
Français
INTRODUCTION
La technologie Bluetooth® permet d’établir des communications voix et données via une liaison
radio courte distance. Elle permet à de nombreux équipements électroniques de communiquer
entre eux, notamment les téléphones et les kits mains-libres.
Parrot tire bénéfice de ses longues années d’expérience en traitement du signal et reconnais--
sance vocale pour vous proposer un kit mains-libres d’une qualité audio supérieure lors des com--
munications. Le Parrot MK6000 est notamment le 1er kit mains-libres qui intègre la technique
Beamforming à travers un double microphone. Cette technologie permet une meilleure qualité de
communication et une meilleure réduction de bruit.
Avec le Parrot MK6000, vous allez pouvoir passer des appels téléphoniques depuis votre voiture
en gardant les mains sur le volant.Vous pouvez également utiliser la fonction STREAMING AUDIO
de votre kit mains-libres pour écouter les fichiers musicaux de votre téléphone / PDA ou de votre
lecteur audio sur les haut-parleurs de votre véhicule (si votre téléphone/ PDA ou lecteur audio
supporte la fonction streaming audio). Il fonctionne comme une véritable extension de votre
téléphone portable.
CONTENU DE L’EMBALLAGE
• Clavier
• Câble d’installation
• Boîtier électronique
• Double microphone
• Notice d’utilisation
PREMIÈRE UTILISATION
INSTALLATION DU PARROT MK6000
Avant de fixer les différents éléments du kit mains-libres dans l’habitacle, commencez par
connecter les différents câbles sur le boîtier électronique.
Retirez les connecteurs d’origine du système audio de votre véhicule.
Les câbles fournis sont équipés de connecteurs « ISO « ainsi que de deux sorties « Line».
Les sorties « Line » peuvent être utilisées si votre système audio possède cette option.
Plusieurs montages sont donc possibles selon le type de votre autoradio et de votre véhicule :

Parrot MK6000
18
Autoradio avec connecteur « ISO » ( voir schéma suivant) :
• Branchez les connecteurs mâles du kit mains-libres à l’autoradio.
• Reliez les faisceaux audio et alimentation du véhicule aux connecteurs femelles du Parrot
Parrot MK6000
• Sur le câble d’installation, reliez le fil jaune libre à l’une des entrées mute correspondante
du système audio s’il en est équipé (mute in1, mute in2 ou mute in3).
Note : La fonction Mute permet d’interrompre le son de votre autoradio pour laisser
place au son de la communication. Le choix de l’entrée Mute dépend de la configura--
tion de votre autoradio.
Utilisation de connecteurs ISO
• A :12V clé
• B : 12V permanent
• C : Masse
• D : Connexion sur l’alimentation du véhicule
• E : Connexion sur les haut-parleurs du véhicule
1.Haut-parleur arrière droit (violet / violet-noir)
2.Haut-parleur avant droit (gris / gris-noir)
3.Haut-parleur avant gauche (blanc / blanc – noir)
4.Haut-parleur arrière gauche (vert / vert – noir)
• F : Ce câblage n’est pas utilisé

19
Parrot MK6000
Autoradio avec entrées « line in » (voir schéma suivant) :
• Utilisez ce type de connexion en reliant une sortie « Line » (fils marron et blanc ou fils rouge
et noir) sur l’entrée « Line » de votre système audio.
• L’utilisation des deux paires de sorties « Line » permet de bénéficier de la fonction Strea-
ming Audio en stéréo sur les haut-parleurs de votre véhicule.
• Sur le câble d’installation, reliez le fil jaune libre à l’une des entrées mute correspondante
du système audio s’il en est équipé (mute in1, mute in2 ou mute in3).
Note : La fonction Mute permet d’interrompre le son de votre autoradio pour laisser
place au son de la communication. Le choix de l’entrée Mute dépend de la configura--
tion de votre autoradio.
Utilisation d’entrée « Line »
• A : 12V clé
• B : 12V permanent
• C : Masse
• D : Connexion sur l’alimentation du véhicule
• E : Sortie 1 « Line »
1 : Line 1 + : blanc
2 : Line 1 - : marron
• F : Sortie 2 « Line »
1 : Line 2 + : rouge
2 : Line 2 - : noir
• G : Ce câblage n’est pas utilisé
Note : Avec ce type de montage, il est nécessaire de ne pas retirer les connecteurs d’origine du système audio de votre véhicule

Parrot MK6000
20
Bouton Décrocher / Valider •
Bouton Mute en téléphone,
Lecture / Pause en Streaming Audio •
• Bouton Raccrocher / Annuler
• Bouton Avance Rapide,
piste suivant
Bouton Retour Rapide,
piste précédent •
• Bouton Rotateur :
- Réglage volume
- Déplacement dans les menus
- Appuyez pour valider
Double microphone •
Autoradio sans connecteurs « ISO « :
• Afin de faciliter le montage, vous devez vous procurer un câble adaptateur « ISO »,
• Consultez la gamme d’adaptateur ISO sur notre site internet : www.parrot.biz
Installation du câble d’alimentation du kit :
• Consultez le schéma électrique de votre autoradio.
• Le fil rouge du câble du kit doit correspondre au +12V permanent, le fil orange au 12V
après-contact et le fil noir à la masse.
• Vérifiez que votre fil orange n’est pas connecté au 12V permanent, vous risqueriez de dé
charger la batterie du véhicule et cela entraînerait un dysfonctionnement de votre mains-
libres.
• Sur certains véhicules, il est nécessaire d’inverser les fils rouge et orange d’alimen-
tation.Cette opération s’effectue simplement en inversant les deux portes fusibles situés sur
le câble d’installation du Parrot MK6000.
Note : Sur certains véhicules, il n’y a pas de +12V après contact sur les connecteurs
du véhicule. Il est alors nécessaire de brancher le fil d’alimentation orange sur la boite
à fusible ou sur une autre source d’alimentation après contact.
Vérification de l’installation :
• A la coupure du contact de votre véhicule, vous devez observer le comportement suivant :
- Les LEDs rouge et verte doivent s’éteindre.
- Les LEDs « Avance rapide » et « Retour rapide » doivent s’allumer pendant une
seconde.
- La LED « Lecture » doit ensuite s’allumer pendant une seconde.
• A la remise du contact, vous devez observer le comportement inverse.
Si vous n’observez pas ce comportement, le 12V clé et le 12V permanent sont inversés. Dans
ce cas là, veuillez inverser les deux portes fusibles du câble d’alimentation du kit.
Choisissez l’emplacement du clavier dans l’habitacle de votre véhicule. Nous vous conseillons
de le positionner au centre de votre tableau de bord ou proche de vous. Le double microphone
doit être dirigé vers le conducteur et installé de préférence entre le pare-soleil et le rétroviseur
central
DESCRIPTION DU PARROT MK6000
