Patpet p-collar 310 Setup guide

For 1 Dog
p-collar 310
For 2 Dogs
p-collar 310B
PLEASE READ THIS ENTIRE GUIDE BEFORE BEGINNING
Remote Training Collar
operating and training guide
B-310-TEX-111(3)

Important Safety Information
important that you and your dog remain
safe while learning during on-leash training.
Your dog should be on a strong leash, long enough for him to
attempt to chase an object, but short enough for him not to reach
a road or other unsafe area. You must also be physically strong
Safety during on-leash training. It is vitally
enough to restrain your dog when he tries to chase.
long or made too tight on the pet’s neck may cause skin damage.
commonly known as bed sores.
Risk of skin damage. Please read and follow
the instructions in this manual. Proper fit of
the collar is important. A collar worn for too
Ranging from redness to pressure ulcers; this condition is
behavior. Aggressive dogs can cause severe injury and even
use this Product if your dog is aggressive,
or if your dog is prone to aggressive
Not for use with aggressive dogs. Do not
death to their owner and others. If you are unsure whether this
product is appropriate for your dog, please consult your
veterinarian or certified trainer.
3
Avoid leaving the collar on the dog for more than 12 hours per day.
When possible reposition the collar on the pet’s neck every
Check the fit to prevent excessive pressure; follow the
Never connect a lead to the electronic collar; it will cause
excessive pressure on the contacts.
When using a separate collar for a lead, don’t put pressure
1 to 2 hours.
instructions in this manual.
on the electronic collar.

If redness or sores are found, discontinue use until the skin
Millions of pets are comfortable while they wear stainless steel
contacts. Some pets are sensitive to contact pressure. You
collar. If so, you may relax some of these precautions. It is
may find after some time that your pet is very tolerant of the
These steps will help keep your pet safe and comfortable.
important to continue daily checks of the contact area.
has fully healed.
Table of Contents
Components...............................................................
Other Items You May Need........................................
Main Features............................................................
Overview....................................................................
Operating Guide.........................................................
How to turn the p-collar 310 on/off..........................
How the transmitter buttons work...........................
Collar fitting.............................................................
How to set the best Vibration/Shock Level.............
To maximize the distance.......................................
The LCD & LED indicator.......................................
Charging the unit....................................................
How to pair the Transmitter and Receiver Collar....
How to use the Test Light............................... ........
Gerneral Training Tips...............................................
Frequently Asked Questions.....................................
Troubleshooting......................................................
Warranty and Repair Informatiion.............................
Reference Size for Difference Dogs..........................
Reference Weight for Dogs.......................................
6
9
20
54
Wash the dog’s neck area and the contacts of the collar
weekly with a damp cloth.
If the condition persists beyond 48 hours, see your veterinarian.
If a rash or sore is found, discontinue use of the collar until
the skin has healed.
6
7
8
9
10
12
13
14
15
16
18
19
21
22
23
27
27
Dog 1/2 Button Function......................................... 11

Main Features
Shock, Vibration, and Tone Commands
100% Waterproof Receiver Collar
2-hour Rapid Charging Lithium Polymer Battery
300M Remote Training Range
User Expandable to a Two-dog System
Blind Operation with Touch Distinguishing Mode Buttons
8 Adjustable Intensity Levels for Vibration and
16 Adjustable Intensity Levels for Shock
76
For 1 Dog
For 2 Dogs
Backlit LCD Display Shows Intensity Level, Battery
and Dog 1/2.
ŸScrewdriver
ŸScissors
ŸLighter
Test Light
Dog 1 Receiver Collar
Battery Charger
Wrist Strap
Dog 2 Receiver Collar
Collar
for Transmitter
for Receiver
USB Port
conductive
Silicone Jacket
Contact Points
Remote
Transmitter
Components
Other Items You May Need
Collar

Overview
LED Indicator Light
White Backlit
LCD Display
Blind Operation
Identification Point
Easily distinguish
and send the correct
training command
without eyes on by
touching and feeling
on buttons with
different structure.
Selecting Channels
Intensity Level
Adjustment
Antenna
Wrist Strap Pin
Transmitter
Contact
Points
Charging Jack
(with cover)
Receiver Collar
On/Off
Button
Operating Guide
Step
1
How to turn the p-collar 310 on/off
To turn the Transmitter on
98
To turn the Receiver Collar off
2. Release the On/Off Button.
light shuts off.(This takes approximately three seconds.)
1. Press and hold the On/Off Button until the Red LED
Note: To extend the life of the batteries, turn the
Receiver Collar off when it is not in use.
2. Backlight will stay for about 30 seconds. if no operation
then, backlight off.
3. LCD display will stay for about 5 minutes. if no operation
then, LCD display shuts off.
1. Press any of to active the Transmitter.
The backlight on.
To turn the Receiver Collar on
Press once, the green light on and will flash every
5 seconds under working mode.
Action Buttons
Avoid the injuryto the
dog’s skin becauseof
the friction of metal
contact points.
Conductive Silicone Jacket
To turn the Transmitter off
Transmitter DO NOT have turn off function. In order
to give a rapid reation by pressingTransmitter in
time when dogs have a badbehavior. In this case,
if need to turn on the transmitter, we may miss the
best training time.

Step
2
How the Transmitter buttons work
TONE
SHOCK
Up/Down
Button
VIBRA
Dog 1/2 Button
Dog 1/2 Button
10 11
2. Press and hold , Receiver Collar will have a
continuous vibration/shock, and stop after 10 seconds.
Note: Do not suggest to press and hold for long
time to avoid physical or psychological hurt to the dog.
1. Press once to send a vibration, sound,
shock command to Receiver Collar.
1. Press once to switch between Dog 1 and Dog 2.
2. Press and hold until the Vibration digit flashes.
Press “ + - “ to adjust Vibration Level from 1-8.
1/2
3. Press and hold until the Shock digit flashes.
Press “ + - “ to adjust Shock Level from 1-16.
1/2
1/2

Step
4
How to find the best
Vibration/Shock Level
The unit comes with Up and Down buttons to control
the Vibration/Shock Level, with Level 1 being the
The level of Vibration/Shock best suited for your dog
for Vibration/Shock. Always start at the lowest level
and work your way up.
The appropriate level can be found when the dog
/Shock Level may vary depending on the training
situation. When highly distracted, dogs will require a
lowest level for Both Vibration and Shock, Level 8
depends on your dog’s temperament and threshold
higher level of Vibration/Shock.
being the highest for Vibration and Level 16 being
responds to the Vibration/Shock with a mild reaction,
such as a tensing of the neck muscles. The Vibration
the highest for Shock.
Collar fitting
you dog’s skin. When properly fitted, the Receiver/Collar
should not move on the dog. The best location for
A loose fit can allow the Receiver/Collar to move
The Receiver/Collar should be fitted so that the surgical
around on the dog’s neck. When this happens, the
contact points may rub the skin and cause irritation.
If the Receiver/Collar is too tight, the dogs may have
difficulty breathing.
dog’s skin. When properly fitted, you should be able
the Receiver/Collar box is either side of the dog’s
windpipe.
stainless steel contact points press firmly against the
to fit a finger or two snugly in between the collar and
Step
3
12 13
Step
5
1/2
1/2
1. Press and hold until the Vibration digit flashes.
Press “ + - “ to adjust Vibration Level from 1-8.
2. Press and hold until the Shock digit flashes.
Press “ + - “ to adjust Shock Level from 1-16.
How to switch Between
Vibra Level and Shock Level

Transmitter LED Indicator Light – Function and Response
Button Button Function Transmitter Indicator
Light Response
Delivers audible tone to collar Red LED on for
length of button press
Delivers vibration to collar
base on current level shown
on Digital Display (vibration
will time-out if pressed
continuously for 10 seconds
and will reset after release
the VIBRA button)
Red LED on for
length of button press
Delivers shock to collar base
on current level shown on
Digital Display (shock will
time-out if pressed
continuously for 10 seconds
and will reset after release
the SHOCK button)
Red LED on for
length of button
press
*Avoid touching the antenna or the range may
decrease substantially.
The unit has a 300 meter range. The range may vary
the Transmitter away from your body to receive the
depending on the way the Transmitter is held. Hold
greatest range. For maximum signal strength, keep
the device properly charged.
Maximum range Typical range Minimum range
14 15
To maximize the distance
6
Step Step
7
The LCD & LED indicator
Indicates Vibration levels ranging from 1-8,
and appears in the right upper part.
Indicates the active dog receiver and
appear in the left part.
Indicates battery’s power level.
Note: The battery indicator will flash every
second to indicate low battery.
Indicates Shock levels ranging from 1-16,
and appears in the right lower part.

3. Connect the charger connectors to the Transmitter and
1. Plug the charger into a standard wall outlet.
2. Lift the rubber covers protecting the Transmitter/Receiver
Collar Charging Jack.
4. Connect the USB port to the Charging Adapter.
5. Charge the unit for 4 hours for the first charge. Recharges
Receiver Collar Charging Jack, and as shown below.
take only 2-3 hours.
Note: The Battery Indicator on the Transmitter will scroll and
the indicator light in steady red while charging; and the Battery
flashes when fully charged.
The indicator light on the Receiver Collar will be in steady red
Indicator will become steady, and the LED Indicator Light
while charging and green light turned on when fully charged.
6. When charging is completed, remove the charger connector.
Charging the unit
The unit uses Lithium-Polymer batteries.
1. Charge the unit before using the unit for the first time.
2. Do not charge the unit near any flammable
substances.
3. Fully charge if the unit is to be stored without use for
a period of 3 months or more.
Receiver Collar Function
Normal operation
- Low battery
Red LED Response
On for 3 seconds
Flashes rapidlly
On length of VIBRA/SHOCK
button press
On length of charging within
2-3 hours
Power off
Vibration/Shock
Charging
Step
8
Recharge the unit if:
The indicator light on the collar is emitting a red color
and flashes rapidly.
The 3 bar indicator on the Transmitter LCD shows just
1 bar.
Battery Charging Procedure
NOTE: The unit has a partial charge when it leaves our facility,
upon receipt of the collar, be sure to give it a 4-hour initial charge
before the first use.
The indicator light on the Transmitter or Receiver will not come on.
The indicator light on the Transmitter or Receiver comes on
momentarily when any of the Mode Buttons is pushed.
16 17
Normal operation
- Good battery
Charging Complete
Receiver Collar Function Green LED Response
Flashes once
1 flash every 5 seconds
On length of TONE button press
Flashes once every second
within 15 seconds
Flashes rapidly for five times
On length of the charger connected
Power on
Training tone
In pairing position
Pairing Complete
Receiver Indicator Light – Function and Response

How to use the Test Light
Transmitter.
Save the Test Light for future testing.
Note: If the Test Light does not flash, recharge
Note: At higher Shock Levels, the Test Light
1. Turn the Receiver Collar on.
Points.
4. The Test Light will flash.
will flash brighter.
2. Hold the Test Light Contacts to the Contact
3. Press the SHOCK Button on the Remote
5. Turn the Receiver Collar off.
the Receiver and re-test. If Test Light still does
not flash, contact us for Customer Service.
Step
10
18 19
Step
9
How to pair the Remote
Transmitter & Receiver Collar
If your Receiver Collar does not beep when the TONE
Button of the Remote Transmitter is pushed,or if you
feel the Receiver Collar is not responding to the Remote
Transmitter, follow these steps to pair:
Two Dog System
NOTE: If you wish to add another Receiver Collar to
Dog 1/2 Button.
2. Turn on the Receiver Collar for Dog 2, press any
the training system, extra Receiver Collars are available
where you bought your unit.
Remote Transmitter
1. Switch Dog1 to Dog2 by pressing and releasing the
may be needed.Repeat steps in How to pair the Remote
Transmitter & Receiver Collar above.
Mode Buttons to verify function.
3. If Dog 2 Receiver Collar does not respond. Pairing
2. Press any of on the transmitter,
the Green LED Light on the Receiver Collar flashes
rapidly for 5 times which means pairing is completed.
1. With the Receiver Collar off your pet, turn the
Receiver Collar off. Restart, press and hold the On/Off
Button until the Green LED flashes every second on
the Receiver Collar.

Training Guide
General Tips
Never use the Remote Training Collar to
correct or eliminate any form of aggressive
trainer to determine if your pet might be
behavior. We recommend you contact
aggressive. See page 3 for more information.
your local veterinarian or professional
Frequently Asked Questions
Is the Vibration/Shock
safe for my pet?
How old does my pet
have to be before
using the Remote
Training Collar?
Probably not. You may need to
Is the Receiver Collar
waterproof?Yes.
20 21
Eliminate one misbehavior or teach one obedience
command at a time. If you move too fast with training,
your pet may become confused.
Be consistent. Correct your pet every time he misbehaves.
Unless you can supervise him, it is recommended that
you restrict your pet from situations in which he has a
history of misbehaving. However, setting up a situation
as a training session can dramatically improve your
chances of success.
If your pet reacts to the tones by hiding or acting fearful,
redirect his attention to a simple and appropriate behavior,
such as the “sit” command.
Pets should be at least 6 months old before using the
Training Collar.
Only let responsible family members use the Training
Collar. It is not a toy!
Other pets in hearing range will be affected by the
training tones. Therefore, training sessions should be
conducted out of hearing range of other pets.
How to switch Between
Vibra Level and Shock
Level
Press and hold until the Vibration
Press and hold until the Shock
digit flashes. Press “ + - “ to
adjust Shock Level from 1-16.
1/2
1/2
digit flashes. Press “ + - “ to
adjust Vibration Level from 1-8.
While the Vibration/Shock is
unpleasant, it is harmless to your
the owner to achieve desired results.
require interaction and training from
pet. Electronic training devices
Your pet should be able to recognize
basic obedience commands such as
Training Collar.
least 6 months old before using the
“Sit” or “Stay”. Pets should be at
reinforce training with the Receiver
Collar from time to time.
The range of the Remote Training
will vary according to terrain,weather,
.
vegetation, as well as transmission
from other radio devices. See “To
maximize the distance” for tips on
maximizing your range.
Once my pet is trained
and has been obeying
my commands, will he
have to continue to
wear the Receiver
Collar?
the Remote Training
Collar?
meters of range with
Will I get exactly 300

22 23
Troubleshooting
My pet does not
respond when I
press a button.
Make sure the Receiver Collar has
been turned on.
•
• If your range has reduced from the first
time you used the Remote Training
Collar, the battery(s) may be low in
Terrain, weather, vegetation,
transmission from other radio devices
and many other factors can impact the
amount of range you have with the unit.
• Test the Receiver Collar. See “How to
use the Test Light” for details.
• Increase the Vibration/Shock Level.Refer
to “How to find the best Vibration/Shock
Level” for more information.
•
more information.
Make sure the Receiver Collar’s Contact
Points are placed snugly against your
pet’s skin. Refer to “Collar fitting” for
The Receiver
Collar will not
turn on.
•
be sure to charge it for 4 hours.
been charged. For the initial charge,
2-3 hours.
Make sure the Receiver Collar has
Subsequent charges only take
•
The maximum amount of time you
pet continuously is 10 seconds. After
press the button again.
can press the Vibration/Shock Button
and deliverVibration/Shock to your
this, Vibration/Shock cannot be
delivered until You release and
my pet?
continuously deliver
Vibration/ Shock to
How long can I
•
Verify the Receiver Collar is on.
Warranty and repair information
1-Year Limited Lifetime Warranty
The original purchaser for this unit is provided with 1-YEAR
WARRANTY.
The warranty begins from the date of purchase. For the first
year, coverage is for both Parts and Labor on warranty repair
services.
Accessories such as chargers, splitter cables, antennas, straps,
and batteries are covered for the first year only. After the first
year, the Limited Lifetime Warranty covers Parts only and does
not cover Labor Fees and Accessories. All shipping fees
incurred, the cost of Accessories after the first year, and Labor
fees associated with out of warranty repair work, are the
customer’s responsibility. Labor fees wil be variable depending
on the extent of the work required. The Limited Lifetime
Warranty expires 5 years after a model is discontinued from
production.
To Qualify for the Warranty
All products must provided a proof of purchase is required to
initiate repair work under warranty. We strongly recommend
keeping the original receipt. If a proof of purchase is not
available at the time of service, we will estimate the age of
unit by the serial number. Serial number estimates can differ
from the actual purchase date. A serial number estimate is
the only method of determining an apporoximate date of
purchase without a proof of purchase.
If the Indicator Light does not come on
when any button is pressed on the
Transmitter, ensure that the batteries
are fully charged.
•
The Receiver
Collar is not
responding to
the Remote
Transmitter.
Remote Transmitter & the Receiver Collar”.
If the first two solutions did not resolve
your problem, see “How to pair the
•
either the Remote Transmitter or
Receiver Collar.

24 25
replace defective units or provide refunds for products purcha
sed from us after 30 days from the date of purchase.
Issues of replacement and refunds on units purchased less
than 30 days from an authorized dealer must be addressed
to the dealer directly. If the products purchased from an
authorized dealer are after 30 days from the date of purchase,
please send the units to us for service and repair.We DO NOT
cover the cost of repairs and replacements due to misuse by
the owner or dog, improper maintenance, and/or lost units.
Any water damage on the Water Resistant Transmitters and
the Water Resistant Receivers of our product series will not
be covered. All replacement costs for either the transmitter
or receiver will be the owner’s responsibility.
The warranty is void if the unit has been altered or an
unauthorized person has damaged the unit while attempting
repair work.
Battery replacement by the customer during the first year of
the Limited Lifetime Warranty is not recommended. If the
customer chooses to replace the batteries, any damage to
the unit during the change-out by the owner will void the
warranty.We reserve the right to retain and discard any parts
or accessories that have been found damaged upon
replacement and repair.
We DO NOT offer warranty for products that have been
bought secondhand or as a resold product.We DO NOT
Not Covered Under Warranty
Procedure for Repair Work
If the unit is malfunctioning, please refer to the “Troubleshooting
Guide” in the Operating and Training Guide before sending it
back for Service.
The cost of shipping products under warranty back is the
customer’s responsibility. We are not responsible for units
damaged or lost in transition. We are not responsible for loss
of training time or inconvenience while the unit is in for repair
work. We do not provide loaner units or any form of
compensation during the repair period.
A copy of the sales receipt showing the purchase date may
be required before warranty work is initiated.Please include
a brief explanation outlining the problem and include your
name, address, city/state/zip code, daytime phone number,
evening phone number, and email address.
Compliance
FCC - USA
This device complies with part 15 of the FCC Rules.
Operation
is subject to the following two conditions: (1) This device
may
not cause harmful interference, and (2) this device must
accept
any interference received, including interference that may
cause undesired operation.
expressly approved by Patpet Technology Co., Ltd may
CAUTION: Modification or changes to this equipment
not
void the user’s authority to operate the equipment.

(in) (in) (in)
Reference Size for Different Dogs
Chihuahua,
YorkshireTerrier
7.8-8.6 9.8-11.8 7.5
Chihuahua,
YorkshireTerrier
Poodle,Pomeranian
7.8-9.5 11.4-14.2 9
Maltese Dog,
Shih Tzu
9-11 13.7-16.5 11
10.6-12.2 16.2-18.5 12.2
Schnauzer,English
Cocker Spaniel
11.8-13.4 18.1-20.8 13.8
13-14.5 20.5-23.2 15.7
17-18.9 30-33 23.6
18.5-20.5 34.6-38.2 25.6
Golden Retriever,
Old English
Sheepdog
21.6-24.4 36.2-39.3 27.5
Large Dog(Body height above 24 inch, Weight above 88 lbs)
Medium Dog(Height 16-24 inch, Weight 24.2-66 lbs)
Small Dog(Height 10-16 inch, Weight 8.8-22 lbs)
Mini Dog(Height under 10 inch, Weight under 8.8 lbs)
26 27
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
TV technician for help.
• Consult customer care, the dealer, or an experienced radio/
can radiate radio frequency energy and, if not installed and
with the limits for a Class B digital device, pursuant to part 15
guarantee that interference will not occur in a specific
installation. If interference does occur to radio or television
interference by one or more of the following measures:
off and on, the user is encouraged to try to correct the
reasonable protection against harmful interference in a
residential installation. This equipment generates,uses, and
NOTE: This equipment has been tested and found to comply
used in accordance with the instructions, may cause harmful
reception, which can be determined by turning the equipment
interference to radio communications. However, there is no
of the FCC Rules. These limits are designed to provide
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.

Find more about Patpet
Email: [e-mail]
[e-mail]
Web : www.patpet.com
®
