MACHINE SCREWS:
USE #7 OR 13/64" [5.1] DRILL AND 1/4-20 TAP
WOOD DOOR/FRAME SCREWS:
USE 5/32" [4.0] DRILL
SEX NUTS:
USE 3/8" [9.5] DRILL
FOLD BACK
TO 120° MAX
TO 180° MAX
FOLD AT HINGE/PIVOT
CENTERLINE FOR THE
REQUIRED OPENING ANGLE .
BRACKET
(LH DOOR)
FOLD HERE (LH)
BRACKET
(RH DOOR)
FOLD HERE (RH)
THIS SIDE UP
FOR LH DOOR
THIS SIDE UP
FOR RH DOOR
STOP
FOLD HERE (LH)
STOP
STOP
STOP
FOLD HERE (RH)
FOLD HERE, POSITION ON DOOR
FOLD BACK
HINGE/PIVOT
ALIGN WITH
CENTERLINE
HINGE/PIVOT
ALIGN WITH
CENTERLINE
CLOSER BODY (RIGHT HAND DOOR)
CLOSER BODY (LEFT HAND DOOR)
HINGE C
L
3 3/16" [81.0]
B
3/4" [19.1]
BOTTOM OF STOP
11 1/8" [282.6]
SWEEP/ LATCH VALVES
THIS END OF CLOSER BODY
A
AND ALIGN WITH BOTTOM OF STOP
FOLD HERE, POSITION ON DOOR
AND ALIGN WITH BOTTOM OF STOP
OPENING
TO 120°
TO 180°
DIM A
6-1/8" [155.6]
2-9/16" [65.1]
DIM B
9-1/8" [231.8]
5-9/16" [141.3]
FOLD HERE (LH)
FOLD HERE (RH)
2" [50.8]
3/8" [9.5]
UNDERSIDE OF
SOFFIT / STOP
UNDERSIDE OF
SOFFIT / STOP
PDQ Manufacturing
2230 Embassy Dr.
Lancaster, PA 17603
833-273-7832
833-2 PDQTECH
www.pdqlocks.com
REV. 2 09-06-19
INSTRUCTION: 519353
5100 DOOR CLOSER INSTRUCTION SHEET
PARALLEL ARM INSTALLATION - PUSH SIDE - NON-HOLD OPEN AND HOLD OPEN APPLICATIONS
DOOR WIDTH APPROX.
SIZE INTERIOR EXTERIOR #360° TURNS
1 28" [711.2] N/A -5 (CCW)
2 32" [812.8] 28" [711.2] -3 (CCW)
3 36" [914.4] 32" [812.8] 0 (PRESET)
4 42" [1066.8] 36" [914.4] +5 (CW)
5 48" [1219.2] 42" [1066.8] +9 (CW)
6 54" [1473.2] 48" [1219.2] +12 (CW)
SWEEP SPEED
CONTROL
DELAYED
ACTION
BACKCHECK
LATCH
SPEED
CONTROL
COVER
INSTALL 5100 COVER:
1. Align cover with closer spindle.
Slide insert into unused cutout.
2. Slide cover over closer until
flush with door face.
3. Secure with
screw
provided.
LH RH
LH
RH
NUT DOWN
NUT UP
ARM
ARM
OPTIONAL HOLD OPEN ARM:
Important: Do not use arm as limiting
stop, separate dead stop is required.
Friction HO arm is not recommended
for doors frequently operated in/out
of hold open
1. Install hold-open foot/nut.
Left Hand (LH) door = Nut points down.
Right Hand (RH) door = Nut points up.
2. Loosen HO nut.
3. Open door several degrees before HO position.
4. Tighten nut.
PREPARE DOOR AND FRAME:
1. Determine maximum opening angle.
2. Determine door hand (LH or RH).
3. Align & attach
full size template
(see reverse side).
4. Mark door & frame
with center punch.
5. Remove template before
machining door & frame.
5100 DOOR CLOSER INSTRUCTION SHEET
PARALLEL ARM INSTALLATION - PUSH SIDE - NON-HOLD OPEN AND HOLD OPEN APPLICATIONS
INSTRUCTION: 519353
REV. 2 09-06-19
ADJUST SPRING POWER:
1. Use 4 mm hex key provided to adjust to size on chart.
Clockwise (CW) turns increase spring power (+).
Counter-clockwise (CCW) turns decrease spring power (-).
CW
CCW
(-) (+)
SPRING
POWER/SIZE
ADJUSTING NUT
HEX
KEY
6
1. Confirm this sheet is correct for your product and application.
2. Read the complete instruction sheet before starting installation.
3. Incorrectly installed or adjusted door closers can cause
personal injury or property damage.
4. To ensure safe operation, closers should be examined
and serviced regularly.
TOOLS REQUIRED:
1. Power drill
2. 10mm box/combo wrench
3. Phillips screw driver
4. #7 or 13/64" drill bit and
1/4-20 tap (machine screws)
5. Tap handle
6. 5/32" drill bit (wood screws)
7. 3/8" drill bit (sex nuts)
8. Center punch
1. See reverse side of this sheet to machine door & frame.
2. Dimensions based on 4-1/2" x 4-1/2" full mortise butt hinges
with 5/8" stop and 1/8" door gap.
3. Confirm door & frame are properly reinforced.
4. Sex nuts required for un-reinforced or composite fire doors.
5. Do not install closer on the exterior (weather) side of building.
1
2
3
4
5
SLOWER
FASTER
INCREASE
DECREASE
1. Use hex key provided.
2. Adjust SWEEP (closing max.°- 10°).
3. Adjust LATCH (closing 10°- 0°).
4. Adjust BACKCHECK resistance (opening 70°- max.°).
DO NOT COMPLETELY CLOSE VALVE
5. Adjust (optional) DELAYED ACTION (closing max.°- 70°);
Provides additional hesitation for access (ADA/BF) through door.
CONTROL ADJUSTMENTS:
Closing time of 3-7 seconds is typical.
More time may be needed for ADA/BF access.
Clockwise (CW) = SLOWER.
Counter-clockwise (CCW) = FASTER.
DO NOT REMOVE VALVES
CLOSING CYCLE
Y
A
L
E
D
E
E
W
S
P
H
C
T
A
L
MAX.°
K
C
A
B
C
E
H
C
K
N
E
P
O
I
N
G
OPENING CYCLE
MAX.°
7
8
9
PDQ Manufacturing
2230 Embassy Dr.
Lancaster, PA 17603
833-273-7832
833-2 PDQTECH
www.pdqlocks.com
INSTALL CLOSER AND ARM:
1. Attach closer body to door.
Spring adjustment nut points toward hinges.
2. Attach PA bracket to bottom of frame soffit.
PARALLEL ARM INSTALLATION - PUSH SIDE - NON-HOLD OPEN AND HOLD OPEN APPLICATIONS
5301/5501 DOOR CLOSER MODELS INSTRUCTION SHEET TEMPLATE: 539353,
REV. 0 01-18-17
BRACKET
(LH DOOR)
BRACKET
(RH DOOR)
THIS SIDE UP
FOR LH DOOR
THIS SIDE UP
FOR RH DOOR
CLOSER BODY (LEFT HAND DOOR)
CLOSER BODY (RIGHT HAND DOOR)
RH DOOR SHOWN
CLOSER
BODY
PA
BRACKET
ARM SCREW OR BOLT
45°
R
L
S
SPINDLE
MAIN ARM
MAIN
ARM
7. Open door slightly and slide
connecting arm into
adjustment arm.
8. Close door.
9. Rotate main arm until it is
approximately parallel to door.
10. Tighten arm screw or bolt.
3. Rotate closer spindle 45°
towards hinge / pivot.
4. Install main arm parallel to door
face, pointing away from hinge or pivot.
5. Secure main arm to closer spindle.
6. Remove foot from connecting arm
and install arm onto PA bracket.
