PDQ GR2 User manual

SF INSTALLATION INSTRUCTION
GR2 CYLINDRICAL LOCK
Phone: 833-2-PDQTEC | www.pdqlocks.com
2. PREPARE AND INSTALL
LATCH
 Adjust latch to desired backset using
included pick.
Options are 2-3/8" or 2-3/4".
 Latch faceplate is 1". For doors with
1-1/8" prep, use included filler on back of
latch.
 Install latch into front of door with bevel
pointing toward door frame
 Secure using two combo screws
SF10300 Rev0 – 7/15/20
1. PREPARE DOOR
 Full machining templates can be found
on website: www.pdqlocks.com
 Minimum stile width = backset + 1-½”
3. INSTALL LOCK
 Lock is preset from the factory for 1-3/4”
thick door. To adjust, spin threaded rose
until chassis is centered in door.
 Install lock chassis into thru hole in door
making sure to properly engage ears of
latch into lock chassis.
 Install rose support plate and secure with
(2) screws.
ENSURE
PROPER
MESH
ROSE
SUPPORT
PLATE
1-1/8" FILLER
CONFIGURE
FACEPLATE
PICK
ADJUST
BACKSET
1-3/8" to 1-3/4"
DOOR THICKNESS
2-1/4"
1"
HOLE
1" or 1-1/8"
FACEPLATE
WIDTH
2-3/8" or 2-3/4"
BACKSET
2-1/8"
HOLE
INSTALL
LATCH

SF INSTALLATION INSTRUCTION
GR2 CYLINDRICAL LOCK
4. INSTALL STRIKE
Install strike onto frame using provided
combo screws.
4. INSTALL ROSE AND LEVER
 Install rose – ensure indents on side of
rose align with slots in rose support.
 Install lever by pushing on to spindle until
clip engages with lever.
 Verify proper operation of lock.
SF10300 Rev0 – 7/15/20
RE-HANDING INSTRUCTION
For Memphis Lever Only – 126/176 Functions
Locks with handed levers are shipped RH
 Swap inside and outside levers.
 Use included pick to depress lever clip
through hole in front of lever to remove.
LH/LHR RH/RHR
OUTSIDE TRIM
