PDQ MRS User manual

MRS INSTALLATION INSTRUCTIONS
BLE ONLY MORTISE LOCK
Rev0 – 5-26-23
For Mechanical Concerns:
Phone: [phone]
www.pdqlocks.com
For Mechanical Concerns:
Phone: [phone]
www.pdqlocks.com
1.CHECKHANDINGOFLOCKBODY
• If handing of lock body is not correct for opening, consult factory
for handing instruction.
LH/LHR RH/RHR
2. DOOR PREPARATION
• Prepare the door for the mortise lock.
• Install the mortise case while feeding chassis wire into
hole on inside of door.
• Gently pull wire through hole as chassis is inserted
• Secure using two (2) combo screws supplied in the
hardware kit, W51411
3. JAMB PREPARATION
• Prepare the jamb for the mortise lock strike.
• Install Dead Latch Plate behind strike with slider toward bottom for
dead latch.
• Install the strike and secure with two (2) combo screws supplied in
the strike screw pack.
4. LEVER ATTACHMENT
• Assembly Outside Lever - If outside scalp was removed, install scalp.
Assemble rose as shown using the supplied hex key to tighten the socket
head cap screw.
Orlando/Memphis Levers & Ball Knob - Skip the following step. Do not install
inside lever and discard one (1) socket head cap screw. Refer to step 6.
• Assembly Inside Lever – Remove inside scalp. Assemble the inside rose as
shown using the supplied hex key to tighten the socket head cap screw.
Dead Latch
Slider
Dead Latch
Slider
Inside
Outside

MRS – MORTISE LOCK
Rev0 – 5-26-23
5. INSTALL DRIVE SPINDLES / OUTSIDE
TRIM
Drive Spindles:
• Install drive spindles and springs on both sides in orientation shown.
Outside Trim
• Install outside trim to door while aligning lever with drive spindle.
• Confirm spindle engagement in lock by rotating the lever down,
retracting the latch.
INCORRECT CORRECT
SPINDLE ORIENTATION
INCORRECT CORRECT
SPINDLE ORIENTATION
6. INSTALL INSIDE TRIM / ROSE
• Install the inside rose assembly to the inside of the door. Align
the spindle with the lever.
• Secure inside rose assembly with 1-1/2" long flat head
machine screws, supplied in the hardware kit, W51411 -
Confirm the spindle engagement.
• Install the rose scalp by aligning the dimples with the slots in
the rose plate. Secure by rotating clockwise until tight.
FOR ORLANDO/MEMPHIS LEVERS & BALL KNOB
• Slide lever onto spindle. Install set screw in bottom of lever.
Tighten from underside with supplied hex key.
7. CYLINDER, TURNPIECE AND ARMOR
PLATE INSTALLATION
• Assembly cylinder, cylinder spring and cylinder trim collar.
• Thread the cylinder into the lock body until the cylinder is flush or
slightly recessed in the cylinder trim collar.
• Secure the cylinder by tightening set screw through front of case,
on the side of cylinder, with the hex key provided in the hardware
kit, W51411.
For I/C housings, install the slotted set screw through the I/C bore
to secure the housing.
• Install the turnpiece and secure with two (2) truss head sheet metal
screws, supplied in the thumb turn screw pack.
• Install the armor plate with two (2) flat head machine screws.
Orlando
Memphis
Ball Knob
Only
Short Ends
Into Case
Short Ends
Into Case

MRS – MORTISE LOCK
Rev0 – 5-26-23
INSIDE
MOUNTING
PLATE
CHASSIS
WIRE
CHASSIS
WIRE SLOT
CHASSIS
WIRE SLOT
CHASSIS
WIRE
CHASSIS
WIRE SLOT
INSIDE
MOUNTING
PLATE
CHASSIS
WIRE
CHASSIS
WIRE SLOT
9.INSTALLBATTERYPACK
▪ Plug in battery wire to control board.
▪ Install battery pack over two studs on
mounting plate.
▪ Snap battery pack onto retainers on
mounting plate.
8.INSTALLINSIDEMOUNTING
PLATEASSEMBLY
• Install inside mounting plate assembly.
• Feed chassis wire through T slot in
mounting plate.
• Secure with (4) pan head wood/metal
screws.
• Make wire connection after reader is
secure. Push extra wire into door cavity.
BATTERY
PLUG
BATTERY
RETAINERS
BATTERY
PACK
BATTERY
PLUG
BATTERY
RETAINERS
BATTERY
PACK
11.INSTALLBATTERIES
ANDBATTERYCOVER
▪ Install batteries and battery cover with
(2) black pan head screws.
BATTERY
COVER
BATTERY
COVER
