PEERLESS PARAMOUNT PT640 and assembly Instruction Manual

ISSUED: 01-17-08 SHEET NO: 202-9570-3 07-10-08
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax [phone]
www.peerlessmounts.com
page 1 of 3
©2008PeerlessIndustries,Inc. Allrightsreserved.
Peerlessisaregisteredtrademark;ParamountandSorted-For-YouaretrademarksofPeerlessIndustries,Inc.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
Dimensions:
Weight:
6.71 lb (3.1 kg)
Shipping weight:
8.4 lb (3.9 kg)
Maximum Load Capacity:
150 lb (68 kg)
ShippingCartondimensions:
L= 20.25in(515mm)
W= 8.5 in (216 mm)
H= 3.88 in (99 mm)
Easily install mid-size screens with this simple, intuitive
mounting solution. Its three step installation combined
with its tool-less, one-touch tilt angle adjustment enables
flat panel screens to be installed and adjusted fast.
Features:
• Universalmount accommodatesscreens withmounting
patters up to 17.5" W x 12.94" H
• Adjustable15° forward tilt and -5° backward tilt for
findingthe optimal viewingangle.
• Easy-grip handle locks the screen position into place
• OptionalIncreLokTM feature offers fixed tilt anglesof -5°,
0°, 5°, 10°, 15°
• Easy-glide brackets easily hook onto wall plate for a
simple, safe and quick installation
• Horizontalscreen adjustment of up to6" (depending on
screenmodel) forperfect screen placement
• Mounts to wood studs, concrete, cinder block or metal
studs (metal stud accessory required)
• Comeswith Peerless'Sorted-for-YouTM fastenerpack
withall necessary screen attachment hardware
• UL listed
Accessories:
• ACC415 - Metal Stud Fastener Kit
• PS200- Paramount™A/V ComponentShelf
A R C H I T E C T S S P E C I F I CAT I O N S
MODEL:PT640
R
*NOTE: Most 42" and larger plasma screens may not
work wth this mount. Use Mount finder to confirm
compatibility.
TECHNICAL DATA SHEET - Universal Tilt
Wall Mount for 23" to 46"* LCD Flat Panel Screens
The Paramount® Universal Tilt Wall Mount shall be Peerless models and shall be located where indicated on the plans. It shall
feature adjustable 15° of forward tilt and -5° backward tilt. It shall be constructed of heavy gauge cold rolled steel and finished with scratch
resistant gloss black fused epoxy. Assembly and installation shall be done according to instructions provided by the manufacturer.

TECHNICAL DATA SHEET MODEL:PT640
page 2 of 3
ISSUED: 01-17-08 SHEET NO: 202-9570-3 07-10-08
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax [phone]
www.peerlessmounts.com ©2008PeerlessIndustries,Inc. Allrightsreserved.
Peerlessisaregisteredtrademark;ParamountandSorted-For-YouaretrademarksofPeerlessIndustries,Inc.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
All dimensions = inch (mm)
Side View
Top View
Front View
19.25
(489)
18.73
(476)
17.50
(446)
12.94
(329)
13.75
(349)
2.54
(65)

TECHNICAL DATA SHEET MODEL:PT640
page 3 of 3
ISSUED: 01-17-08 SHEET NO: 202-9570-3 07-10-08
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax [phone]
www.peerlessmounts.com ©2008PeerlessIndustries,Inc. Allrightsreserved.
Peerlessisaregisteredtrademark;ParamountandSorted-For-YouaretrademarksofPeerlessIndustries,Inc.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
All dimensions = inch (mm)
19.25
(489)
18.50
(470)
7.45
(189)
7.2
(183)
8
(203)
2
(51)
TYP.
1.5
(38)
3.5
(89)
11.75
(298)
5
(127)
1.1
(28)
2.46
(63)
Wall Plate Detail
Adapter Bracket Detail
2.75
(70)
4
(102)
