Pepperl+Fuchs UC500-L2-E7-V15 Operating instructions

Germany: [phone]Pepperl+Fuchs Group
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
USA: [phone] Singapore: [phone]
www.pepperl-fuchs.com [e-mail] [email protected].com
[e-mail]
1
Ultrasonic sensor UC500-L2-E7-V15
Release date: 2014-01-08 10:05 Date of issue: 2014-01-08 188197_eng.xml
Technical data
General specifications
Sensing range 35 ... 500 mm
Adjustment range 50 ... 500 mm
Unusable area 0 ... 35 mm
Standard target plate 100 mm x 100 mm
Transducer frequency approx. 380 kHz
Response delay ≤35 ms
Indicators/operating means
LED green Operating display
LED yellow 1 switching state switch output 1
LED yellow 2 switching state switch output 2
LED red error
Electrical specifications
Operating voltage UB10 ... 30 V DC , ripple 10 %SS
No-load supply current I0≤50 mA
Interface
Interface type Serial interface (programming adapter required)
9600 BPS, no parity, 8 data bits, 1 stop bit
Input/Output
Input/output type 1 synchronization connection, bidirectional
0 Level 0 ... 1 V
1 Level 4 V ... UB
Input impedance > 12 kΩ
Output rated operating current < 12 mA
Pulse length 0.5 ... 300 ms (level 1)
Pulse interval ≥14 ms (level 0)
Synchronization frequency
Common mode operation ≤70 Hz
Multiplex operation ≤90 Hz / n , n = number of sensors , n ≤10
(factory setting: n = 5 )
Output
Output type 2 switch outputs NPN, NO/NC, programmable
Rated operating current Ie200 mA , short-circuit/overload protected
Voltage drop Ud≤2 V
Repeat accuracy ≤0.1 % of full-scale value
Switching frequency f ≤14 Hz
Range hysteresis H programmable , preset to 1 mm
Temperature influence < 1.5 % of full-scale value
Ambient conditions
Ambient temperature -25 ... 70 °C (-13 ... 158 °F)
Storage temperature -40 ... 85 °C (-40 ... 185 °F)
Mechanical specifications
Protection degree IP67
Connection 5-pin V15 (M12 x 1) connector
Material
Housing PA-GF35
Transducer epoxy resin/hollow glass sphere mixture; polyurethane foam
Mass 115 g
Factory settings
Output 1 near switch point: 50 mm
far switch point: 500 mm
output function: Window operation mode
output behavior: NO contact
Output 2 near switch point: 100 mm
far switch point: 250 mm
output function: Window operation mode
output behavior: NO contact
Beam width wide
General information
Supplementary information Switch settings of the external programming adapter:
"output load": pull-up
"output logic": inv
Compliance with standards and
directives
Standard conformity
Standards EN 60947-5-2:2007
IEC 60947-5-2:2007
Approvals and certificates
UL approval cULus Listed, General Purpose
CSA approval cCSAus Listed, General Purpose
CCC approval CCC approval / marking not required for products rated
≤36 V
Model Number
UC500-L2-E7-V15
Single head system
Features
• Sensor head bidirectional and ro-
tatable
• Function indicators visible from all
directions
• Quick mounting bracket
• Selectable sound lobe width
• Programmable
Diagrams
0 200 400 600 800 1000
250
200
150
100
50
0
-50
-100
-150
-200
-250
X
Y
Characteristic response curve
Distance X [mm]
Distance Y [mm]
flat surface 100 mm x 100 mm
round bar, Ø 25 mm
wide sound lobe
narrow sound lobe

Ultrasonic sensor UC500-L2-E7-V15
2
Release date: 2014-01-08 10:05 Date of issue: 2014-01-08 188197_eng.xml
Germany: [phone]Pepperl+Fuchs Group
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
USA: [phone] Singapore: [phone]
www.pepperl-fuchs.com [e-mail] [email protected].com
[e-mail]
Dimensions
Electrical Connection
Pinout
LED yeLED gnLED ye
LED gn
3
7
M12 x 1
28
67
40
20
30
40
5.5
ø 5.546
60
T1T2
out 1 pwr/out 2
40
Switch output 1
Switch output 2
Synchronization
1
4
5
3
2
L+
L-
1
3
4
5
2
1 BN
2 WH
3 BU
4 BK
5 GY
Wire colors in accordance with EN 60947-5-2
(brown)
(white)
(blue)
(black)
(gray)

Ultrasonic sensor UC500-L2-E7-V15
3
Release date: 2014-01-08 10:05 Date of issue: 2014-01-08 188197_eng.xml
Germany: [phone]Pepperl+Fuchs Group
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
USA: [phone] Singapore: [phone]
www.pepperl-fuchs.com [e-mail] [email protected].com
[e-mail]
Description of Sensor Functions
Programming procedure
The sensor features two outputs with two programmable switch points, each (for a total of 4). Programming the switch points and the operating mode can be done in two
different ways:
- via the sensor’s programming buttons
- via the serial interface, which requires an external interface adapter
The procedure for programming via the sensor's programming buttons is described below. For programming using the serial interface, please refer to the software manual.
Switch points and operating modes of each output can be programmed independently without influencing each other.
Note:
- Programming is enabled for 5 minutes after power-on. After 5 minutes without programming activity the programming feature will be locked.
- During any programming step it is possible to leave the programming routine without changing the sensor settings by pressing the currently used programming button
for 10 s.
Programming the Switch Points
Notes:
- The description below leads you through programming output 1’s switch points. The procedure for output 2 is exactly the same with the only difference, being to use the
Programming Button T2.
- If the red LED flashes during the programming procedure, it indicates uncertain target detection. In this case, please correct the target alignment until the yellow LED
flashes. The new settings will only be stored in the sensor’s memory if the yellow LED flashes.
Programming the Near Switch Point
1. Place the target at the desired near switch point position
2. Press Programming Button T1 for 2 s (corresponding yellow LED flashes)
3. Press Programming Button T1 briefly (green LED flashes three times for confirmation). The sensor returns to normal operation.
Programming of the Far Switch Point
1. Place the target at the desired far switch point position
2. Press Programming Button T1 for 2 s (corresponding yellow LED flashes)
3. Press Programming Button T1 for 2 s (green LED flashes three times for confirmation). The sensor returns to normal operation.
Programming Modes of Operation
Note:
The description below leads you through programming of the modes of operation for output 1. The procedure for output 2 is exactly the same with the only difference,being to
use Programming Button T2.
The sensor provides a three step routine to program the modes of operation. In this routine you can program:
1. Output function
2. Output behavior
3. Beam width
Programming the modes is carried out sequentially. To toggle from one mode to the next, press the Programming button for 2 s.
Press Programming Button T1 for 5 s to enter the operating modes programming routine.
Programming the output function
1. The green LED flashes. The number of flashes indicates the current output function:
single flash: Switch point output function
double flash: Window output function
triple flash: Hysteresis output function.
2. Press Programming Button T1 briefly to toggle sequentially through these output functions and select the desired mode.
3. Press Programming Button T1 for 2 s to save and enter the programming routine for output behavior
Programming the output behavior
1. The yellow LED flashes. The number of flashes indicates the current output behavior:
single flash: Normally Open (NO)
double flash: Normally Closed (NC).
2. Press Programming Button T1 briefly to toggle sequentially through these output behaviors and select the desired mode.
3. Press Programming Button T1 for 2 s to save and enter the programming routine for beam width.
Programming the beam width
1. The red LED flashes. The number of flashes indicates the current beam width setting:
single flash: narrow
Accessories
PACTware 3.6
FDT-Framework
PACTware 4.X
FDT-Framework
Ultraschall-Sensoren DTM
DTM devices for communication with cube style and UMC... sensors
UC-PROG1
Programming adapter
V15-G-2M-PVC
Female cordset, M12, 5-pin, PVC cable
V15-W-2M-PUR
Female cordset, M12, 5-pin, PUR cable
Microsoft .NET

Ultrasonic sensor UC500-L2-E7-V15
4
Release date: 2014-01-08 10:05 Date of issue: 2014-01-08 188197_eng.xml
Germany: [phone]Pepperl+Fuchs Group
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
USA: [phone] Singapore: [phone]
www.pepperl-fuchs.com [e-mail] [email protected].com
[e-mail]
double flash: medium
triple flash: wide.
2. Press Programming Button T1 briefly to toggle sequentially through these beam shapes.
3. Press Programming Button T1 for 2 s to save and exit the operating modes programming routine.
Note:
Independently programming the beam width for each individual output is not possible. The last programmed beam width is valid for both outputs. It doesn’t matter which Pro-
gramming Button is used.
Reset Sensor to Factory Settings
The sensor has a feature to reset to factory settings
1. Disconnect the sensor from power supply
2. Press and hold one of the Programming Buttons T1 or T2
3. Connect Sensor to power supply (red and yellow LED flash simultaneously for 5 s then green and yellow LED flash simultaneously)
4. Release Programming Button
The sensor now operates with default factory settings.
Factory settings
See technical data.
Display
The sensor is provided with LEDs to indicate various conditions.
#
*) off if yellow LED out2 is on
Synchronization
This sensor features a synchronization input for suppressing ultrasonic mutual interference ("cross talk"). If this input is not connected, the sensor will operate freewheeling
using internally generated clock pulses. It can be synchronized by applying an external square wave or by means of appropriate programming via the serial interface. Each
falling edge of the synchronization pulse triggers transmission of a single ultrasonic pulse. If the synchronization signal remains low for ≥ 1 second, the sensor will revert to
normal operating mode. Normal operating mode can also be activated by opening the signal connection to the synchronization input.(See note below)
If the synchronization input goes to a high level for > 1 second, the sensor will switch to standby mode, indicated by the green LED. In this mode, the output(s) will remain in
the last valid output state. When using the external synchronization feature, please refer to the software description.
Note:
If the option for synchronization is not used, the synchronization input has to be connected to ground (0V) or the sensor has to be operated via a V1 cordset (4-pin).
The synchronization function cannot be activated during programming mode and vice versa.
The following synchronization modes are possible:
1. Several sensors (max. number see technical data) can be synchronized together by interconnecting their respective synchronization inputs. In this case, each sensor
alternately transmits ultrasonic pulses in a self multiplexing mode. No two sensors will transmit pulses at the same time. (See note below)
2. Several sensors (max. number see technical data) can be synchronized together by interconnecting their respective synchronization inputs. Due to programming via the
sensors interface one sensor acts as a master device, all the others as slave devices. (see description of the interface) In this master / slave mode the sensors are triggered
in parallel and are synchronized by a common synchronization pulse, provided by the master device.
3. Multiple sensors can be controlled by the same external synchronization signal. In this mode the sensors are triggered in parallel and are synchronized by a common
external synchronization pulse. All sensors must be parameterized for external synchronization by means of the sensor interface. See software description.
4. A separate synchronization pulse can be sent to each individual sensor. In this mode the sensors operate in external multiplex mode. (See note below). All sensors must
be parameterized for external synchronization by means of the sensor interface. See software description.
5. A high level (+UB) or a low level (-UB)on the synchronization input switches the sensor to standby mode if it is parameterized for external synchronization.
Note:
Sensor response times will increase proportionally to the number of sensors that are in the synchronization string. This is a result of the multiplexing of the ultrasonic transmit
and receive signal and the resulting increase in the measurement cycle time.
Note:
The sensors syncronization input delivers an output current in case of low level and burdens with its input impedance in case of high level. Please pay attention that the syn-
chronizing device needs to have that driver capability:
driver current against +UB≥n * high-level/input impedance (n = number of sensors to be synchronized)
driver current against 0V ≥n * output current (n = number of sensors to be synchronized).
Green LED Yellow LED out1 / out2 Red LED
During Normal operation
Proper operation
Interference (e.g. compressed air)
On*)
Off
Switching state
output 1 / output 2
remains in previous state
Off
On
During Switch Point Programming
Object detected
No object detected
Confirmation after Programming
Programming failed warning
Off
Off
Triple flashing
Off
Flashing
Off
Off
Off
Off
Flashing
Off
Triple flashing
During Sensor Mode Programming
Programming the output function
Programming the output behaviour
Programming the beam width
Flashing
Off
Off
Off
Flashing
Off
Off
Off
Flashing
