Pepperl+Fuchs LGM Series Reference guide

LGM Series
Measuring Automation
Light Grid
Brief Instructions

With regard to the supply of products, the current issue of the following docu-
ment is applicable: The General Terms of Delivery for Products and Services
of the lectrical Industry, published by the Central Association of the lectrical
Industry (Zentralverband lektrotechnik und lektroindustrie (ZV I) e.V.) in its
most recent version as well as the supplementary clause: " xpanded reserva-
tion of proprietorship"
Worldwide
Pepperl+Fuchs Group
Lilienthalstr. 200
68307 Mannheim
Germany
Phone: [phone] - 0
-mail: [email protected]-fuchs.com
North American Headquarters
Pepperl+Fuchs Inc.
1600 nterprise Parkway
Twinsburg, Ohio 44087
USA
Phone: [phone]
-mail: [e-mail]
Asia Headquarters
Pepperl+Fuchs Pte. Ltd.
P+F Building
18 Ayer Rajah Crescent
Singapore 139942
Phone: [phone]
-mail: [e-mail]
https://www.pepperl-fuchs.com

251720 2021-03
3
LGM Series
Contents
1 Introduction ..............................................................................
1.1 Purpose of These Brief Instructions..................................
1.2 Product documentation on the internet ............................
1.3 Intended Use........................................................................
2 Product Description.................................................................6
2.1 Indicators and Control elements ....................................... 6
2.2 Interfaces and Connections ............................................... 8
2.3 Scope of Delivery ................................................................ 9
3 Installation ..............................................................................10
3.1 Mounting ............................................................................ 10
3.2 Connecting the Sensor Units ........................................... 12
Commissioning the Light Grid..............................................16
5 Operation ................................................................................17
5.1 Operating the Light Grid Using the Programming
Interface ............................................................................. 17
5.2 Commissioning and Operating the Light Grid with
IO-Link ................................................................................ 22
5.2.1 Process Data ............................................................................23
5.2.2 Programmable Functions of the Light Grid................................24
6 Appendix.................................................................................28
6.1 Technical Data.................................................................... 28

251720 2021-03
4
LGM Series
Introduction
1 Introduction
1.1 Purpose of These Brief Instructions
These brief instructions contains basic instructions for operating the device. How-
ever, the manual takes priority over the brief instructions.
1.2 Product documentation on the internet
You can view all the relevant documentation and additional information on your
product at http://www.pepperl-fuchs.com. Simply enter the product name or
model number in the Product/Key word search box and click Search.
Select your product from the list of search results. Click on the information you
require in the product information list, e.g., Technical documents.
A list of all available documents is displayed.
1.3 Intended Use
The measuring LGM light grid consists of an emitter and receiver strip. Located
between the strips is the measuring range consisting of infrared light beams.
When an object enters the measurement field, one of several selectable measur-
ing methods sends out data on the interrupted beams via I/O-Link. The reading is
in mm.
Application areas
■Warehousing and material handling, packaging industry
Always operate the device as described in these instructions to ensure that the
device and connected systems function correctly. The protection of operating per-
sonnel and plant is guaranteed only if the device is operated in accordance with
its intended use.
The device and its input and output circuits must be operated from a power supply
that fulfills the requirements of P LV/S LV systems.
Only use recommended original accessories.
The operating company bears responsibility for observing locally applicable
safety regulations.
Caution!
Not a safety component
The light grid is not a certified safety light grid in accordance with N 61496. It is
also not a safety component under the terms of the U Machinery
Directive 2006/42/ C. The light grid must therefore not be used for the purpose of
preventing risk to individuals or parts of the body.

251720 2021-03
5
LGM Series
Introduction
Installation and commissioning of all devices may be performed only by trained
and qualified personnel.
It is dangerous for the user to make changes and/or repairs. Additionally, doing so
voids the warranty and excludes the manufacturer from any liability. In the event of
any serious errors, stop using the device. Secure the device against unintended
operation. To have the device repaired, return it to your local Pepperl+Fuchs rep-
resentative or your sales center.
Note
Repairs
If the light grid requires repair, please send the emitter and receiver together to
Pepperl+Fuchs.

251720 2021-03
6
LGM Series
Product Description
2 Product Description
2.1 Indicators and Control elements
Emitter unit
Figure 2.1 Function indicator on the emitter unit
Operation indicator and status indicator on the emitter
Receiver unit
Figure 2.2 Function indicator on the receiver unit
Operation indicator: indicates power-on or power-save mode
Status indicator: indicates transmission power, fault state, or active test mode
Function Diagnostic description
Operation indicator (green L D)
Green L D on Power-on
Green L D off
Yellow L D flashing
Power-save mode
Status indicator (yellow L D)
Yellow L D off Power of emitter is low
Yellow L D is on Power of emitter is high
Yellow L D flashing Fault state
Yellow L D changes state Test mode is active
Operation indicator: indicates power-on, power-save mode, IO-Link mode ak-
tive, or fault state
Status indicator: indicates detection field status, functional reserve, or fault
state
23
2
3
23
Q
H1 H2 H3 F2
2
3

251720 2021-03
7
LGM Series
Product Description
Operation indicator and status indicator on the receiver
The control panel on the receiver unit consists of 12 indicator elements. The two
outer two symbols act as control elements (touch buttons). The receiver unit can
be parametrized via menu selection on the control panel (see chapter 5.1).
Figure 2.3 Controls on the Receiver unit
Function Diagnostic Description
Operation indicator (green L D)
Green L D permanently on Power-on
Green L D permanently off Power-save mode
Green L D flashes with short interrup-
tion
Active IO-Link mode, receiver's operat-
ing panel locked
Green L D flashes with 4 Hz Fault status: short circuit at the outputs
Status indicator (yellow L D)
Yellow L D permanently on Detection field interrupted
Yellow L D permanently off Detection field vacant
Yellow L D flashes (approx. 4 Hz) Insufficient functional reserve
Yellow L D flashes (approx. 8 Hz) Fault state: fault during signal measure-
ment
1
12
Q
H1
H2
H3 F2

251720 2021-03
8
LGM Series
Product Description
Control elements
For a detailed description of the function status indicators, please see see chapter
5.1.
2.2 Interfaces and Connections
Use two M12 plugs for the electrical connection. The emitter unit has a cable with
a 4-pin plug and the receiver unit a cable with an 8-pin plug.
Emitter unit
Figure 2.4 mitter unit connection layout
Receiver unit
Number Symbol Parameter Description
Menu button Function selection
OK button Function confirmation
1
12
124 V DC
2Range (In)
30 V DC
Test (In)
1
3
4
2

251720 2021-03
9
LGM Series
Product Description
Figure 2.5 Receiver unit connection layout
IO-Link communication is established via the C/Q (Pin 4) connection.
2.3 Scope of Delivery
The scope of delivery includes:
■mitter unit and receiver unit
■Quick start guide
■Cable lug and housing screw as spare part
Brackets and cables are not included in the scope of delivery. See the appendix or
visit http://www.pepperl-fuchs.com for a selection of compatible mounting brack-
ets and recommended cables.
1+ UB
2SC (Stability Control, Out)
30 V DC
C/Q (IO-Link / Out)
5Q (Out)
6not connected
7not connected
8Teach-In (In)
1
4
6
7
8
53
2

251720 2021-03
10
LGM Series
Installation
3 Installation
3.1 Mounting
Make sure the detection field is free from obstacles. The first and last beams
within the detection field are used for optical synchronization of emitter and
receiver units. If both beams are blocked, synchronization is lost and the mea-
surement is inhibited. The system is preconfigured for operation wth cable outlet
upwards. For installation with cable outlet downwards, the receiver unit can be
configured via IO-Link for the zero-point reference on the cable side.
Figure 3.1 Light Grid Dimension Drawing
To mount the slim panels, use customized bore holes (d = 4.5 mm for M4 screws)
or a rear, continuous groove (for flat M6 nuts in accordance with ISO 4035).
Various brackets are available for mounting the light grid .
Mounting Using the Rear Groove
There is a continuous groove located on the rear of the strip on the light grid. Stan-
dard flat M6 nuts (in accordance with DIN 4035) fit into this groove. You can mount
the light grid using these inserted nuts.
Mounting Using Customized Bore Holes
You can mount the light grid using user-defined holes. The maximum screw size is
M4. Make sure to follow the instructions when positioning the hole. Improper han-
dling can damage internal electronics.
Q
H1
Fix
H2 H3 Fn
Emitter unit
Detection field + 159
n Beam 1. Beam
Receiver unit
Detection field
5
21.2 137.8
20
30.5

251720 2021-03
11
LGM Series
Installation
Preparation
1. Mark the position of the holes. Focus on the lateral continuous line on the light grid
.
2. Mark the position of the holes.
3. Using a 4.5 diameter drill, drill right through the housing.
. Deburr the hole.
5. Repeat the first steps to drill all the holes.
6. Make sure that the aluminum chippings do not scratch the optical surface.
Secure the light grid in its final position with the holes you made.
Figure 3.2 Position the center point of the installation holes.
Figure 3.3 Installation holes
Installation
1. Align the emitter and receiver units so they are parallel to one another and at the
same height.
2. The units must be aligned with an accuracy of approximately ± 5°.
3. During installation, ensure that the two units are the same way up. (Both units with
the cable outlet either up or down).
. Do not exceed the maximum range.
9

251720 2021-03
12
LGM Series
Installation
Figure 3.4 Maximum offset between emitter and receiver
3.2 Connecting the Sensor Units
Connecting the Emitter unit
Connect the emitter unit as described in the section Interfaces and Connections
(see chapter 2.2). Insulate unused wires. See circuit example on the following
page.
Offset Y [mm]
Distance X [m]
Characteristic response curve
800
700
600
500
400
300
200
100
0
0 1 2 3 4 5 6 7 8
x
y
Caution!
lectrical connection
Wiring work that requires the opening and closing of electrical connections must
always be performed with the power disconnected.
Use a Class 2 power supply to supply the power (certified according to UL 1310).
Connection Description
Range input
Pin 2
The emitter power can be adjusted for specific sens-
ing ranges according to application requirements.
Reducing emitter power is useful for avoiding optical
interference with other sensors.
Input open Max. 1.6 m
+U
B
Max. 6 m
0 V Max. 6 m

251720 2021-03
13
LGM Series
Installation
Connecting the Receiver unit
Connect the receiver unit as described in the section Interfaces and Connections
(see chapter 2.2). All outputs are short-circuit proof. Insulate unused wires. See
circuit example shown below.
Test input
Pin 4
The emitter unit features a test input with two func-
tionalities:
•test mode
•power safe mode
These functionalities can be activated by connection
of the test input to either +U
B
or 0 V. The functions
are inactive if the test pin is left open (high imped-
ance).
Test mode: Activate the test input for
max. 1.2 seconds. The
emitter beams are turned
off. The receiver unit will
detect this the same way
as a beam interruption by
an object.
Power save mode: Test input is active for
more than 1.2 seconds:
The emitter unit enters
the power save mode.
The receiver unit will
change to power save
mode if optically synchro-
nized with the emitter.
The measurement is
inhibited in this mode and
power consumption is
reduced to minimum. Test
input set to to inactive:
mitter and receiver units
resume to normal opera-
tion. Note: The receiver
unit as well resumes to
normal operation if the
optical synchronization is
lost.
Connection Description

251720 2021-03
14
LGM Series
Installation
Circuit Example
The L Ds on the outputs are optional.
Connection Description
Stability control (SC) output
Pin 2
The SC output gets active with a delay
of 5 seconds, if the receiver unit detects
signals below stability control thresh-
old (functional reserve). The status indi-
cator flashes at 4 Hz. The SC output
returns immediately to normal opera-
tion (inactive state) with receiver sig-
nals above the stability control
threshold.
Switching output (C/Q)
Pin 4
This connection has 2 functions. (By
default, the switching output is active
once the device is powered on; SIO
mode)
Switching output: This signal output
is active (active with dark ON, inactive
with light ON) if an object is detected or
identified according to parameter set-
tings. This means that the output is
always active when status indicator 4
(Q) is on.
IO-Link interface: When the light grid
is running in IO-Link mode, it communi-
cates with the master via this connec-
tion.
Remote control (Teach-in input)
Pin 8
The receiver unit features a Teach-in
input. This input can be used to
remotely stimulate the functions of the
two control buttons:
•Menu button (input connected to +U
B
)
•OK button (input connected to 0 V)
(see circuit example below)
Note: The Teach-in input functionality
can be inhibited by connecting this ter-
minal permanently to +U
B
.

251720 2021-03
15
LGM Series
Installation
Figure 3.5 Circuit example LGM
24 V
0 V
Test
Emitter unit Receiver
unit 24 V DC
Stability Control
0 V
C/Q
Q
n.c.
n.c.
Teach-In
24 V
Range
0 V
Test
Test
RangeRange
Menu buttonOK button
1
2
3
4
5
6
7
8
1
2
3
4

251720 2021-03
16
LGM Series
Commissioning the Light Grid
Commissioning the Light Grid
1. Check that the power supply and signal lines to the light grid are connected
correctly. When using an IO-Link Master, make sure that the C/Q communication
line is connected to the corresponding port on the IO-Link master.
2. Check that the light grid is in the correct position and orientation.
3. Turn on the power supply. The green operation indicators on emitter and receiver
units are on.
. If the emitter and receiver units are aligned, the status indicator is off. The status
indicator lights up when the device is misaligned or an object is detected.
The two units are perfectly aligned and can now be configured .
For commissioning and operation of the light grid in IO-Link mode, please refer
see chapter 5.2.

251720 2021-03
17
LGM Series
Operation
5 Operation
5.1 Operating the Light Grid Using the Programming
Interface
The Receiver Strip Can Be Manually Configured and
Parameterized Using the Programming Interface
■Standard operation in accordance with configuration and parameterized
values
■Functions of first parameterization level
■Functions of second parameterization level
Displays and Operating Elements
Figure 5.1 Function indicators on the receiver strip
Number Symbol Function Description
Menu key Press the Menu key once to switch the
device to parameterization mode.
Operating indi-
cator
Indicator for operating state and power
save mode
Status indica-
tor
Indicator for detection field status, oper-
ating reserve status, and fault status
Q display Display for object identification status
and, in general, for detection field sta-
tus
7
6
5
4
2
1
11
10
9
8
12
3
Q
H1
H2
H3 F2
1
2
3
4
Q

251720 2021-03
18
LGM Series
Operation
When you select a function, the current status of this function is displayed within
parameterization mode. The indicator flashes at approx. 1 Hz according to the fol-
lowing pattern:
The following table shows the indicators and functions of the programming inter-
face in parameterization mode.
OK key Press OK once to display the parame-
terization status. (First-level functions)
The other indicators have no function in standard operation
Table 5.1 Display and function in standard operation
Display mode Display pattern
Active Long on, short off
Inactive Long off, short on
Number Symbol Function Description
12
Number
Sym-
bol Parameter
Display
mode Description
Menu key Repeatedly press the Menu key to
select the required parameterization
function
OK key Press OK to modify a value or to initi-
ate the selected function
Q display Object identification function selected
Inactive Inactive Reset parameters for object identifi-
cation
Active Active Teach-in parameters for object identi-
fication
Object identifica-
tion type
Object identification type function
selected
Stationary Inactive Identification of stationary objects
selected
Moving Active Identification of moving objects
selected
Beam mode Beam mode function selected
Single-beam scan-
ning
Inactive Simple resolution
Corresponds to the beam spacing
Three-way beam
crossover
Active Double resolution
1
12
4
Q
8
9

251720 2021-03
19
LGM Series
Operation
Tolerance field Tolerance field function selected
(applies to object field, gaps, and
suppression area)
Off Inactive No tolerance applied
Simple resolution Active Tolerance corresponds to resolution
set
2. Level
(Skip/Select)
Second-level functions selected
In the second level, the F2 indicator
lights up in combination with the
selected function
Suppression area Suppression areas function selected
Inactive Inactive Suppression areas are deactivated
Active Active Suppression area corresponds to
taught-in values
Object identifica-
tion mode
Object identification function selected
Object detection Inactive Object identification in accordance
with taught-in parameters
Gap detection Active Gap detection in accordance with
taught-in parameters
Switching signal
polarity
Switching signal polarity function
selected
Not inverted – dark-
on
Inactive Output Q is activated if an object/gap
is detected
Inverted – light-on Active Output Q is activated if no object/gap
is detected
Default settings Default settings function selected
Skip Inactive The function is not executed
Restore Active The default settings are restored
Number
Sym-
bol Parameter
Display
mode Description
10
11
F2
11
4
F2
Q
11
5
F2
H1
11
6
F2
H2
11
7
F2
H3

251720 2021-03
20
LGM Series
Operation
Signal tracking Signal tracking function selected
In non-stable ambient conditions,
e.g., soiling and temperature
changes, signal tracking ensures that
the response threshold remains con-
stant . Reflective objects that are
occasionally present along the detec-
tion field can distort signal tracking
and cause switching faults. In the
worst-case scenario, permanent
detection is signaled even though
there is no object in the monitoring
field. In this case, the function must
be disabled. Signal tracking is inac-
tive in the factory setting.
Parameterization via IO-Link:
Parameterization via IO-Link allows
the response threshold and signal
tracking to be defined independently
of each other.
=> Without tracking: The response
threshold can be selected in 10 %
increments between 0 = minimum
threshold, 1 = 10 %, and 9 = 90 %.
•0 = minimum threshold, no tracking,
maximum gain, default value
•1 = 10 % of value of response thresh-
old, no tracking
•2 = 20 % of value of response thresh-
old, no tracking
•9 = 90 % of value of response thresh-
old, no tracking
=> With tracking: The response
threshovalue for response threshold
that can be freely selected, with track-
ingld can be freely selected between
10 % ... 90 %. This allows customized
configuration between fine resolution
(high threshold) and high immunity to
reflective objects (low threshold).
•10 % …90 % = value for response
threshold that can be freely selected,
with tracking
Inactive Inactive Pressing the OK button again dis-
ables signal tracking. When signal
tracking is disabled, the lowest
switching threshold is configured. The
optical resolution is increased by
≤4 mm.
Active Active Pressing the OK button enables sig-
nal tracking. When signal tracking is
enabled, the specified resolution is
reached. The value of the switching
threshold is set to ≥60 %.
Number
Sym-
bol Parameter
Display
mode Description
11
8
F2
