Assembly and Operation Manual (hereinafter - the Manual) for the TTR-07.1
electromechanical tripod turnstile with automatic anti-panic folding arms (hereinafter
- the turnstile) contains data that is necessary for the most full use of operating advantages
of the turnstile as well as chapters on packaging, installation and maintenance.
Only qualified personnel, following the instructions of this Manual, must carry out
installation and maintenance.
Abbreviations:
ACS — access control system;
RC panel – remote control panel;
WRC – wireless remote control;
CLB – control logic board.
1 APPLICATION
The TTR-07.1 electromechanical tripod turnstile with automatic anti-panic folding arms
(hereinafter - the turnstile) is designed for managing pedestrian flows at entrance points of
industrial facilities, banks, administrative buildings, retail outlets, railway terminals, airports
providing free passageway in emergency situations.
To ensure fast and convenient passage it is recommended to install one turnstile per
500 people working the same shift, and on the basis of maximum working load
30 persons/min. See Chapter 3for information on the throughput capacity of the turnstile.
2 OPERATION CONDITIONS
The turnstile with regard to resistance to environmental exposure complies with
GOST15150-69, category NF4 (operation in premises with climate control).
Operation of the turnstile is allowed at ambient air temperature from +1°Сto +40°Сand at
relative air humidity of up to 60% at + 20°С.
3

Assembly and Operation Manual
3 TECHNICAL SPECIFICATIONS
Operating voltage ........................................................................................... 12±1.2 V DC
Power consumption ........................................................................................... max. 72 W
Consumption current ......................................................................................... max. 6.0 A
Throughput rate in the single passage mode ............................................. 30 persons/min
Throughput rate in the free passage mode ................................................. 60 persons/min
Passage width ....................................................................................................... 530 mm
Arm rotation force ............................................................................................... max. 3 kgf
RC panel cable length1....................................................................................... min. 6.6 m
Ingress Protection Rating ................................................................ IP41 under EN 60529
Electric shock protection class ..................................................................
III (IEC 61140)
Mean time to failure .................................................................... min. 4,000,000 passages
Mean lifetime .......................................................................................................... 8 years
Turnstile overall dimensions (L×W×H) ................................................ 798×752×1054 mm
Turnstile net weight ........................................................................................... max. 38 kg
Figure 1. TTR-07.1 tripod turnstile. Overall dimensions
1MPS 8×0.12 mm. MAX allowed cable length – 40m. Using of cables more than 40 m long may
result in interferences in a control line.
4

TTR-07.1 Electromechanical Tripod Turnstile
4 DELIVERY SET
4.1 Standard delivery set
Basic equipment:
Turnstile housing .............................................................................................................. 1
Hub with barrier arms and fastening ................................................................................. 1
RC panel with cable min. 6.6 m long ................................................................................ 1
Installation tools:
Ø30 mm plug .................................................................................................................... 5
Ø16 mm plug .................................................................................................................... 1
Nylon cable tie 100 mm .................................................................................................... 5
Self-adhesive cable tie mount .......................................................................................... 3
Technical documentation:
Certificate ........................................................................................................................ 1
Assembly and operation manual ...................................................................................... 1
Package:
Box ................................................................................................................................... 1
4.2 Optional equipment supplied on request:
WRC kit (includes a receiver and transmitter (tag)
with operation range up to 40 m) ...................................................................................... 1
Siren (for alerts on unauthorized entry attempts) .............................................................. 1
Intrusion detector ............................................................................................................. 1
Anchor PFG IH 10 ............................................................................................................ 4
Power supply unit ............................................................................................................ 1
Note:
Power supply for turnstile housing is not included in the standard deliver set and is
customer supply. MPS: 12V DC @ 6A.
5

Assembly and Operation Manual
Figure 2. Turnstile overall view
1 – turnstile housing; 2 – cover with LED indication display; 3 – hub;
4 – hub fastening bolts; 5 – barrier arm; 6 – AC power cable; 7 – turnstile power supply;
8 – turnstile power cable; 9 – emergency unblocking device (“Fire Alarm”) ;
10 – emergency unblocking device cable;
11 – RC panel / WRC kit / ACS controller;
12 – cable of RC / WRC /ACS controller;
13 – PFG IR 10-15 anchor bolt; 14 – plug Ø30
6

TTR-07.1 Electromechanical Tripod Turnstile
5 BRIEF DESCRIPTION
5.1 Main features
The turnstile can be operated from the RC panel or WRC as well as from an ACS.
The turnstile is supplied with safe voltage — maximum 14V.
The turnstile has power consumption — maximum 72W (in start-up mode).
Automatic unblocking of passageway is performed by bringing the barrier arm into
vertical position at a power loss or by alarm signal.
After each passage the turnstile provides automatic complete rotation of the barrier
arms to home position, i.e. automatic reset.
After the turn of barrier arm for more than 60º angle its reverse rotation is blocked.
Smoothness of reset and quiet operation are ensured by a damper.
The optical arm rotation sensors are built into the turnstile housing to ensure
accurate count of inputs to an ACS.
The turnstile has relay outputs for connection of an intrusion detector and a siren.
There are two modes for the turnstile control — a pulse control mode and a potential
control mode.
Galvanic decoupling of the outputs ensures noise-immunity of the turnstile
electronics.
The turnstile has outputs for connection of remote indicators.
A purpose-designed «Fire alarm» control input is intended for unlocking the turnstile
at the fire alarm command or from emergency unblocking button.
The turnstile requires a power supply source with a load current minimum 6 A in
5 sec.
5.2 Design
The design of the turnstile is shown in Fig. 2. Numbers in brackets correspond to Fig. 2of
this Manual.
5.2.1 The turnstile comprises a turnstile housing (1) with set of barrier arms (5) and RC
panel (11). The turnstile housing (1) is a formed and welded metal structure with a cover
(2). On the front panel of the cover there is a LED indication display. Inside the turnstile
housing there are CLB and a self-centering mechanism consisting of a resetting device (a
pusher, springs and a roller), a control mechanism with optical arm rotation sensors and a
locking device, and electromechanical barrier arm unblocking device. The self-centering
mechanism also contains a damper, an arm rotation sensor disc and a hub (3) with three
barrier arms (5).
5.2.2 The large LED indication display with bright pictograms (located on the cover (2)) is
intended for status and direction indication: a Green Arrow indicates the direction of
authorised passage (the turnstile is open in the set direction); a Red Cross indicates ban
on passage (the turnstile is locked).
5.2.3 The RC panel / WRC / ACS controller (11), emergency unblocking device, LED
indication display, control mechanism and the turnstile power supply unit (7) are
connected to the CLB with the cables in accordance with the connection layout
(see Fig.11).
5.2.4 The RC panel is designed as a small desktop device with a shockproof ABS plastic
case and is intended for setting and indicating operating modes when the turnstile is
operated manually. The RC panel overall view is shown in Fig. 3.
7

Assembly and Operation Manual
Figure 3. RC panel overall view
1, 2, 3 – buttons LEFT, RIGHT, STOP for setting the passage mode;
4, 5 – green indicators «Left», «Right»;
6 – red indicator «Stop», 7 – RC cable.
There are three control buttons on the RC front panel intended for setting the turnstile
operating modes. The LED indicators are located above the buttons. The middle button on
the RC panel (hereinafter — the STOP button) is intended to set the turnstile to the
“Always locked” mode. The left (LEFT) and the right (RIGHT) buttons are intended to
unlock the turnstile for passage in the chosen direction.
The RC panel is connected to the CLB with a multicore cable (12) via the “XT1.L” connector
block(See Fig.4and Fig.11).
If the turnstile orientation relatively to the operator’s terminal is not standard (e.g. the
terminal is placed at the backside of the turnstile housing), the RC panel orientation
towards the turnstile can be changed by exchanging places of the RC wires to the contacts
“Unlock A” and “Unlock B” as well as contacts “Led A” and “Led B” accordingly (see Fig. 4
and Fig. 11).
5.2.5 The CLB (Fig. 4) includes:
X1 (LED), X2 (SENS), X3 (MOTOR) connectors to connect the indication module,
optical arm rotation sensors and control mechanism with a locking device (from the
X1, X2, X3 connectors with the turnstile cable);
XT1.L (In) connector block to connect the RC panel / the WRC / ACS controller (11)
inputs as well as an emergency unblocking device (Fire Alarm) (9) and intrusion
detector;
XT1.H (Out) connector block to connect a siren and ACS outputs, providing the
turnstile status data to the ACS controller;
XT3 (+12VDC) connector block to connect the turnstile power supply;
XT4 (Light A) and XT5 (Light B) connector blocks to connect “open/closed” remote
indicators, one indicator per each direction;
8

TTR-07.1 Electromechanical Tripod Turnstile
XT6 (AntiPanic) connector block to connect the electromagnet of automatic
anti-panic unblocking device;
J1 connector to select the turnstile control mode, the jumper is fixed — the pulse
control mode, the jumper is not fixed — the potential control mode. The jumper is
fixed at the factory before the delivery
J2 connector for programming.
Power – power LED indicator on the control board.
Figure 4. Control Logic Board (CLB)
5.3 Control over the turnstile
5.3.1 The turnstile can be operated from the following control devices:
the RC panel;
WRC;
the ACS controller.
The above devices can be connected to the turnstile as follows:
any device separately;
in any combination with each other;
all devices simultaneously (in parallel).
Note:
At the parallel connection of the above devices to the turnstile the superposition
of the control signals from them may occur. In that case the turnstile response will
conform to response to the obtained combination of input signals. (App. A and B).
5.3.2 Connection of the devices stated in Clause 5.3.1 is made with the cable (5) to the
corresponding connector blocks XT1.L and XT1.H of the CLB in accordance with the
connection layout (Fig. 4and Fig. 11).
5.3.3 The RC is connected to the contacts GND, Unlock A, Stop, Unlock B, Led A,
Led Stop and Led B of the XT1.L. connector block.
5.3.4 WRC is connected to the contacts GND, Unlock A, Stop and Unlock B of the XT1.L.
connector block.
9
