Oxgard CUBE C-04 Series Quick start guide

VOZROZHDENIE, LLC
OKPD 2 26.30.50.110
TU 26.30.50-007-33120038-2017
APPROVED
VZR.235900.000 VZR.235900.000 LU
TURNSTILE
MODEL CUBE С-04
С-04-c, С-04-К, С-04-Кc, С-04-H, С-04-Hc, С-04-НК, С-04-НКc
VZR.235900.000 OM
OPERATIONAL MANUAL
Sheets 48
2019

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
2
CONTENTS
1. Description and Operation.............................................................................................................4
1.1 Description and operation of the Product................................................................................4
1.3 Card collector description and operation (optionally) ............................................................11
2Intended Use .................................................................................................................................12
2.1 Operating Limitations............................................................................................................12
2.2 Preparing the product for use...............................................................................................13
2.3 Product Operation ................................................................................................................17
2.4 Procedure for actions in extreme situations..........................................................................26
2.5 Product Calibration...............................................................................................................27
3Maintenance..................................................................................................................................28
3.1 General Guidelines...............................................................................................................28
3.2 Safety Precautions...............................................................................................................29
3.3 Product maintenance procedure...........................................................................................30
3.4 Product external examination...............................................................................................30
3.5 Product partial disassembly..................................................................................................31
3.6 Inspection of product assemblies..........................................................................................33
3.7 Lubrication of product mechanism moving parts................................................................... 34
3.8 Product assembly and serviceability check...........................................................................34
4Current Repair............................................................................................................................... 36
4.1 Product current repair...........................................................................................................36
4.2 Current repair of product component parts...........................................................................37
4.3 Faults during warranty period...............................................................................................37
5Storage ..........................................................................................................................................38
6Transportation...............................................................................................................................39
7Disposal.........................................................................................................................................40
APPENDIX A — Distributors and service centers .............................................................................41
List of approved abbreviations...........................................................................................................47

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
3
This Operational Manual (OM) applies to Turnstile Oxgard Cube С-04 and
its modifications (hereinafter referred to as “the product”). The firmware version of
the product: FW v2.2
The manufacturer reserves the right to change the product’s scope of
supply, technical data and appearance without any additional notices.
Prior to operating the product, the personnel should additionally become
familiar with Datasheet VZR.235900.000 DS.
This OM is the document certifying basic parameters and performance of
the product, which are guaranteed by the manufacturer.
OM is designed to instruct on the product’s principle of operation, its
structure and design in order to ensure its proper operation, full use of its technical
capabilities and to keep it constantly ready for operation.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
4
1. DESCRIPTION AND OPERATION
1.1 Description and operation of the Product
Turnstile Oxgard Cube С-04 is designed to control access and
manage people’s streams by dividing their stream in a “one-by-one” manner.
The product can be used at checkpoints of enterprises, organizations and
banks, educational institutions, sports and entertainment centers, stores, stations
and other facilities. To provide easy and fast passage of people, it is
recommended to install one product for every 500 people working on a one-shift
basis.
The product’s scope of supply is detailed in Table 1.
Table 1 – Product’s scope of supply
Designation Description Quantity Note
Turnstile Cube С-04 1
RC panel Praktika multi-purpose control panel 1
Power supply unit* 1
Reader for PC* 1
Card collector* 1
Barrier section set* Praktika barrier 1
Note — The product’s component parts marked with (*) are supplied optionally.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
5
The individual features of the product modifications.
The turnstile housing can be designed in two options:
Option No.1: side covers and central overlays are made of stainless steel,
and the internal stand elements and the top cover are painted (color according tor
the Customer's choice).
Table 2 – Complete set of turnstile modifications.
Table 2 – Turnstile modifications (Option No.1)
Modification Features
С-04-Кс (Card collector +
Reader)
1) two readers are built in housing with LED highlighting;
2) built-in card collector, containing 200 visitor cards;
3)
the turnstile is equipped with simple card withdrawal access
system;
4) the housing includes the painted elements.
С-04-К (Card collector)
1) the built-in card collector, containing 200 visitor cards;
2)
the turnstile is equipped with simple card withdrawal access
system;
3) the housing includes painted elements.
С-04-с (Reader) 1) two readers are built in housing with LED illumination;
2) the housing includes the painted elements.
С-04 1) the housing includes the painted elements.
2) without readers.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
6
Option No.2: all overlay turnstile elements shall be made of stainless steel.
Table 3 – Complete set of turnstile modifications.
Table 3 – Turnstile modifications (Option No.2)
Modification Features
С-04-НКс (Card collector +
Reader)
1) two readers are built in the housing with LED illumination;
2) built-in card collector, containing 200 visitor cards;
3)
the turnstile is equipped with simple card withdrawal access
system;
4) stainless steel housing.
С-04-НК (Card collector)
1) built-in card collector, containing 200 visitor cards;
2)
the turnstile is equipped with simple card withdrawal access
system;
3) stainless steel housing.
С-04-Нс (Reader) 1) two readers are built in housing with LED illumination;
2) stainless steel overlays.
С-04-Н1) stainless steel housing.
2) without readers.
Barrier arms of all the turnstile modifications are made of ground stainless
steel.
In the product modifications with readers – the readers of magnetic cards
PROX-13 or PROX-125 are installed (specified in the turnstile order). The readers
are installed on the turnstile left and right side into the stand top parts.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
7
The product Specifications are given in Table 4
Table 4 - Specifications
Parameter description Value
Overall dimensions (HхWхL), mm:
- in operating condition
- with assembled arms
1000х950х735
1000х950х192
Weight, kg 50.0
Temperature range, °С:
- operation
- transportation and storage
+1...+40
+1...+40
Relative air humidity, %, maximum 80
Width of formed passage, mm 565-595
Through-flow rate, pax per min 30
Max number of connected RC panels, pcs. 2
Service life, years 8
Power supply voltage (direct current), V:
- nominal
- operating
12.0
10.8...13.2
Average current in suspended mode*, A 1.5
Average current in passage mode*, A 1.5
Maximum consumption current*, A 3.0
Note — * the values of current are specified under nominal power supply voltage

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
8
Product design.
The side covers, central overlays and products are made of stainless steel,
and the internal stand elements and the top cover are painted (color according tor
the Customer's choice). The turnstile’s barrier arms are made of ground stainless
steel. Housing fitted with LED illumination.
For connection of PSU, RC panel and AMCS cables, the motherboard,
located and removable cover in the product housing top part is used. A hole is
provided in the bottom part of the product housing to input these cables.
Figure 1 – General view of the product
Figure 1 – Turnstile’s general view
1 -top cover; 2 – card collector slot; 3 – reader;
4 – side decorative covers; 5 –barrier arms;
6 – front display model; 7 - arms fixation locking device

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
9
1.1.6 Display system.
The turnstile front display panel is located in the turnstile top part with the
Caprolon insert.
Figure 2 - Turnstile modes of operation are displayed on the front display
panel (1) and are duplicated with the side display panels (2).
Figure 2 - Display system appearance
1.1.7 The labeling includes the manufacturer's trademark, designation,
serial number.
1.1.8 Overall dimensions of the packaging containers make:
1) Height - 1170 mm;
2) Width - 500 mm;
3) Length - 1040 mm.
1 - front display model;
2 - side display panel;
3 - card collector slot

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
10
1.2 Description and Operation of Oxgard Praktika RC Panel
Multi-purpose Oxgard Praktika console is designed for control of Oxgard
turnstiles.
1.2.1 The housing is made of stainless steel; the control buttons and
the LED operation mode indicators are located on the front side. Specifications
are given in Table 5.
Table 5 - Specifications
Parameter description Value
Overall dimensions (HхWхL), mm: 25х107х107
Weight, kg 0.5
Temperature range, °С:
- operation
- transportation and storage
+1...+40
+1...+40
Relative air humidity, %, maximum 80
Service life, years 8
Power supply voltage (direct current), V:
- nominal
- operating
12.0
7.5...15.0
1.2.2 Design features:
1) An option for connection of two consoles to one turnstile;
2) High interference resistance;
3) The wire length from console turnstile can make up to several kilometers with no
loss of command transmission rate;
4) Standard length of the cable supplied in the complete set makes 5 metres.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
11
1.3 Card collector description and operation (optionally)
1.3.1 Card collector purpose
The card collector is designed for collection and storage of swipe cards
upon leaving the facility. Flexible card collector controller operation logic and
connection allows for its integration with any access monitoring and control
systems.
1.3.2 Description of construction elements. Figure 2 - Card collector
slot.
On the inner side of card collector stands there are two containers with
locks for fast access to withdrawn cards.
The container design allows for containing at least 200 cards.
Note — The Customer selects the side of the card collector installation on the product,
which is stipulated during supply agreement conclusion

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
12
2. INTENDED USE
2.1 Operating Limitations
ATTENTION: FAILURE TO COMPLY WITH SAFETY
REQUIREMENTS SPECIFIED IN THIS SECTION MAY CAUSE DAMAGE TO
HUMAN LIFE AND HEALTH, AND FULL OR PARTIAL LOSS OF THE
OPERABILITY OF THE PRODUCT AND/OR AUXILIARY EQUIPMENT.
ATTENTION: THE TURNSTILE INSTALLATION SHALL BE
CARRIED OUT BY QUALIFIED SPECIALISTS IN ACCORDANCE WITH
INSTALLATION GUIDELINES.
ATTENTION: IN CASE OF FAILURE TO COMPLY WITH SAFETY
REQUIREMENTS SPECIFIED IN THIS SECTION, THE MANUFACTURER
SHALL NOT BE HELD LIABLE FOR DAMAGE TO HUMAN LIFE AND HEALTH,
FULL OR PARTIAL LOSS OF THE OPERABILITY OF THE PRODUCT AND/OR
AUXILIARY EQUIPMENT, AND TERMINATE THE PRODUCT’S WARRANTY.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
13
IT IS NOT ALLOWED:
INSTALL THE POWER SUPPLY UNIT INSIDE THE TURNSTILE CASING,
BECAUSE THIS MAY CAUSE ELECTROCUTION.
INSTALL THE TURNSTILE ANYWHERE OUTSIDE DRY AND HEATED
ROOMS.
OBSTRUCT OR ACCELERATE THE MOVEMENT OF THE TURNSTILE
BARS.
USE FOR CLEANING ANY PASTES OR FLUIDS THAT ARE
CHEMICALLY AGGRESSIVE TO MATERIALS OF THE HOUSING.
2.2 Preparing the product for use
2.2.1 Safety precautions during the preparation of the product for use
ATTENTION: PRIOR TO TURNSTILE CONNECTION, FREE THE
ARMS ROTATION ZONE FROM PEOPLE AND FOREIGN OBLECTS TO AVOID
INJURIES AND TURNSTILE LOCKING.
2.2.2 Regulations and procedure for product inspection
The product visual inspection prior to its connection to power supply
network is mandatory and includes:
1) checkup for no mechanical damage of the product housing: checkup for no cracks,
through holes from lost fasteners;
2) careful inspection of all product connections.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
14
2.2.3 Product switching on.
The turnstile arrives to the Customer in the assembled state (transportation
mode).
Prior to starting operation, it shall be switched to working position: pull off
the arm fixation locking device (Figure – 7) holding one arm with hand in the fixed
position, distribute the rest of the arms in the operating position.
Connect PSU to ~220 Volt mains and and then switch it on. Red indication
will light on the turnstile front display panel.
The side display panels will illuminate red. The passage will then be closed,
the LED button indicator (Figure 5 - 2) will illuminate red on the RC panel.
One of the arms will be in the blocking condition, which prohibits the
passage.
The turnstile is ready for operation.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
15
2.2.4 Inspection and checkout of product readiness for use:
Figure 3 - possible free travel of the arm. In “STOP” mode, it makes 6
degrees on each side.
Figure 3 - Possible free travel of the arm in “STOP” mode
2.2.5 Guidelines on product orientation.
ATTENTION: PASSAGE ZONES SHALL BE PROVIDED TO
ALLOW RECORDING OF PASSAGES DURING TURNSTILE OPERATION
UNDER AMCS CONTROL AND TO AVOID UNAUTHORIZED PASSAGES.
6 deg

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
16
Recommended diagram
Non-recommended diagram
Figure 4 - Turnstile passage zone arrangement.
2.2.6 Control console settings
Figure 5 – Appearance of RC panel. In relation to the user, the product can
be installed using different methods. In some cases, it is required to change
positions of left/right passage buttons. This may be done by means of the
following operations:
Switch off the product power supply;
3) Push and hold left (1) and right (3) buttons;
4) Switch on the product power supply;
5) Holding buttons 1 and 3, push stop button (2);
6) Release buttons 1 and 3;
7) Release button 2.
Now, upon pushing “left” button, the right passage will be authorized, and
vice versa. Current dedication of buttons is stored in the memory and is not reset
200 mm min
50 mm max
1 - barrier

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
17
upon power supply disconnection. For return to original option, it is necessary to
perform the above mentioned sequence of operations again.
Figure 5 - control buttons 1 (left), 2 (stop), 3 (right), 4 (antipanic) and the
product operation mode LED indicators.
Figure 5 – Appearance of RC panel
2.3 Product Operation
2.3.1 Product operating modes
The product has several operating modes. Switch to the desired mode
using RC panel or AMCS. Indication of operating modes is displayed on the panel
in the form of passage authorization and prohibition mnemonic symbols.
Operation of the product with AMCS is considered in IG.
1 - left; 2 - stop; 3 - right; 4 - antipanic

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
18
2.3.2 Product operation by means of RC panel
Figure 5 - The LED indicator displaying the turnstile operating mode is
located above each RC panel’s button.
“Stop” Mode
The “Stop” mode is set during switching on the product. Switching to “Stop”
mode from the other mode is performed using button 2. At that, the LED indicator
above RC panel’s button 2 illuminates red. At that, the front and side display
panels glow red. In this mode, both ways passage is prohibited.
The middle arm may be deviated from the initial position by a small angle of
6 degrees. Upon arm deviation, the locking device will actuate automatically and
will not let the arm turn for passage execution.
Single passage mode
Button 1(3) actuates the left (right) single passage mode. Upon this mode
actuation, the single left (right) passage with subsequent switching to “Stop” mode
will be authorized.
At that, the side display panel glows green, demonstrating free left (right)
passage. On the front display panel, the group of red lights is running in the
authorized passage direction.
On RC panel, the LED indicator illuminates green above the button, to
which the passage is authorized, and it illuminates red above button 2. If the
passage was not performed during 5 seconds, the product switches to “Stop”
mode automatically.
Multi-passage mode in one direction

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
19
Push and hold button 2 for switching to this mode; push button 1(3) after
that. After that, both buttons may be released.
The multi-passage mode is displayed on RC panel by green indication
above button 1(3), the red LED indicator above button 2 does not glow.
The side display panel glows green demonstrating free left (right) passage;
on the front display panel, the group of red lights is running in the authorized
passage direction.
In this mode, the passage in the authorized direction may be performed for
unlimited times.
There is also an option to authorize a single passage in the prohibited
direction pushing button 1(3). After this passage performance or upon expiry of 5
seconds, the product will return to the initial mode.
Free passage mode
For switching to this mode, push and hold button 1, after which push
button 3 and release both buttons. In this mode, the both way passages for
unlimited times are allowed.
The side display panels glow green demonstrating free left (right) passage;
on the front display panel, two divergent groups of red lights are moving.
On RC panel, the LED indicators above buttons 1 and 3 illuminate green.

VZR.235900.000 OM
Turnstile Cube С-04
Operational Manual
20
“Antipanic” Mode
Switching to this mode is carried out mechanically.
Put the turnstile to “Antipanic” mode; for this purpose, push button 4 on RC
panel.
Pull off the arm fixation locking device (Figure – 7) holding one arm with
hand in the fixed position, turn over the second arm clockwise with the other hand
so that all bars match each other (Figure 7 - 1).
Figure 6 - Bar fixation locking device
1 - arm fixation locking device
