Performance Tool W54006 User manual

3-SHELF
MECHANICS SHOP CART
OWNER’S MANUAL
Stock Number W54006
FOR YOUR SAFETY,
please read these instructions carefully and retain them for future use.
LIMITED WARRANTY
PERFORMANCE TOOL extends only the following warranties, and only to original retail purchasers. These warranties give
specific legal rights. Except where prohibited by local law, the law of the State of Washington governs all warranties and all
exclusions and limitations of warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL warrants the product to be free from defects in materials and workmanship under normal use and
service. A defective product may be returned for a free replacement within 90 days from the date of purchase, provided that
product is returned to place of purchase immediately after discovery of defect. After 90 days and up to 1 year from date of
purchase, PERFORMANCE TOOL will replace at no charge any parts which our examination shall disclose to be defective and
under warranty.
These warranties exclude blades, bits, punches, dies, bulbs, fuses, and other consumables which must be replaced under normal
use and service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed,
or which has been repaired or altered in any way so as to affect adversely its performance or reliability, nor shall these warranties
apply to any product or part which has been subject to misuse, neglect, accident or wear and tear incident to normal use and
service.
PERFORMANCE TOOL does not authorize any other person to make any warranty or to assume any liability in connection with
its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL makes no express or
implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL makes no implied warranty of
merchantability and no implied warranty of fitness for any particular purpose, except that for goods purchased primarily for
personal, family or household use and not for commercial or business use, PERFORMANCE TOOL makes an implied warranty of
merchantability (and, if otherwise applicable, an implied warranty of fitness for a particular purpose), but only for the particular
qualities or characteristics, and for the duration, expressly warranted above. The laws on limitation of implied warranties may
differ from state to state, so the above limitations may not apply in all cases.
PERFORMANCE TOOL shall not be liable for consequential, incidental or special damages resulting from or in any manner
related to any product, or to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective
product or part shall be the repair, or replacement thereof as provided above. The laws on limitation of remedies or on
consequential, incidental or special damages may vary from state to state, so the above limitations may not apply in all cases.
Replacement Part: Part Number:
Locking Caster W54005-1
Standard Caster W54005-2
Nut & Bolt Hardware Kit W54005-HW
REPLACEMENT PARTS

19mm Socket or Adjustable Wrench
1/4” Slotted Screwdriver
10mm Socket, Nut Driver or Combination Wrench
OPTIONAL: Thread Locking Compound
1. Ensure there are no missing parts. Refer to part number W54006.
2. Note that each upright has an open end and an end with a drilled plate for
mounting a caster. Ensure that the end with the drilled plate is on the bottom
before beginning assembly.
3. Lay a single upright on a flat surface. Using the 10mm slotted screws and
acorn nuts, attach all three shelves to the upright. Ensure that the shelf with
storage drawer is the highest shelf (farthest from the bottom of the upright).
4. Attach a second upright directly across from the first upright, then carefully flip
the unit over. Install the third and forth uprights, ensuring all nuts are securely
tightened. The use of a thread-locking compound is recommend to prevent
fasteners from loosening with use.
5. Install tool tray on either side of top shelf, as desired.
6. Install a single handle bracket on the side opposite the tool tray. Slide
handlebar in and install second handle bracket.
7. Install casters and foam pads.
WARNIN!
• MAXIMUM CAPACITY OF TOOL CART IS 200 LBS. DO NOT OVERLOAD.
•READ, STUDY, AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUCTIONS
PRIOR TO USE.
•FAILURE TO HEED THESE WARNINGS MAY RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
• WHEN POSITIONING TABLE NEXT TO PAINTED OR VALUABLE WORK AREAS, INSURE
TABLE LOCKING DEVICE IS SECURE AND SURFACES HAVE PROTECTIVE, NON-SCRATCH
COVERS.
• NO ALTERATIONS SHALL BE MADE TO THIS PRODUCT.
• DO NOT SIT OR STAND ON CART.
TOOLS RE!UIRED
ASSEMBL! INSTRUCTIONS
PARTS LIST
NO. DESCRIPTION !T!.
1 LOCKING CASTERS 2
2 STANDARD CASTERS 2
3 CASTER FLAT WASHERS 4
4 CASTER LOCK WASHERS 4
5 19mm CASTER NUTS 4
6 10mm SLOTTED MACHINE SCREWS 38
7 10mm ACORN NUTS 38
8 UPRIGHT BARS 4
9 TOOL TRAY 1
10 HANDLE BRACKETS 2
11 HANDLE BAR 1
12 SHELF WITH STORAGE DRAWER 1
13 PLAIN SHELF 2
14 LARGE FOAM SHELF PADS 3
15 SMALL FOAM BIN PADS 3
