Performance Tool W85025 User manual
WARNING!
It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance instructions
contained on the product label and instruction manual prior to operation of this creeper seat tool box. The owner
operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning labels and while in use,
maintaining the unit in good working order. If the owner and/or operator are not fluent in English, the product warnings
and instructions shall be read and discussed with the operators’ native language by the purchaser/owner or his
designee. Make sure that the operator comprehends its contents. Safety information shall be emphasized and
understood prior to usage. The tool shall be inspected per the operating instructions.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
CREEPER SEAT TOOL BOX
OWNERS MANUAL
Stock Number W85025
On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to merchandise which will not be reflected
in this manual. Although we strive to maintain complete and accurate information, it is possible in some instances, that the product may differ slightly from
printed specifications. Illustrations are intended for reference only. Actual merchandise may vary. Wilmar is not responsible for typographical errors.
Please read these instructions carefully and retain them for future use.
WARNING! READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS, AND WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO
SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
SPECIFICATIONS
Capacity:.................................................................350 Lbs.
Overall Dimensions:..........................26-3/8 x 14-1/8 x 16''
This product is designed to support a maximum capacity of 350 lbs. (159 kg), including all tools and equipment. It is
intended to be used to support and transport, along a smooth and level surface. This product is not intended, designed
or engineered to be used for any other purpose.
Specifications are subject fo change without notice
IMPORTANT SAFETY INFORMATION
2
PARTS DIAGRAM
Maximum Drawer Capacity: ..................................22 Lbs.
Side tool tray maximum capacity:.................
.........
11 Lbs.
PARTS LISTING
No. Description Qty.
1 Stool Pad 1
2 Body Frame 2
3 Plastic Tray 2
4 Side tray frame 2
5 Bolt M6x10 2
6 Tool Holder Shelf 1
7 Bolt M6x30 8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
No. Description Qty.
8 Plastic Tube Cap 4
9 2.5" PVC Caster 4
10 Bolt M8x40 4
11 Nut M8 8
12 Washer 8 8
13 Body with 3 Drawers 1
No. Description Qty.
14 Sleeve Nut 4
15 Bolt M8x16 4
16 Washer 8 4
17 Bolt M8x35 4
18 Support Bar 2
19 Buckle 2
Step 1: Assemble 4 casters (No. 9), through the
hole on the side tray’s frame (No. 4) as shown in
Fig. A. Then tighten the sleeve nut using an inner
hexagon wrench.
Step 2: To assemble two magnetic tool trays, insert
the bolt (No. 10) through the support bar (No. 18),
then through the holes on the frame of side tray
(No. 4), then through the body frame (No. 2), then
add the washer (No. 12) to tighten the nut
(No. 11), as shown (Fig. B).
Step 3: To assemble the rear tool and screwdriver
holder, screw the bolt (No. 5) into the hole on the
back side of the body, as shown (Fig. C).
Step 4: Final assembled product shown (Fig. D).
Step 5: The side tray folds down using the Buckle
(No. 19), which is inserted in the hole in the
frame, as shown (Fig. E).
ASSEMBLY
3
Fig. A
Fig.B
Fig. C
Fig. D
Fig. E
Before assembly of this product, make sure all parts are present. Compare parts with the contents list and diagram.
If any part is missing or damaged, do not attempt to assemble, install or operate the product.
1 YEAR LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These warranties give specific legal rights.
Except where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions and limitations of warranties and
remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal use and service. A defective
product may be returned for a free replacement within 90 days from the date of purchase, provided that product is returned to place of purchase
immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge
any parts which our examination shall disclose to be defective and under warranty.
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be replaced under normal use and
service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed, or which has been repaired
or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to misuse, neglect, accident or wear and
tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no express or implied warranties of
any kind with respect to its products. In particular, PERFORMANCE TOOL® makes no implied warranty of merchantability and no implied warranty
of fitness for any particular purpose, except that for goods purchased primarily for personal, family or household use and not for commercial or
business use, PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied warranty of fitness
for a particular purpose), but only for the particular qualities or characteristics, and for the duration, expressly warranted above. The laws on
limitation of implied warranties may differ from state to state, so the above limitations may not apply in all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any manner related to any product,
or to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective product or part shall be the repair, or
replacement thereof as provided above. The laws on limitation of remedies or on consequential, incidental or special damages may vary from state
to state, so the above limitations may not apply in all cases.
Little maintenance is required for this product. Wipe clean as needed; use mild upholstery cleaner (not caustic) to clean seat.
• NEVERaddlubricanttocasters!
• Periodicallycheckthatallofthefastenersaretight.
• Keeptheseatclean.Washitwithamildsoapanddryimmediately.
Whenyouarenishedusingthestool,storeitinasafeplacewhereitwillnotdisturborhinderothers.
CARE & MAINTENANCE
STORAGE
