Philips Dynalite DMC2 User manual

DMC2
Installation Guide
Revision 03
Area for main photograph
Area for insert photo
W: 46.1mm up to 79 mm
H: 46.1mm
X: 12.6mm absolute on page
Y: 132.6mm abs on page
This insert has a shadow

Contents
DMC2 1
1Product Overview 5
1.1 DMC2 Enclosure 6
1.1.1 Dimensions 6
1.1.2 Enclosure diagram 7
1.2 DSM2-XX 8
1.2.1 Dimensions / Diagrams 8
1.3 DMD31X Module 9
1.3.1 Dimensions 9
1.3.2 DMD31X module output wiring 10
1.4 DMP310-GL 11
1.4.1 Dimensions / Diagrams 11
1.5 DMR310 / DMR316 12
1.5.1 Dimensions / Diagrams 12
2Installation 13
2.1 Installation requirements 13
2.2 Cabling 15
2.3 Mounting the DMC2 16
2.4 Inserting and connecting modules 17
2.4.1 DCM-DyNet 19
2.4.2 DSM2-XX 20
2.4.3 Control module installation 22
2.4.4 Wiring loom 24
3Post-installation testing 25
3.1 Service LEDs and switch 25
3.2 Manual override keypad 26

DMC2 4
About this Guide
Overview
This guide is designed to assist in the installation of the DMC2 Modular Controller.
A working knowledge of Dynalite commissioning processes is required to effectively use this
document. For more information on the commissioning process, consult the DMC2
Commissioning Guide.
Disclaimer
These instructions have been prepared by Philips Dynalite and provide information on Philips
Dynalite products for use by registered owners. Some information may become superseded
through changes to the law and as a result of evolving technology and industry practices.
Any reference to non- Philips Dynalite products or web links does not constitute an
endorsement of those products or services.
Copyright
© 2019 Signify Holding. All rights reserved. Specifications are subject to change without
notice. No representation or warranty as to the accuracy or completeness of the
information included herein is given and any liability for any action in reliance thereon is
disclaimed. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke
Philips N.V. All other trademarks are owned by Signify Holding or their respective owners.

DMC2 5 Product Overview
1Product Overview
The Philips Dynalite DMC2 is a versatile modular controller that consists of a power supply
module, communication module, and up to two interchangeable control modules.
The power and communication modules are listed below:
•DSM2-XX – Single-phase or three-phase supply module that supplies power to the
communications and control modules.
•DCM-DyNet – Communications module that supports DyNet, DMX Rx, dry
contact inputs and UL924 input.
A variety of control modules provide simultaneous control of multiple load types and
capacities:
•DMD – Driver control module for 1-10V, DSI and DALI drivers.
•DMP – Phase control dimmer module for Leading or Trailing Edge output, suitable
for use with most types of dimmable electronic drivers.
•DMR – Relay control module for most types of switched loads.
The DMC2 can be surface or recess-mounted, and features a number of cabling knockouts
to accommodate a variety of communication, supply and load configurations.

January 15, 2019
DMC2 6 Product Overview
1.1 DMC2 Enclosure
The DMC2 enclosure is a galvanized steel case with powder coated front covers. It includes
mounting bays for power supply module, communication module and two output modules.
1.1.1 Dimensions

January 15, 2019
DMC2 7 Product Overview
1.1.2 Enclosure diagram

January 15, 2019
DMC2 8 Product Overview
1.2 DSM2-XX
The DSM2-XX fits into the top module bay of the enclosure, and supplies power to the
communication and control modules.
1.2.1 Dimensions / Diagrams

January 15, 2019
DMC2 9 Product Overview
1.3 DMD31X Module
The DMD31X module is a three-channel signal controller. Each channel is individually
configurable to DALI Broadcast, 1-10V or DSI.
1.3.1 Dimensions

January 15, 2019
DMC2 10 Product Overview
1.3.2 DMD31X module output wiring
The control signal must be terminated into the top six terminals on the module. The power
circuit must be terminated into the bottom six terminals as indicated in the diagram below.
Ensure that each signal and power channel has been paired and segregated correctly.
For installation involving 120 VAC circuits only:
Wire all output circuits using conductors suitable for Class 1 / Light and Power circuits rated
150 V minimum. The signal control circuit conductors can be intermingled with the branch
circuit wiring in the wire trough. The signal control circuit conductors can be considered as
Class 2 conductors. Class 2 wiring methods can be used for the signal control circuit outside
the DMC control panel.
For installation involving 240 or 277 VAC circuits:
Wire all output circuits using conductors suitable for Class 1 / Light and Power circuits rated
300V min. The signal control circuit conductors can be intermingled with the branch circuit
wiring in the wire trough. The signal control circuit conductors are to be considered as
Class 1 conductors. Class 1 / Light and Power wiring methods must be used for the signal
control circuit outside the DMC control panel.

January 15, 2019
DMC2 11 Product Overview
1.4 DMP310-GL
The DMP310-GL is a phase-cut dimming controller, software-selectable between leading
edge and trailing edge, and is compatible with most dimmable drivers.
1.4.1 Dimensions / Diagrams

January 15, 2019
DMC2 12 Installation
1.5 DMR31X
The DMR31X module is a three-channel relay controller, capable of controlling most types
of switched loads, including lighting and motor control.
1.5.1 Dimensions / Diagrams

January 15, 2019
DMC2 13 Installation
2Installation
The DMC2 enclosure and modules are shipped separately and assembled onsite. This
section describes the requirements and procedure for mounting and assembly.
2.1 Important Information
WARNING: Isolate from mains supply before terminating or adjusting any terminals. No
serviceable parts inside. Service by qualified personnel only.
We recommend that you read this entire document prior to commencement of installation.
Do not energize the DMC until all the installation steps detailed in this chapter are
complete.
Installation of the home and building automation and control system shall comply with
HD60364-4-41 where applicable.
Once assembled, powered and terminated correctly, this device will operate in basic mode.
A new Philips Dynalite user interface on the same network will turn all output lighting
channels on from button 1 and off from button 4 allowing testing of network cables and
terminations. Advanced functions and custom presets can then be configured via the System
Builder commissioning software.
If commissioning services are required, contact your local distributor for details.
This device should only be operated from the type of supply specified on installed modules.
This device must be earthed.
Do not Megger test any circuitry connected to the dimming system, as damage to the
electronics may result.
WARNING: The DMC must be de-energized before terminating the control and data
cables.
Installation Overview
1. Confirm that all installation requirements are met
2. Remove knockout plates for cabling
3. Mount enclosure
4. Install modules
5. Connect cabling
6. Energize and test unit

January 15, 2019
DMC2 14 Installation
2.2 Installation requirements
The DMC2 is designed for indoor use only. If installed in an outdoor location, the DMC2
must be housed in a suitable well-ventilated enclosure. Choose a dry location that will be
accessible after the installation is complete.
To ensure sufficient cooling, you must mount the DMC2 vertically, as shown below.
The DMC2 requires an air gap of at least 200mm (8 inches) on all sides of the front cover for adequate
ventilation. This gap also ensures that the device is serviceable while still mounted.
During operation the DMC2 may emit some audible noise such as humming or relay chatter.
Take this into account when choosing the mounting location.

January 15, 2019
DMC2 15 Installation
2.3 Cabling
Remove the required knockout plates for the supply cables before mounting the enclosure.
The DMC2 includes the following cabling knockouts. Cables should enter the enclosure
through the nearest knockout to the relevant module.
Supply/Control: Top: 4 x 28.2mm (1.1”) 2 x 22.2mm (0.87”)
Side: 7 x 28.2 (1.1”) 7 x 22.2mm (0.87”)
Back: 4 x 28.2mm (1.1”) 3 x 22.2mm (0.87”)
Data: Side: 1 x 28.2mm (1.1”)
Bottom:1 x 28.2mm (1.1”)
The 28.2mm (1.1”) knockouts are suitable for 3/4” conduit, while the 22.2mm (0.87”)
knockouts are suitable for 1/2” conduit.
The recommended cable for connections to the serial port is screened stranded RS485
compatible CAT-5E data cable with three twisted pairs. Refer to the Installation Instructions
for the communication module for more cabling information. This cable must be segregated
from mains and Class 1 cables as per local electrical code. If anticipated cable runs are over
600 meters for serial cables, consult your dealer for advice. Do not cut or terminate live
data cables.
The DSM2-XX module input terminals accept supply cables up to 16mm2. Supply cables
should have a capacity of 32A per phase for three-phase supply or up to 63A for single
phase to allow the device to be loaded to its maximum capacity. The Earth bar is located in
DMC unit near the top of case.
If mounting the unit to a cable tray or a Unistrut-style product, you can route cables
between the unit and the mounting surface to enter the enclosure via the knockouts on the
rear face.
Control/communication cables enter at the bottom of the enclosure. Never run control
cables through the mains voltage section of the enclosure.
WARNING: Do not remove any labels or stickers from cables, wiring, modules or other
components in the DMC. Doing so may violate local safety regulations.

January 15, 2019
DMC2 16 Installation
2.4 Mounting the DMC2
The DMC2 can be surface or recess mounted.
Surface mounting uses four mounting points, indicated below:
Recess mounting is supported by four mounting holes suitable for M6 (1/4”) fasteners, two
on either side of the enclosure as shown below.
The minimum spacing between studs is 380mm (15”), and the minimum mounting depth is
103mm (4.1”).
Ensure no dust or other debris enters the device during installation. Do not leave the front
cover off for any length of time. Excessive dust may interfere with cooling.

January 15, 2019
DMC2 17 Installation
2.5 Inserting and connecting modules
Control modules fit in either mounting bay, and you can install any two modules in the same
unit. Control modules are connected to the supply module with the supplied wiring loom,
and to the communication bus with the ribbon cable connectors on the left-hand side of the
enclosure.
Install modules:
1. Mount the enclosure using one of the methods described in 2.3 Mounting the
DMC2.
2. Mount the communication module below the high-voltage barrier. Refer to the
instructions in 2.4.1 DCM-DyNet.
3. Mount the power supply module in the top of the enclosure. Refer to the
instructions in 2.4.2 DSM2-XX.
4. Mount the control modules in the remaining module spaces. Any module can be
mounted in any location and a location can be left empty. Refer to the instructions
in 2.4.3 Control module installation, and the Quick Installation Guide provided with
each module.

January 15, 2019
DMC2 18 Installation
5. Connect the supplied wiring loom to the modules. Use only the loom supplied with
the unit, and do not modify the loom in any way. Refer to 2.4.4 Wiring loom.
6. Check and retighten all terminals. Remove the required knockouts from the top
cover plate, then reattach the cover plate to the unit and make sure all screws are
tightened securely. Stick the labels provided with modules on the cover to indicate
what module is installed in each location.
7. Reattach the bottom cover plate and make sure all screws are tightened securely.

January 15, 2019
DMC2 19 Installation
2.5.1 Communication Module - DCM-DyNet
The DCM-DyNet module is mounted in the bottom section of the enclosure, below the
high-voltage barrier.
Remove the protective film from the keypad before installing this module.
Insert the DCM-DyNet:
1. Adjust the jumper located next to the control ribbon cable connector to select the
required DyNet voltage: 12V (factory default) or 24V.
2. Connect the control ribbon cable from the module to the DMC communication bus.
3. Align the mounting tab with the slot on the left and slide the module into position.
4. Secure the module using the fixing screw on the right. The unit should sit securely with
no movement.
The DCM-DyNet installation is now complete.

January 15, 2019
DMC2 20 Installation
2.5.2 Supply Module - DSM2-XX
The DSM2-XX module is mounted in the top section of the enclosure.
Insert the DSM2-XX:
1. Connect the 24VDC Class 2/SELV supply plug to the two-way socket behind the DMC
communication bus socket. Note that the internal power supply is derived from phase
L1. For correct operation of the unit, ensure that supply on phase L1 is always present.
2. Locate the tab and slide the module into position as shown.
3. Secure the module using the fixing screw on the right. The unit should sit securely with
no physical movement.
