Phonak inspiro User manual

User Guide
029-xxxx-02/V1.00/2007-12/A+W Printed in Switzerland © Phonak AG All rights reserved
www.phonak.com
Your hearing care professional
!
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 1

34
Contents
Welcome 5
inspiro and accessories 7
inspiro key figures 8
Controls 9
Getting Started 11
Charging inspiro 11
Low battery alarms 13
Wearing inspiro 14
Attaching the clip to the inspiro 15
Attaching the lavalier to the inspiro 17
Wearing iLapel 18
iLapel wearing position 19
Wearing iBoom 20
Switch on inspiro 23
Activate the key pad lock 24
Service and warranty 25
Declaration of conformity 26
Phonak distributors worldwide 27
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 3

56
inspiro is an FM transmitter ideally suited to the
needs of teachers and suitable for use in regular
schools as well as special schools.
The outstanding design with its large color display
makes this transmitter unique. Soft keys, an alarm
clock, wearing options to suit different types of
clothing and a wealth of other details reflect Phonaks
passion for user friendliness.
Please read this manual carefully to benefit from all
the features of your inspiro FM transmitter. Ask your
hearing care professional if you have any questions.
Inspiro is a quality product developed by the Swiss
company Phonak, the world leader in FM technology,
innovation and reliability. With proper care and
usage, your inspiro will support your hearing and
communication needs for many years.
Phonak – life is on
Further resources:
• Please check www.eSchoolDesk.com, a very
detailed website dedicated to supporting
teachers especially, but also parents in their
use of the inspiro.
• There is a dedicated brochure available for
parents and teachers with many useful and
practical tips.
• inspiro also provides integrated online help
instructions on the large LCD display.
The following symbol appears in this user guide:
Important notes for all users.
Welcome
!
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 5

8
7
inspiro is delivered with either the iBoom or the
iLapel microphone, depending on the customer wish.
All the accessories can also be ordered separately.
햲inspiro
햳Microphones: iLapel and iBoom
햴inspiro wearing options:
Belt clip and lavalier cord
햵Audio cable
햶Charging unit
햷Home and travel case
inspiro and accessories
Operating time and charging:
• Operating time if the battery is fully charged:
 approx. 12 hours
• Charging time for an 80% charge:
 approx. 1 hour
• Charging time for a 100% charge:
 approx. 2 hours
Operating range:
• Inside a building:
 approx. 50 feet (15 meters)
• Outside:
 approx. 130–170 feet (40-50 meters)
High-powered electronic equipment, larger
electronic installations and metallic structures
may impair and significantly reduce the
operating range.
inspiro key figures
!
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 7

9
Controls
Jenny Jones
Monitor
01.10.2008 01:57pm
Sync
H33
햲
햴
햵
햷햸
햳
햶
10
inspiro
햲On/Off slider
햳Color LCD
햴Soft Keys
햵Keypad lock key
햶Microphone
mute key
햷3.5mm audio
input
햸Mini USB
for charging
햹Button to attach
the belt clip
and the lavalier
햺Cable wrapper
iLapel microphon
햻Microphone
openings
(do not cover!)
햽Wearing clip
iBoom microphon
햾Adjustable ear loop
햿Microphone
(do not cover!)
햹
햺
햻
햽
햾
햿
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 9

11
Charging inspiro
inspiro contains a re-chargeable built-in state-of-the-
art lithium polymer battery with fast-charge capability.
A fully-discharged battery takes one hour for an 80%
charge and two hours for a 100% charge.
Select an easily accessible
socket outlet and plug
the charging unit into the
socket outlet.
Connect the MiniUSB plug
from the charging unit to
the inspiro.
Use only the original Phonak charging unit
for insprio.
The segments in the battery symbol flash during
charging. The battery cannot be over-charged.
If the charging unit is
removed from the inspiro,
the segments in the
battery symbol show the
actual capacity.
If the battery is fully
charged, the battery
symbol in the LCD
shows four segments.
Getting Started
12
!
Jenny Jones
Monitor
01.10.2008 01:57pm
Sync
H33
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 11

14
13
Low battery alarms
inspiro provides an automatic vibra alarm if the
battery is low.
•Approximately 1 hour before battery is empty:
A vibra alarm appears. Check the message
on the LCD and follow the instructions.
•Approximately 15 minutes before battery is
empty:
If inspiro has not been charged after the first
alarm, the second vibra alarm is automatically
activated before the battery is completely
exhausted. Check the message on the LCD and
follow the instructions. If the battery is not
being charged at that time, inspiro switches off
automatically after approx. 15 minutes.
If the battery is completely exhausted, there are
no segments in the battery symbol anymore and the
battery symbol in the LCD changes its color from
white to red.
Getting Started
Wearing inspiro
inspiro can either
be worn on the belt
by using the clip…
( see page 18)
…or around the neck
by using the lavalier
(see page 20)
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 13

16
15
Getting Started
Attaching the clip to the inspiro:
Attach the clip to the button on the
backside of the insiro. Make sure
the clip holds securely on the inspiro.
Fixe the clip on the belt
or trousers. Make sure
the clip holds securely on
the inspiro.
햲
햳
The clip can also be fixed on the belt or trousers
before the inspiro is attached.
Make sure the clip holds securely on the inspiro.
To remove the clip
from the inspiro,
press the button on
the clip and carefully
remove the clip
from the inspiro.
햲
햲
햳
햳
“klick”
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 15

18
17
Wearing iLapel
iLapel is an easy-to-use directional lapel
microphone which provides excellent sound quality.
a) Unwind the iLapel from the inspiro.
b) Fix the iLapel on your
shirt and make sure
the distance between the
microphone and your
mouth is approximately
8 inches (20 cm).
Getting Started
햲햳 햴
Attaching the lavalier to the inspiro:
Attach the lavalier to the button
Adjust the lavalier length
Make sure the microphone
cable is unwinded.
GA_Inspiro_GB_2.qxp 29.1.2008 16:01 Uhr Seite 17

20
19
iLapel wearing position:
OK!
Do not cover the two
microphone openings!
If you are uncertain whether the iLapel is positioned
well, activate the Sound check feature in inspiro.
Sound check helps to position the iLapel correctly.
Wearing iBoom
iBoom is an ultra-lightweight boom microphone.
Extremely comfortable in wear, it can be worn on the
left or right ear and adjusts easily to fit all ear and
head sizes.
How to fix the iBoom on the ear:
a) Slightly enlarge the diameter of the ear loop.
Getting Started
!
Wrong!
햲
햳
