Piusi MC BOXdc B.SMART Quick start guide

MC BOXdc
BULLETINM0579C_EN
Installation, use and maintenance Manual EN

M0579C2 / 64
Installation, use and maintenance
Bulletin M0579C
ENGLISH

MC BOXdc
EN
3 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
1 GENERAL PRECAUTIONS ......................................................................................................5
11 SYMBOLSUSEDINTHEMANUAL......................................................................................................................... 5
12 MANUALSTORAGE....................................................................................................................................................... 5
13 RIGHTSFORREPRODUCTION ............................................................................................................................... 5
2 DECLARATION OF CONFORMITY .......................................................................................6
21 FACSIMILEOFTHEEUDECLARATIONOFCONFORMITY.................................................................... 6
3 INSTRUCTIONS AND SAFETY NORMS.................................................................................7
4 FIRST AID MEASURES .............................................................................................................9
5 TRANSPORT, HANDLING AND UNPACKING.....................................................................10
51 DIMENSIONSANDWEIGHTS ................................................................................................................................10
6 MACHINE AND MANUFACTURER IDENTIFICATION......................................................... 11
61 PLATESPOSITIONS.......................................................................................................................................................11
7 DESCRIPTION OF MAIN PARTS.......................................................................................... 12
8 TECHNICAL CHARACTERISTICS ........................................................................................14
9 USE........................................................................................................................................... 16
91 INTENDEDUSE...............................................................................................................................................................16
92 IMPROPERUSE...............................................................................................................................................................16
93 REASONABLYFORESEEABLEMISUSE..............................................................................................................17
10 INSTALLATION ....................................................................................................................... 17
101 DANGEROUSAREA......................................................................................................................................................19
11 ELECTRICAL CONNECTIONS ............................................................................................20
111 POWERANDMOTOROUTPUTCABLINGONTHETERMINALBLOCK ..........................................21
112 POSSIBLEELECTRONICBOARDANDPUMPMOTORPOWERCABLING....................................22
113 PUMPPOWERCABLESPECIFICATIONS ........................................................................................................22
11.3.1 CONFIGURATION 1: SEPARATE ELECTRONIC BOARD AND PUMP POWER CABLES
22
11.3.2 CONFIGURATION 2: JUMPER ON THE TERMINAL BLOCK FOR DELIVERING
POWER TO THE ELECTRONIC BOARD.......................................................................................... 23
114 KEYCONTACT ..............................................................................................................................................................25
115 SIGNALSCONNECTOR............................................................................................................................................26
116 TANKLEVELMANAGEMENTWITHOCIO20VIARS485SERIALPORT......................................30
117 NOZZLECONTACT......................................................................................................................................................31
118 CANBUSCONNECTION............................................................................................................................................31
12 INITIAL CONFIGURATION ...................................................................................................32
121 STARTUP..........................................................................................................................................................................32
122 CONFIGURATIONVIAAPP....................................................................................................................................33
123 CONFIGURATIONVIAWEBAPP........................................................................................................................37
CONTENTS

M0579C4 / 64
Installation, use and maintenance
13 DRIVER ACCESS.................................................................................................................... 38
131 FIRSTDRIVERACCESSFROMAPP.................................................................................................................... 38
132 DRIVERDISPENSINGVIAAPP.......................................................................................................................... 40
133 DISPENSINGVIAUSERKEYIBUTTON......................................................................................................... 44
14 METER CALIBRATION.......................................................................................................... 46
15 TANK LEVELS MONITORING.............................................................................................. 46
16 DISPLAY CONFIGURATION in STAND-BY......................................................................... 49
17 ALARM AND WARNING STATES ........................................................................................ 49
18 ELECTRONIC KEYS AND THE READER ............................................................................ 54
19 MAINTENANCE..................................................................................................................... 54
191 ROUTINEMAINTENANCE...................................................................................................................................... 54
192 EXTRAORDINARYMAINTENANCE.................................................................................................................... 54
193 CHECKANDREPLACEMENTOFFUSES ........................................................................................................ 54
20 TROUBLESHOOTING........................................................................................................... 56
201 ELECTRICAL/ELECTRONICPROBLEMS........................................................................................................ 56
202 PROBLEMSWITHTHESMARTPHONEAPP...................................................................................................57
21 FAQ...........................................................................................................................................57
22 SCRAPPING AND DISPOSAL...............................................................................................60
23 REPLACEMENT PARTS TABLE............................................................................................. 61

MC BOXdc
EN
5 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
1 GENERAL PRECAUTIONS
In order to protect workers’ safety and to avoid the risk of any damage, before performing any operation,
please read and become familiar with the contents of the instruction manual.
11 SYMBOLSUSEDINTHEMANUAL
In order to signal particularly important instructions or warnings, the following symbols are used:
ELECTRICAL HAZARD
This symbol identifies the risk of electric shock from equipment powered by voltages
potentially dangerous for humans.
CAUTION
This symbol indicates accident prevention regulations addressed to operators and other
exposed persons.
WARNING
This symbol indicates that there is a possibility of damaging the units and/or their
components.
NOTE
This symbol indicates useful information.
Read the instruction manual carefully.
12 MANUALSTORAGE
This manual must be intact and completely readable. The final users, as well as the qualified technicians
authorised to installation and maintenance must be able to view it at any time.
13 RIGHTSFORREPRODUCTION
THIS MANUAL BELONGS TO PIUSI S.p.A.
All rights for reproduction are reserved for PIUSI S.p.A.
The text cannot be used in other printed documents unless expressly authorised in written form by PIUSI
S.p.A.
© PIUSI S.p.A. - WHOLE OR PARTIAL REPRODUCTION OF THIS MANUAL IS FORBIDDEN.
PIUSI S.p.A. is the exclusive owner of all rights envisaged by applicable laws, including the rules concerning
copyrights. All the rights deriving from such norms belong to PIUSI S.p.A.
Reproduction, publication, editing, transcription, public disclosure, distribution, sale in any form, translation
and/or processing, loan, and any other activity concerning this manual, also partial, are reserved by law
to PIUSI S.p.A.

M0579C6 / 64
Installation, use and maintenance
2 DECLARATION OF CONFORMITY
21 FACSIMILEOFTHEEUDECLARATIONOFCONFORMITY
The undersigned: PIUSI S.p.A
Via Pacinotti 16/A z.i. Rangavino
46029 Suzzara – Mantua – Italy
DECLARES on its own responsibility, that the equipment described below:
Description: Dispenser for diesel fuel
Model: MC BOXdc B.SMART
Serial number: see the Lot Number on the plate affixed to the product
Year of construction: See the production year on the plate stamped on the product.
Complies with the following legislation:
-Machine Directive
-E.M.C. Directive
-ROHS Directive
-RED Directive
The technical file is at the disposal of the competent authorities in response to a motivated request made to
PIUSI S.p.A. PRODUCT or further to a request sent by e-mail to: [e-mail].
THE ORIGINAL DECLARATION OF CONFORMITY IS SUPPLIED SEPARATELY IN CONJUNCTION
WITH THE PRODUCT.

MC BOXdc
EN
7 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
3 INSTRUCTIONS AND SAFETY NORMS
FIREHAZARD
If there are flammable liquids in the working area, flammable vapours may be present and
may cause fire or explosion during use.
EXPLOSION HAZARDS
To eliminate fire and explosion hazards use the dispenser only in well ventilated places.
Keep work area free of debris, including rags and spilled or open containers of solvent and
gasoline. Do not plug or unplug power cords or turn lights on or off when flammable fumes
are present. Keep a working fire extinguisher in the work area.
RISKOFFIREANDEXPLOSION
This product is NOT SUITABLE for use in Classified Areas subject to the presence of
potentially explosive atmospheres.
The PIUSI B.SMART product is designed for use with the user’s mobile phone only and
exclusively for connection and authentication operations and to link the user’s device to
the dispenser in order to perform certain operations in remote mode as described in this
manual.
Mobile phone use when refilling vehicles, also with other non-flammable liquids is in any
case strongly discouraged as it can cause distractions that may prove hazardous. PIUSI
shall not be held liable in the event of damage to persons or property of the user or
third parties resulting from failure to comply with the above warnings and / or any other
negligent, reckless or inept behaviour of the user.
This equipment must have a protective earth connection between metal masses and
for electrical components that require grounding. Improper installation or use of the
equipment may result in danger of electric shock. All electrical equipment in the work
area must have a protective earth connection. Stop operation immediately if static
sparking occurs or if you feel a shock. Do not use the dispenser until you have identified
and rectified the issue.
You must avoid any contact between the electrical power supply and the fluid that needs
to be pumped.
Install the equipment in a sheltered location. Do not expose to rain.
Do not switch on the fluid dispensing equipment with damaged electrical parts, such
as cables, or damaged hydraulic parts, such as the suction/delivery pipe or the delivery
nozzle.
Call the maintenance technicians immediately and replace all damaged parts before
using the equipment.
DANGEROFBURNS
To avoid severe burns, do not touch liquids or equipment.
NOSMOKING
Do not smoke near the fuel transfer pump and do not use the pump near naked flames.

M0579C8 / 64
Installation, use and maintenance
PRECAUTIONSFORUSE
PERSONALPROTECTIONEQUIPMENTFEATURES
Wear personal protection equipment that is:
- suitable to the operations to be performed;
- resistant to the various cleaning products used.
PERSONALPROTECTIVEEQUIPMENTTOBEWORN
Safety shoes
Close-fitting clothes
Protective gloves
Safety glasses

MC BOXdc
EN
9 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
OTHERSAFETYDEVICES
INSTRUCTIONMANUAL
- Do not operate the unit when fatigued or under the influence of drugs or alcohol.
- Do not leave the work area while equipment is energised or in operation.
- Turn off the equipment when not in use.
- Do not alter or modify the equipment. Alterations or modifications may void agency
approvals and create safety hazards.
- Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot
surfaces.
- Do not twist the hose or use a stronger hose.
- Keep children and animals away from the working area.
- Respect all safety norms in force.
- Do not exceed the maximum working pressure or temperature of the component with
the lowest system rating.
- See the technical specifications in all machine manuals.
- Use liquids and solvents that are compatible with the wet parts of the unit. See the
technical specifications in all machine manuals. Read the manufacturer’s warnings for
liquids and solvents. To obtain more information about the material, request the Safety
Data Sheet (MSDS) from your MC distributor or dealer.
- Check the unit every day. Repair or replace worn or damaged parts immediately with
original manufacturer’s spare parts only.
- Make sure that the unit is classified and approved in accordance with the regulations
for the environment in which it is used.
- Use only the unit for its intended purpose. Contact your Dealer for more information.
- Keep hoses and cables away from transit areas, edges, moving parts and hot surfaces.
- Do not bend hoses excessively or use them to pull the unit.
TOXICFLUIDORFUMESHAZARD
For issues arising from the treated product with eyes, skin, inhalation and ingestion refer
to the safety data sheet of the fluid used
Store hazardous fluid in approved containers, and dispose of it according to applicable
guidelines.
Prolonged contact with the product may cause skin irritation; during delivery phases,
always wear protective gloves.
EQUIPMENTMISUSE
Do not use the equipment for uses other than those for which it is designed and built. All
different uses may be hazardous for property, animals, or persons.
4 FIRST AID MEASURES
PERSONSWHOHAVESUFFEREDELECTRICSHOCK
Disconnect the power source, or use a dry insulator to protect yourself while you move the injured person
away from any electrical conductor. Avoid touching the injured person with your bare hands until he is far
away from any conductor. Immediately call for help from qualified and trained personnel. Do not operate
switches with wet hands.

286 163
267
FAC SIMILEFAC SIMILE
M0579C10 / 64
Installation, use and maintenance
5 TRANSPORT, HANDLING AND UNPACKING
The MC BOXdc B.SMART is shipped packaged in a non-stackable cardboard box. During storage the
machine must be kept in an upright position as indicated by the graphic symbols printed on the box showing
the direction of handling.
51 DIMENSIONSANDWEIGHTS
MODEL OVERALL WEIGHT (kg) PACKAGING DIMENSIONS (mm)
MC BOXdc B.SMART 5.3 480 x 370 x 265
Whenever the machine needs lifting, make sure
all the hoisting gear and accessories (such as the
rigging belts) have an adequate load bearing
capacity. Mechanical handling and lifting gear must
only be used by authorised and suitably trained
staff.
During periods of non-use, the machine, be it
packed or unpacked, must be stored in an area
protected against the elements (e.g. rain, humidity,
direct sunlight, etc.) and dust.
The packaging carries the following indications:
-‘THIS WAY UP’ arrow;
-label with all the information relating to the
equipment (model, weight, etc.).

MC BOXdc
EN
11 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
6 MACHINE AND MANUFACTURER IDENTIFICATION
The MC BOXdc B.SMART stations are equipped with an identification plate attached to the frame:
- Model.
- Serial number / year of manufacture.
- Technical data.
- CE marking.
- Manual code.
CAUTION: before installing, always make sure the type of dispensing system is correct and suitable
for the available power supply (Voltage/Frequency).
61 PLATESPOSITIONS
The dispensing system is equipped with adhesive decals containing key information for the operator. Make
sure the decals do not deteriorate or become detached from the equipment over time.
NOTE: should this occur, please contact customer service and request replacements for any
damaged or missing decals, then affix the new decals in their designated positions.
Decals are the following ones:
CE plate with technical data:
Corner label plate applied on the box
Warning decal prohibiting smartphone use near
the transfer pump when dispensing is under way
After dispensing has been activated, during
refuelling operations, do not use your smartphone
at a distance of less than 30 cm from the pump.
TO BE APPLIED BY THE INSTALLER
To be applied if MC BOXdc B.SMART is installed
near a classified area.
Product warranty label
FAC SIMILEFAC SIMILE
FAC SIMILEFAC SIMILE
FAC SIMILEFAC SIMILE
FAC SIMILEFAC SIMILE

FAC SIMILEFAC SIMILE
FAC SIMILEFAC SIMILE
M0579C12 / 64
Installation, use and maintenance
7 DESCRIPTION OF MAIN PARTS
MC BOXdc B.SMART is an electronic system for controlling the dispensing of fluids via smartphone.
The control system consists of:
1. An electronic controller
Equipped with a BlueTooth interface (BLE 4.0 and later), a display and two interface LEDs that control the
bluetooth connection and a dispensing pump. It can receive level readings for one tank via RS485 digital
communications or 0-10 V or 4-20 mA analog communications thanks to the optional Tank Watchdog
package.
2. A smartphone app
Installed on a smartphone equipped with an Android operating system or Apple iOS.
3. A WEBAPP
namely an internet portal accessible from any PC or Tablet connected to the internet from which the entire
site can be monitored.
FAC SIMILEFAC SIMILE

MC BOXdc
OCIO 2.0
CANbus
MC BOXdc B.SMART 1 MC BOXdc B.SMART N
OCIO 2.0
EN
13 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
“TYPICALSITE”LAYOUT
The figure shows an example of one of the most complex site layouts that can be managed by the system
There are numerous system configurations when using one or more controller.
An example of the basic system structure is provided showing the possibility to:
• Monitor fuel tank levels.
• Manage multiple distributors, within the same plant.
For more specific details on modes of connection and communication between dispensers, refer to the site
management manual available in the WEBAPP.
SYSTEMFUNCTIONS
• Site configuration, acquisition and management of filling operations, management of filling dispensers,
management of drivers, vehicles and detailed reporting of dispensing operations on the WEBAPP
accessible from any PC/Tablet, using your credentials
• Fuel dispensing using the dedicated app: PIUSI app, downloadable for smartphones only from the
Play Store and App Store, which connects to the dispenser / controller via a BLE (Bluetooth Low
Energy) link.
• Fuel dispensing using the dedicated APP also in areas without 3/4G coverage and Wi-Fi.
• Dispensing via i-Button associated with the individual driver.
• Facility for interface with systems for tank level measurement in digital mode via RS485 port with
PIUSI Ocio 2.0 with 0-10V or 4-20 mA analog interfaces.
• Possibility to remotely manage sites far from the company headquarters.
Pump Pump

M0579C14 / 64
Installation, use and maintenance
COMPATIBILITYWITHSMARTPHONEOPERATINGSYSTEMS
The system is compatible with the following iOS versions:
iOS Android
iOS10 5.0 - 5.1
iOS11 6.0
iOS12 7.0 - 7.1
iOS13 8.0
iOS14 9.0
iOS15 10
iOS16 and subsequent versions 11
12
13 and subsequent versions
CLOUD
Space on dedicated Servers that hold the database for storing the configurations of the site and the
dispenser, drivers, vehicle license plates and all dispensed fuel data.
WEBAPP
WEB interface used by the site manager. It has various functions: it monitors the dispensing cycles
(who carried them out, when, from which controller), creates/deletes users from the site, adds/removes
controllers/dispensers from the site. The only external device the WEBAPP connects to is a USB reader
for i-Button.
APP
It makes several operations:
• It manages two types of users: driver and manager.
• It sends commands to the controller and receives responses. The commands are used to perform:
dispensing, calibration, updating of the controller firmware, downloading of updates to controller
configuration, management of drivers or uploading to the CLOUD of the dispensing cycles performed
by the controller.
8 TECHNICAL CHARACTERISTICS
INTENDEDUSE
Implementation of a fluid delivery and control system for private use and not subject to special regulations
such as ATEX standards for potentially explosive atmospheres.
CAUTION: do not install MC BOXdc B.SMART in potentially explosive locations according to Atex
directive.
MAXIMUMELECTRICALPARAMETERVARIATIONS
The electrical motors installed in the dispensers can handle the following maximum variations:
-+/- 5% of power voltage;
SEETHETECHNICALDATATABLEBELOW
CAUTION: before installing, always make sure the type of dispensing system is correct and suitable
for the available power supply.

MC BOXdc
EN
15 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
Technical data Standard
conditions Limits Note
Power supply input 12 – 24 Vdc
Maximum power
absorbed in stand-by:
5W
Motor piloting
output 12 – 24 Vdc Imax = 50 A (a 12 Vdc)
Imax = 25 A (a 24 Vdc)
Electronic Key
Interface
YELLOW key
(i-button): Enabling
input from PIUSI
electronic key.
The yellow key can only
be registered in the
controller and the user
key is authorised only
for the controller itself
It is possible to configure the presence or
not of said key.
Nozzle contact
input
(only for versions
where available)
Clean contact or
Open Collector
electronic signal
(NPN).
Approximately 250
µA at 5 Vdc will be
supplied to the clean
contact (or open
collector).
It is possible to configure the presence
or not of this contact, furthermore it is
possible to configure the type of signal
(normally open or normally closed).
Pulser IN input
Free contact or
Open Collector
electronic signal
(NPN)
Approximately 250 µA
at 5Vdc will be supplied
to the clean contact (or
open collector).
The input signal may
have a maximum
frequency of 300
Hz with a Duty Cycle
between 20% - 80%.
The input signal may have a maximum
frequency of 300 Hz with a Duty Cycle
between 20% - 80%.
Level 1 and 2
contact input
(only for versions
where available)
Clean contact or
Open Collector
electronic signal
(NPN)
The terminal also
outputs 24VDC
power
Approximately 250
µA at 5 Vdc will be
supplied to the clean
contact (or open
collector).
It is possible to configure the presence
or not of this signal, furthermore it is
possible to configure the type of signal
(normally open or normally closed for
those versions where envisaged). Finally,
it is possible to select the action which
the main controller must perform when
it receives this signal: it may simply
generate an alarm on the display or
completely inhibit further dispensing if
Block Pump is set.
Auxiliary power
supply output 24
Vdc
Auxiliary 24 Vdc
power supply output
to power external
electronic devices.
Imax = 25 mA.
The device being powered must not
absorb more than 25 mA with a 24 Vdc
power supply. Typically it could be a level
sensor.
Fuses F1 (Vdc power supply input) 1A T (delayed).
F2 60 A T (delayed) motor fuse.
Housing
protection rating Rain-resistant casing
Working
temperature
From -10° C to
+40°C
Storage
temperature
From -20° C to
+60°C
Humidity < 90%
Maximum altitude
above sea level 2000 m
Pollution degree 2
Wiring distances Max pulser distance 15 m
Max level sensors
distance 100 m

M0579C16 / 64
Installation, use and maintenance
Technical data Standard
conditions Limits Note
Display and counting
limits
Floating decimal point sequence: 0.00 --> 9.999 --> 99.99 --> 999.9 --> 9999
The maximum quantity which can be dispensed is 9999 units, regardless of the unit of
measure set, be it litres, gallons or pints.
PRESET: Maximum
preset quantity
9999 litres/gallons/
pints
Memory storage
The Electronic Controller can store:
-Up to 500 Users
-Up to 500 dispensing cycles
9 USE
91 INTENDEDUSE
The MC BOXdc B.SMART dispenser is designed as a diesel filling station for private use.
A dedicated smartphone APP and WEBAPP make it easy to use, returning a summary of all dispensing
operations.
CAUTION: ambient conditions for use
Ambient temperature: min. -10°C / max. +40°C
Relative humidity: max 90%.
92 IMPROPERUSE
CAUTION: flammable liquids and explosive atmospheres
MC BOXdc B.SMART has not been designed to comply with the ATEX directive or to operate in
potentially explosive atmospheres.
Do not install the MC BOXdc B.SMART in a potentially explosive location.
The system was not designed for dispensing of petrol, flammable liquids with flash point <55°C/131°F,
or for operation in environments with potentially explosive atmosphere.
The use in the above mentioned conditions is forbidden.
CAUTION: improper use
It is strictly forbidden to use the system for purposes other than the ones indicated. Any other use
different from the one for which the system has been conceived and described in this manual is
considered “MISUSE”. Therefore, PIUSI S.p.A. shall not be held responsible for any damage caused
to people, animals or to the system itself.

MC BOXdc
EN
17 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
93 REASONABLYFORESEEABLEMISUSE
The smartphone is an indispensable tool for MC BOXdc B.SMART to set up and record the dispensing
cycles managed by the system, but it is forbidden to use your mobile phone near the transfer pump when
refuelling operations are under way.
CAUTION: Use your smartphone only and exclusively to connect, authenticate and link your device
to the dispenser. When refilling the vehicle, even with non-flammable liquids, the use of the telephone
is in any case strongly discouraged as it can cause distractions that can be dangerous.
10 INSTALLATION
FOREWORD
MC BOXdc B.SMART can be installed outdoors.
However, it is advisable to shelter it under a canopy to ensure a longer life and provide more comfort when
refilling in bad weather. Installation of the transfer pump must be carried out by specialised personnel and
carried out according to the instructions provided in this chapter.
If MC BOXdc B.SMART is not sheltered under a canopy, a “display cover” is provided as protection.
NOTE: It is also suitable for use in wet locations
WARNING: Personnel authorised to install the device
All installation procedures must be performed exclusively by qualified and authorised staff. They
must:
Install the system in a dry and well ventilated place;
Properly install all the components necessary for the equipment to function properly;
Only use accessories that have been supplied with the system.
CAUTION: use of unsuitable accessories not supplied with the system is strictly prohibited. PIUSI
S.p.A. shall not be held responsible for damages caused to people, things or to the environment
deriving from failure to meet such instructions.
THE UNIT IS FOR PROFESSIONAL USE ONLY.
The equipment must be installed in a well lit place, in compliance with the norms in force.
The equipment has been designed to be used in a dry environment. If it is installed outdoors, provide
adequate protective covering.
The motors are not explosion-proof. Do NOT install in places with explosion hazard.
MC BOXdc B.SMART can be mounted to a wall or on a pedestal.
To install the equipment on a wall you will need 4 x M8 screws.
To install it on a pedestal you will need 4 x M6 screws.
Diagrams showing the distance between holes for precise installation are provided below.
The pedestal is a Piusi accessory supplied separately from the MC BOXdc B.SMART.

232.4
286
Ø9
4x
15070.2
262
171.1
157.25
7522.8
236
286
Ø94x
optional
M0579C18 / 64
Installation, use and maintenance
WALLMOUNTING
PEDESTALMOUNTING
CAUTION: BE SURE TO INSTALL THE MCBOX B-SMART ONLY IN AN AREA WHERE THERE IS
NO RISK OF EXPLOSION

MC BOXdc
EN
19 / 64
This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
EN (Translation of the original instructions)
INSTALLATION TO VEHICLES WITH VIBRATION DAMPERS
For installation on a vehicle, the anti-vibration kit must be used
101 DANGEROUSAREA
Any fuel dispenser is considered a danger zone as defined in the National Electrical Code. Installation must
be performed in compliance with the following standards:
• National Electrical Code (NFPA No. 70).
• Code for motor fuel dispensing facilities and repair garages (NFPA No. 30A).
WARNING: the installer is responsible for gaining familiarity with and observing all the relevant local
codes.
The Product is designed for use in unclassified areas.
All the equipment must be installed outside the danger zones.
NOTE: local codes may impose specific installation requirements. Installation is subject to approval
of the local authorities having jurisdiction for the site.

M0579C20 / 64
Installation, use and maintenance
11 ELECTRICAL CONNECTIONS
The electrical connections must be carried out in a workmanlike manner by specialised personnel, in full
compliance with the regulations in force in the country of installation and with the instructions in the
electrical diagrams in this manual.
CAUTION: the MC BOXdc B.SMART is NOT equipped with circuit breakers; it is therefore essential
to install an electrical power supply panel upstream from MC BOXdc B.SMART, equipped with a
circuit breaker / disconnector with a current rating suitable for the power feeding line and a suitable
RCD for the type of electrical load.
It is specified in detail that:
-a switch or circuit-breaker must be included in the installation;
-it must be suitably located and easily reached;
-it must be marked as the disconnecting device for the equipment.
CAUTION: The power supply panel equipped with switch or circuit breaker must be near the
equipment and the disconnecting means shall disconnect all current-carrying conductors.
CAUTION: before accessing the electrical parts, make sure that you have disconnected all the main
switches that energise the unit.
The operations required for correct wiring are described below:
• Controller PG connection.
• Power input (pump motor and board) and motor output cabling.
• Connector for: 24 Vdc service power supply, nozzle contact, level contact.
• OCIO connection on RS485 (if used).
• Connection for interfacing with other controllers via CANbus.
CABLEGLANDCONNECTION
The cable glands to be used for the various signals are indicated in the picture in order to obtain an
optimised cable route inside the controller.
1. Motor output.
2. Pump power supply input.
3. Board power supply input.
4. Pulser input.
5. Level contact.
6. Nozzle contact.
7. RS485 data line / CANbus line.
CAUTION: Use copper conductors only for
wiring.
