Piusi Delphin PRO AC Installation and operating instructions

Bulletin M0502EN _ 00
DELPHIN AC
PRO
PRO IBC
PRO_X
Installaltion, use and maintenance EN

M0502
2 /28
Installaltion, use and maintenance
Bulletin M0502ITEN
ENGLISH

3/124
3 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
1INDEX
2 Conformity 4
2.1 EC Declaration of conformity 4
2.2 Declaration of compatibility 4
3 General precautions 5
4 Safety instructions 5
4.1 Safety warnings 6
4.2 First aid measures 7
4.3 General safety norms 7
5 Distribution system packaging 7
5.1 Contents of the packaging 7
5.2 Delphin composition 8
6 Machine and manufacturer identification 8
6.1 Plates positions 9
7 Technical characteristics 10
8 Intended use 10
9 Characteristics of the products handled 10
10 Installation 11
11 Assembling 11
12 Operation and use 11
12.1 Display 12
12.2 Flow rate adjusment lever 14
12.3 Phases of delivery 14
13 System customization 15
13.1 Users buttons 15
13.2 Operating modes 15
13.3 Daily use 16
13.4 Dispensing in normal mode 16
13.5 Partial reset (normal mode) 17
13.6 Resetting the reset total 17
13.7 DIspensing with flow rate mode display 18
13.7.1 Partial reset (flow rate mode) 18
13.8 Calibration 19
13.8.1 Definitions 19
13.8.2 Calibration mode 19
13.8.3 Display and restoring k-factor 19
13.8.4 Direct modification of k-factor 20
13.9 Meter configuration 22
14 Leaving the system unused for long periods of time 23
15 Washing the dispensing system 23
16 Maintenance 24
17 Troubleshooting 25
18 Scrapping and disposal 26

M0502
4 /28
Installaltion, use and maintenance
2 CONFORMITY
21 ECDECLARATIONOFCONFORMITY
The undersigned: PIUSI S.p.A
Via Pacinotti 16/A - z.i. Rangavino
46029 Suzzara - (MN) - Italy
DECLARES
on its own responsibility, that the machine described below:
Description: Dispenser AD-Blue® for cars.
Model: Delphin PRO AC- Delphin PRO-X AC - Delphin IBC AC
Serial number: see the Lot Number on the EC plate stamped on the product.
Year of construction: see the production year on the EC plate stamped on the product.
is in compliance with the legislative regulations which transpose directives:
- Machinery Directive 2006/42/EC
- Electromagnetic Compatibility Directive 2014/30/EC
Documents are made available to the appropriate authority on request at Piusi S.p.A. Alternatively, it
can be requested writing to: e-mail: [email protected]
The person in charge of writing both the technical file and the conformity statement is Otto Varini as
the legal representative.
Suzzara 20/04/2016 Otto Varini
The legal representative
22 DECLARATIONOFCOMPATIBILITY
The undersigned: PIUSI S.p.A
Via Pacinotti 16/A - z.i. Rangavino
46029 Suzzara - (MN) - Italy
DECLARES
That DELPHIN components in direct contact with the liquids handled, have been tested in conformity
with the following directives
ISO22241-1 : 2006 (quality standard)
Diesel engines -- NOx reduction agent AUS 32 -- Part 1: Quality requirements
and have been tested with the requirements of the following norm
ISO22241-2 : 2006 (quality standard)
Diesel engines -- NOx reduction agent AUS 32 -- Part 2: Test methods
The Adblue liquid , both before and after testing, resulted within the specified AUS32 (AdBlue) limit in
conformance with ISO22241-2-2006 ( as per Norm DIN V 70070)
Suzzara 20/04/2016 Otto Varini
The legal representative

5/124
5 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
3 GENERALPRECAUTIONS
Warnings To ensure operator safety and to protect the dispensing system from potential
damage, workers must be fully acquainted with this instruction manual before
attempting to operate the dispensing system.
Symbols used
in the manual
The following symbols will be used throughout the manual to highlight safety
information and precautions of particular importance:
ATTENTION
This symbol indicates safe working practices for operators and/or potentially
exposed persons.
WARNING
This symbol indicates that there is risk of damage to the equipment and/or its
components.
NOTE
This symbol indicates useful information.
Manual pres-
ervation
This manual should be complete and legible throughout. It should remain avail-
able to end users and specialist installation and maintenance technicians for
consultation at any time.
Reproduction
rights
All reproduction rights are reserved by Piusi S.p.A. The text cannot be reprinted
without the written permission of Piusi S.p.A.
© Piusi S.p.A.
THIS MANUAL IS THE PROPERTY OF Piusi S.p.A.
ANY REPRODUCTION, EVEN PARTIAL, IS FORBIDDEN.
This manual belongs to Piusi S.p.A., which is the sole proprietor of all rights indicated
by applicable laws, including, by way of example, laws on copyrights. All the rights
deriving from such laws are reserved to Piusi S.p.A.: the reproduction, including par-
tial, of this manual, its publication, change, transcription and notification to the pub-
lic, transmission, including using remote communication media, placing at disposal
of the public, distri¬bution, marketing in any form, translation and/or processing,
loan and any other activity reserved by the law to Piusi S.p.A..
4 SAFETYINSTRUCTIONS
Mains - pre-
liminary
checks be-
fore inst
ATTENTION
You must avoid any contact between the electrical power supply and the fluid
that needs to be FILTERED.
Maintenance
control
Before any checks or maintenance work are carried out, disconnect the power
source.
ATTENTION
FIRE AND
EXPLOSION
When flammable
fluids are present
in the work area,
such as gasoline
and windshield
wiper fluid, be
aware that flam-
mable fumes can
ignite or explode.
To help prevent fire and explosion:
Use equipment only in will ventilated area.
Keep work area free of debris, including rags and spilled or open containers of
solvent and gasoline.
Do not plug or unplug power cords or turn lights on or off when flammable
fumes are present.
Ground all equipment in the work area.
Stop operation immediately if static sparking occurs or if you feel a shock. Do
not use equipment until you identify and correct the problem.
Keep a working fire extinguisher in the work area.

M0502
6 /28
Installaltion, use and maintenance
ELECTRIC
SHOCK
Electrocution
or death
FThis equipment must be grounded. Improper grounding, setup or usage of the
system can cause electric shock.
Turn off and disconnect power cord before servicing equipment.
Connect only to a grounded electrical outlets.
Use only 3 wire extension cords in accordance with local electrical codes. Exten-
sion cords should have a ground lead.
Ensure ground prongs are intact on power and extension cords.
Do not expose to rain. Store indoors.
Never touch the electric plug of socket with wet hands.
Do not turn the dispensing system on if the power connection cord or other important
parts of the apparatus are damaged, such as the inlet outlet plumbing, dispensing noz-
zle or safety devices. Replace damaged components before operation.
Before each use check that the power connection cord and power plug are not
damaged. If damaged, have power connection cord replaced before use by a
qualified electrician.
The electrical connection between the plug and socket must be kept well away
from water.
Unsuitable extension leads can be hazardous, in accordance with current regulations.
only extension cords that are labelled for outdoor use and have a sufficient conduction
path should be used outdoors.
For safety reasons, we recommend that, in principle, the equipment be used only with a earth-leakage
circuit breaker (max 30 mA).
Electrical connections must use ground fault circuit interrupter (GFCI).
Installation operations are carried out with the box open and accessible electri-
cal contacts. All these operations have to be done with the unit isolated from
the power supply to prevent electrical shock!
EQUIPMENT
MISUSE
Misuse can
cause death
or serious in-
jury
!
Do not operate the unit when fatigued or under the influence of drugs or alcohol.
Do not leave the work area while equipment is energized or under pressure.
Turn off all equipment when equipment is not in use.
Do not alter or modify equipment. Alterations or modifications may void agen-
cy approvals and create safety hazards.
Route hoses and cables away from traffic areas, sharp edges, moving parts,
and hot surfaces.
Do not kink or over bend hoses or use hoses to pull equipment.
Keep children and animals away from work area.
Comply with all applicable safety regulations.
Toxic Fluid or
Fumes Haz-
ard
Read MSDS’s to know the specific hazards of the fluids you are using.
Store hazardous fluid in approved containers, and dispose of it according to
applicable guidelines.
41 SAFETYWARNINGS
ATTENTION
Prohibitions
Lifting or transporting the system by way of the electric cables attached to it is
strictly forbidden.
It is strictly forbidden to support or transport the system using a suction or outlet pipe.
ATTENTION In the event of a suspected contamination of the liquid in the car tank, sanitize
the tank.
Do not use the Delphin Dispenser before recovery

7/124
7 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
42 FIRSTAIDMEASURES
Persons who
have suf-
fered electric
shock
Disconnect the power source, or use a dry insulator to protect yourself while you move
the injured person away from any electrical conductor. Avoid touching the injured per-
son with your bare hands until he is far away from any conductor. Immediately call for
help from qualified and trained personnel. Do not operate switches with wet hands.
43 GENERALSAFETYNORMS
Personal protection
equipment features
Wear personal protection equipment that is:
• suitable to the operations to be performed;
• resistant to the various cleaning products used.
Personal
protection
equipment to
be worn
Safety shoes;
Close-fitting clothes;
Protective gloves;
Safety glasses;
Other
equipment Instructional manual
Protective
gloves
Prolonged contact with the product may cause skin irritation; during delivery
phases, always wear protective gloves.
DANGER Never touch the plug or the socket with wet hands
Do not switch the dispensing system on if the network connection cable or impor-
tant parts of the apparatus are damaged, such as the inlet/outlet pipe, nozzle or
safety devices. Replace the damaged pipe immediately.
Before each use, check that the network connection cable and power plug are not dam-
aged. Have the network connection cable replaced immediately by a qualified electrician.
5 DISTRIBUTIONSYSTEMPACKAGING
The dispensing system comes packed in a card-
board box bearing the following markings:
- an arrow indicating the TOP side;
- a label containing all the information relating to
the equipment (model, weight, etc..).
51 CONTENTSOFTHEPACKAGING
FOREWORD In order to open the cardboard box, use scissors or a cutter, paying attention
not to damage the distribution system or its components. Open the packaging
and make sure it contains the following components provided:

M0502
8 /28
Installaltion, use and maintenance
NOTE In case one or more herewith described components should not be in the box,
contact Manufacturer's technical assistance service.
ATTENTION Make sure the plate data correspond to the desired ones. In case of anomalies,
promptly contact the supplier, signalling the nature of the problems and, in case
you should doubt the device safety, do not use it.
52 DELPHINCOMPOSITION
1A 1B
2
3
4
5
6
7
8
1A MACHINE BODY FOR CART 5BRACKETS + BAND
1B MACHINE BODY FOR IBC 6SUCTION KIT
2SUPPORT CART 7AIR RETURN HOSE
3WHEEL KIT 8INSTRUCTION MANUAL
4HANDLE WITH BRACKET
6 MACHINEANDMANUFACTURERIDENTIFICATION
The distribution system is provided with an identification marking located di-
rectly on the pump. This indicates the following information:
• model;
• lot number / Production year;
• technical data;
• use and maintenance handbook code.
ATTENTION Before installing, always make sure the type of dispensing system is correct and
suitable for the available power supply (Voltage/Frequency).

9/124
9 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
61 PLATESPOSITIONS
On the distribution system there is an adhesive label that shows the operator
the most important information. Make sure it stays on and that it does not de-
teriorate over time.
NOTE Should this situation arise, please contact our support department and arrange
to have the damaged or missing plates sent back and replaced where necessary.
Decals are the following ones:
1 - PPE plate
- protective gloves
- safety glasses
- close-fitting clothes
- see user and maintenance manual
- safety shoes
3 - CE plate with technical data

M0502
10 /28
Installaltion, use and maintenance
7 TECHNICALCHARACTERISTICS
DELPHIN AC PRO DELPHIN AC IBC DELPHIN AC PRO-X
Length (A) 800 mm 500 mm 800 mm
Depth (B) 860 mm 340 mm 860 mm
Height (C) 1200 mm 590 mm 1200 mm
Weight 43 Kg 23 Kg 43 Kg
Voltage 220 / 230 V 220 / 230 V 120 / 240 V
Frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz
Power rating 400 W 400 W 200 W
Absorption 1,95 A 1,95 A 1,1 A
Operating temperature 0 °C / + 40 °C 0 °C / + 40 °C 0 °C / + 40 °C
Flow Rate min. 2 l/min.
max 11 l/min.
min. 2 l/min.
max 11 l/min.
min. 2 l/min.
max 15 l/min.
8 INTENDEDUSE
Intended use The dispensing system “Delphin” was designed and built for the distribution of
the product called AdBlue®, D.E.F (Diesel Exaust Fluid) or water.
Conditions
of use
The distribution system “DELPHIN” must be used respecting the following con-
ditions:
Max. temperature of dispensed product: +35 °C.
Min temperature of dispensed product: -11 °C.
Max. temperature of dispensed product permitted by materials: +40°C.
Voltage variation permitted: +/- 5%
Leq - Measured value of the average surface sound pressure level:
[dB(A)] 64,6
Operator station - Sound pressure value dB(A): 69,8
Make sure the pump is working in its nominal operating range.
ATTENTION
Inflammable
liquids and
explosive
atmosphere
The system “DELPHIN” has not been designed to distribute diesel, gasoline, in-
flammable fluids having an explosion limit of <55°C/131°F,or to operate in places
with potentially explosive atmosphere. Such use is therefore forbidden.
ATTENTION
Unenvisaged
use
It is strictly forbidden to use the system for purposes other than the ones indi-
cated in point "Intended use".
Any other use different from the one for which the system has been conceived and de-
scribed in this manual is considered "MISUSE". Therefore, the Manufacturer shall not be
held responsible for any damage caused to people, animals or to the system itself.
9 CHARACTERISTICSOFTHEPRODUCTSHANDLED
Products
permitted
The "DELPHIN" dispensing system was designed and built to dispense a special
liquid, made from an aqueous urea solution, known as AdBlue®/D.E.F., based on
the ISO 22241 standard DELPHIN can also be used with water.

11/124
11 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
ATTENTION
Forbidden
products
All products not listed in the "Intended Use" and "Treated Product Character-
istics" paragraphs are to be considered not permitted, improper and therefore
prohibited.
The Manufacturer shall not be held responsible for damages caused to people or
things deriving from failure to meet such instructions.
10 INSTALLATION
Foreword The "DELPHIN" dispensing system has been designed and arranged on a trolley
for ease of use and delivery.
Personnel
authorised
to install the
device
Installation must be performed exclusively by qualified and authorised staff.
They must:
- properly install all the components necessary for the pump to function prop-
erly;
- only use accessories that have been supplied with the system.
ATTENTION The use of accessories that are unsuitable and were not provided with the system
is strictly prohibited. The Manufacturer shall not be held responsible for damag-
es caused to people, things or to the environment deriving from failure to meet
such instructions.
The distribution system DELPHIN is for professional use only.
The distribution system DELPHIN must be installed in a well lit place, in compli-
ance with the norms in force.
The DELPHIN dispensing system has been specifically designed for use in a dry
place. I
11 ASSEMBLING
DEPENDING ON THE MODEL, PROCEED WITH ASSEMBLY AS DETAILED IN THE M0431 SHEET
SUPPLIED WITH THE STATION.
12 OPERATIONANDUSE
Foreword Directions on how to start and stop operation of the system are given below.
WARNING To remove any substance residue or foreign matters from the pipes, wash the
system before putting it into operation.
To wash the system, follow the same dispensing procedures using demineralized
or deionized water and eventually rinse with ADBlue®
ATTENTION During operation the motor may be hot: be careful.
WARNING For the proper functioning of the system, allow a 10-minute stop for every 20
minutes of dispensing.
We recommend that the pump remains switched off whenever the system is
not in use.
ATTENTION If ever the voltage is lagging, push the switch to the OFF position and return the
nozzle to its rest position
FLUID LEAKS CAN DAMAGE OBJECTS AND INJURE PERSONS.
Strictly observe the maximum capacity limits indicated on the dataplate.

M0502
12 /28
Installaltion, use and maintenance
WARNING Under no circumstances must the data on the dataplate, the closure and au-
thentication seals be modified or removed.
Any tampering or removal will result in immediate nullification of the warranty
and the manufacturer will not be held liable for any material or economic dam-
age resulting thereof.
ATTENTION Once the filling operation has been completed, replace the filler hose in its seat.
121 DISPLAY
DELPHIN PRO + IBC
BA
GF E
D
C
APOWER button: used to power the system.
BREFILL button: press for at least 5 seconds to start product delivery.
Cred/green LED
DLCD Display
EMODE button
FRESET button
GMachine plate
LED INDICATOR TABLE
Power Button Red LED Green LED Meaning
Off X X System OFF
On Off Off Stand By - Awaiting commands
On Off Fast Blink Start-up sequence underway
On Off On Dispensing
On Off Slow Blink Filling completed - Full level
On Fast Blink Off Filling completed - Time out
On Slow Blink Off Selected flow rate - too high

13/124
13 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
DELPHIN PRO - X
RESET
on/off STAT US
MADE IN ITALY
RESET
Preset
Not for resale
Flow-Rate
REFILL
3sec
POWER
0,1110
ENTER
AUTO
FLOW
max
min
DELPHIN PRO X
RESET
on/off STAT US
MADE IN ITALY
RESET
Preset
Not for resale
Flow-Rate
REFILL
3sec
POWER
0,1110
ENTER
AUTO
FLOW
max
min
DELPHIN PRO X
BA
IH G
D
E
C
F
APOWER button: used to power the system.
BREFILL button: press for at least 3 seconds to start product delivery.
CRed/green LED
DLCD Display
EBattery charging indicators LEDs
FPRESET buttons
GRESET button
HENTER button
IFLOW RATE / OPERATION setting knob
ATTENTION If the labels is damaged, DO NOT use the machine and replace the label imme-
diately.
ATTENTION
FOR THE OPERATION OF THE DELPHIN PRO-X MODEL, REFER TO THE
QUICK GUIDE M0495

M0502
14 /28
Installaltion, use and maintenance
122 FLOWRATEADJUSMENTLEVER
NOTE The adjustment lever is located on the side of the trolley.
ATTENTION This function is only valid for the DELPHIN PRO and DELPHIN IBC models.
In the DELPHIN PRO-X model the flow rate is regulated by the management sys-
tem.
Lever in the
LOW FLOW RATE position
Lever in the
STOPPOSITION
(present only in
Delphin PRO model)
Lever in the
HIGH FLOW RATE position
ATTENTION Use the flow rate adjustment lever as indicated.
Use in “Van” mode when filling a car could result in damage to the vehicle.
123 PHASESOFDELIVERY
1 Connect the connector to the tank by screwing it clockwise
2Press POWER button A.
3Press the REFILL button B for 3 seconds.
4Wait for the filling end.
5Disconnect the connector from the tank by unscrewing it counter-clockwise.
6Place the connector in the appropriate housing by screwing it clockwise.
ATTENTION DO NOT USE IF:
- THE CONNECTOR IS NOT COMPLETELY CONNECTED TO THE CAR TANK
- THE CONNECTOR IS NOT CONNECTED TO THE SAFETY HOOK.

15/124
15 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
13 SYSTEMCUSTOMIZATION
THISCHAPTERWITHALLITSPARAGRAPHSREFERSTOTHE“PRO”AND“PRO_IBC”MODELS
FORTHEFUNCTIONSOFTHEPRO_XMODELSSEETHEQUICKGUIDEM0495
131 USERSBUTTONS
FOREWORD The METER features two buttons (RESET and MODE) which individually
perform two main functions and, together, other secondary functions .
MAIN FUNCTIONS
PERFORMED
- for the RESET key, resetting the partial register and Reset Total
- for the MODE key, entering instrument calibration mode
SECONDARY
FUNCTIONS
Used together, the two keys permit entering configuration mode where the
desired unit of measurement can be set.
LEGEND CALIBRATE MEANS PERFORMING ACTIONS ON THE METER KEYS. BE-
LOW IS THE LEGEND OF THE SYMBOLS USED TO DESCRIBE THE AC-
TIONS TO BE PERFORMED
BRIEF
PRESS OF
MODE
BUTTON
MODE LONG
PRESS OF
MODE
BUTTON
MODEMODE
MODE BRIEF
PRESS OF
RESET
BUTTON
LONG
PRESS OF
RESET
BUTTON
132 OPERATINGMODES
OPERATING
MODES
The user can choose between two different operating modes:
The meter features a non-volatile memory for storing the dispensing data, even
in the event of a complete power break for long periods.
The measurement electronics and the LCD display are fitted in the top part of
the measurement device which remains isolated from the fluid-bath measure-
ment chamber and sealed from the outside by means of a cover.
1 - Normal Mode Normal Mode: Mode with display of Partial and Total dispensed quanti-
ties
2 - Flow rate Mode Flow Rate Mode: Mode with display of Flow Rate, as well as Partial dis-
pensed quantity.

M0502
16 /28
Installaltion, use and maintenance
133 DAILYUSE
FOREWORD The only operations that need to be done for daily use are partial and/or reset-
table total register resetting. The user should use only the dispensing system
of measurement device. Occasionally the meter may need to be configured or
calibrated. To do so, please refer to the relevant chapters.
Below are the two typical normal operation displays. One display page shows the partial and reset
total registers. The other shows the partial and general total. Switchover from resettable total to
general total display is automatic and tied to phases and times that are in factory set and cannot be
changed.
NOTE 6 digits are available for Totals, plus two icons x 10 / x100. The incre-
ment sequence is the following:
0.0 -> 99999.9 -> 999999 -> 100000 x 10 -> 999999 x 10 ->100000 x
100 -> 999999 x 100
134 DISPENSINGINNORMALMODE
FOREWORD Normal mode is the standard dispensing. While the count is made, the partial
and resettable total are displayed at the same time (reset total).
WARNING Should one of the keys be accidentally pressed during dispensing, this
will have no effect.
STAND BY A few seconds after dispensing has ended, on the lower register, the display
switches from resettable total to general total: the word reset above the word
total disappears, and the reset total is replaced by the general total.
This situation is called standby and remains stable until the user operates the
measurement device again.

17/124
17 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
135 PARTIALRESETNORMALMODE
The partial register can be reset by pressing the reset key when the
meter is in standby, meaning when the display screen shows the word
“TOTAL”.
After pressing the reset key, during reset, the display screen first of all
shows all the lit-up digits and then all the digits that are not lit up.
At the end of the process, a display page is first of all shown with the
reset partial and the reset total.
and, after a few moments, the reset total is replaced by the non reset-
tableTotal.
136 RESETTINGTHERESETTOTAL
The reset total resetting operation can only be performed after reset-
ting the partial register. The reset total can in fact be reset by pressing
the reset key at length while the display screen shows reset total as
on the following display page:
Schematically, the steps to be taken are:
1 - Wait for the display to show normal standby display page (with
total only displayed)
2 - Press the reset key quickly
3 - The meter starts to reset the partial
4 - While the display page showing the reset total is displayed
Press the reset key again for at least 1 second
5The display screen again shows all the segments of the display
followed by all the switched-off segments and finally shows the display
page where the reset Reset Total is shown.

M0502
18 /28
Installaltion, use and maintenance
137 DISPENSINGWITHFLOWRATEMODEDISPLAY
It is possible to dispense fluids, displaying at the same time::
1 the dispensed partial.
2 the Flow Rate in [Partial Unit / minute] as shown on the following
display page:
Procedure for entering this mode:
1 wait for the Remote Display to go to Standby, meaning the display screen shows Total only
2 quickly press the MODE key.
3 Start dispensing.
The flow rate is updated every 0.7 seconds. Consequently, the display could be relatively unstable
at lower flow rates. The higher the flow rate, the more stable the displayed value.
ATTENTION The flow rate is measured with reference to the unit of measurement
of the Partial. For this reason, in case of the unit of measurement of
the Partial and Total being different, as in the example shown below,
it should be remembered that the indicated flow rate relates to the
unit of measurement of the partial. In the example shown, the flow
rate is expressed in Qts/min.
The word “Gal” remaining alongside the flow rate refers to the re-
gister of the Totals (Reset or NON Reset) which are again displayed
when exiting from the flow rate reading mode.
To return to “Normal” mode, press the MODE key again. If one of the two keys RESET or MODE is
accidentally pressed during the count, this will have no effect.
ATTENTION Even though in this mode they are not displayed, both the Reset Total
and the General Total (Total) increase. Their value can be checked
after dispensing has terminated, returning to “Normal” mode, by
quickly pressing MODE.
1371 PARTIALRESETFLOWRATEMODE
To reset the Partial Register, finish dispensing and wait for the Remote Dis-
play to show a Flow Rate of 0.0 as indicated in the illustration
then quickly press RESET.

19/124
19 /28
This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian delphin PRO - IBC - PRO_X
EN
138 CALIBRATION
When operating close to extreme use or flow rate conditions (close to minimum or maximum accept-
able values), an on-the-spot calibration may be required to suit the real conditions in which the mea-
surement device is required to operate.
1381 DEFINITIONS
CALIBRATION
FACTOR OR
“KFACTOR”
Multiplication factor applied by the system to the electrical pulses received, to
transform these into measured fluid units.
FACTORY K
FACTOR
Factory-set default factor. It is equal to 1,000. This calibration factor ensures
utmost precision in the following operating conditions:
Fluid water/urea solution or liquid food products
Temperature: 20°C
Flow rate: 10 - 30 ltr/min
Even after any changes have been made by the user, the factory k factor can
be restored by means of a simple procedure.
USER K FACTOR: Customized calibration factor, meaning modified by calibration.
1382 CALIBRATIONMODE
Why calibrate? 1Display the currently used calibration factor:
2Return to factory calibration (Factory K Factor) after a previous cali-
bration by the user
3Change the calibration factor using one of the two previously indicated
procedures
FOREWORD Two procedures are available for changing the Calibration Factor:
1In-Field Calibration, performed by means of a dispensing operation
2
Direct Calibration, performed by directly changing the calibration factor
In calibration mode, the partial and total dispensed quantities indicated on the display screen take on
different meanings according to the calibration procedure phase. In calibration mode, the measure-
ment device cannot be used for normal dispensing operations. In “Calibration” mode, the totals are
not increased
ATTENTION The Measurement device features a non-volatile memory that keeps the
data concerning calibration and total dispensed quantity stored for an
indefinite time, even in the case of a long power break; after changing
the batteries, calibration need not be repeated.
1383 DISPLAYANDRESTORINGKFACTOR
MODEMODE
MODE By pressing the MODE key while the appliance is in
Standby, the display page appears showing the cur-
rent calibration factor used. If no calibration has
ever been performed, or the factory setting has been
restored after previous calibrations, the following dis-
play page will appear:
The word “Fact” abbreviation for “factory” shows that
the factory calibration factor is being used

M0502
20 /28
Installaltion, use and maintenance
If, on the other hand, calibrations have been made by
the user, the display page will appear showing the cur-
rently used calibration factor ( in our example 0,998) .
The word “user” indicates a calibration factor set by
the user is being used..
MODE
The flow chart alongside
shows the switchover logic
from one display page to
another
In this condition, the Reset
key permits switching from
User factor to Factory factor.
To confirm the choice of cali-
bration factor, quickly press
MODE while “User” or “Fact”
are displayed.
After the restart cycle, the
Measurement device uses
the calibration factor that
has just been confirmed
MODE
MODEMODE
MODE
TIME OUT
RESET
RESET
ATTENTION When the Factory Factor is confirmed, the old User factor is deleted
from the memory
1384 DIRECTMODIFICATIONOFKFACTOR
If normal Meter operation shows a mean percentage error, this can be corrected by applying to the
currently used calibration factor a correction of the same percentage. In this case, the percentage
correction of the USER K FACTOR must be calculated by the operator in the following way
New Cal. Factor = Old Cal. Factor * ( 100 - E% / 100 )
EXAMPLE:
Error percentage found: E% - 0.9 %
CURRENT calibration factor: 1.000
New USER K FACTOR: 1.000 * [(100 – ( - 0.9))/100] = 1.000 * [(100 + 0.9)/100] = 1.009
If the Meter indicates less than the real dispensed value (negative error) the new calibration factor
must be higher than the old one as shown in the example. The opposite applies if the Meter shows
more than the real dispensed value (positive error).
